Evelo Omega User manual

Omega and Atlas Rack
Battery Installation
This guide shows how to install the rear rack and
secondary battery on your new EVELO bicycle. This
applies to Atlas and Omega models.

EVELO Omega and Atlas Battery Rack Installation 2
Step 1: Open the seatpost quick release, then
unscrew it to remove the light. Unplug the
connector, then reassemble and tighten the
seatpost quick release.
Step 2: Using an allen wrench, remove the four
rack mounting bolts from the frame and discard.
New, longer bolts will be included with the
rack.
Step 3: Remove the battery from the rack and
hold the rack in place on the bike.
REMOVING THE BATTERY FROM THE RACK
PRIOR TO INSTALLATION IS CRUCIAL TO AVOID
DAMAGE TO BATTERY AND/OR BICYCLE.

EVELO Omega and Atlas Battery Rack Installation 3
Step 4: Using an allen wrench, install the lower
mounting bolts. Use the longer bolts from the
rack package; the bolts that came on the bike
are too short to hold the rack securely.
Step 5: Using an allen wrench, install the upper
mounting bolts. Use the longer bolts from the
rack package; the bolts that came on the bike
are too short to hold the rack securely.
Step 6: Connect the new taillight to the
connector you unplugged earlier. Line up the
arrows on each half of the connector and push
them together.
MAKE SURE REAR BATTERY IS REMOVED
AND BICYCLE IS POWERED OFF BEFORE
CONNECTING PLUGS

EVELO Omega and Atlas Battery Rack Installation 4
Step 7: Open the cover and plug the battery
into the frame port. It will only go in one way, so
be aware of the plug orientation.
MAKE SURE REAR BATTERY IS REMOVED
AND BICYCLE IS POWERED OFF BEFORE
CONNECTING PLUGS
Step 8: Your connections should now look like
this.
Go ride your bike!
Charging:
To charge the bike with both batteries installed,
connect only the charger that came with the
bike to either battery and both will be charged.
DO NOT PLUG A CHARGER INTO THE MAIN
BATTERY AND THE SECONDARY BATTERY AT
THE SAME TIME WHEN BOTH ARE INSTALLED
ON THE BIKE.

EVELO Omega and Atlas Battery Rack Installation 5
Questions? Get In Touch:
EVELO.COM
First Edition
877-991-7272
