Enwork IMPRESSION FLIP TABLE User manual

Impression Flip Table Installation Guide Rev B - 12/16/19
IMPRESSION FLIP TABLE
INSTALLATION GUIDE
OPEN PLAN / BENCHING
TI0025

INSTALLATION GUIDE
1) PARTS AND FASTENERS INCLUDED
2) TOOLS AND SUPPLIES REQUIRED
Leg Column (LCRSxxx)
Drill/Driver
#10 x 1.00” Wood Screw
QTY: 8
Worksurface (CRFxxxx)
5mm Hex Bit
M8-1.25 x 70mm
QTY: 2
Frame Sub Assembly (RZNTxxxx)
#2 Phillips Bit
(#2 Square Bit Optional)
M8-1.25 x 55mm
QTY: 2
Cap Cover
QTY: 8

INSTALLATION GUIDE
3) ASSEMBLY
• Locate Leg Column, Frame and M8 x 70mm and M8 x
55mm Flat head bolts included in the hardware pack.
• Slide the beam of the Frame onto the Leg Column.
• Line up the clearance holes in the beam with the tapped
holes in the Leg Column.
• Connect the legs to the frame using the M8 x 70mm and
M8 x 55mm Flat head bolts. Verify that the M8 x 70mm
bolt is used on the hole closest to the end of the beam.
• Repeat for the second leg.
• Lay the Worksurface face down on a non-marring surface.
• Place the Frame and Leg Assembly on the Worksurface,
locating it evenly spaced from the all sides of the table.
• Line up the holes in the Frame Assembly with the pre-
drilled holes in the worksurface and attach using the
included wood screws.
• Insert the included Cap Covers into the holes in the Frame
Assembly to cover the screws.
FIGURE 1
FIGURE 2
FIGURE 3

INSTALLATION GUIDE
4) COMPLETED TABLE
• Ensuring that the casters are locked, ip the table into the upright position.
• Using two hands, grab the release handle and verify that the ip mechanism functions properly.
FIGURE 4

Specications subject to change without notice.
Rev 01.2020
1.800.815.7251
www.enwork.com
12900 Christopher Dr. Lowell, MI 49331
