Zori Conference Table Installation
ZORI CONFERENCE TABLES
INSTALLATION GUIDE
CONFERENCE TABLES
ZI0009 / CYYDXXX

2
INSTALLATION GUIDE
1) PARTS AND FASTENERS INCLUDED
2) TOOLS AND SUPPLIES REQUIRED
5/16 - 18 x 1.25 Bolts
Footbars (2 Lengths)
Zori Feet
5/16 - 18 Locknuts
5/16 - 18 x 7/8 Bolts
Zori Columns
¹/2“ Racheting Wrench

3
INSTALLATION GUIDE
3) ASSEMBLY OVERVIEW:
FIGURE 1 ZORI CORNER LEG
FEET ATTACHMENT
FIGURE 2 ZORI CENTER LEG
FEET ATTACHMENT
FIGURE 3 ZORI END FOOTBAR
1. Center Legs on the table are square. There are four legs
that are not square, these go at the corners of the table.
2. If the feet have not been assembled, attach them to the
Corner Legs in the orientation in Figure #1. You will need
the 5/16-18 x 1.25 Bolts and 5/16-18 Locknuts.
3. The Center Leg feet are attached as seen in Figure #2.
Tables shorter than 108” long will not use Center Legs.
4. Once the feet are attached the footbars must be
assembled. All the footbars use the 5/16-18 x 7/8 Bolts.
5. Start by attaching the shorter footbar between the Corner Legs.
Figure #3. You will need to do this twice to make both ends.

4
INSTALLATION GUIDE
3) ASSEMBLY OVERVIEW CONT:
FIGURE 4 FOOTBARS ATTACHED
FIGURE 5
FIGURE 6
6. Once both ends have been assembled the longer
footbars can be used to tie the two ends together.
Start by attaching the footbars to one Corner Leg pair.
The result can be seen in Figure #4.
7. Next, attach the Center Legs, as seen in Figure #5, or for
tables shorter than 108”, skip to step 8.
8. Finally, attach the second Corner Leg pair to complete
the table. Figure #6.

Specications subject to change without notice.
Rev 02.2020
