Event Lighting PS200LECW User manual

LED Profile Spot
PS200LECW PS200LEWW
Light Engines
PS19LENS PS26LENS PS36LENS
Lenses
USER MANUAL
For safety, please read this user manual carefully before initial use.
Event Lighting reserves the right to revise the manual at any time. Information and specifications within this manual are subject to
change without notice. Event Lighting assumes no liability or responsibility for any errors or omissions. Please consult Event Lighting
for any clarification or information regarding this item.
www.event-lighting.com.au Ver 1.0

www.event-lighting.com.au
1
CONTENTS
Safety Instructions
- Power Input & Power Linking
- Product installation
Product Installation
- Fuse replacement
Product appearance
- Lux Chart
- Dimensions
Control Board Operation
- DMX Addressing
- DMX Modes
- Dimmer Curves
- Static Settings
DMX Values
Technical Specifications
Warranty

www.event-lighting.com.au
2
Safety Instructions
WARNING
•Do not open this device, there is no user-serviceable parts inside. Risk of electric shock.
•Do not look at the light source when the device is on.
•CAUTION: This unit's housing may be hot during and after operation.
•Install this device in a location with adequate ventilation, at least 20 inch (50 cm) from adjacent surfaces.
•Do not leave any flammable material within 50 cm of this unit while operating or connected to power.
•Use a safety chain when mounting this device overhead.
•Do not operate this device outdoors or in any location where dust, excessive heat, water, or humidity may affect it.
•Do not operate this device if the housing, lenses, or cables appear damaged.
•Do not connect this device to a dimmer or rheostat.
•ONLY connect this device to a grounded and protected circuit.
•ONLY use the hanging bracket to carry this device.
•In case of a serious operating problem, stop using immediately.
•The maximum ambient temperature is 104° F (40° C). Do not operate this device at higher temperatures.
Power Input & Power Linking
This device has an auto-switching power supply work with input voltage range of 100~240 VAC, 50/60 Hz.
Link up to the maximum 8A. DO NOT exceed this.
Fuse Replacement
If the fine-wire fuse of the device fuses, only replace the fuse by a fuse of same type and rating.
Before replacing the fuse, unplug mains lead.
Procedure:
Step 1: Unscrew the fuse holder on the rear panel with a fitting screwdriver from the housing (anticlockwise).
Step 2: Remove the old fuse from the fuse holder.
Step 3: Install the new fuse in the fuse holder.
Step 4: Replace the fuse holder in the housing and fix it.
Product Installation
This device can be mounted in many orientations provided each individual device is secured by the use of correct
mounting bracket.
Use a safety chain when mounting this device overhead.

www.event-lighting.com.au
3
Dimensions
Lux Chart

www.event-lighting.com.au
4
CONTROL BOARD OPERATION
Press the Menu until one of the following had been displayed:
Display
Function
1.DMX Address
To set DMX address
2.DMX Channel
To set DMX channel modes: CH 01, CH 02, CH 03
3.Dimmer Curve
To set dimmer speeds: 01, 02, 03, 04
4.Manual Control
To set intensity of Dimmer, Dimmer Fine and Strobe
5.Reset
To recover to manufactory default
Use “Up”and “Down”button to select your desired operation, press “Enter”to set all function
Set DMX address
After selecting the "DMX Address" and press “Enter”, then use “Up”and “Down”to set the desired DMX address,
press "Enter" again to confirm.
Set DMX modes
After selecting the "DMX Channel" and press “Enter”, then use “Up”and “Down”to set the desired DMX mode,
press "Enter" again to confirm.
Set Dimmer curve
After selecting the "Dimmer Curve" and press “Enter”, then use “Up”and “Down”to set the desired dimmer curve,
press "Enter" again to confirm.
Set Manual Control
Set up intensity of Dimmer, Dimmer Fine and Strobe rate through the control panel. Use “Enter”to save your set for
each step. Use “Up” and “Down”to set strobe speed from Sp 000 to Sp 100, (“0”is freeze, “001 –100”is slow to fast),
then press "Enter" to confirm.
Factory Reset
To recover factory default, select the "Reset" and press “Enter”, press "Enter" again to confirm to recover factory default

www.event-lighting.com.au
5
DMX VALUES
1 channel mode
Channel
Value
Function
1
000-255
Dimmer Course
2 channels mode
Channel
Value
Function
1
000-255
Dimmer Course
2
000-255
Dimmer Fine
3 channels mode
Channel
Value
Function
1
000-255
Dimmer Course
2
000-255
Dimmer Fine
3
000-255
Strobe
TECHNICAL SPECIFICATIONS
Model
PS200LECW
PS200LEWW
Dimensions and Weight
Overall size LxWxH (mm)
538 X 270 X 395
Weight (kg)
8.6
Power
Power Supply
100~240V AC, 50/60 Hz
Power Consumption (w)
200
Fuse
T 2 A, 250 V
Details
LED
200W COB
LED lifespan
50 000hrs
Colour Temperature
5600K
3000K
Operation Modes
DMX, static control
Beam Angle
19 / 26 / 36 (dependent on lens option used)
Dimming
16 bit –0-100%
Strobe rate
1-25 Hz
Refresh Rate
8000Hz
DMX Channel mode
1 / 2 / 3
Power Input / Output
Neutrik® Powercon
Power Output
Neutrik® Powercon
DMX connector
3 pin male XLR and 3 pin female XLR
Construction
Matte Black finish aluminium and ABS
WARRANTY
Please refer to your local dealer or please contact Event Lighting Pty Ltd
Website: www.event-lighting.com.au.
