Entrematic PSL Retrofit Kit User manual

Sliding Door Operator
Entrematic PSL Retrofit Kit
Installation Manual
Original instructions
1018482-EMen-2.0 –Issue 2019-07-13

© All rights in and to this material are the sole property of Entrematic Group AB. Copying, scanning, alterations or modifications are
expressly forbidden without the prior written consent of Entrematic Group AB. Rights reserved for changes without prior notice.
Backtrack information: folder:Workspace Main, version:a546, Date:2019-07-13 time:03:00:15, state: Frozen

CONTENTS - Original instructions
51 Tools required ..........................................................................................................................................................................
62 Mechanical installation ........................................................................................................................................................
62.1 Entrematic PSL Retrofit Kit for universal bracket solutions ............................................................................................
62.1.1 Check the components and kits ..............................................................................................................................
142.1.2 I/O board and the battery installation (option) .................................................................................................
142.1.3 Fix the brackets to the backbone assembly .........................................................................................................
182.1.4 Fix the brackets to the tension wheel ....................................................................................................................
182.1.5 Fix the brackets to the belt lock (option) .............................................................................................................
192.1.6 Fix the transmission bracket to the connecting bracket .................................................................................
192.1.7 Attachment of slack reducer ....................................................................................................................................
202.1.8 General rules of the installation ..............................................................................................................................
212.1.9 List of the adapted door types .................................................................................................................................
232.1.10 Adapted door types .....................................................................................................................................................
232.1.10.1 ATS CLIXMASTER .......................................................................................................................................
242.1.10.2 ATS TSF 2100 ..............................................................................................................................................
252.1.10.3 Baumgartner Al-Profil .............................................................................................................................
262.1.10.4 Baumgartner steel ...................................................................................................................................
272.1.10.5 DORMA ES 50 ............................................................................................................................................
282.1.10.6 DORMA ES 55/60 ......................................................................................................................................
292.1.10.7 DORMA ES 70 ............................................................................................................................................
302.1.10.8 DORMA ES 90/100 ...................................................................................................................................
312.1.10.9 DORMA ES 200 ..........................................................................................................................................
322.1.10.10 ELDEBE GSX ................................................................................................................................................
332.1.10.11 EMD ...............................................................................................................................................................
342.1.10.12 EMC ...............................................................................................................................................................
352.1.10.13 Faiveley 6 .....................................................................................................................................................
362.1.10.14 Faiveley 12 ..................................................................................................................................................
372.1.10.15 Faiveley 17 ..................................................................................................................................................
382.1.10.16 GEZE ECdrive ..............................................................................................................................................
392.1.10.17 GEZE TSA 340 .............................................................................................................................................
402.1.10.18 GEZE TSA 350 N/350 W ..........................................................................................................................
412.1.10.19 GEZE TSA 360 .............................................................................................................................................
422.1.10.20 GEZE TSA 450 .............................................................................................................................................
432.1.10.21 Gilgen SLK/SLG ..........................................................................................................................................
442.1.10.22 Gilgen SLM/SLP ..........................................................................................................................................
452.1.10.23 HORTON Series 2001 ..............................................................................................................................
462.1.10.24 Manusa PA 80 ............................................................................................................................................
472.1.10.25 Manusa STK ................................................................................................................................................
482.1.10.26 Manusa Visio ..............................................................................................................................................
492.1.10.27 Portalp 2000B ............................................................................................................................................
502.1.10.28 Porte Automatiche GTS-L/-P .................................................................................................................
512.1.10.29 Porte Automatiche GTV .........................................................................................................................
522.1.10.30 Record STA7 ...............................................................................................................................................
532.1.10.31 Record STA8 ...............................................................................................................................................
542.1.10.32 Record STA9/STA10 .................................................................................................................................
552.1.10.33 Record STA11 ............................................................................................................................................
562.1.10.34 Record STA12/STA14 Steel ....................................................................................................................
572.1.10.35 Record STA12/STA14 AL .........................................................................................................................
582.1.10.36 Record STA13 ............................................................................................................................................
592.1.10.37 Record STA15 ............................................................................................................................................
602.1.10.38 Record STA16/17 ......................................................................................................................................
612.1.10.39 Record STA19 ............................................................................................................................................
622.1.10.40 Record STA20 ............................................................................................................................................
632.1.10.41 Record STA21 ............................................................................................................................................
642.1.10.42 Tormax TMP ................................................................................................................................................
652.1.10.43 Tormax TX/TM/TMX .................................................................................................................................
662.1.10.44 Tormax TEP/TXP ........................................................................................................................................
672.1.10.45 Waldoor EC .................................................................................................................................................
682.1.10.46 Waldoor UC ................................................................................................................................................
692.1.10.47 Waldoor UWS 800 ...................................................................................................................................
702.1.10.48 Waldoor UWS 2400 .................................................................................................................................
3Issue 2019-07-131018482-EMen-2.0

712.1.10.49 Ditec VALOR (escape route) .................................................................................................................
722.1.10.50 Ditec Bis O ..................................................................................................................................................
732.1.10.51 Ditec Bis V ...................................................................................................................................................
742.2 Entrematic PSL Retrofit Kit for TORMAX iMotion 2202 ...................................................................................................
742.2.1 Check the components ..............................................................................................................................................
752.2.2 Preparing .........................................................................................................................................................................
762.2.3 I/O board and the battery installation (option) .................................................................................................
772.2.4 Fix the nuts and screws on the drive unit kit and the main control assembly .........................................
812.2.5 Fix the drive unit kit and the main control assembly .......................................................................................
822.2.6 Fix the tension wheel assembly ...............................................................................................................................
832.2.7 Fix the transmission brackets ...................................................................................................................................
842.2.8 Placement of the transmission brackets ...............................................................................................................
852.2.9 Attachment of the tooth belt ...................................................................................................................................
862.2.10 Checking and adjusting the belt tension ..............................................................................................................
872.2.11 Bi-parting operators ....................................................................................................................................................
872.2.12 Attachment of slack reducer ....................................................................................................................................
882.2.13 Install the belt lock (option) .....................................................................................................................................
892.3 Entrematic PSL Retrofit Kit for GEZE Slimdrive ...................................................................................................................
892.3.1 Check the components ..............................................................................................................................................
902.3.2 Preparing .........................................................................................................................................................................
912.3.3 Exchange the extension beams ...............................................................................................................................
922.3.4 Fix the PSU (power supply unit) and drive unit kit ............................................................................................
952.3.5 Fix the mounting plate and MCU (control unit) ................................................................................................
962.3.6 I/O board and the battery installation (option) .................................................................................................
972.3.7 Fix the tension wheel assembly ...............................................................................................................................
982.3.8 Fix the transmission brackets ...................................................................................................................................
992.3.9 Placement of the transmission brackets ...............................................................................................................
1002.3.10 Attachment of the tooth belt ...................................................................................................................................
1012.3.11 Checking and adjusting the belt tension ..............................................................................................................
1022.3.12 Bi-parting operators ....................................................................................................................................................
1022.3.13 Attachment of slack reducer ....................................................................................................................................
1032.3.14 Install the belt lock (option) .....................................................................................................................................
1042.3.15 Fix the cable bracket ....................................................................................................................................................
1052.4 Entrematic PSL Retrofit Kit for Entrematic EMSL .................................................................................................................
1052.4.1 Check the components ..............................................................................................................................................
1062.4.2 Preparing .........................................................................................................................................................................
1072.4.3 Fix the backbone assembly ........................................................................................................................................
1082.4.4 Fix the I/O board and the battery (option) ..........................................................................................................
1102.4.5 Fix the tension wheel assembly ...............................................................................................................................
1112.4.6 Fix the connector brackets ........................................................................................................................................
1122.4.7 Placement of the transmission brackets ...............................................................................................................
1132.4.8 Attachment of the tooth belt ...................................................................................................................................
1142.4.9 Checking and adjusting the belt tension ..............................................................................................................
1152.4.10 Bi-parting operators ....................................................................................................................................................
1152.4.11 Attachment of slack reducer ....................................................................................................................................
1162.5 Entrematic PSL Retrofit Kit for Entrematic EMSL-T .............................................................................................................
1162.5.1 Check the components ..............................................................................................................................................
1172.5.2 Preparing .........................................................................................................................................................................
1182.5.3 Fix the backbone assembly ........................................................................................................................................
1192.5.4 Fix the I/O board and the battery (option) ..........................................................................................................
1202.5.5 Fix the tension wheel assembly ...............................................................................................................................
1212.5.6 Fix the connector brackets (for fast door leaves) ..............................................................................................
1222.5.7 Placement of the transmission brackets (for fast door leaves) .....................................................................
1232.5.8 Attachment of the tooth belt (for fast door leaves) .........................................................................................
1242.5.9 Checking and adjusting the belt tension (for fast door leaves) ....................................................................
1252.5.10 Bi-parting operators (for fast door leaves) ..........................................................................................................
1252.5.11 Attachment of slack reducer ....................................................................................................................................
1018482-EMen-2.0Issue 2019-07-134

1 Tools required
•Allen key 6 mm with spherical tip
•Torx (T10 and T20)
•Phillips screw driver
•Multi/Wire cutter
•Spanner 10mm
•Tape measuring tool
5Issue 2019-07-131018482-EMen-2.0
1 Tools required

2 Mechanical installation
2.1 Entrematic PSL Retrofit Kit for universal bracket solutions
Note! Following are the common steps for connecting components, please refer to cross-view for
each adapted door type.
2.1.1 Check the components and kits
Check the components (Universal)
Screw: ISO 14583 (MRT-TT) M6x10 FZB 8.84
Screw: DIN 6921 (M6SF) M6x8 FZB 8.811
Backbone assembly12
Slack reducer (Not needed if belt lock
equipped)
13
Washer: ISO 7089 (BRB) 6.4x12x1.5 FZB14
Tension wheel assembly15
Tooth belt18
Belt clamp20
Connecting bracket24
Transmission bracket26
Mounting bracket28
1018482-EMen-2.0Issue 2019-07-136
2 Mechanical installation

Check B1 kit
Washer: ISO 7089 (BRB) 6.4x12x1.5 FZB14
Bracket 125
Mounting plate27
Square nut: M629
Nut: M630
Nut: ISO 4035 (ML6M) M6 FZB31
Screw: DIN 6921 (M6SF) M6x12 FZB 8.832
Screw: DIN 6921 (M6SF) M6x14 FZB 8.833
Screw: DIN 6921 (M6SF) M6x16 FZB 8.834
Screw: ISO 14583 (MRT-TT) M6x16 FZB 8.835
Screw: ISO 14583 (MRT-TT) M6x20 FZB 8.836
Screw: ISO 14583 (MRT-TT) M6x25 FZB 8.837
Screw: ISO 14583 (MRT-TT) M6x35 FZB 8.838
7Issue 2019-07-131018482-EMen-2.0
2 Mechanical installation

Check B2 kit
Washer: ISO 7089 (BRB) 6.4x12x1.5 FZB14
Bracket 125
Mounting plate27
Screw: DIN 6921 (M6SF) M6x12 FZB 8.832
Screw: DIN 6921 (M6SF) M6x14 FZB 8.833
Screw: DIN 6921 (M6SF) M6x16 FZB 8.834
Screw: ISO 14583 (MRT-TT) M6x16 FZB 8.835
Bracket 240
1018482-EMen-2.0Issue 2019-07-138
2 Mechanical installation

Check B3 kit
Washer: ISO 7089 (BRB) 6.4x12x1.5 FZB14
Mounting plate27
Square nut: M629
Screw: DIN 6921 (M6SF) M6x14 FZB 8.833
Screw: ISO 14583 (MRT-TT) M6x16 FZB 8.835
Screw: ISO 14583 (MRT-TT) M6x35 FZB 8.838
Bracket 341
Spacer block42
Screw: DIN 6921 (M6SF) M6x10 FZB 8.843
9Issue 2019-07-131018482-EMen-2.0
2 Mechanical installation

Check B4 kit
Washer: ISO 7089 (BRB) 6.4x12x1.5 FZB14
Bracket 125
Screw: DIN 6921 (M6SF) M6x12 FZB 8.832
Screw: DIN 6921 (M6SF) M6x14 FZB 8.833
Screw: ISO 14583 (MRT-TT) M6x16 FZB 8.835
Screw: ISO 14583 (MRT-TT) M6x20 FZB 8.836
Screw: DIN 6921 (M6SF) M6x10 FZB 8.843
Bracket 444
Bracket 545
Nut: M646
1018482-EMen-2.0Issue 2019-07-1310
2 Mechanical installation

Check belt lock fixing bracket kit 1
Screw: ISO 14583 (MRT-TT) M6x10 FZB 8.84
Screw: DIN 6921 (M6SF) M6x8 FZB 8.811
Washer: ISO 7089 (BRB) 6.4x12x1.5 FZB14
Mounting plate27
Square nut: M629
Nut30
Nut: ISO 4035 (ML6M) M6 FZB31
Screw: DIN 6921 (M6SF) M6x12 FZB 8.832
Screw: DIN 6921 (M6SF) M6x14 FZB 8.833
Screw: DIN 6921 (M6SF) M6x16 FZB 8.834
Fixing bracket47
Mounting bracket48
11Issue 2019-07-131018482-EMen-2.0
2 Mechanical installation

Check belt lock fixing bracket kit 2
Screw: ISO 14583 (MRT-TT) M6x10 FZB 8.84
Screw: DIN 6921 (M6SF) M6x8 FZB 8.811
Washer: ISO 7089 (BRB) 6.4x12x1.5 FZB14
Screw: DIN 6921 (M6SF) M6x14 FZB 8.833
Screw: DIN 6921 (M6SF) M6x16 FZB 8.834
Bracket 240
Screw: DIN 6921 (M6SF) M6x10 FZB 8.843
Bracket 444
Bracket 545
Nut: M646
Fixing bracket47
Mounting bracket48
1018482-EMen-2.0Issue 2019-07-1312
2 Mechanical installation

Nut: M535
Screw: ISO 14583 (MRT) M5x10 FZB 8.836
Screw: ISO 7046 (MFTS) M3x5 FZB 8.829
Belt guide30
Fixing bracket (belt lock) TORMAX iMotion
2202
55
Screw: DIN 6921 (M6SF) M6x10 FZB 8.812
Square nut: M637
Fixing bracket (belt lock) GEZE Slimdrive56
13Issue 2019-07-131018482-EMen-2.0
2 Mechanical installation

2.1.2 I/O board and the battery installation (option)
Note! I/O board must be selected when bi-stable.
Fix the I/O board (7) and the battery (8) to the backbone assembly (12) with the screws (9) and
(10).
I/O board7
Battery8
Screw: ISO 14583 (MRT) M4x69
Screw: ISO 14583 (MRT-TT) M4x6010
Backbone assembly12
2.1.3 Fix the brackets to the backbone assembly
Note! The brackets in the picture is only an example, please choose the suitable brackets for the
specified operator that shall be upgraded.
1018482-EMen-2.0Issue 2019-07-1314
2 Mechanical installation

a How to install the mounting plate. Please refer to the dimension on the surface of plate (27)
firstly.
Mounting plate27
15Issue 2019-07-131018482-EMen-2.0
2 Mechanical installation

bAssemble the mounting plate (27) and mounting bracket (28) with the washers (14) and screws
(4).
Screw: ISO 14583 (MRT-TT) M6x10 FZB 8.84
Washer: ISO 7089 (BRB) 6.4x12x1.5 FZB14
Mounting plate27
Mounting bracket28
c Fix two screws (11) to the backbone assembly (12), don't tighten the screws (11).
Screw: DIN 6921 (M6SF) M6x8 FZB 8.811
Backbone assembly12
1018482-EMen-2.0Issue 2019-07-1316
2 Mechanical installation

d Fix the brackets to the backbone assembly (12), then tighten the screws (11) with a torque of
8 - 10 Nm.
Screw: DIN 6921 (M6SF) M6x8 FZB 8.811
Backbone assembly12
17Issue 2019-07-131018482-EMen-2.0
2 Mechanical installation

2.1.4 Fix the brackets to the tension wheel
Fix the brackets to the tension wheel assembly (15) in the same way as 2.1.3 .
Screw: DIN 6921 (M6SF) M6x8 FZB 8.811
Tension wheel assembly15
2.1.5 Fix the brackets to the belt lock (option)
Fix the brackets to the belt lock (39) in the same way as 2.1.3.
Screw: DIN 6921 (M6SF) M6x8 FZB 8.811
Belt lock39
1018482-EMen-2.0Issue 2019-07-1318
2 Mechanical installation

2.1.6 Fix the transmission bracket to the connecting bracket
a Fix the transmission bracket (26) to the connecting bracket (24) with the screws (4) and
washers (14).
Screw: ISO 14583 (MRT-TT) M6x10 FZB 8.84
Washer: ISO 7089 (BRB) 6.4x12x1.5 FZB14
Connecting bracket24
Transmission bracket26
2.1.7 Attachment of slack reducer
Please refer to PSL150 Installation and Service Manual (1016248).
19Issue 2019-07-131018482-EMen-2.0
2 Mechanical installation

2.1.8 General rules of the installation
Position of the belt connecting to the transmission brackets.
Bi-parting opening
The transmission bracket (16) on the left door leaf shall be connected to the upper belt.
The transmission bracket (16) on the right door leaf shall be connected to the lower belt.
Transmission bracket16
Single left opening
The transmission bracket (16) shall be connected to the upper belt.
Transmission bracket16
Single right opening
The transmission bracket (16) shall be connected to the lower belt.
Transmission bracket16
1018482-EMen-2.0Issue 2019-07-1320
2 Mechanical installation
