Event Lighting STROBEXRGB User manual

RGB Strobe
Model No. STROBEXRGB
USER MANUAL
For safety, please read this user manual carefully before initial use.
Event Lighting reserves the right to revise the manual at any time. Information and specifications within this
manual are subject to change without notice. Event Lighting assumes no liability or responsibility for any
errors or omissions. Please consult Event Lighting for any clarification or information regarding this item.
www.event-lighting.com.au Ver 1.0

www.event-lighting.com.au
1
CONTENTS
Safety Instructions
- Power input & power Linking
Product Installation
- Fuse replacement
Diagrams
- Lux chart
- Dimensions
Control Board Operation
- DMX address setting
- DMX modes setting
- Manual modes setting
- Auto run setting
- Master/slave setting
DMX chart
Technical specifications
Warranty

www.event-lighting.com.au
2
Safety Instructions
WARNING
•Do not open this device, there is no user-serviceable parts inside. Risk of electric shock.
•Do not look at the light source when the device is on.
•CAUTION: This unit's housing may be hot during and after operation.
•Install this device in a location with adequate ventilation, at least 20 inch (50 cm) from adjacent surfaces.
•Do not leave any flammable material within 50 cm of this unit while operating or connected to power.
•Use a safety chain when mounting this device overhead.
•Do not operate this device outdoors or in any location where dust, excessive heat, water, or humidity may affect it.
•Do not operate this device if the housing, lenses, or cables appear damaged.
•Do not connect this device to a dimmer or rheostat.
•ONLY connect this device to a grounded and protected circuit.
•ONLY use the hanging bracket to carry this device.
•In case of a serious operating problem, stop using immediately.
•The maximum ambient temperature is 104° F (40° C). Do not operate this device at higher temperatures.
Power Input & Power Linking
This device has an auto-switching power supply work with input voltage range of 100~240 VAC, 50/60 Hz.
Link up to the maximum 8A. DO NOT exceed this number.
Product Installation
This device can be mounted in many orientations provided each individual device is secured by the use of correct
mounting bracket.
Use a safety chain when mounting this device overhead.
Fuse Replacement
If the fine-wire fuse of the device fuses, only replace the fuse by a fuse of same type and rating.
Before replacing the fuse, unplug mains lead.
Procedure:
Step 1: Unscrew the fuse holder on the rear panel with a fitting screwdriver from the housing (anticlockwise).
Step 2: Remove the old fuse from the fuse holder.
Step 3: Install the new fuse in the fuse holder.
Step 4: Replace the fuse holder in the housing and fix it.

www.event-lighting.com.au
3
Lux Chart
Dimensions

www.event-lighting.com.au
4
Menu Map
Address
<001> to <512>
DMX address
Channel
3, 6, 9, 18, 25
DMX channel modes
Option
Standard, Quiet
Select quite mode or standard mode
Monitor
(Manual
mode)
Channel 3 Mode
CH:01 to CH:03
Select DMX channel mode first, set up eachchannel
values to manual control according to DMX chart.
Channel 6 Mode
CH:01 to CH:06
Channel 9 Mode
CH:01 to CH:09
Channel 10 Mode
CH:01 to CH:10
Channel 18 Mode
CH:01 to CH:18
Channel 25 Mode
CH:01 to CH:25
Auto
Auto00
Speed <000> to <255>
Select auto program and adjust auto run speed
Auto01
Auto02
….
Auto36
Effect
on Auto
Dimmer
<000> to <255>
Adjust dimmer level and switch on strobe at different
speed for auto run
Strobe
<000> to <255>
MasMode
Yes
Master or Slave
Select master/slave mode
No
Master mode off
Back L
on
Back light always stays on
60s
Back light turns off after 60s
120s
Back light turns off after 120s
300s
Back light turns off after 300s
Temp
Temp1
XXº
Display current temperature on LED panel
Temp1
XXº
Display current temperature on chassis
Info
Test 1
Test mode without strobe
Test 2
Test mode with strobe
Reset
Yes or No
Recover to factory default
Version
Display current version
Dimmer
Control
Speed
<000> to <007>
Fade Time
DMX Address
After select the “Address” and press “Enter”, use “Up” and “Down” button to select the desired DMX address, press
“Enter”to save new setting.
DMX Modes
After select the “Channel” and press “Enter”, use “Up” and “Down” button to select the desired DMX channel mode, press
“Enter”to save new setting.
Manual Mode
It is manual control mode according to DMX chart without DMX controller.

www.event-lighting.com.au
5
Set up DMX channel from control panel. When fixture is in 3 DMX channel mode, you will only able to set up from Ch1 to
Ch3. When fixture is in 25 DMX channel mode, you will only able to set up from Ch1 to Ch25.
Use “Up” and “Down” button to set up each channel value from <000> to <255>, press “Enter" to save new setting.
Auto Mode
This fixture has 36 built-in programs. Entered "Auto" mode, use “Up” and “Down” button to select the built-in programs
"Auto 1 ~ Auto 36", then press the "Enter" to confirm. Use “Up” and “Down” button to select the operating speed of the
program from 000 to 255, press “Enter" to save new setting. You have to use “Effect on Auto”mode to adjust the
brightness and add strobe effect to auto run.
Effect on Auto
Use “Effect on Auto”to switch ondimmer and strobe function to auto mode. Entered “Effect on Auto” mode, use “Up” and
“Down” button to select dimmer level, then press the "Enter" to confirm. Use “Up” and “Down” button to select strobe
speed from 000 to 255, press “Enter" to save new setting.
Master/Slave Mode
Set the master fixture to auto or manual modes.
Entered “Master”mode, use “Up” and “Down” button to select “No”, press “Enter” to set fixture to slave mode.
Use DMX to link master and slave fixture together.
DMX Data
When there is a ‘*’ flashing, the StrobeX is not receiving any DMX signal. A solid ‘*’ indicated DMX signal is being
received. DMX takes priority over all other functions when a signal is being received.
Once DMX signal is lost, the StrobeX will revert back to the original setting, which also could be DMX or Manual or
Automatic mode.
DMX Chart
3 channels Mode
Channel
Value
Function
1
000-255
Red: 0% ~ 100%
2
000-255
Green: 0% ~ 100%
3
000-255
Blue: 0% ~ 100%
6 channels Mode
Channel
Value
Function
1
000-255
Master dimmer
2
000-255
Strobe speed and repetitions
3
000-255
Strobe interval (0 = longest, 255 = shortest)
4
000-255
Random strobe
5
000-255
Special effect
6
000-255
Speed of special effect

www.event-lighting.com.au
6
9 channels Mode
Channel
Value
Function
1
000-255
Master dimmer
2
000-255
Red: 0% ~ 100%
3
000-255
Green: 0% ~ 100%
4
000-255
Blue: 0% ~ 100%
5
000-255
Strobe speed and repetitions
6
000-255
Strobe interval (0 = longest, 255 = shortest)
7
000-255
Random strobe
8
000-255
Special effect
9
000-255
Speed of special effect
10 channels Mode
Channel
Value
Function
1
000-255
Master dimmer
2
000-255
Red: 0% ~ 100%
3
000-255
Strobe interval for red
4
000-255
Green: 0% ~ 100%
5
000-255
Strobe interval for green
6
000-255
Blue: 0% ~ 100%
7
000-255
Strobe interval for blue
8
000-031
No function
032-063
Red
064-095
Red + green
096-127
Green
128-159
Green + blue
160-191
Blue
192-223
Red + blue
224-255
Red + green +blue
9
000-255
Special effect
10
000-255
Speed of special effect
18 channels Mode
Channel
Value
Function
1
000-255
Master dimmer
2
000-255
Block 1 red
3
000-255
Block 1 green
4
000-255
Block 1 blue
5
000-255
Block 2 red
6
000-255
Block 2 green
7
000-255
Block 2 blue
8
000-255
Block 3 red
9
000-255
Block 3 green
10
000-255
Block 3 blue

www.event-lighting.com.au
7
11
000-255
Block 4 red
12
000-255
Block 4 green
13
000-255
Block 4 blue
14
000-255
Strobe on duration
15
000-255
Strobe rate
16
000-255
Random strobe
17
000-255
Special effect
18
000-255
Speed of special effect
25 channels Mode
Channel
Value
Function
1
000-255
Master dimmer
2
000-255
Block 1 red
3
000-255
Strobe rate for red
4
000-255
Block 1 green
5
000-255
Strobe rate for green
6
000-255
Block 1 blue
7
000-255
Strobe rate for blue
8
000-255
Block 2 red
9
000-255
Strobe rate for red
10
000-255
Block 2 green
11
000-255
Strobe rate for green
12
000-255
Block 2 blue
13
000-255
Strobe rate for blue
14
000-255
Block 3 red
15
000-255
Strobe rate for red
16
000-255
Block 3 green
17
000-255
Strobe rate for green
18
000-255
Block 3 blue
19
000-255
Strobe rate for blue
20
000-255
Block 4 red
21
000-255
Strobe rate for red
22
000-255
Block 4 green
23
000-255
Strobe rate for green
24
000-255
Block 4 blue
25
000-255
Strobe rate for blue

www.event-lighting.com.au
8
Technical Specifications
Power
•Power Consumption: 480W
•Input Voltage: 100V~240V AC, 50/60Hz
•Power Connection: PowerCON In
Photometrics
•Light Source: 968 pcs 0.8W SMD5050 RGB LEDs
•LED Beam Angle: 120°
•Output: 650 lux @3M
•PWM: 2000Hz
•LED Lifespan: 50,000 hours
Effects
•Dimming: 0 –100%
•Strobe: 1 –25 Hz
Control
•Operation: DMX, Manual, Auto Program & Master / Slave
•Display: 4-button LCD control panel
•DMX Protocol: DMX512
•DMX Channel Mode: 3 / 6 / 9 / 18 / 25
•DMX Interface: 3-pin XLR
Housing
•Housing Materials: Aluminium & ABS
•Housing Finishing: Matte Black
•Dimension: 500 x 135 x 270 mm
•Cooling: Sensor thermostat controlled variable speed fan
•Net Weight: 6.5 kg
WARRANTY
Please refer to your local dealer or please contact Event Lighting Pty Ltd
Website: www.event-lighting.com.au.
