Enwork Sensation Flip Table User manual

Sensation Flip Table Installation Instructions
Rev 1117

Installation Instructions
Tables Flipping DownTables Flipping Up
System Installation
Leg Installation
1. Match orientation and position to enclosed diagram
for each style of table leg and attach each leg with
(4) four ¼”–20 Pan Head Machine Screws.
*FAILURE TO USE ALL SCREWS PROVIDED MAY
VOID PRODUCT WARRANTY
*Optional Beam Shown
*Please note Leg Orientation as it
relates to the position of the handle
and each respective mechanism.
*Please note Leg Orientation as it
relates to the position of the handle
and each respective mechanism.
*Optional Beam Shown
1. Place work surface bottom side up on a non-
marring surface.
2. Align holes on mounting plates with pre-drilled
holes on bottom side of work surface. Fasten each
mounting plate to work surface using the (4) four
corner holes with #12 x 1” Phillips Pan Head screws.
3. Align holes on handle base with pre-drilled holes on
bottom side of work surface. Fasten handle base to
work surface with (4) four #12 x 1” Phillips Pan Head
screws.
4. Position cable clips evenly along the cable and
fasten to bottom side of work surface with #6 x ½”
Phillips Pan Head screws.
5. Use handle assembly to release the mechanisms
and lock the mechanisms in the upright position.
6. Critical Step: Complete installation of the system by
fastening each mounting plate to work surface using
the (4) four interiorholes with #12 x 1” Phillips
Pan Head screws.
7. Install NWBRACE as shown on tops 60”W and wider.
8. Use handle assembly to release the mechanisms
and return the mechanisms to lowered position.
NWBRACE:
52” Support Brace
NWBRACE:
52” Support Brace
