Enwork Foundation User manual

Foundation
Tapered Drum Base
Installation Guide
TI0085 - Foundation Tapered Drum Base Installation Guide – Rev 01.24.24

2TI0085 - Foundation Tapered Drum Base Installation Guide
1/2" SOCKET ADJUSTABLE WRENCH
LEVEL
TOOLS & SUPPLIES REQUIRED
DRILL SQUARE HEAD DRIVER RATCHET

3TI0085 - Foundation Tapered Drum Base Installation Guide
INCLUDED PARTS & FASTENERS
BASE5/16-18 SERRATED HEX NUT
WORKSURFACE SANDBAGSTOP PLATE
#10 X 1" PHILLIPS PAN HEAD5/16-18 X 1-1/4" HEX HEAD
SERRATED FLANGE BOLT

4TI0085 - Foundation Tapered Drum Base Installation Guide
1 — ASSEMBLY
FIG 1.1 (POSITION BASE & LEVEL)
Position the base in the desired location. Check levelness and adjust
base levelers if necessary.
FIG 1.3 (TOP PLATE ATTACHMENT)
Attach the top plate to the base using 5/16-18 x 1-1/4" Hex Head Serrated
Flange Bolts and 5/16-18 Serrated Hex Nuts.
FIG 1.4 (WORKSURFACE ATTACHMENT)
Place the worksurface on the base. Make sure to align the worksurface
pockets with the ribs located in the top plate. Use #10 X 1" Phillips Pan Head
screws to secure the connection.
FIG 1.2 (SANDBAG WEIGHT PLACEMENT)
Insert 2x sandbags into the base. Position sandbags at opposite ends for
stability.
Note: For smaller bases, sandbags may need to be inserted from the
underside of the base.
