EAST COAST Devon Wardrobe User manual

Devon
Wardrobe

Hardware
2
H x 8
(25mm)
E x 7
B x 6
N x 4
K x 2
(30mm)
J x 2
(15mm)
A x 6
(45mm)
D x 8
(30mm)
G x 4
(35mm)
M x 6
C x 14
I x 12
(15mm)
F x 4
Hexagon Key x 1
L x 26
(15mm)
Please read the instructions and warnings carefully before use to ensure safe and satisfactory operation
of this product.
Your child’s safety is your responsibility. If you have a query with this product or require replacement
parts, please contact 01692 408802.
Lay out the parts on a soft level surface and compare to the part/fixing checklist on pages 2 and 3. Do
not discard any packaging until you are sure that you have all the parts.
Keep children clear during assembly as pack contains small parts which may present a choking hazard.
You will need the following tools to complete assembly:
Flat-headed screwdriver and Cross point screwdriver.
Important
Retain for future reference: Read carefully

Wooden Parts
3
Wardrobe Side x 2 (L & R)
Back Panel x 2
Wardrobe Top
Door x 2
Back Panel Joining Strip
Clothes Rail x 2
Front Lower Crossbar
Rear Crossbar
Front Upper Crossbar
Drawer Back
Drawer Base
Shelf x 2
Drawer Brace
Drawer Front
Drawer side x 2 (L & R)

Assembly 1
Assembly 2
4
B
A
x 3
NOTE: Take care to insert the
dowels into the correct holes as
indicated. Repeat for the opposite
end of each part. (Total 10 x part C)
Front Lower Crossbar
Rear Crossbar
Front Upper Crossbar
Wardrobe Side
C x 5
Front Upper Crossbar
(Note hole in top edge)
Front Lower Crossbar
Rear Crossbar
Shelf
Shelf

Shelf
D x 4
D x 4
Wardrobe Side
B
A
x 3
Shelf
Assembly 3
Assembly 4
5

C x 4
Wardrobe Top
E x 7
Assembly 5
Assembly 6
6

7
Back Panel Joining Strip
Back Panel
NOTE:
This stage is best carried out with the Wardrobe laid on its front on a soft surface.
1. Place one Back Panel into the recess on the back of the Wardrobe with the screw holes
on the outer edges.
2. Position the second Back Panel alongside the first, leaving a gap between them.
3. Place the Back Panel Joining Strip in the gap between the Back Panels with the wide
edge facing outward.
4. Secure in place with 13 x screws L in each Back Panel and 4 x screws H in the Back
Panel Joining Strip.
L x 13
L x 13
H x 4
Assembly 7
Back Panel

Assembly 9
Assembly 8
Assembly 10
H x 4
F x 4
NOTE:
Ensure slots in part F are visible.
8
Drawer Side
Drawer Side
Drawer Front
Drawer Base
Drawer Brace
Drawer Back

Assembly 11
Assembly 12
N x 2
J x 2
G x 4
Clothes Rail
Clothes Rail
Completed Drawer
Turn 90°
9

10
Assembly 13
The wardrobe is supplied with a fixing kit which will secure it and help to guard against accidental tipping.
WARNING : Installation only to be carried out by a competent person.
Check the suitability of the wall before fitting.
1. Place the wardrobe against the wall where it is to be fitted. Mark the wall at the centre of the top edge of the
wardrobe. Move the wardrobe away.
2. Using the 25mm screw, washer and the appropriate wall fixing, attach the fabric strap to the marked position.
3. Re-position the wardrobe. Attach the strap to the top of the wardrobe using the 15mm screw and the washer.
4. Proceed to Assembly 14 to fit and adjust the doors.
Before use, ensure that the strap is securely fixed to both the wall and the wardrobe.
Washer x 2
Screw (15mm)
Screw (25mm)
Plastic wall plug
(for brick and masonry wall use only)
Fabric strap
1
2
3
The type of wall fixing you will require depends on the construction of the wall. See below for details. If in doubt,
seek professional advice:
Wood: If fixing to wood make
sure that it isn’t chipboard as
screws can easily pull away
the core structure.
Brick or masonry: Use the
wall plug, provided you are
sure that your wall is sound.
Cavity wall: Special toggle
wall plugs needed.
Seek expert advice.

Assembly 14
Assembly 15
N x 1
K x 1
I x 2
(6 total)
M
Door
NOTE:
Repeat for second Door.
Screw 1
Screw 2
NOTE:
To Adjust the fit of the doors in the frame,
position the wardrobe where it will be
used and use screws 1 and 2:
Screw 1 loosens the hinge to move the
door forward or backward.
Screw 2 moves the door closer to, or
further from the frame.
1.
2.
11

Customer Care line for this Product 01692 408802
7844-01
East Coast Nursery Ltd. Robertson House, North Walsham, Norfolk, NR28 0BX
www.eastcoastnursery.co.uk
Care & Maintenance
Your furniture may be cleaned by wiping with a damp cloth and drying with a soft clean cloth.
Do not use abrasives, bleach, alcohol or ammonia-based household polishes.
Take care when handling or moving the furniture. Careless handling may cause damage.
Regularly check that all fixings are tightened and that there are no broken or damaged parts.
In use
All assembly fixings should always be tightened properly.
Be aware of the risks of open fires and other such sources of strong heat, such as electric bar fires, gas
fires, etc. in the near vicinity of the wardrobe.
Do not use if any of the parts are broken, torn or missing.
Any additional or replacement parts can only be obtained from the manufacturer or the distributor.
Only use the wardrobe on a stable and level surface.
Ensure that the wall strap is used to securely attach the wardrobe to the wall to prevent tipping.
