OFF
WARNING
DO NOT ATTEMPT TO INSTALL OR PERFORM MAINTENANCE ON THE
EQUIPMENT WHILE IT IS ENERGIZED. DEATH OR SEVERE PERSONAL
INJURY CAN RESULT FROM CONTACT WITH ENERGIZED EQUIPMENT.
ALWAYS VERIFY THAT NO VOLTAGE IS PRESENT BEFORE PROCEEDING.
Series C F-frame circuit breaker with current
limiter module - instruction leaflet for circuit
breaker and motor circuit protector
Effective April 2016
Supercedes March 2012Instruction Leaet IL01203016E
1

2
Series C F-frame circuit breaker with current
limiter module - instruction leaet for circuit
breaker and motor circuit protector
EATON www.eaton.com
Instruction Leaet IL01203016E
Effective April 2016
10 in-lb(1.1 N•m)
Phase Mounting Barriers
(Provided) Required, Line
Side Only.
Phase Barriers (Provided)
Required, Line Side Only.
Line
Mounted
Limiter
Mounting Barriers
(Provided) Required,
Line and Load Sides
of Breaker.
Phase Barriers (Provided)
Required, Line and Load
Sides of Breaker.
Load
Mounted
Limiter
Phase Barriers Can Be
Shortened to a Minimum
of 2” (51 mm).
2.000
(51)
2
4
3
5
Hardware Required
FD Breaker 8-32, 1.5 in. long
Limiter Module 8-32, 3.5 in. long

3
Instruction Leaet IL01203016E
Effective April 2016
Series C F-frame circuit breaker with current
limiter module - instruction leaet for circuit
breaker and motor circuit protector
EATON www.eaton.com
For 40 A- 200 A
For 15 A- 35 A
ON
TRIP
OFF
RESET
Push to Trip
6
7
 WARNING
INSTALL WIRE APPLICABLE TO THE HIGHEST RATING SHOWN ON
BREAKER.
TA250FJ Collar Torque Values 40 A - 200A For
Limiter Module
Wire Size (AWG) Torque (in-lb) Torque (Nm)
8 - 350 250 28.24
TA50FB Lug Torque Values For 15 A to 35 A
Wire Size (AWG) Torque (in-lb) Torque (Nm)
14 - 10 35 3.96

4
Series C F-frame circuit breaker with current
limiter module - instruction leaet for circuit
breaker and motor circuit protector
EATON www.eaton.com
Instruction Leaet IL01203016E
Effective April 2016
1.765
+.025
3.385 -.015
+.030
3.501 -.020
C
+.030
6.000 -.020
1.219
.218
.266
.750
.078
EB
DA
3.342
3.188
3.625
12.060
.300 WIDE CONDUCTOR
WITH n .219 HOLE.
LOAD END
LINE END
1.562
.375
.740
+.000
4.125 -.020
2.062
1.000
.500
LINE END
LOAD END
8
Breaker
Status
Dimension
A B C D E
On 3.07 2.92 3.96 3.40 3.33
Tripped 2.65 2.57 4.06 2.99 2.98
Off 2.08 2.14 4.12 2.42 2.56
Reset 1.98 2.05 4.11 2.30 2.48

5
Instruction Leaet IL01203016E
Effective April 2016
Series C F-frame circuit breaker with current
limiter module - instruction leaet for circuit
breaker and motor circuit protector
EATON www.eaton.com
4.125
12.039
.750
4X .687
4X 1.375
4.500
4X R.250
.594
1.189 2.313
2.906
5.835
4.689
2.063
2.875
4.125
12.039
.469
4X .687
4X 1.375
4.500
4X R.250
.594
1.189 2.313
2.906
5.839
4.689
2.063
1.906
FD LOAD MOUNTED LIMITER
LOAD END
LINE END
8X 8-32 UNC
BREAKER
HANDLE
C
L
FD LINE MOUNTED LIMITER
LOAD END
LINE END
8X 8-32 UNC
BREAKER
HANDLE
C
L
9

Series C F-frame circuit breaker with current
limiter module - instruction leaet for circuit
breaker and motor circuit protector
Effective April 2016
Eaton
Electrical Sector
1000 Eaton Boulevard
Cleveland, OH 44122
United States
877-ETN-CARE (877-386-2273)
Eaton.com
© 2016 Eaton
All Rights Reserved
Printed in USA
Publication No. IL01203016E / TBG001288
Part Number: IL01203016EH02
April 2016
