Evelo Compass User manual

Assembly of Evelo Compass
The focus of this document is to assist with the assembly of your new EVELO Delta X.
The scope is intentionally narrow – The “User Guide” that was included with your bike
covers a much broader spectrum of topics: fit adjustments, battery care, controls etc.
Our Team is here to help 7 days a week!
[e-mail] |877-991-7272
Feel Free to reach out!
Watch the Assembly
Instructions Video

2
ASSEMBLY OF EVELO COMPASS |
1
3 4
5
2
Begin unboxing the bike by cutting the banding then
opening the box. Use caution regarding the staples
as they can be very sharp. Remove the small boxes.
Carefully remove all packing material from
bike, avoid using sharp objects as to protect
the paint.
Tools and User Guides will be in the small
black Evelo box. The Pedals will be in a
small cardboard box.
For the purpose of assembly, carefully lay the
bike down on its side.
Due to it size, it is ideal to
remove the trike from the
box with the help of another
person.
Unboxing Your EVELOUnboxing Your EVELO

3
ASSEMBLY OF EVELO COMPASS |
6
7 8
9 10
Disassemble to remove the stack of spacers.
Remove screws in frame surrounding rear axle. Hold fender support in position and
replace screws.
Position Spacers between fender support and basket. Attach nut and tighten
with wrench.

4
ASSEMBLY OF EVELO COMPASS |
11
12
13 14
Repeat process for second fender support. Remove screws, position fender support, replace screws.
Repeat process for third fender support. Remove screws, position fender support, replace screws.
Unscrew nut at end of
fender support.
Hold fender in position and replace screw and nut. Tighten using
3mm Allen Wrench and 8mm Box Wrench.

5
ASSEMBLY OF EVELO COMPASS |
15
16
Repeat to attach fender to the other supports.
Repeat to attach fender to the other supports.
17 18
The outside nut is a backwards thread. Rotate
clockwise to remove.
Remove second nut on axle, turn
counter-clockwise to remove.

6
ASSEMBLY OF EVELO COMPASS |
19
20 21
Remove axle cover and cut plastic tie.
Make sure the metal rectangle stays seated
in place during wheel installation.
Note the recession inside the wheel’s hub.
22 Put wheel in place, aligning recession with metal bar.

7
ASSEMBLY OF EVELO COMPASS |
23 24
25 26
Replace nut and tighten clockwise. Add thread locker to these threads before
installing cap nut.
Replace nut and tighten counter-clockwise. Repeat steps for the other side.
27 Remove the screw in the front fork. Remove black spacer as well.

8
ASSEMBLY OF EVELO COMPASS |
28
29 30
Thread headlight and fender support onto screw. Insert spacer between headlight and fender support.
Replace nut and tighten. Remove bolts from each side of fork.
31 Attach lower fender support struts.

9
ASSEMBLY OF EVELO COMPASS |
32 33
34 35
Remove plastic bar
from fork.
Remove black cap from front wheel skewer. Leave the inner
spring in place.
Insert skewer through front wheel
assembly as shown.
Replace cap and spring, tighten partially.
36 Put front wheel into place. Tighten and lock with lever.

10
ASSEMBLY OF EVELO COMPASS |
38 Screw pedals into crank arms. It is important to note that the pedals are threaded differently.
The right pedal screws in clockwise and the le pedal screws in counter-clockwise.
right pedal left pedal
37 Screw pedals into crank arms securely. Installation of the pedals requires a 15 mm wrench.
There is an L and an R stamped into the end of each pedal for reference.
39 40
Two sets of keys are attached to the underside of
the bike.
Carefully turn the bike
upright.

11
ASSEMBLY OF EVELO COMPASS |
41
43 44
42
Tighten headlight and fender assembly.
Remove plastic cover from handlebar stem.
Insert handlebar stem and align with front
wheel.
Once aligned, tighten bolt to secure
handlebars. Make sure this bolt is extra
tight!
Attach cap to handlebar base.
45 Adjust the seat height.

12
ASSEMBLY OF EVELO COMPASS |
46 47
48
The brake lock will keep the bike from moving. Flip the power switch on the bottom
of the battery.
Power up and you’re ready to ride!

13
ASSEMBLY OF EVELO COMPASS |
To register your bike on our website, you will
need to record the serial number. It is located
on the headtube of your bike, just above the
front fork.
Serial Number Location

There is considerable additional information in your “User Guide”.
Of course, if you ever have questions, our team is ready to help!
