Echogear EGLF1 User manual

5/16 x 2¾ in.
Arm and
W
all Plate
TV Bracket
Hex Key
End Cap and
Bracket
Clip Screws
Lag Bolts
Lag Bolt
Washers
TV Screws
Extension Screws
Bracket
Clips
Arm Extensions End Caps
M6 x 12mm
M5 x 12mm
TV Screws TV Washers
Spacers
M4 x 12mm
M4/M5 M6/M8
M6 x 12mm M6 x 35mm
M4 x 35mm
M8 x 16mm M8 x 35mm
M8 x 20mm
FULL-MOTION
TV WALL MOUNT
For 37”-70”
(93.9-177.8 cm)
TVs
Model EGLF1
M6M4 M8
1-1 Select TV Screw Diameter 1-2 Select TV Screw Length
FLAT BACK ROUND BACK CABLESINSET HOLES
AB
Too Short
Too Long
Correct
Stud
Finder Awl or Thin Nail Pencil Level
Drill 1/2 in.
(13 mm)
7/32 in.
(5.5 mm)
Wood
132 lbs.
(60 kg)
Does your TV weight more
than 132 lbs. (60 kg) including
accessories?
No — Perfect!
Yes — This mount is NOT compatible.
Tools: Hardware
11 x4
07 x8 10 x1
06 x4
08 x4
09 x4 12 x4
13 x4
16 x4
17 x4
18 x4
14 x4
15 x4
19 x4
20 x4
21 x2
01 x1
02 x2
03 x2 04 x2 05 x2
1-3 Attach the TV Bracket
If your TV has a flat back AND you want your TV closer to
the wall, use the shorter screws (A).
Use the spacers and longer screws (B) to accommodate:
• Round/irregular back TVs
• TVs with inset mounting holes
• Extra space needed for cables CAUTION:
Verify adequate thread
engagment with the screw or
screw/spacer combination.
-Too short will not hold the TV.
-Too long will damage the TV.
Standard configurations
are shown. For special
applications, or if you
are uncertain about your
hardware selection,
contact Customer Service
at 1-855-428-2490.
Hand thread screws into the threaded inserts
on the back of your TV to determine which
screw diameter (M4, M6, or M8) to use.
WARNING: Exceeding the weight
capacity can result in serious personal injury
or damage to equipment! It is the installer's
responsibility to make sure the weight of the
TV (with accessories) does not exceed 132 lbs
(60 kg).
13
18
14
19
12
11
05
05
A
B
05
05
17
18
20
19
1615
WARNING: This
product contains small
items that could be
a choking hazard if
swallowed.
Before starting
assembly, verify all
parts are included and
undamaged. If any parts
are missing or damaged,
do not return the
damaged item to your
dealer; contact Customer
Service. Never use
damaged parts!
Please read through these instructions completely to be sure you’re comfortable with this
easy install process. Also check your TV owner’s manual to see if there are any special
requirements for mounting your TV.
If you do not understand these instructions or have doubts about the safety of the
installation, assembly or use of this product, contact Customer Service at 1-855-428-2490.
CAUTION: Avoid potential personal injuries and property damage!
●This product is designed for use in wood stud walls - DO NOT install into drywall
alone
●The wall must be capable of supporting five times the weight of the TV and mount
combined
●Do not use this product for any purpose not explicitly specified by manufacturer
●Manufacturer is not responsible for damage or injury caused by incorrect assembly
or use
Drywall with
wood studs?
Perfect!
Call Customer Service:
1-855-428-2490
?
What is your wall made of?
Position your TV bracket
configuration (Aor B)
over your TV hole pattern
- making sure the bracket
is centered over the TV
hole pattern and level.
Secure bracket using your
screw/washer (Flat Back)
or spacer/screw/washer
(Round Back / Extra
Space) selection.
CAUTION: Ensure
TV bracket is securely
fastened before moving
on to the next step.

Milestone AV Technologies and its aliated corporations and subsidiaries (collectively,
“Milestone”), intend to make this manual accurate and complete. However, Milestone
makes no claim that the information contained herein covers all details, conditions,
or variations. Nor does it provide for every possible contingency in connection with
the installation or use of this product. The information contained in this document
is subject to change without notice or obligation of any kind. Milestone makes no
representation of warranty, expressed or implied, regarding the information contained
herein. Milestone assumes no responsibility for accuracy, completeness or suciency
of the information contained in this document.
©2015 Milestone AV Technologies. All rights reserved. ECHOGEAR is a Milestone
brand.
ECHOGEAR and the ECHOGEAR logo are trademarks of Milestone.
Made in China.
Milestone Global Headquarters • 6436 City West Parkway • Eden Prairie, MN 55344 USA
16 in.
(406 mm)
2-1 2-2 2-3 2-4
Step 3
Adjustments
6901-002429 02
01 01 08
09
05
05
03
01
01
02
01
To adjust TV level, loosen the 2 bolts on
the rear of the arm plate, adjust level,
and retighten to secure.
Step 5
Step 4
05
05
Hang TV with
brackets
05
onto the upper
arm extensions
02
and
03
.
Note: TV brackets
05
must span the
faceplate of the arm and be centered.
Secure TV with brackets
05
to the lower arm extensions
02
and
03
with the bracket clips
21
and screws
07
.
Ensure that the
bracket clips
21
and screws
07
are firmly attached and that the TV with
brackets
05
cannot slide side-to-side .
02
02
03
04
04
03
Install arm extensions
02
and
03
and end caps
04
.
07
07
10
07
07
06
06
Step 2 Wood Stud
N
o
t
e
O
r
i
e
n
t
a
t
i
o
n
UP
3 in. (75 mm)
7/32 in.
(5.5 mm)
03
02
To adjust TV tilt, loosen the handle on
the arm plate, tilt TV to desired angle,
and retighten handle to secure.
CAUTION: Avoid potential personal injuries and
property damage!
●Drywall covering the wall must not exceed
5/8 in. (16 mm)
●Minimum wood stud size: common 2 x 4 in.
(51 x 102 mm) nominal 1½ x 3½ in. (38 x 89 mm)
CAUTION: Avoid potential personal injury or
property damage! All lag bolts 08 MUST BE firmly
tightened to prevent unwanted movement of the wall
plate 01 .
CAUTION: Ensure the wall plate is securely
fastened to the wall before continuing on to the next
step. Locate your studs. Verify and mark the center of
the studs by finding the stud edges using an awl,
a thin nail, or an edge-to-edge stud finder.
Install wall plate 01 using lag bolts 08 and
washers 09 . Tighten the lag bolts 08 only until
they are pulled firmly against the wall plate 01 .
Position the wall plate 01 at your desired height
and line up the holes with your stud center line.
Level the wall plate and mark the holes.
Drill pilot holes using a 7/32 in. (5.5 mm) diameter
drill bit.
IMPORTANT: Be sure to drill into the center of the
stud.
IMPORTANT: Pilot holes must be drilled to a depth
of 3 in. (75 mm).
02
03
07
07
05
21
