Event Lighting BLINDER Series User manual

BLINDER
Model No. BLINDER2100, BLINDER2100W
USER MANUAL
For safety, please read this user manual carefully before initial use.
Event Lighting reserves the right to revise the manual at any time. Information and specifications within this
manual are subject to change without notice. Event Lighting assumes no liability or responsibility for any
errors or omissions. Please consult Event Lighting for any clarification or information regarding this item.
www.event-lighting.com.au
Ver 3.0

www.event-lighting.com.au
1
CONTENTS
Safety Instructions
- Power input & power Linking
Product Installation
- Fuse replacement
Diagrams
- Lux chart
- Dimensions
- Fade Mode Chart
Control Board Operation
- DMX address setting
- DMX modes setting
- Dimmer Speed Setting
- Static colour setting
- Manual colour setting
- Auto run and sound active setting
- Master/slave setting
DMX chart
Technical specifications
Warranty

www.event-lighting.com.au
2
Safety Instructions
WARNING
• Do not open this device, there is no user-serviceable parts inside. Risk of electric shock.
• Do not look at the light source when the device is on.
•CAUTION: This unit's housing may be hot during and after operation.
• Install this device in a location with adequate ventilation, at least 20 inch (50 cm) from adjacent surfaces.
• Do not leave any flammable material within 50 cm of this unit while operating or connected to power.
• Use a safety chain when mounting this device overhead.
• Do not operate this device outdoors or in any location where dust, excessive heat, water, or humidity may affect it.
• Do not operate this device if the housing, lenses, or cables appear damaged.
• Do not connect this device to a dimmer or rheostat.
• ONLY connect this device to a grounded and protected circuit.
• ONLY use the hanging bracket to carry this device.
• In case of a serious operating problem, stop using immediately.
• The maximum ambient temperature is 104° F (40° C). Do not operate this device at higher temperatures.
Power Input & Power Linking
This device has an auto-switching power supply work with input voltage range of 100~240 VAC, 50/60 Hz.
Link up to the maximum 8A. DO NOT exceed this number.
The maximum number of units that can be power linked is 4 units at 110V and 8 units at 240V.
Product Installation
This device can be mounted in many orientations provided each individual device is secured by the use of correct
mounting bracket.
Use a safety chain when mounting this device overhead.
Fuse Replacement
If the fine-wire fuse of the device fuses, only replace the fuse by a fuse of same type and rating.
Before replacing the fuse, unplug mains lead.
Procedure:
Step 1: Unscrew the fuse holder on the rear panel with a fitting screwdriver from the housing (anticlockwise).
Step 2: Remove the old fuse from the fuse holder.
Step 3: Install the new fuse in the fuse holder.
Step 4: Replace the fuse holder in the housing and fix it.

www.event-lighting.com.au
3
CONTROL BOARD OPERATION
Blinder2100W
Display Options / Values Function
A001 <001> - <512> Set DMX address for 8 channel mode
D001 <001> - <512> Set DMX address for 4 channel mode
CC50 <01> - <99> Select auto colour switch mode at different speed
DE50 <01> - <99> Select auto colour pulse mode at different speed
CP50 <01> - <99> Select auto colour fade mode at different speed
SU09 <01> - <09> Set sound active mode at different sensitivity
C255 <001> - <255> Select intensity of cool white
Y255 <001> - <255> Select intensity of warm white
S000 <001> - <020> Select strobe from slow to fast
Blinder2100
Display Options / Values Function
A001 <001> - <512> Set DMX address for 12 channel mode
D001 <001> - <512> Set DMX address for 8 channel mode
CC50 <01> - <99> Select auto colour switch mode at different speed
DE50 <01> - <99> Select auto colour pulse mode at different speed
CP50 <01> - <99> Select auto colour fade mode at different speed
SU09 <01> - <09> Set sound active mode at different sensitivity
R255 <001> - <255> Select intensity of red
G255 <001> - <255> Select intensity of green
B255 <001> - <255> Select intensity of blue
W255 <001> - <255> Select intensity of white
S000 <001> - <020> Select strobe from slow to fast

www.event-lighting.com.au
4
DMX Chart
Blinder2100W 4 channels Mode
Channel Value Function
1 000-255 Cool white 1: 0% ~ 100%
2 000-255 Warm white 1: 0% ~ 100%
3 000-255 Cool white 2: 0% ~ 100%
4 000-255 Warm white 2: 0% ~ 100%
Blinder2100W 8 channels Mode
Channel Value Function
1 000-255 Master dimmer: 0% ~ 100%
2 000-255 Strobe: 0% ~ 100%
3
000-005 No function
006-080 Auto colour switch mode
081-160 Auto colour pulse mode
161-240 Auto colour fade mode
241-255 Sound Active mode
4 000-255 Speed of auto programs (slow to fast)
5 000-255 Cool white 1: 0% ~ 100%
6 000-255 Warm white 1: 0% ~ 100%
7 000-255 Cool white 2: 0% ~ 100%
8 000-255 Warm white 2: 0% ~ 100%

www.event-lighting.com.au
5
Blinder2100 8 channels Mode
Channel Value Function
1 000-255 Red 1: 0% ~ 100%
2 000-255 Green 1: 0% ~ 100%
3 000-255 Blue 1: 0% ~ 100%
4 000-255 White 1: 0% ~ 100%
5 000-255 Red 2: 0% ~ 100%
6 000-255 Green 2: 0% ~ 100%
7 000-255 Blue 2: 0% ~ 100%
8 000-255 White 2: 0% ~ 100%
Blinder2100 12 channels Mode
Channel Value Function
1 000-255 Master dimmer: 0% ~ 100%
2 000-255 Strobe: 0% ~ 100%
3
000-005 No function
006-080 Auto colour switch mode
081-160 Auto colour pulse mode
161-240 Auto colour fade mode
241-255 Sound Active mode
4 000-255 Speed of auto programs (slow to fast)
5 000-255 Red 1: 0% ~ 100%
6 000-255 Green 1: 0% ~ 100%
7 000-255 Blue 1: 0% ~ 100%
8 000-255 White 1: 0% ~ 100%
9 000-255 Red 2: 0% ~ 100%
10 000-255 Green 2: 0% ~ 100%
11 000-255 Blue 2: 0% ~ 100%
12 000-255 White 2: 0% ~ 100%

www.event-lighting.com.au
6
TECHNICAL SPECIFICATIONS
Blinder2100W Blinder2100
Input Voltages 100V~240V AC,50/60Hz
Power Consumption 235W
Power Connection Power Con Input / Output Connection
Light Source 2 pcs 100W Warm & Cool White
2-in-1 COB LEDs
2 pcs 100W RGBW 4-in-1 COB LEDs
Beam Angle 60°
PWM 3,000 Hz
Dimming 8-bit Linear Dimming Control
Strobe 0 - 25 Hz
Operational Modes Static, Auto Run Program, Sound Active, Master / Slave & DMX Modes
Display 4-button LED Display Control Panel
DMX Protocol DMX512
DMX Channel Mode 4 / 8 8 / 12
DMX Interface 3-Pin XLR Input / Output
WARRANTY
Please refer to your local dealer or please contact Event Lighting Pty Ltd
Website: www.event-lighting.com.au.
