EtherWAN EX24000 User manual

EX24000 Switch
1
EX24000 Switch Users Guide
FastFind Links
Product Overview
Unpacking and Installation
Computer Setup
Setting the initial IP address
User’s Guide

All Rights Reserved
Dissemination or reproduction of this document, or its contents, is not authorized except
where expressly permitted. Violators are liable for damages. All rights reserved, for the
purposes of patent application or trademark registration.
Disclaimer of Liability
The information contained in this document is subject to change without notice. EtherWAN is
not liable for any errors or omissions contained herein or for resulting damage in connection
with the information provided in this manual.
Registered Trademarks
The following words and phrases are registered Trademarks of EtherWAN Systems Inc.
EtherOS™
Ethernet to the World™
All other Trademarks are property of their respective owners.
Warranty
For details on the EtherWAN warranty replacement policy, please visit our web site at:
https://kb.etherwan.com/index.php?View=entry&EntryID=27
Products Supported by this Manual:
EX24000
Contact EtherWAN Systems
Corporate Headquarters
EtherWAN Systems Inc.
4570 E. Eisenhower Circle
Anaheim, CA 92807
Tel: [phone]
Fax: [phone]
Email: [email protected]
ii
EX24000 Switch Users Guide

Preface
TABLE OF CONTENTS

Table of Contents ................................................................................................... iii
Table of Figures ...................................................................................................... xi
Preface................................................................................................................... xiv
Changes in this Revision...........................................................................................xiv
Document Conventions ............................................................................................. xv
Safety and Warnings ................................................................................................. xv
Typographic Conventions.......................................................................................... xv
Product Overview .................................................................................................. 16
EX24000 Switch ........................................................................................................ 16
Product Highlights .....................................................................................................17
Unpacking and Installation ................................................................................... 18
Package Contents ..................................................................................................... 18
Unpacking .................................................................................................................18
Required Equipment and Software ...........................................................................19
Computer Setup..................................................................................................... 20
Management Methods and Protocols........................................................................ 20
Default IP...................................................................................................................21
Login Process and Default Credentials .....................................................................21
Setting the initial IP address................................................................................. 22
Simple IP Addressing ................................................................................................ 22
CLI Command Usage............................................................................................. 24
Navigating the CLI Hierarchy ....................................................................................24
CLI Keyboard Shortcuts ............................................................................................25
CLI Command modes ...............................................................................................26
General Configuration Mode ............................................................................... 26
MSTP Configuration Mode .................................................................................. 26
Interface Configuration Mode .............................................................................. 27
VLAN Database Configuration Mode .................................................................. 27
Saving a Configuration from the CLI ................................................................... 27
iii
EX24000 Switch Users Guide

Preface
System Menu ......................................................................................................... 28
System Information ...................................................................................................28
System Name/Password ........................................................................................... 30
IP Address................................................................................................................. 31
Static IP ...............................................................................................................31
DHCP Client ........................................................................................................ 31
Default Gateway .................................................................................................. 31
DNS Server .........................................................................................................31
Management Interface .............................................................................................. 33
HTTPS.................................................................................................................33
Telnet...................................................................................................................33
SSH (Secure Shell) .............................................................................................34
Save Configuration Page ..........................................................................................35
Save Configuration .............................................................................................. 35
Load Configuration ..............................................................................................35
Backup Configuration ..........................................................................................35
Restore Default.................................................................................................... 36
Auto Save ............................................................................................................ 36
Firmware Upgrade.....................................................................................................37
Reboot.......................................................................................................................38
Logout .......................................................................................................................38
Diagnostics ............................................................................................................ 39
Utilization...................................................................................................................39
System Log ............................................................................................................... 40
Remote Logging ........................................................................................................ 41
ARP Table .................................................................................................................43
Route Table...............................................................................................................44
Port ......................................................................................................................... 45
Configuration ............................................................................................................. 45
Port Status.................................................................................................................47
Rate Control ..............................................................................................................48
RMON Statistics ........................................................................................................ 49
Per Port VLAN Activities............................................................................................ 50
Port Security Dynamic-MAC...................................................................................... 51
Port Configuration Examples Using CLI Commands ................................................54
Setting the Port Description.................................................................................54
Enable or Disable a Port...................................................................................... 54
Setting the Port Speed ........................................................................................55
Setting Port Duplex.............................................................................................. 55
Enable or Disable Port FlowControl .................................................................... 56
Display Port Status .............................................................................................. 56
iv
EX24000 Switch Users Guide

Preface
Setting a Ports Rate Control................................................................................56
Display a Ports RMON Statistics ......................................................................... 57
Display a Ports VLAN Activities...........................................................................57
Setting Dynamic MAC Port Security....................................................................57
Switching................................................................................................................ 59
Bridging .....................................................................................................................59
Aging Time ..........................................................................................................60
Port Isolation........................................................................................................60
Block Multicast..................................................................................................... 60
Loopback Detect .......................................................................................................62
Enabling Loopback Detection (Global)................................................................62
Changing the Loopback Detect Action ................................................................62
Changing the Loopback Detect Recovery Time .................................................. 62
Changing the Polling Interval............................................................................... 63
Enabling Loopback Detection (Per Port) ............................................................. 64
Storm Detect ............................................................................................................. 65
Enabling Storm Detect Configuration (Global) .................................................... 65
Changing the Storm Detect Interval .................................................................... 65
Changing the Storm Detect Error Disable Recovery Time .................................. 65
Static MAC Entry ....................................................................................................... 68
Adding a Static MAC Address to a Port............................................................... 68
Removing a Static MAC Address from a Port .....................................................69
Adding a MAC to the Static-MAC-Entry Discard Table .......................................69
Removing a MAC address from the Static-MAC-Entry Discard Table ................70
Port Mirroring.............................................................................................................71
Link State Tracking.................................................................................................... 73
Enable/Disable Link State Tracking.....................................................................73
Port Settings ........................................................................................................74
PoE 75
Changing the System Power Budget (Global).....................................................75
Enabling Enable Mode (Per Port)........................................................................75
Changing the Fixed Power Limit (Per Port) ......................................................... 75
Enabling Power Priority (Per Port)....................................................................... 75
PoE Scheduling.........................................................................................................76
Enabling PoE Scheduling (Per Port) ................................................................... 76
Switch Configuration Examples Using CLI Commands ............................................78
Setting the Aging Time Value .............................................................................. 78
Enabling Port Isolation.........................................................................................78
Enabling Block Multicast...................................................................................... 79
Setting Storm Detect by Utilization ...................................................................... 79
Enabling Loopback Detect (Global).....................................................................80
Setting the Loopback Detect Action ....................................................................80
v
EX24000 Switch Users Guide

Preface
Setting the Loopback Detect Recovery Time ...................................................... 80
Setting the Loopback Detect Polling Interval.......................................................81
Enabling Loopback Detect (Port)......................................................................... 81
Adding a MAC Address for Static-MAC-Entry Forwarding .................................. 82
Adding a MAC Address for Static-MAC-Entry Discarding ...................................82
Configuring Port Mirroring ................................................................................... 83
Enabling a Link State Tracking Group................................................................. 83
Assigning a Port to a Link State Tracking Group................................................. 84
Setting the System Power Budget ................................................................... 84
Trunking ................................................................................................................. 85
Overview ................................................................................................................... 85
Static Channel Trunking ......................................................................................85
Link Aggregation Control Protocol.......................................................................85
Port Trunking.............................................................................................................86
LACP Trunking ..........................................................................................................87
Trunking Configuration Examples Using CLI Commands ......................................... 89
Adding an Interface to a Static Trunk .................................................................. 89
Adding an Interface to a LACP Trunk.................................................................. 89
Setting the LACP Port Priority ............................................................................. 90
Setting the LACP Timeout ................................................................................... 90
STP/Ring Page – Overview ................................................................................... 91
Choosing the Spanning Tree Protocols.....................................................................91
Spanning Tree Protocol (STP) ............................................................................ 91
Rapid Spanning Tree protocol (RSTP)................................................................ 91
Multiple Spanning Tree Protocol (MSTP) ............................................................ 91
STP/Ring Page - Configuring RSTP ..................................................................... 92
Global Configuration Page ........................................................................................92
Enabling the RSTP Protocol................................................................................ 92
Additional Global Configuration page settings..................................................... 92
The Root Bridge & Backup Root Bridge .............................................................. 94
Setting the MAX Age, Forward Delay and Hello Timer ....................................... 96
RSTP Port Setting Page............................................................................................ 98
Spanning Tree Port Roles ................................................................................... 98
Path Cost & Port Priority...................................................................................... 99
Point to Point Link..............................................................................................101
Edge Port........................................................................................................... 101
RSTP Configuration Examples Using CLI Commands ...........................................102
Enabling the Spanning Tree Protocol................................................................102
Bridge Priority, Max Age, Forward Delay, and Hello Time ................................ 102
Modifying the Port Priority and Path Cost.......................................................... 103
vi
EX24000 Switch Users Guide

Preface
Manually Setting a Port to be a Shared or Point to Point Link........................... 103
Enabling/Disabling a port to be an Edge Port.................................................... 104
STP/Ring Page - Configuring MSTP................................................................... 105
Global Configuration Page ......................................................................................105
Enabling the MSTP Protocol ............................................................................. 105
The CIST Root Bridge & Backup CIST Root Bridge.......................................... 106
Setting Bridge Priority........................................................................................ 107
Configuring the CST Network Diameter ............................................................ 108
MSTP Properties Page............................................................................................109
Configuring an MSTP Region............................................................................ 109
Configuring the IST Network Diameter.............................................................. 111
MSTP Instance Setting Page .................................................................................. 112
Setting an MSTP Instance................................................................................. 112
Modifying MSTP parameters for load balancing................................................ 113
MSTP Port Setting page.......................................................................................... 115
Adjusting the blocking port in a MSTP network ................................................. 115
MSTI Instance Port Membership ....................................................................... 117
MSTP Configuration Examples Using CLI Commands ...........................................119
Enabling Spanning Tree for MSTP.................................................................... 119
Bridge Priority, Max Age, Forward Delay, and Hello Time ................................ 119
IST MAX Hops................................................................................................... 120
MSTP Regional Configuration Name and the Revision Level ........................... 120
Creating an MSTI Instance................................................................................ 121
Setting MSTI Priority.......................................................................................... 121
Modifying CIST Port Priority and Port Path Cost............................................... 121
Adding a Port to an MSTI Instance.................................................................... 122
STP/Ring Page - Alpha Ring ............................................................................... 123
Alpha Ring Setting Page .........................................................................................123
EtherWAN α-Ring Technology ..........................................................................123
Implementing a Simple α-Ring .......................................................................... 123
Connecting two α-Ring Networks together........................................................125
Chain Setting Page .................................................................................................126
Chain Protocol...................................................................................................126
VLAN (Global) ................................................................................................... 127
Priority (Global).................................................................................................. 127
Timeout Count (Global) ..................................................................................... 127
Enabling Storm Control (Broadcast and Multicast) (Global).............................. 127
Chain Pass-Through Setting Page.......................................................................... 128
Implementing a Chain Pass-Through ................................................................ 129
Advanced Setting ....................................................................................................129
Advanced Bridge Configuration.........................................................................130
vii
EX24000 Switch Users Guide

Preface
Advanced Per Port Configuration ...................................................................... 131
Configuring Spanning Tree Advanced Settings using CLI commands.................... 133
Enabling BPDU Guard Globally......................................................................... 133
Enabling BPDU Guard on a Port ....................................................................... 133
Enabling BPDU Guard Error Disable-timeout.................................................... 134
VLAN..................................................................................................................... 135
Port Based VLAN vs. Tagged Based VLAN............................................................ 135
Configuring VLANs in Port Based VLAN Mode....................................................... 135
Enabling Port Based VLAN ............................................................................... 135
Port Based VLAN Configuration Examples .......................................................136
Port Based VLAN Configuration Examples using CLI Commands....................138
VLAN Configuration in 802.1Q Tag Based VLAN Mode ......................................... 140
General Overview.............................................................................................. 140
Enabling 802.1Q Tagged Based VLAN ............................................................. 141
Configuring 802.1Q VLAN Database................................................................. 142
802.1Q Tag Based VLAN Configuration Examples Using CLI Commands ............ 143
Configuring a 802.1Q VLAN .............................................................................. 143
Configuring an IP Address for a Management VLAN ........................................ 143
Removing an IP Address from a Management VLAN ....................................... 144
Configuring an Access Port...............................................................................144
Configuring a Trunk Port ...................................................................................145
Add an IP to the Management VLAN ...................................................................... 146
Configuring the Port Type and the PVID setting .....................................................147
Configuring the VLAN Egress (outgoing) Member Ports................................... 148
QoS ....................................................................................................................... 150
Global Configuration Page ......................................................................................151
Web GUI Interface............................................................................................. 151
QoS Global Configuration using the CLI Interface ..................................................153
Enable/Disable QoS Trust ................................................................................. 154
Configuring the Egress Expedite Queue ........................................................... 154
802.1p Priority Page................................................................................................ 156
Web GUI Interface............................................................................................. 156
802.1p Priority Submenu – CLI Interface ................................................................ 157
DSCP Page – HTTP Interface................................................................................. 158
DSCP Submenu – CLI Interface .............................................................................159
QoS Interface Commands – CLI Interface .............................................................. 160
SNMP .................................................................................................................... 161
SNMP General Settings .......................................................................................... 161
Configuring SNMP v1 & v2 Community Groups...................................................... 164
Configuring SNMP v3 Users ...................................................................................165
viii
EX24000 Switch Users Guide

Preface
Adding SNMP v3 Users to the switch................................................................ 165
Deleting SNMP v3 Users from the switch.......................................................... 168
SNMP Configuration Examples Using CLI Commands...........................................169
Enabling SNMP and configuring general settings ............................................. 169
Configuring SNMP Traps................................................................................... 171
Configuring SNMP v1 & v2 Community Groups................................................ 173
Adding SNMP v3 Users..................................................................................... 173
IEEE 802.1X .......................................................................................................... 174
Configuring 802.1X from the GUI system................................................................ 174
Enabling Radius ................................................................................................174
Adding a Radius Server..................................................................................... 175
Enabling 802.1X on a Port.................................................................................176
LLDP ..................................................................................................................... 178
LLDP General Settings............................................................................................179
Enable/Disable LLDP ........................................................................................179
Holdtime Multiplier.............................................................................................179
Global TLV Setting ............................................................................................180
LLDP Ports Settings ................................................................................................182
Enabling LLDP transmission for a specific Port................................................. 182
Enabling LLDP Reception for a specific Port..................................................... 182
Enabling Notifications........................................................................................182
LLDP Neighbors ...................................................................................................... 184
LLDP Statistics ........................................................................................................ 185
LLDP Configuration Examples Using CLI Commands ............................................ 186
Enable/Disable LLDP ........................................................................................186
LLDP Holdtime Multiplier ................................................................................... 187
LLDP Transmit Interval...................................................................................... 187
Enable/Disable Global LLDP TLVs.................................................................... 188
Enabling LLDP Transmit on a Port .................................................................... 189
Enabling LLDP Receive on a Port ..................................................................... 189
Enabling LLDP Notify ........................................................................................ 190
Enabling Transmission of the Management IP.................................................. 190
Enabling Specific TLV’s on a Port ..................................................................... 191
Other Protocols.................................................................................................... 192
GVRP ......................................................................................................................192
General Overview.............................................................................................. 194
Enabling the GVRP Protocol at the Global Level .............................................. 195
Enabling the GVRP Protocol at the Port Level .................................................. 197
GVRP Configuration Examples Using CLI Commands .....................................199
IGMP Snooping ....................................................................................................... 202
ix
EX24000 Switch Users Guide

Preface
General Overview.............................................................................................. 202
Enabling the IGMP Snooping Modes ................................................................ 203
Configuring IGMP Snooping General properties ............................................... 203
Configuring IGMP Passive Mode Specific properties........................................ 204
Configuring IGMP Querier Mode Specific properties ........................................ 205
Configuring IGMP Unknown Multicast Forwarding............................................ 206
Monitoring Registered Multicast Groups ........................................................... 211
IGMP Configuration Examples Using CLI Commands ......................................212
Network Time Protocol ............................................................................................ 220
Enabling NTP ....................................................................................................220
Setting the NTP Server IP Address ................................................................... 220
Setting the Timezone.........................................................................................220
Setting the Polling Period .................................................................................. 220
Manually Syncing Time .....................................................................................221
Daylight Savings Time - Weekday Mode........................................................... 221
Daylight Savings Time – Date Mode .................................................................222
Network Time Protocol Configuration Examples Using CLI Commands........... 224
GMRP......................................................................................................................227
General Overview.............................................................................................. 227
GMRP Normal mode ......................................................................................... 227
GMRP Fixed mode ............................................................................................ 227
GMRP Forbidden mode..................................................................................... 228
GMRP Forward All mode................................................................................... 228
GMRP Disabled mode....................................................................................... 228
Enabling the GMRP Feature Globally on the Switch......................................... 228
Configuring the GMRP Feature Per Port........................................................... 229
GMRP Configuration Examples Using CLI Commands ....................................232
DHCP Server........................................................................................................... 234
General Overview.............................................................................................. 234
Configuring the DHCP Server ........................................................................... 234
DHCP Configuration Examples Using CLI Commands ..................................... 237
x
EX24000 Switch Users Guide

Preface
TABLE OF FIGURES
Figure 1: Front view ..............................................................................................................16
Figure 2: Back view...............................................................................................................16
Figure 3: Login screen ..........................................................................................................21
Figure 4: Assigning an IP address ........................................................................................ 23
Figure 5: Saving the Configuration........................................................................................ 24
Figure 6: System Information ................................................................................................ 29
Figure 7: System Name/Password........................................................................................ 30
Figure 8: IP Address .............................................................................................................32
Figure 9: Management Interface ........................................................................................... 34
Figure 10: Save Configuration Page ..................................................................................... 36
Figure 11: Firmware Upgrade Page...................................................................................... 37
Figure 12: Utilization Page ....................................................................................................39
Figure 13: System Log ..........................................................................................................40
Figure 14: Remote Logging Page .........................................................................................42
Figure 15: ARP Table............................................................................................................43
Figure 16: Route Table .........................................................................................................44
Figure 17: Port Configuration ................................................................................................ 46
Figure 18: Port Status ...........................................................................................................48
Figure 19: Rate Control.........................................................................................................49
Figure 20: RMON Page.........................................................................................................50
Figure 21: Port VLAN Activities............................................................................................. 51
Figure 22: Port Security ........................................................................................................53
Figure 23: Bridging................................................................................................................61
Figure 24: Loopback Detection ............................................................................................. 63
Figure 25:Loopback Detection (port)..................................................................................... 64
Figure 26: Storm Detect ........................................................................................................67
Figure 27: MAC Static Entry..................................................................................................68
Figure 28: Removing a Static MAC....................................................................................... 69
Figure 29: Adding a MAC – Static-MAC-Entry Table ............................................................ 70
Figure 30: Deleting a MAC – Static-MAC-Entry Table .......................................................... 70
Figure 31: Port Mirroring .......................................................................................................72
Figure 32: Disabling Port Mirroring ....................................................................................... 73
Figure 33: Link State Tracking .............................................................................................. 74
Figure 34: Link State Tracking – Port Settings......................................................................74
Figure 35: PoE ......................................................................................................................76
Figure 36: PoE Scheduling ................................................................................................... 77
Figure 37: Port Trunking .......................................................................................................87
xi
EX24000 Switch Users Guide

Preface
Figure 38: LACP Trunking..................................................................................................... 88
Figure 39: STP/Ring Global Configuration............................................................................93
Figure 40: Bridge ID ..............................................................................................................94
Figure 41: Bridge ID Display ................................................................................................. 95
Figure 42: Max Age, Hello Timer & Forward Delay............................................................... 97
Figure 43: Spanning Tree Port Roles....................................................................................98
Figure 44: Port ID..................................................................................................................99
Figure 45: Port Priority and Path Cost ................................................................................100
Figure 46: Enabling MSTP .................................................................................................. 106
Figure 47: Bridge ID ............................................................................................................106
Figure 48: Bridge ID Display ............................................................................................... 107
Figure 49: Max Age, Hello Timer & Forward Delay............................................................. 109
Figure 50: MSTP Region and Revision Level ..................................................................... 110
Figure 51: MSTP Properties – Max Hops ...........................................................................111
Figure 52: VLAN Instance Configuration............................................................................. 113
Figure 53: VLAN Instance ID .............................................................................................. 113
Figure 54: Setting the MSTI Regional Root Bridge .............................................................114
Figure 55: Port Cost & Priority ............................................................................................ 116
Figure 56: Port Instance Configuration ............................................................................... 118
Figure 57: Port Instance - Adding Ports .............................................................................. 118
Figure 58: α-Ring Settings .................................................................................................. 124
Figure 59: Ring Coupling .................................................................................................... 126
Figure 60: Chain Settings.................................................................................................... 128
Figure 61: Chain Pass-Through Settings ............................................................................ 129
Figure 62: Advanced Bridge Configuration .........................................................................131
Figure 63: Advanced Per Port Configuration ......................................................................132
Figure 64: Port Based VLAN............................................................................................... 136
Figure 65: Port Based VLAN – Example 1.......................................................................... 137
Figure 66: Port Based VLAN – Example 2.......................................................................... 138
Figure 67: Tag-based VLAN ............................................................................................... 141
Figure 68: Add VLAN .......................................................................................................... 142
Figure 69: Add VLAN Page.................................................................................................142
Figure 70: Management VLAN IP Address .........................................................................146
Figure 71: VLAN Port Setting..............................................................................................147
Figure 72: VLAN Links ........................................................................................................ 148
Figure 73: VLAN Ports ........................................................................................................149
Figure 74: Tag or Untag ports ............................................................................................. 149
Figure 75: Global Configuration .......................................................................................... 151
Figure 72: 802.1p Priority.................................................................................................... 156
Figure 77: DSCP .................................................................................................................158
Figure 78: SNMP General Settings.....................................................................................163
Figure 79: Community Name V1/V2c..................................................................................164
Figure 80: Add User ............................................................................................................165
xii
EX24000 Switch Users Guide

Preface
Figure 81: SNMP v3 Settings.............................................................................................. 166
Figure 82: User name & Access Mode ...............................................................................166
Figure 83: Auth Password................................................................................................... 167
Figure 84: Privacy PassPhrase...........................................................................................168
Figure 85: Delete User ........................................................................................................ 168
Figure 86: Select User ........................................................................................................ 169
Figure 87: Enable Radius.................................................................................................... 175
Figure 88: Radius Setup ..................................................................................................... 176
Figure 89: Resulting Radius Server Setup..........................................................................176
Figure 90: Enabling 802.1X on a Port ................................................................................. 177
Figure 91: LLDP Global Settings.........................................................................................181
Figure 92: LLDP Ports Settings........................................................................................... 183
Figure 93: LLDP Neighbors.................................................................................................184
Figure 94: LLDP Statistics................................................................................................... 185
Figure 95: GVRP.................................................................................................................193
Figure 96: GVRP Configuration Distribution Switch............................................................ 196
Figure 97: GVRP Configuration Access Switch ..................................................................197
Figure 98: GVRP Per Port Settings.....................................................................................198
Figure 99: IGMP Mode........................................................................................................ 203
Figure 100: IGMP General Properties.................................................................................204
Figure 101: IGMP Passive Mode ........................................................................................205
Figure 102: Querier Mode Properties..................................................................................206
Figure 103: Disabled Mode Forwarding Port ......................................................................207
Figure 104: PassiveForwardMode ...................................................................................... 208
Figure 105: ForceForwardMode.......................................................................................... 209
Figure 106: IGMP Querier Mode Forwarding...................................................................... 210
Figure 107: Current Multicast Groups ................................................................................. 211
Figure 108: NTP Settings.................................................................................................... 221
Figure 109: Daylight Savings – Weekday Mode ................................................................. 222
Figure 110: Daylight Savings – Date Mode.........................................................................223
Figure 111: GMRP Global Setting.......................................................................................229
Figure 112: DHCP Server ...................................................................................................235
Figure 113: DHCP Bindings ................................................................................................236
Figure 114: DHCP Binding Table........................................................................................ 237
xiii
EX24000 Switch Users Guide

Preface
PREFACE
Audience
This guide is designed for the person who installs, configures, deploys, and maintains the
Ethernet network. This document assumes the reader has moderate hardware, computer,
and Internet skills.
Document Revision Level
This section provides a history of the revision changes to this document.
Revision Document Version Date Description
A Version 1 05/09/2014 Initial release
Changes in this Revision
N/A - this is first version of this document.
xiv
EX24000 Switch Users Guide

Preface
xv
EX24000 Switch Users Guide
Document Conventions
This guide uses the following conventions to draw your attention to certain information.
Safety and Warnings
This guide uses the following symbols to draw your attention to certain information.
Symbol Meaning Description
Note Notes emphasize or supplement important points of the main text.
Tip Tips provide helpful information, guidelines, or suggestions for performing tasks more
effectively.
Warning Warnings indicate that failure to take a specified action could result in damage to the
device, or could result in serious bodily injury.
Electric Shock Hazard This symbol warns users of electric shock hazard. Failure to take appropriate
precautions such as not opening or touching hazardous areas of the equipment could
result in injury or death.
Typographic Conventions
This guide also uses the following typographic conventions.
Convention Description
Bold Indicates text on a window, other than the window title, including menus, menu options, buttons, fields, and labels.
Italic Indicates avariable, which is a placeholder for actual text provided by the user or system. Angled brackets (< >)
are also used to indicate variables.
screen/code Indicates text that is displayed on screen or entered by the user.
< > angled
brackets Indicates a variable, which is a placeholder for actual text provided by the user or system. Italic font is also used to indicate variables.
[ ] square
brackets Indicates optional values.
{ } braces Indicates required or expected values.
| vertical bar Indicates that you have a choice between two or more options or arguments.

PRODUCT OVERVIEW
EX24000 Switch
The EX24000 Switch Provides the 16-port 10/100BASE-TX (PoE) and 2 combo Gigabit
SFP ports. The EX24000 Switch is a fully managed switch.
Figure 1: Front view
Figure 2: Back view
16
EX24000 Switch Users Guide

17
EX24000 Switch Users Guide
Product Highlights
Basic Features:
16 x 10/100BASE (PoE) ports
Provides up to two combo Gigabit SFP ports
Supports 8192 MAC addresses, Provides 2M bits memory buffer
Store-and-forward mechanism, Full wire-speed forwarding rate
Supports IEEE802.3af Power over Ethernet (PoE) Power Sourcing Equipment
(PSE)
Supports Max. 15.4W power for each PSE/PoE port
RS-232 console, Telnet, SNMP V1, V2c & V3, RMON, Web Browser, and TFTP
Management
Supports Command Line Interface from RS-232 Console
α-ring and RSTP/MSTP/STP for Ethernet redundancy
IP Multicast Filtering
Port-based VLAN, IEEE802.1Q VLAN Tagging and GVRP
IEEE802.1p QoS with four priority queues
MAC-based trunking with automatic link fail-over
Supports IEEE802.1X Security
Bandwidth Rate Control
Per-port programmable MAC address locking
Up to 24 Static Secure MAC addresses per port
Port mirroring
Supports NTP
Supports IEEE802.3/802.3u/802.3ab/802.3z/802.3x
1000Mbps-Full-duplex, 10/100Mbps-Full/Half-duplex, Auto-Negotiation, Auto-
MDI/MDIX
Alarms for port and power failure by relay output
Power Supply: 100~240VAC, 50~60Hz internal universal PSU
Power consumption: 12W Max. (Without PoE)
Power budget: 195W Max
Push and hold the reset button for less than 10 seconds: system reboot
Push and hold the reset button for more than 10 seconds: reset to default
password
0°C to 45°C (32°F to 113°F) operating temperature range
Supports Rack Mounting installation

UNPACKING AND INSTALLATION
This chapter describes how to unpack and install the EX24000 Switch
The topics covered in this chapter are:
Package Contents (Page 18)
Unpacking (Page 18)
Required Equipment and Software (Page 19)
Computer Setup (Page 20)
Management Methods and Protocols (Page 20)
Default IP (Page 21)
Login Process and Default Credentials (Page 21)
Setting the initial IP address (Page 22)
Package Contents
When you unpack the product package, you will find the items listed below. Please inspect
the contents, and report any apparent damage or missing items immediately to your
authorized reseller.
This Management Switch
User’s Manual
External power adapter
Unpacking
Follow these steps to unpack the EX24000 Switch and prepare it for operation:
1. Open the shipping container and carefully remove the contents.
2. Return all packing materials to the shipping container and save it.
3. Confirm that all items listed in the "Package Contents" section are included in
the shipment. Check each item for damage. If any item is damaged or missing, notify
your authorized EtherWAN representative.

Required Equipment and Software
The following hardware and software are needed in order to manage the switch from the
web interface:
Computer with an Ethernet Interface (RJ-45)
Managing the switch requires a personal computer (PC) or notebook computer
equipped with a 10/100base-TX Ethernet interface and a physical RJ-45
connection. The preferred operating system for the computer is Microsoft Windows
XP/Vista/7. It is possible to use Apple OSX or Linux systems as well, but, for the
sake of brevity, all web configurations in this manual will be shown using Windows
7 as the underlying operating system.
Cat 5+ Ethernet Cables
An Ethernet cable of at least Category 5 rating is required to connect your
computer to the switch. The cable can be configured as “straight-through” or
crossover.
TFTP Server Software
Trivial file transfer protocol (TFTP) server software is needed to update the switch
firmware and to upload/download configuration files to the switch. Users not
performing these tasks do not need TFTP software installed. Several good TFTP
servers are available for free online. The server that will be used in this manual is
TFTPD32 by Philippe Jounin.
Web Browser Software
The end user can employ any of the following web browsers during switch
configuration: Internet Explorer, Firefox, or Chrome. Internet Explorer is the
preferred browser for EtherWAN switch configuration. If there is trouble with other
browsers while attempting to program the switch, Internet Explorer should be used.
19
EX24000 Switch Users Guide

COMPUTER SETUP
The end user’s management computer may need to be reconfigured prior to connecting to
the switch in order to access the switch’s web interface through its default IP address (See
Default IP).
Management Methods and Protocols
There are several methods that can be used to manage the switch. This manual
will show the details of configuring the switch using a web browser. Each section
will be followed by the CLI (Command Line Interface) commands needed to
achieve the same results as described in that section.
The methods available to manage the EX24000 Switch include:
SSH - Secure Shell CLI that is accessible over TCP/IP networks which and is
generally regarded as the most secure method of remotely accessing a
device.
Telnet - is like SSH in that it allows a CLI to be established across a TCP/IP
network, but it does not encrypt the data stream.
HTTP (Hypertext Transfer Protocol) is the most popular switch management
protocol involving the use of a web browser.
RS232 – The EX24000 Switch is equipped with a RS232 serial port that can
be used to access the switches CLI. The Serial port is DCE DB9F. A
straight through serial cable is used to connect to a typical computer serial
port.
20
EX24000 Switch Users Guide
