Empire Comfort Systems EMBF-1S-C-1 User manual

17802-3-0414 Page 1Empire Comfort Systems Inc. • 918 Freeburg Avenue • Belleville, IL 62220
MANTEL ASSEMBLY INSTRUCTIONS
EMBF-1S-(C,DO,O,UH,UO,W)-1 EMBF-2S-(C,DO,O,UH,UO,W)-1
EMBF-3S-(C,DO,O,UH,UO,W)-1 EMBF-4S-(C,DO,O,UH,UO,W)-1
EMBF-5S-(C,DO,O,UH,UO,W)-1 EMBF-6S-(C,DO,O,UH,UO,W)-1
EMBF-7S-(C,DO,O,UH,UO,W)-1 EMBF-8S-(C,DO,O,UH,UO,W)-1
FULL CABINET MANTEL
3. Position breastboard assembly to the front of left side assembly
and right side assembly. See Figure 3.
BREAST BOARD
Figure 3
1. Placebaseindesiredlocation.Placereplaceonbaseand
routegaslinetoreplace.SeeFigure1.
BASE
Figure 1
2. Position left side assembly and right side assembly against
base. See Figure 2.
Figure 2
INSTRUCTIONS MUST BE LEFT WITH THE OWNER FOR FUTURE REFERENCE AFTER INSTALLATION.

17802-3-0414Page 2 Empire Comfort Systems Inc. • 918 Freeburg Avenue • Belleville, IL 62220
4. Use six (6) 1 1/4" screws to attach breastboard assembly to
left side assembly and right side assembly. See Figure 4.
(6)11/4” SCREWS
Figure 4
5. Attach"L"Brackettotopofreboxtosecuremanteltorebox.
See Figure 5.
“L” BRACKET
Figure 5
6. Placetopassemblyontoleftsideassemblyandrightside
assembly. See Figure 6.
TOP
Figure 6
7. Installationofmanteliscompleted.
