Enwork eBench Table User manual

eBench Table Installation Instructions – Rev B. 12.17.19
eBENCH TABLE
INSTALLATION GUIDE
OPEN PLAN BENCHING
EI0004

INSTALLATION GUIDE
1) PARTS AND FASTENERS INCLUDED
EBE EBC
EBM-1327
EBF3
M8-1.25 x 45mm Flatbold Head
EBD
EBF1
EBF9A
10 x 1.5” Panhead Phillips
EBSL
EBF2
M8-1.25 x 40mm Socket
Head
Tight Joint

INSTALLATION GUIDE
2) TOOLS AND SUPPLIES REQUIRED
3) ASSEMBLY: SINGLE SIDED EBENCH
Screwdriver
1 Bar eBench Table:
EBZ4848 / EBZ4860 / EBZ4872
EBZ6048 / EBZ6060 / EBZ6072
2 Bar eBench Table:
EBZ4896 / EBZ48120 / EBZ481442
EBZ6096 / EBZ60120 / EBZ6481442
Allen Driver BitsPhillips Driver Bit
FIGURE 1
FIGURE 2

INSTALLATION GUIDE
3) ASSEMBLY: CONT. 1
3 Bar eBench Table:
EBZ481443 / EBZ48156 / EBZ48180 /
EBZ48192 / EBZ48204 / EBZ48216
EBZ601443 / EBZ60156 / EBZ60180 /
EBZ60192 / EBZ60204 / EBZ60216
4 Bar eBench Table:
EBZ482404
EBZ602404
5 Bar eBench Table:
EBZ482405
EBZ602405
FIGURE 3
FIGURE 4
FIGURE 5

INSTALLATION GUIDE
3) ASSEMBLY: CONT. 2
EBC LENGTHS
FIGURE 6
FIGURE 7
FIGURE 9
FIGURE 8
FIGURE 10
Attach EBF1 to all the EBC ends.
Connect crossbar to EBE using 1 EBF1, EBF2, and a Sockethead bolt.
Repeat for all crossbars
Note: Connection to run mid leg shown in Figure 10 is the same as
shown in Figure 11.
Connect 2 EBD to 2 EBSL using the Flathead bolts.
Note: Holes on the sides of EBD face outward.
The countersunk holes on EBD must face up.
Remove backer from disks on the EBC crossbar and attach the
plastic disk EBF9A to the adhesive.
Place one EBF9A at all sticker locations.

INSTALLATION GUIDE
3) ASSEMBLY: CONT. 3
Attach top surface using 2 Panhead
Screws through all the EBF3 blocks.
Surface is centered all around base.
Leg cover EBM-1327 magnetically
attaches to the mid run legs for power
cord concealment.
FIGURE 11
FIGURE 12

Specications subject to change without notice.
Rev 02.2020
1.800.815.7251
www.enwork.com
12900 Christopher Dr. Lowell, MI 49331
