User Guide
Analog Telephones
Analog and Ericsson Basic/Medium telephones
for BusinessPhone 250 and BusinessPhone 50

BusinessPhone - Analog Telephone
Welcome
Welcome to the User Guide for the Ericsson Analog Basic,
Medium and the ordinary Analog phone in the BusinessPhone
250 and BusinessPhone 50 system from Ericsson.
It is a state-of-the-art business communications system.
Its alliance of features and facilities effectively improves
communications for virtually any kind of organization.
To take full advantage of these advanced features and facilities
there is a line of phones, designed for ease of use in every
situation, e.g. the Ericsson Dialog 3105 Basic and 3145 Medium
analog telephones are very versatile and adaptable phones.
Note: The features described in this user guide are
related to version 5.0 of the BusinessPhone 250 and
BusinessPhone 50 system. Some might not work in
earlier versions of the system and/or might be protected by
a hardware dongle that has to be bought separately.
This guide will demonstrate how the Analog phone helps you access the
functions of the BusinessPhone 250 and BusinessPhone 50 system.
Important
The BusinessPhone 250 and BusinessPhone 50 system supports
all types of analog telephones, but some features require that an
Ericsson Basic or Medium analog telephone is connected to the
system.
Throughout the guide you will be advised if a function is adapted
for a particular telephone or not.
Note: Since the Ericsson Basic and Medium analog
telephones easily can be switched between pulse and
tone dialling they can be connected to all types of
telephone exchanges, but remember that analog
telephones must be connected to analog lines.
ERICSSON MAKES NO WARRANTY OF ANY KIND WITH
REGARD TO THIS MATERIAL, INCLUDING, BUT NOT LIMITED
TO, THE IMPLIED WARRANTIES OF MERCHANTABILITY AND
FITNESS FOR A PARTICULAR PURPOSE. Ericsson shall not be
liable for errors contained herein nor for incidental or consequential
damages in connection with the furnishing, performance or use of
this material.

Quick Reference Guide and Quick Reference Card
Analog Telephones
Analog and Ericsson Basic/Medium telephones for BusinessPhone 250 and BusinessPhone 50
Answer calls
Answer: Lift handset
Answer on another
extension: Lift handset Ext. No. 6
Make calls
Internal calls: Lift handset Ext. No.
External calls: Lift handset 0
External No.
Common
abbreviated number: Lift handset Abbreviated No.
Individual
abbreviated number: Lift handset **
Abbreviated no. 0-9
Last external
number redial: Lift handset ***
You get busy tone or no answer
Automatic call-back: 5Replace handset
Lift handset when called back
Camp on: 4Keep handset off hook
Intrusion: 8
Conference
Ongoing
conversation: Call 3rd party
(To establish)
Replace handset (To leave)
Inquiry
Ongoing
conversation: Call 3rd party
Refer back
Switch between calls: 2
To terminate: 1
Transfer
Transfer a call: Call 3rd party
Replace handset
(Before or after answer)
Tandem configuration
Activate: Lift handset *28#
Replace handset
Deactivate: Lift handset #28#
Replace handset
Transfer a call
between members: Own directory No.
Replace handset
Reminder
Reminder (24 hours): Lift handset *32*
Reminder time #
Cancel reminder: Lift handset #32#
Password
DISA and Message check:
Company number
DISA Number Message system

Quick Reference Guide and Quick Reference Card - Analog Telephones
This is a part of EN/LZTBS 102 003 R5B. Subject to alteration without prior notice.
Project name Account number
Special account numbers for business calls:
1
2
3
4
This is a part of EN/LZTBS 102 003 R5B
Account number
Costs on a selected
account no.: Lift handset *9*
Account number #
Call forwarding
Fixed diversion: Lift handset *21#
Internal diversion: Lift handset *21*
New No. #
Cancel internal
diversion: Lift handset #21#
Follow me, re-direct
from answering
extension: Lift handset *21*
Own No. *New No. #
Cancel from
answering
extension: Lift handset #21*
Own No. #
Bypass call
forwarding: Lift handset *60*
Ext. No. #
External diversion:
Program: Lift handset *22*
Line access code
External No. #
Cancel: Lift handset #22#
Re-activate: Lift handset *22*#
Messages
”Call me”: 9#
Voice: 99 Speak
Play-back: *
Re-record: 9Speak
Send: #
Receive messages: Lift handset *59#
Information
Enter information
(pre-text): Lift handset *23*
Enter ”Info code” and
”Completing info” (see below)
#
Info code Completing info
Time of return 1. hour (00-23) minute (00-59)
Date of return 2. month (01-12) day (01-31)
Lunch 3. back at, hour minute
Meeting 4. back at, hour minute
Vacation 5. back, month day
Illness 6. back, month day
Individual abbreviated numbers
**0................................................
**1................................................
**2................................................
**3................................................
**4................................................
**5................................................
**6................................................
**7................................................
**8................................................
**9................................................

5
Table of Contents
BusinessPhone - Analog Telephone
Table of Contents
page
Description - Ericsson Basic Telephone..............6
Description - Ericsson Medium Telephone..........8
Incoming Calls ................................................10
Outgoing Calls ................................................12
During Calls ....................................................16
Call Forwarding ..............................................20
Information ......................................................26
Internal Messages ..........................................29
Mailbox System ..............................................32
Abbreviated Numbers ......................................34
Group Facilities ................................................38
Other Useful Facilities ......................................41
Security ..........................................................46
Least Cost Routing ........................................49
Audible Adjustments ........................................50
Tones and Signals ..........................................53
Glossary ..........................................................55
Installation ......................................................57
Troubleshooting ..............................................60
Useful Hints ....................................................61
Index ................................................................62
Designation Card Manager and Voice Guide ....65
EN/LZTBS 102 003 R5B
© Ericsson Austria AG 2001
All rights reserved. No parts of this publication may be reproduced,
stored in retrieval system, or transmitted in any form
or by any means, electronic, mechanical, photocopying,
recording or otherwise, without prior written permission of the publisher.

6
Description - Ericsson Basic Telephone
BusinessPhone - Analog Telephone
Description -
Ericsson Basic Telephone
ABC DEF
GHI JKL MNO
PQRS TUV WXYZ
Tone Redial
Prog R
1
2
3
45
12 8
7
6
11
9
10
(bottom side)

7
Description - Ericsson Basic Telephone
BusinessPhone - Analog Telephone
1 Mute
To switch the microphone on or off. See section ”During calls”.
2 Tone
Temporary change to tone dialling.
3 Last number redial / Pause key
a. Redial last number dialled.
b. Insert a pause if you have to wait for dial tone.
4 R-key
Used for example to make an inquiry, to transfer a call or to
establish a conference, see section ”During calls”. Can be set to
two different modes, see section ”Audible adjustments”.
5 Program quick dial number
Store your most frequently called number, see section
“Abbreviated numbers”.
Note: If you unplug the telephone, the stored number will
remain for about 4 hours.
6 Handset volume
Adjust handset volume. See section ”Audible adjustments”.
7 Ringing signal volume
Adjust ringing signal volume. See section ”Audible adjustments”.
8 Ringing signal character
Adjust ringing signal character. See section ”Audible adjustments”.
9 Tone / Pulse dialling
Switch between tone or pulse dialling. See section ”Audible
adjustments”.
10 Flash / Earth mode
Switch between “flash” (timed break) or “earth” mode for the
R-key. See section ”Audible adjustments”.
11 Loudspeaker
12 Handset with hearing aid function
See section ”Audible adjustments”.
Please note: The handset may retain small metal
objects in the earcap region.

8
Description - Ericsson Medium Telephone
BusinessPhone - Analog Telephone
Description -
Ericsson Medium Telephone
1 Mute
To switch the microphone on or off. See section ”During calls”.
2 Tone
Temporary change to tone dialling.
Program
Message
waiting
ABC DEF
GHI JKL MNO
PQRS TUV WXYZ
Tone Redial
R
Line
123
45
16
11
10
9
15
6
7
(bottom side)
8
12
13
14

9
Description - Ericsson Medium Telephone
BusinessPhone - Analog Telephone
3 Last number redial / Pause key
a. Redial last number dialled.
b. Insert a pause if you have to wait for dial tone.
4 R-key
Used for example to make an inquiry, to transfer a call or to
establish a conference, see section ”During calls”. Can be set to
two different modes, see section ”Audible adjustments”.
5 Loudspeaker on/off
To switch the loudspeaker on or off. See section ”During calls”.
6 Program
Storing numbers. See section “Abbreviated numbers”.
7 Programmable keys
Nine keys for storing frequently called numbers. You can store
one number per key, see section “Abbreviated numbers”.
Note: If you unplug the telephone, stored numbers will
remain for about 4 hours.
8 Message waiting LED (optional)
A flashing light indicates a waiting message. See section “Internal
messages”.
9 Handset volume
Adjust handset volume. See section ”Audible adjustments”.
10 Ringing signal volume
Adjust ringing signal volume. See section ”Audible adjustments”.
11 Speaker volume
Adjust speaker volume. See section ”Audible adjustments”.
12 Tone / Pulse dialling
Switch between tone or pulse dialling. See section ”Audible adjustments”.
13 Flash / Earth mode
Switch between “flash” (timed break) or “earth” mode for the
R-key. See section ”Audible adjustments”.
14 Ringing signal character
Adjust ringing signal character. See section ”Audible adjustments”.
15 Loudspeaker
16 Handset with hearing aid function
See section ”Audible adjustments”.
Please note: The handset may retain small metal
objects in the earcap region.

10
Incoming Calls
BusinessPhone - Analog Telephone
Incoming Calls
A ringing signal indicates an incoming internal- or external call.
Answer calls
Lift the handset
On another extension
You can answer a call to another extension from any phone in
your office.
Lift the handset and call the ringing extension
You receive busy tone.
6Press

11
Incoming Calls
BusinessPhone - Analog Telephone
Answer a second call
A call waiting tone will inform you, during a conversation, that a
second call is waiting on your phone. (See also Camp on).
You have two options.
Option 1:
Finish the ongoing call:
Replace the handset
The new call will be signalled on your phone.
Lift the handset to receive the new call
Option 2:
Ask your conversation partner to wait:
Press and replace the handset
The waiting call will be signalled on your phone.
Lift the handset to receive the new call
After finishing the new call:
Replace the handset
Your first call will be signalled on your phone.
Lift the handset to receive the first call again

12
Outgoing Calls
BusinessPhone - Analog Telephone
Outgoing Calls
Sometimes you make a call but the person is not available.
These functions will help you in your attempts to establish
contact with the called party.
Make calls
How to make internal and external calls.
Lift the handset and dial either:
An extension number to make an internal call,
or
0The digit(s) for external call access and the external number
Note: Which digit to press for external call access,
depends on the configuration of the system.
Replace the handset to end the call
Note: You can make your calls faster, using common
abbreviated numbers and by programming your own
abbreviated numbers.

13
Outgoing Calls
BusinessPhone - Analog Telephone
Wait for dial tone
Sometimes it is required to wait for a new dialling tone after dialling
the prefix digit when making an external call. In such situations, you
must store the pause for a new dial tone into the number:
On the Ericsson Basic and Medium telephone:
Press
Note: This function is not supported for other analog
telephones.
Last external number redial
When you initiate an external call the system automatically stores
all the dialled digits, irrespective of whether the call was successful
or not. Stored numbers can consist of maximum 32 digits.
Note: To redial a number that incorporates a wait for a
new dial tone, you must indicate to the telephone where
in the number it must pause and wait for the new dial
tone. To do this, press the required key at the proper
place in the number. See section “Make calls”.
On the Ericsson Basic and Medium telephone:
Lift the handset
Press to redial the last dialled external number
On other analog telephones:
Lift the handset
*** Press to redial the last dialled external number
Redial
Redial

14
Outgoing Calls
BusinessPhone - Analog Telephone
Automatic call-back
You call an extension and receive busy tone or get no answer.
This can also be used if no external line is free:
5Press
Verification tone.
Replace the handset
You are called back if the extension finishes the ongoing call or the
next time the extension finishes a new call. You have to answer
within eight seconds otherwise the call-back service is cancelled.
Lift the handset when you are called back
The requested extension is called automatically.

15
Outgoing Calls
BusinessPhone - Analog Telephone
Busy extension
You call an extension and receive busy tone.
Camp-on
You can notify a busy extension of your call by a muted ringing
call (if this function is allowed).
4Press to camp on
(Keep handset off hook) When the called extension replaces the
handset it will be called automatically.
Note: If you receive the busy tone again, the desired
extension does not allow camp-on.
Intrusion
You can intrude on an ongoing call on a busy extension
(if this function is allowed).
8Press to intrude
Intrusion tone is heard and a three-party call is established.
When the called extension replaces the handset and you keep off
hook, the called extension will be recalled automatically.
Note: If you still hear the busy tone, then your extension
does not have the authority to intrude or the desired
extension is protected against intrusion.

16
During Calls
BusinessPhone - Analog Telephone
During Calls
The BusinessPhone 250 and BusinessPhone 50 system allows
you to handle calls in many different ways. You can for instance
make an inquiry, transfer the call or create a conference.
Monitoring
Note: This section only applies to the Ericsson Medium
telephone.
You have an ongoing conversation via the handset.
Press to switch the loudspeaker on
Replace the handset
The loudspeaker monitors the call.
Note: When the loudspeaker is on, the microphone is
automatically switched off in the handset. You can adjust
the volume, see section ”Audible adjustments”.
From monitoring to handset
Lift the handset
Continue your conversation via the handset.

17
During Calls
BusinessPhone - Analog Telephone
Mute
Note: This section only applies to the Ericsson Basic and
Medium telephone.
You have an ongoing conversation.
Press to switch the microphone on or off
When the lamp lights, the caller will not be able to hear the
conversation in your room.
Inquiry
During an ongoing conversation you like to make an inquiry to an
internal or external party.
Press
The first call is put on hold.
Call the third party
When the third party answers you can switch between the calls,
create a conference and end one of the calls.
Refer back
You can switch between connected parties:
2Switch between calls
1Press to terminate
The ongoing call is terminated. The other call is connected.
Note: Sometimes the ”R”-key must be pressed twice. If
no speech connection could be established, it may take
a few seconds until you are re-connected to the original
call. Whether you can put internal calls on hold or transfer
calls to external lines depends on the configuration of your
PBX. Consult your system administrator.

18
During Calls
BusinessPhone - Analog Telephone
Transfer
You have an ongoing internal or external conversation and you
want to transfer the ongoing call.
Press
Call the third party
You can transfer the call before answer or wait for answer
Note: Make sure, that you are connected to the desired
party. Please read the notes and warnings in section
”Useful hints”.
Replace the handset
The call is transferred.
Transfer to a busy extension
You can even transfer calls to busy extensions. The other party
will hear a muted signal (camp-on), and the call will be extended,
as soon as the ongoing call is terminated (if camp-on is allowed).
Call-back
You are called back, if you have transferred an external call and
the other extension has not answered the call within a certain
time. Your telephone will ring again.

19
During Calls
BusinessPhone - Analog Telephone
Conference
You have an ongoing conversation and you want to establish a
telephone conference.
Press
Call the third party
3Press to establish a three party conference
Now you have established a three party conference. To mark the
conference, all conference members will hear a periodical
conference tone.
Repeat the procedure to include other persons to the
conference
In this way, you can include up to six parties in a conversation.
How many of them can be external callers depends on the
programming of the system.
Replace the handset to leave the conference
Dial mode
Note: This section only applies to the Ericsson Basic and
Medium telephone.
If your telephone is in the pulse dialling mode, and you want to
use any of the automated data services that require tone dialling,
you can switch temporarily to tone dialling during a call, e.g.
when calling interactive tele services or controlling telephone
answering machines remotely.
Note: After you end the call, dialling is reset to pulse
dialling.
Press to switch to tones
Tone

20
Call Forwarding
BusinessPhone - Analog Telephone
Call Forwarding
When you are not available to take calls or decide to answer your
calls on another extension, it is useful to forward your calls to an
alternate answering position.
If you urgently need to talk to someone who has forwarded his
calls, the system is also equipped with a bypass function.
Depending on the type of diversion you are also able to record
your personal greeting, see section “Personal greeting”.
Note: You can still make calls as usual.
Diversion on no reply
If you are not available to answer incoming calls (internal or
external), your system administrator can program your extension
to automatically divert calls to a programmed diversion address
(default time: 15 seconds).
Diversion on busy
If your extension is busy and you receive an incoming call
(internal or external), your system administrator can program
your extension to automatically divert the call to a programmed
diversion address.
