Dynojet Power Commander III User manual

i303-411www.powercommander.com 1998-2003 Suzuki TLR1000 - PCIII USB - 1
1998-2003 Suzuki TLR1000
Installation Instructions
Dynojet Research 2191 Mendenhall Drive North Las Vegas, NV 89081 [phone] www.powercommander.com
Parts List
1Power Commander
1USB Cable
1CD-ROM
1Installation Guide
1Power Adapter
2Power Commander Decals
2 Dynojet Decals
2 Velcro®Strip
1Alcohol Swab
You can also download the Power
Commander software and latest maps
from our web site at:
www.powercommander.com
The ignition MUST be turned
OFF before installation!
PLEASE READ ALL DIRECTIONS BEFORE STARTING INSTALLATION
Button Adjustment Display
Faceplate Buttons
USB Port
Expansion Port

1 Remove the main seat and the passen-
ger seat or solo cover.
2Prop the fuel tank up using the prop
rod in the tail section.
3Lay the PCIII in the tail section.
4Route the wiring harness from the
PCIII under the tail section and go
towards the battery.
5Route the PCIII harness under the fuel
tank bracket and to the left side of the
rear cylinder (Fig. B).
6Locate the 6 pin clear connector to the
left rear of the air box (Fig. C).
Unplug this connector.
Fig. A
Fig. BFig. C
i303-411www.powercommander.com 1998-2003 Suzuki TLR1000 - PCIII USB - 2
Unplug this connector
PCIII wiring harness
PCIII wiring harness

7Plug the connectors from the PCIII in-
line of the stock wiring harness and
throttle body harness (Fig. D).
8Locate the Throttle Position Sensor
wiring harness. This harness has
RED - GREY - BLACK/BROWN
wires and is located on the left hand
side of the throttle body.
Fig. D
Fig. EFig F
i303-411www.powercommander.com 1998-2003 Suzuki TLR1000 - PCIII USB - 3
PCIII connectors
Stock connectors
Unplug
PCIII connectors
9Plug the connectors from the PCIII
in-line of the stock wiring harness and
throttle body (Fig. F).
Stock connector

10 Remove the battery access panel from
the left hand fairing (Fig. G).
11 Remove the battery cover.
12 Route the ground wire from the PCIII
down the left side of the engine to the
battery.
13 Attach the ground wire from the PCIII
to the negative side of the battery
(Fig. H).
14 Install the PCIII in the tail section
using the supplied velcro. Make sure
to clean both surfaces with the acohol
swab before attaching.
15 Replace all body work and lower the
fuel tank back into position making
sure none of the wires get pinched or
damaged.
Fig. G
Fig. H
i303-411www.powercommander.com 1998-2003 Suzuki TLR1000 - PCIII USB - 4
Ground wire
