Echogear EGMF1 User manual

5/16 x 2¾ in.
4 mm
Hex Key
Lag Bolts TV Screws
Extender Brackets
Extender
Screws
Wallplate and Arm
Lag Bolt Washers
TV Washers
Spacers
M4 x 12mm
M4/M5 M6/M8
M6 x 12mm M6 x 35mm
M4 x 35mm
M8 x 16mm
M8 x 35mm
M8 x 20mm
Stud
Finder Awl or Thin Nail Pencil Level
Drill 1/2 in.
(13 mm)
7/32 in.
(5.5 mm)
Wood
Please read through these instructions completely to be sure you’re comfortable with this
easy install process. Also check your TV owner’s manual to see if there are any special
requirements for mounting your TV.
If you do not understand these instructions or have doubts about the safety of the
installation, assembly or use of this product, contact Customer Service at 1-855-428-2490.
CAUTION: Avoid potential personal injuries and property damage!
●This product is designed for use in wood stud walls - DO NOT install into drywall
alone
●The wall must be capable of supporting five times the weight of the TV and mount
combined
●Do not use this product for any purpose not explicitly specified by manufacturer
●Manufacturer is not responsible for damage or injury caused by incorrect assembly
or use
FULL-MOTION
TV WALL MOUNT
For 26”-50”
(66-127 cm)
TVs
Model EGMF1
7 ⅞ in.
(200 mm)
7 ⅞ in.
(200 mm)
5 ⅛ in.
(130 mm)
5 ⅛ in.
(130 mm)
4 in.
(100 mm)
4 in.
(100 mm)
15 ¾ in.
(400 mm)
15 ¾ in.
(400 mm)
13 ⅜ in.
(340 mm)
13 ⅜ in.
(340 mm)
11 ¾ in.
(300 mm)
11 ¾ in.
(300 mm)
Tools:
Hardware
08 x4
05 x2
04 x8
06 x2
07 x1
09 x4
10 x4 11 x4
12 x4
13 x4
14 x4
15 x4 16 x4
17 x4
01 x1
02 x2 03 x2
03
02
03
02
100 mm = 10 cm ≈ 4 in.
130 mm = 13 cm ≈ 5 1/8 in.
200 mm = 20 cm ≈ 7 7/8 in.
300 mm = 30 cm ≈ 11 3/4 in.
340 mm = 34 cm ≈ 13 3/4 in.
400 mm = 40 cm ≈ 15 3/4 in.
Using the hex key 07 , remove
the screws [S] and separate
the faceplate from the arm.
Keep screws for use in Step 6.
Measure your TV hole pattern. Determine which
TV bracket
configuration
(Aor B) to use
based on your
TV hole pattern
measurements.
If your TV hole pattern is greater than 200 mm x 200
mm (configuration B), attach TV bracket extenders
02 and 03 to faceplate using extender screws 04 .
[S]
60 lbs.
(27 kg)
Does your TV weight more
than 60 lbs. (27 kg) including
accessories?
No — Perfect!
Yes — This mount is NOT compatible.
WARNING: Exceeding the weight
capacity can result in serious personal injury
or damage to equipment! It is the installer's
responsibility to make sure the weight of the
TV (with accessories) does not exceed 60 lbs
(27 kg).
Drywall with
wood studs?
Perfect!
Call Customer Service:
1-855-428-2490
?
What is your wall made of?
Step 1 Step 2 Step 3
WARNING: This
product contains small
items that could be
a choking hazard if
swallowed.
Before starting assembly,
verify all parts are
included and undamaged.
If any parts are missing or
damaged, do not return
the damaged item to your
dealer; contact Customer
Service. Never use
damaged parts!
A
B
04
07
07
