Entrematic EM SW EMO Manual

Swing Door Operator
EM SW EMO
ILL-01780
Installation and Service Manual
Original instructions
1005088-EMEI-11.0 –Issue 2014-11-24

© All rights in and to this material are the sole property of Entrematic Group AB. Copying, scanning, alterations or modifications are
expressly forbidden without the prior written consent of Entrematic Group AB. Rights reserved for changes without prior notice.
Backtrack information: folder:Workspace Main, version:a178, Date:2014-11-21 time:10:42:44, state: Frozen

CONTENTS - Original instructions
51 Revision .....................................................................................................................................................................................
62 Instructions for safe operation ...........................................................................................................................................
73 Important information .........................................................................................................................................................
73.1 Intended use ....................................................................................................................................................................................
73.2 Safety precautions .........................................................................................................................................................................
73.3 Electronic equipment reception interference .....................................................................................................................
83.4 Environmental requirements .....................................................................................................................................................
94 Technical specification ..........................................................................................................................................................
104.1 Permitted door weight and door width .................................................................................................................................
114.2 Classification ....................................................................................................................................................................................
125 How the EM SW EMO works ...............................................................................................................................................
125.1 Opening ............................................................................................................................................................................................
125.2 Closing ...............................................................................................................................................................................................
125.3 Functions on the basic control unit CU-ESD .........................................................................................................................
125.3.1 Power failure ..................................................................................................................................................................
125.3.2 Spring force ....................................................................................................................................................................
125.3.3 Extended closing force/torque (CLTQ) ..................................................................................................................
125.3.4 Power assist (POAS) .....................................................................................................................................................
125.3.5 Push and go (PAG) ........................................................................................................................................................
125.3.6 Overhead presence detector (OPD), frame mounted .....................................................................................
135.3.7 Mat ....................................................................................................................................................................................
135.4 Functions on the extension unit EXU-SI .................................................................................................................................
135.4.1 KILL function ..................................................................................................................................................................
135.4.2 Function of locks ...........................................................................................................................................................
135.4.3 Program selector ..........................................................................................................................................................
135.4.4 Impulses ..........................................................................................................................................................................
145.4.5 OPEN/CLOSE impulse ..................................................................................................................................................
145.4.6 Power failure mode (backup batteries are installed) –optional ..................................................................
145.4.7 Nurse and bed functionality .....................................................................................................................................
145.5 Functions on the extension unit EXU-SA –optional ...........................................................................................................
145.5.1 Presence impulse approach, door mounted .......................................................................................................
145.5.2 Presence detection swingpath, door mounted ..................................................................................................
155.5.3 Monitored safety sensors ...........................................................................................................................................
155.5.4 Open door indication ..................................................................................................................................................
155.5.5 Error indication .............................................................................................................................................................
166 Models ........................................................................................................................................................................................
166.1 EM SW EMO, standard cover (wall mounted) ......................................................................................................................
177 Part identification & Accessories ......................................................................................................................................
187.1 Arm system, PUSH .........................................................................................................................................................................
187.1.1 PUSH-arm extensions .................................................................................................................................................
187.2 Arm system, PULL ...........................................................................................................................................................................
187.3 Arm system, PULL-P .......................................................................................................................................................................
197.4 Arm system, ST-V / ST-H ...............................................................................................................................................................
197.4.1 Options for ST-V / ST-H ................................................................................................................................................
197.5 Reveal spacer: PULL / PULL-P ......................................................................................................................................................
207.6 Drive shaft extension kits ............................................................................................................................................................
207.7 Control switches ............................................................................................................................................................................
207.7.1 Power ON/OFF switch .................................................................................................................................................
207.7.2 ON/OFF/HOLD open switch (will not operate electric lock) ..........................................................................
217.7.3 4-position switch PS-4C (operates the electric lock) .......................................................................................
217.8 Sync cable for double doors (synchronizing of 2 operators) ..........................................................................................
237.9 Extension units ................................................................................................................................................................................
237.10 Battery backup unit .......................................................................................................................................................................
247.11 Cover piece kit ................................................................................................................................................................................
247.11.1 Middle piece kit .............................................................................................................................................................
247.12 Labels .................................................................................................................................................................................................
3Issue 2014-11-241005088-EMEI-11.0

258 Pre-installation ........................................................................................................................................................................
258.1 General tips/Safety concerns .....................................................................................................................................................
258.2 Operator/Door handing ...............................................................................................................................................................
268.3 Installation examples ....................................................................................................................................................................
278.4 Fastening requirements ...............................................................................................................................................................
278.5 Tools required .................................................................................................................................................................................
278.6 Installation on double doors ......................................................................................................................................................
289 Mechanical installation ........................................................................................................................................................
289.1 Operator with PUSH arm system ..............................................................................................................................................
349.2 Operator with PULL arm system ...............................................................................................................................................
409.3 Installation of operator with arm system ST .........................................................................................................................
4910 Electrical connection .............................................................................................................................................................
4910.1 Mains connection ..........................................................................................................................................................................
5010.2 Control units ....................................................................................................................................................................................
5010.2.1 CU-ESD .............................................................................................................................................................................
5010.2.2 Arm system selection ..................................................................................................................................................
5110.2.3 Extension units EXU-SI / EXU-SA ..............................................................................................................................
5210.2.4 Extension unit EXU-SI ..................................................................................................................................................
5310.2.5 Extension unit EXU-SA ................................................................................................................................................
5411 Start-up ......................................................................................................................................................................................
5411.1 Adjusting the door stop ...............................................................................................................................................................
5611.2 Auto-learn –automatically sets back and latch check (recommended) .....................................................................
5611.2.1 One push / two pushes on the LEARN BUTTON (LRN) .....................................................................................
5611.2.2 Double doors .................................................................................................................................................................
5711.3 General adjustment ......................................................................................................................................................................
5811.4 Connection of activation units and accessories ..................................................................................................................
5912 Cover ..........................................................................................................................................................................................
5912.1 Fitting and removing the cover .................................................................................................................................................
6012.2 Middle piece cover ........................................................................................................................................................................
6113 Signage .......................................................................................................................................................................................
6214 Changing group of parameters ..........................................................................................................................................
6315 Classification ............................................................................................................................................................................
6315.1 Entering the program mode (classification) .........................................................................................................................
6315.2 Identify the current classification .............................................................................................................................................
6315.3 Changing the classification .........................................................................................................................................................
6315.4 Classification table .........................................................................................................................................................................
6516 Advanced settings ..................................................................................................................................................................
6516.1 Learn with advanced setting of “back- and latch-check”..................................................................................................
6516.2 Revert to default values for “back- and latch-check”.........................................................................................................
6616.3 Reducing / Increasing the “Spring pre-tension”(SPTE) .....................................................................................................
6717 Installation and adjustments ..............................................................................................................................................
6717.1 Complementary Safety Devices Swing Doors ......................................................................................................................
6717.2 Swing Doors Opening and Closing Time ................................................................................................................................
6717.2.1 How to find the correct opening and closing time ...........................................................................................
6817.3 Diagrams for Door weight ..........................................................................................................................................................
6817.3.1 Aluminium frame with glass .....................................................................................................................................
6918 Installation instructions for Accessories .........................................................................................................................
6918.1 Armsystem PULL-P .........................................................................................................................................................................
6918.1.1 Mounting instruction for magnetic switch G1 ...................................................................................................
6918.1.2 Installation of PULL-P ...................................................................................................................................................
7119 Troubleshooting .....................................................................................................................................................................
7219.1 Error indication ...............................................................................................................................................................................
7320 Service/Maintenance .............................................................................................................................................................
1005088-EMEI-11.0Issue 2014-11-244

1 Revision
The following pages have been revised:
Revision 10.0 →11.0Page
Added new part of permitted door weight and door width.10
Added new part of nurse and bed functionality.14
Updated measurment.16
Updated back plate and measurements.29
Updated back plate.30
Updated back plate and measurements.31
Updated back plate.32
Updated back plate.33
Updated back plate and measurements.35
Updated back plate.36
Updated back plate and measurements.37
Updated back plate.38
Updated back plate.39
Updated back plate and measurements.41
Updated back plate.44
Updated back plate and measurements.43
Updated back plate.45
Updated back plate.46
Updated back plate.47
Updated back plate.48
Updated connection of activation units and accessories.58
5Issue 2014-11-241005088-EMEI-11.0
1 Revision

2 Instructions for safe operation
•Failure to observe the information in this manual may result in
personal injury or damage to equipment.
•To reduce the risk of injury to persons - use this operator with single
or double pedestrian swinging or folding doors only.
•Do not use the equipment if repair or adjustment is necessary.
•Disconnect supply when cleaning or other maintenance is to be
carried out.
•The operator can be used by children age 8 and above, and persons
with reduced physical, sensory or mental capabilities, or lack of ex-
perience and knowledge, if they have been given supervision or in-
struction by a person responsible for their safety concerning safe
operator use and the possible hazards involved.
This does not however prevent those persons to use the door where
the operator is installed.
•Cleaning and user maintenance shall not be made by children
without supervision.
•Do not let children climb on or play with the door or the fixed/re-
mote controls.
•Risk of battery explosion if wrong type of battery is used.
•In all instances, where work is being done, the area is to be secured
from pedestrian traffic, and the power removed to prevent injury.
•The doorset can be operated automatically by sensors or manually
by activators. It can also be used manually as a door closer.
1005088-EMEI-11.0Issue 2014-11-246
2 Instructions for safe operation

3 Important information
3.1 Intended use
The door is designed to offer continuous use, a high degree of safety and maximum lifetime. The
system is self-adjusting to the effects caused by normal variations in the weather conditions and
to minor friction changes caused by e.g. dust and dirt.
For escape in emergency situations the doorset is opened manually.
This manual contains the necessary details and instructions for the installation, maintenance and
service of the Swing Door Operator EM SW EMO.
The EM SW EMO is an automatic swing door operator developed to facilitate entrances to buildings
and within buildings through swing doors. The EM SW EMO is a low-energy operator using a DC
motor and a gear-reduction system to drive an arm system, which opens the door. It is to be installed
indoors where it is suitable for almost all types of external and internal swing doors. This widely-
used operator can be found on applications ranging from handicapped-access in private homes
to high-traffic retail operations.
The motor and gear system are combined into a compact unit mounted alongside the control unit
within the cover. The operator is connected to the door leaf with different arm systems.
For use see User manual 1005099.
Save these instructions for future reference.
3.2 Safety precautions
Be sure to complete a risk assessment and site acceptance test before taking the door into operation.
To avoid bodily injury, material damage and malfunction of the product, the instructions contained
in this manual must be strictly observed during installation, adjustment, repairs and service etc.
Training is needed to carry out these tasks safely. Only Entrematic Group-trained technicians should
be allowed to carry out these operations.
3.3 Electronic equipment reception interference
The equipment complies with the European EMC directive (US market FCC Part 15), provided in-
stalled according to Installation and Service manual.
The equipment may generate and use radio frequency energy and if not installed and used properly,
it may cause interference to radio, television reception or other radio frequency type systems.
If other equipment does not fully comply with immunity requirements interference may occur.
There is no guarantee that interference will not occur in a particular installation. If this equipment
does cause interference to radio or television reception, which can be determined by turning the
equipment off and on, the user is encouraged to try to correct the interference by one or more of
the following measures:
•Re-orient the receiving antenna.
•Relocate the receiver with respect to the equipment.
•Move the receiver away from the equipment.
•Plug the receiver into a different outlet so that equipment and receiver are on different branch
circuits.
•Check that protective earth (PE) is connected.
If necessary, the user should consult the dealer or an experienced electronics technician for addi-
tional suggestions.
7Issue 2014-11-241005088-EMEI-11.0
3 Important information

3.4 Environmental requirements
Entrematic Group products are equipped with electronics and may also be equipped with batteries
containing materials which are hazardous to the environment. Disconnect power before removing
electronics and battery and make sure it is disposed of properly according to local regulations (how
and where) as was done with the packaging material.
1005088-EMEI-11.0Issue 2014-11-248
3 Important information

4 Technical specification
Ensure that the door operator with technical specification below is suitable for the installation.
Entrematic Group ABManufacturer:
Lodjursgatan 10, SE-261 44 Landskrona, SwedenAddress:
EM SW EMOType:
100-240 V AC +10/-15%, 50/60 HzMains power supply:
Note! The mains power supply shall be installed with protection
and an all-pole mains switch with isolating capability of Category
III, at least 3 mm between contacts, shall be installed according to
local regulations. These articles are not provided with the door.
Max. 75 WPower consumption:
24 V DC, max. 400 mAAuxiliary voltage:
2 x T 6,3 AH 250 VMains fuse F1, F2:
Max. 1200 mmDoor width:
45-90 kgDoor weight:
For PUSH = 45 kg m2 Max. Inertia J:
For PULL = 16 kg m2
Inertia = Door weight x (Door width)2/ 3
Selectable: 12V DC, max. 500 mA / 24 V DC, max. 250 mAElectro-mechanical locking
device:
PUSH arm: 80° - 110°, with reveal 0 - 100 mm (300 mm with longer
telescopic part)
Door opening angle:
PULL arm: 80° - 110°, with reveal 0 - 130 mm
variable between 3 - 6 secondsOpening time (0° - 80°):
variable between 3 - 6 secondsClosing time (90° - 10°):
1,5-30 secondsHOLD open time:
-20 °C to +45 °CAmbient temperature:
IP 20Degree of protection:
IP54Degree of protection, con-
trol actuators:
Max. 85%Relative humidity
(non-condensing):
Third party approvals from established certification organizations
valid for safety in use, see Declaration of Incorporation.
Approvals:
9Issue 2014-11-241005088-EMEI-11.0
4 Technical specification

This product is to be installed internally.
65
130
38 3834
7518
110
ILL-01607
4.1 Permitted door weight and door width
0
50
100
150
200
250
300
350
400
450
0.8 0.9 1 1.1 1.2 1.3 1.4
PUSH arm
PULL arm
J=45 kgm²
J=16 kgm²
Door weight (kg)
Door width (m)
1005088-EMEI-11.0Issue 2014-11-2410
4 Technical specification

4.2 Classification
Classification to DIN 18650-1
Digit 8Digit 7Digit 6Digit 5Digit 4Digit 3Digit 2Digit 1
20030131
swing door drive1Type of drive, digit 1.
1 000 000 test cycles, at 4 000 cycles/day3Drive durability, digit 2.
swing door1Type of door leaf, digit 3.
not suitable for use as a fire protection door0Suitability for use as a fire protec-
tion door, digit. 4
low energy3Drive safety devices, digit 5.
no special requirements0Special requirements for
drives/functions/fittings, digit 6.
no safety devices0Safety at door leaf or leaves, digit
7.
−15 °C to +50 °C2Ambient temperature, digit 8.
11Issue 2014-11-241005088-EMEI-11.0
4 Technical specification

5 How the EM SW EMO works
The swing door operator EM SW EMO uses a DC motor and a gear-reduction system to drive an
arm system, which opens the door. Closing power is provided by a motor and a clock spring. An
electronic control unit uses a motor encoder and a microprocessor to control the door’s movement.
5.1 Opening
When an opening signal is received by the control unit, the door is opened at the operator-adjusted
opening speed. Before the door is fully open at back check, it slows automatically to low speed.
The motor stops when the selected door opening angle has been reached. The open position is
held by the motor.
If the door is obstructed while opening, it will either stall or stop which can be selected with a DIP-
switch (SOS). Stop on stall is always active in program selector Mode Off.
•Continue on stall - the door will continue to try to open during the hold open time.
•Stop on stall - the door will, even if hold open time has not expired, close after 2 seconds.
5.2 Closing
When the hold open time has elapsed, the operator will close the door automatically, using spring
force and motor. The door will slow to low speed at latch check before it reaches the fully closed
position. The door is kept closed by spring power or combined with extended closing torque by
the motor.
5.3 Functions on the basic control unit CU-ESD
Also see page 50 for more information.
5.3.1 Power failure
During power failure the operator acts as a door closer with controlled closing speed.
5.3.2 Spring force
The operator is delivered with spring pre-tension factory set to 210°. If necessary, the spring tension
can be electronically adjusted with a potentiometer to required closing force.
5.3.3 Extended closing force/torque (CLTQ)
If the potentiometer CLTQ is set to 0°, the door will close with normal spring power. If the poten-
tiometer is turned clockwise, the motor will increase the closing force/torque.
5.3.4 Power assist (POAS)
If the potentiometer POAS is set to 0°, the door gives no power assist. If the potentiometer is turned
clockwise, the motor will give/increase power assist when the door is opened manually.
5.3.5 Push and go (PAG)
DIP-switch to select PUSH and GO, ON or OFF. PUSH and GO is available from any door position.
PUSH and GO is not active in programme selector setting OFF.
5.3.6 Overhead presence detector (OPD), frame mounted
When an OPD sensor is mounted on the frame or operator cover just above the swing side of the
door, it will–when activated–either keep the door open or closed. The sensor is not active during
opening and closing. Lock-out signal must be connected for proper function.
•a closed door will not open, if the OPD detects activity in the field
1005088-EMEI-11.0Issue 2014-11-2412
5 How the EM SW EMO works

•an open door will not close, if the OPD detects activity in the field
•during opening, the door will continue to open, even if the OPD detects activity in the field
•during closing, the door will continue to close, even if the OPD detects activity in the field
•the OPD is not active in program mode OFF, manually opened door or during battery operation
(Power Save Mode).
5.3.7 Mat
Mat safety means that:
•a closed door will not open, if someone steps on the mat
•an open door will not close, if someone steps on the mat
•during opening, the door will continue to open, even if someone steps on the mat
•during closing, the door will continue to close, even if someone steps on the mat
•opening impulses are prevented during closing, if someone steps on the mat
•the mat is not active in program mode OFF, manually opened door or during battery operation
(Power Save Mode).
5.4 Functions on the extension unit EXU-SI
Also see page 52 for more information.
5.4.1 KILL function
•If KILL circuit is closed, the control will ignore all signals and close door(s) at normal speed.
•When KILL is no longer active, operator will resume normal operation.
•If KILL function must have manual reset, jumper must be removed and reset button connected
to terminal No. 8 and Ground.
•The lock will lock when KILL is active regardless of program selector setting.
•The function of the lock can be changed during KILL (see page 62).
•In a double door application, KILL is only connected to the master operator.
5.4.2 Function of locks
•The lock output is short circuit proof and can source a lock with 12 V DC, max. 500 mA or 24 V
DC, max 250 mA. Lock function is active in programme selection EXIT and OFF
•DIP-switch to select 12 or 24 V DC
•DIP-switch to select locked with or without power
•DIP-switch for lock release and potentiometer for opening delay
•DIP-switch for lock kick if door is not fully closed, to overcome binding in the locking device
during closing
•Input to unlock signal from lock. Potentiometer for opening delay is to be set to max. As soon
as unlock signal is received the door will start to open. The output signal shall be active low.
5.4.3 Program selector
•Input for OPEN, EXIT and OFF (if no program selector, AUTO is default).
5.4.4 Impulses
•Input for OUTER impulse, KEY impulse and OPEN/CLOSE impulse.
13Issue 2014-11-241005088-EMEI-11.0
5 How the EM SW EMO works

5.4.5 OPEN/CLOSE impulse
The impulse will open the door and the door will stay open until a new impulse is given. If no impulse
is given the door will close after 15 minutes. This can be made infinite by changing group of para-
meters, see page 62.
OPEN/CLOSE impulse works only in program selection ON.
5.4.6 Power failure mode (backup batteries are installed) –optional
•In case of power failure, normal operation can be carried out with impulses from the KEY SWITCH.
•Two contacts are available for connection of 2 x 12 V batteries (NiMH)
•DIP-switch for monitoring of batteries is also available. Faulty battery will be indicated by the
LED on the CU-ESD. If selected the relay on EXU-SA can give a contact information. An audible
warning signal can be achieved by using the accessory board AIU. It is connected to the 24 VDC
and plugged into the EXU-SA relay output terminal.
•During POWER FAILURE MODE the operator will finish the actual operating cycle and then switch
of the battery supply. The battery powered operator can be reactivated to achieve a new oper-
ating cycle by an impulse on the KEY input.
•The operating mode during battery power can be changed from POWER SAVE to CONVENI-
ENCE,see page 62. During CONVENIENCE MODE the operator will work as normal until the
batteries are discharged. The batteries are rechargeable and will be charged by the control unit
in the operator. New, fully charged batteries can typically open and close a door max. 300 times
in convenience mode. In power save mode the operator can stand-by in up to 1 week, waiting
for KEY impulse.
5.4.7 Nurse and bed functionality
To make it possible to open the master door only in a double door, connect a 0/1 switch to the
slave operator EXU-SI board Kill impulse terminal 7 and 3.
5.5 Functions on the extension unit EXU-SA –optional
Also see page 53 for more information.
5.5.1 Presence impulse approach, door mounted
The presence impulse is active during fully open and closing. The sensor is mounted to the approach
side of the door. Once the door is closed, the sensor is ignored and will not be active until the next
impulse is received.
Note! When installed as a pair of doors, the presence impulse signal will re-open both doors. The
sensor is not active in program mode OFF, manually opened door or during battery operation
(Power Failure Mode).
5.5.2 Presence detection swingpath, door mounted
When a sensor that is mounted on the swing side of a door detects an object, it will send a command
to the control unit to stall the door. If the control unit has received a short signal from the sensor
and there is still hold open time left on the control unit, the door will continue on its way open if
the object has cleared.
The inhibit/blanking potentiometer can be adjusted so that the sensor will avoid detecting a wall
or object near the full open position. Presence detection has a higher priority than presence impulse.
Note! When installed as a pair of doors the presence detection signal will stop both doors, except
for double egress doors. The behavior for double egress doors can be changed (see page 62). The
sensor is not active in program mode OFF, manually opened door or during battery operation.
1005088-EMEI-11.0Issue 2014-11-2414
5 How the EM SW EMO works

5.5.3 Monitored safety sensors
Both presence impulse and presence detection can be monitored. If a sensor becomes defective,
the operator will not accept any impulses and will then work as a manual door closer.
5.5.4 Open door indication
A relay output is used to indicate an opening cycle or a specific position of the door. The indication
position is set by adjusting the inhibit/blanking potentiometer.
5.5.5 Error indication
A potential free contact COM/NO/NC for external error indication, see page 72.
15Issue 2014-11-241005088-EMEI-11.0
5 How the EM SW EMO works

6 Models
One main model with standard cover is available of the EM SW EMO.
The operator are non-handed and not dependent on the hinges. The operator suits both pushing
and pulling arm systems.
6.1 EM SW EMO, standard cover (wall mounted)
EM SW EMO is the standard operator. Pushing arm system shown. Measurement from hinge
centerline to outgoing shaft is always 210 mm regardless if butt or pivot hinged systems.
ILL-01608
716
40 210
1005088-EMEI-11.0Issue 2014-11-2416
6 Models

7 Part identification & Accessories
6
6
13
8
1
11
10
14
9
7
3
4
2
15
5
12
DescriptionArt. No.Item No.
Back plate10127531
Transmission unit/operator3310034982
Control unit CU-ESD3310035323
EXU-SI (Kit to extend the security functions) –optional331003554
EXU-SA (Kit to extend the safety functions) –optional331003557
Cable kit3310063404
Door stop body3310035405
Top end plate*6
Bottom end plate3310035437
Cover3310049988
Power ON/OFF switch3310035819
ON/OFF/HOLD open switch –optional331003582
Cable holder (50 pcs)*33100357810
Knockouts for cable inlet–11
Belt tension device–12
Fill cover (output shaft)*13
Battery backup unit –optional33100356714
Encoder cable33000023315
Sync cable –optional331003583–
* Included in Mounting Kit 331005081
17Issue 2014-11-241005088-EMEI-11.0
7 Part identification & Accessories

7.1 Arm system, PUSH
Art.No. 1003576BK
PUSH
This arm system is delivered with drive arm, telescopic part and door
fitting.
It is used if the operator is installed on the wall on the opposite side of
the door swing and approved for fire door applications.
7.1.1 PUSH-arm extensions
345 mm extension
Art. No. 173005
ExtensionReveal = A
None (standard arm)0-100 mm
345 mm100-210 mm
230 mm + Joint part210-300 mm
230 mm extension
Art. No. 173004
A
Joint part
Art. No. 173191
7.2 Arm system, PULL
Art. No. 1003577BK
PULL
This arm system is delivered with drive arm, guide shoe and door fitting.
It is used if the operator is installed on the wall on the same side as the
door swing.
7.3 Arm system, PULL-P
Art. No. 1005273BK
This arm system is delivered with drive arm, guide shoe and door fitting
with break-out unit.
It is used if the operator is installed on the wall on the same side as the
door swing and break-out unit is required.
1005088-EMEI-11.0Issue 2014-11-2418
7 Part identification & Accessories

7.4 Arm system, ST-V / ST-H
Art. No. ST-V 172313
ILL-01676
Art. No. ST-H 172315
This arm system is delivered with drive arm and guide roller.
Note! Door fitting not included.
It is used if the operator is installed on the wall on the same side
as the door swing and break-out unit is required.
7.4.1 Options for ST-V / ST-H
Door fitting standard
Art. No. 172071
Door fitting Break-out (pivot doors)
Art. No. 172325, right, reveal A = 0-60 mm or left when A > 60-100 mm
Art. No. 172327, right, reveal A > 60-100 mm or left when A = 0-60 mm
Arm extension
Art. No. 172320 required when the reveal A >60-100 mm
7.5 Reveal spacer: PULL / PULL-P
Art. No. PULL 173804BK
Art. No. PULL-P 173831BK
40 (1-9/16") 60 (2-3/8")
40 mm (1-9/16")
60 mm
(2-3/8")
19Issue 2014-11-241005088-EMEI-11.0
7 Part identification & Accessories

7.6 Drive shaft extension kits
20 mm
(3/4")
50 mm
(2")
70 mm
(2-3/4")
Art. No.
173109
Art. No.
173108
Art. No.
173107
7.7 Control switches
7.7.1 Power ON/OFF switch
P/N: 1003581
POWER
ON
OFF
White
Brown
Art. No. 1003581
7.7.2 ON/OFF/HOLD open switch (will not operate electric lock)
P/N: 1003582
FUNCTION
ON
OFF HOLD
White Brown
Green
Art. No. 1003582
ProgramFunction
Impulses from activation units connected to XIMP are forwarded into inner impulse
(see page 50).
ON
Impulses from activation units connected to XIMP are not forwarded into inner impulse.
These units cannot open the door.
OFF
The door is held permanently open.HOLD
1005088-EMEI-11.0Issue 2014-11-2420
7 Part identification & Accessories
