Event Lighting M7W15RGBW User manual

1
WASH MOVING HEAD
M7W15RGBW
USER MANUAL
For safety, please read this user manual carefully before initial use.
Event Lighting reserves the right to revise the manual at any time. Information and specifications within this manual are subject to
change without notice. Event Lighting assumes no liability or responsibility for any errors or omissions. Please consult Event Lighting
for any clarification or information regarding this item.
www.event-lighting.com.au V1.1

2
Safety Instructions
WARNING
•Do not open this device, there is no user-serviceable parts inside. Risk of electric shock.
•Do not look at the light source when the device is on.
•CAUTION: This unit's housing may be hot during and after operation.
•Install this device in a location with adequate ventilation, at least 20 inch (50 cm) from adjacent surfaces.
•Do not leave any flammable material within 50 cm of this unit while operating or connected to power.
•Use a safety chain when mounting this device overhead.
•Do not operate this device outdoors or in any location where dust, excessive heat, water, or humidity may affect it.
•Do not operate this device if the housing, lenses, or cables appear damaged.
•Do not connect this device to a dimmer or rheostat.
•ONLY connect this device to a grounded and protected circuit.
•ONLY use the hanging bracket to carry this device.
•In case of a serious operating problem, stop using immediately.
•The maximum ambient temperature is 104° F (40° C). Do not operate this device at higher temperatures.
Power Input & Power Linking
This device has an auto-switching power supply work with input voltage range of 100~240 VAC, 50/60 Hz.
Link up to the maximum 8A. DO NOT exceed this.
Fuse Replacement
If the fine-wire fuse of the device fuses, only replace the fuse by a fuse of same type and rating.
Before replacing the fuse, unplug mains lead.
Procedure:
Step 1: Unscrew the fuse holder on the rear panel with a fitting screwdriver from the housing (anticlockwise).
Step 2: Remove the old fuse from the fuse holder.
Step 3: Install the new fuse in the fuse holder.
Step 4: Replace the fuse holder in the housing and fix it.
Product Installation
This device can be mounted in many orientations provided each
individual device is secured by the use of correct mounting bracket.
Use a safety chain when mounting this device overhead.

3
Product Appearance, LUX chart, Dimensions
1. Project lens
2. Head
3. Arm
4. Base
5. Display
6. Foot stand
7. Operation button
8. Wireless indicator
9. Mic
10. Left Button
11. Enter Button
12. Down Button
13. Up Button
14. Right Button
15. Fuse Holder
16. Powercon in
17. Power switch
18. Powercon out
19. 3-pin DMX out
20. 3-pin DMX in

4
Menu Operation
Description of icons in the menu
CONNECT
LIGHT
INFOMATION
SET
PROGRAM
Menu
Default setting shadowed. mark with ①can be basic reloaded, ②be program reloaded, ③can be private reloaded.
Connect
DMX Address①
XXX
DMX address setting
Light
Max Temperature
①
80~139℃, 90℃/176~282℉, 194℉
Lamp switch off when
temperature continuously
over for 5 minutes
Lamp Adjust①
Adjust value of each
channels
Information
Time Info.
Current XXXX(Hours)
Fixture Life XXXX(Hours)
Fixture boot time
Fixture total run time
Temperature
Near Lamp Temp (depends on fixture)
Temperature Sensors
Fans Speed
Near Lamp Fan (depends on fixture)
Fan speed Sensors
Channel Value
Display value of channel
Error Message
Error channels
Fixture Model
M7W15RGBW
Display brand and model
Software Ver
1U01 V1.0.00
2U01 V1.0.00
Version of each IC
Set
Reset
All
Pan & Tilt
Others
Reset all
Reset Pan & Tilt
Reset Others
Movement
Pan Reverse①
Tilt Reverse①
Pan Degree①
Encoders①
Pan/Tilt Mode①
ON/OFF
ON/OFF
630°/540°
ON/OFF
Stand/Smooth
Pan Reverse
Tilt Reverse
Choose Pan Degree
Encoder wheel on/off
Choose pan/tilt mode
UI Set
Mic Sens. ③
No Signal①
Temperature. C/F①
Fans Mode①
Hibernation①
Backlight①
Flip Display①
Display Bright③
Brand Show①
0~99%,60%
Close/Hold/Auto/Music
Fahrenheit /Celsius
Auto Speed /High Speed
OFF, 01M~99M，15M
02~60m 02m
ON/OFF
00~31 10
ON/OFF
Sensitivity of Mic
Mode when no signal
Temperature at ℃/℉
Fans mode
Sleeping mode
Show backlight time
Display 180°reverse
Display Brightness
Show brand or not

5
Key Lock①
Language①
ON/OFF
En/简/繁/Fr/Sp
Key lock on/off
Language Select
Users
User Mode①
Standard
Extended
Basic-8bit
Basic-16bit
User
Standard mode
Extended mode
Basic-8bit mode
Basic-16bit mode
User program mode
Edit User③
Max Channel = XX
PAN = CH01
:
Edit users mode
Calibration③
-Password-
Pan…
=XXX
=XXX
Password: 050
Calibrate channel value
Fixture ID③
Name
-Password-
PID Code
Name
Password: 050
Set PID of RDM
Reload Default
Basic Reload(①)
Program Reload(②)
---Password---
Private Reload(③)
All Reload
ON/OFF
ON/OFF
XXX
ON/OFF
ON/OFF
Basic Reload
Program Reload
Password: 050
Private Reload
All Reload
Program
Play①
DMX Receive
Slave Receive
Sequence
Music
Slave Receive 1,2,3
Master / Alone
Master / Alone
DMX Receive
Choose slave position
Run Sequence
Music mode
Select Chase②
Chase Part 1
Chase Part 2
Chase Part 3
Chase 1 ~ 8 Chase 1
Chase 1 ~ 8 Chase 2
Chase 1 ~ 8 Chase 3
Select and run auto
program
Edit Chase②
Chase 1
:
Chase 8
Chase Test
Step 01
Step 64
=SCxxx
=SCxxx
Test
Beginning scene
Ending scene
Edit Scenes②
Edit Scene 001
~ Edit Scene 250
Pan,Tilt,……
Fade Time--
Secne Time--
DMX Input
=xxx
=xxx
=xxx
Input manual scene
Modify fading time
Modify scene time
Input scene from exterior
controller
Scenes Record
ScXX=>ScXX
Auto Input scenes

6
DMX chart
Channel
name
function
Min
DMX
Max
DMX
St
Ex
Ba1
Ba2
1
1
1
1
Pan
Pan Coarse
0
255
2
2
Pan fine
Pan Fine
0
255
2
3
2
3
Tilt
Tilt Coarse
0
255
4
4
Tilt fine
Tilt Fine
0
255
3
5
3
5
Movement Speed
fastest to Slowest
0
255
6
movement Function
Normal
0
15
Movement With Blackout
16
31
TBD
32
255
4
7
Shutter Function
Normal Shutter mode
0
15
Pulse-effect Forward
16
31
Pulse-effect Reverse
32
47
Random Strobe
48
63
TBD
64
255
5
8
Shutter
Normal Shutter mode with shutter close
0
31
Normal Shutter mode speed slow to fast
32
223
Normal Shutter mode with shutter Open
224
255
Pulse-effect Forward shutter Close
0
31
Pulse-effect Forward Strobe speed slow to fast
32
223
Pulse-effect Forward shutter Open
224
255
Pulse-effect Reverse shutter Close
0
31
Pulse-effect Reverse Strobe Rate slow to fast
32
223
Pulse-effect Reverse shutter Open
224
255
Random Strobe , shutter Close
0
31
Random Strobe Strobe speed slow to fast
32
223
Random Strobe , shutter Open
224
255
4
6
Shutter
Shutter closed
0
31
No function (shutter open)
32
63
Strobe effect slow to fast
64
95
No function (shutter open)
96
127
Pulse-effect in sequences
128
159
No function (shutter open)
160
191
Random strobe effect slow to fast
192
223
No function (shutter open)
224
255
6
9
5
7
Dimmer
Dimmer (0->100%)
0
255
7
10
6
8
Virtual Color Function
On Function
0
15
CTC Function
16
31
Forward Spin
32
47
Reverse Spin
48
63
Continuous
64
79

7
Color Bounce
80
111
TBD
112
255
8
11
7
9
Virtual Color1
CTC Function
Colour Temperature Correction 2000K->2700K
0
223
White 3200K
224
231
White 4200K
232
239
White 5600K
240
247
White 8000K
248
255
Forward Spin
Rainbow Effect (Slow->Fast)
0
255
Reverse Spin
Rainbow Effect (Slow->Fast)
0
255
Continuous & Color Bounce
Black
0
0
Red
1
1
Green
2
2
Blue
3
3
White
4
4
Red=0, Green->up,Blue=full,White=0
5
46
Red=0, Green=full,Blue->down,White=0
47
88
Red->up, Green=full,Blue=0,White=0
89
130
Red=full, Green->down,Blue=0,White=0
131
172
Red=full, Green=0,Blue->up,White=0
173
214
Red->down, Green=0,Blue=full,White=0
215
255
9
12
8
10
Virtual Color2 (Only
On Color Bounce)
Black
0
0
Red
1
1
Green
2
2
Blue
3
3
White
4
4
Red=0, Green->up,Blue=full,White=0
5
46
Red=0, Green=full,Blue->down,White=0
47
88
Red->up, Green=full,Blue=0,White=0
89
130
Red=full, Green->down,Blue=0,White=0
131
172
Red=full, Green=0,Blue->up,White=0
173
214
Red->down, Green=0,Blue=full,White=0
215
255
10
13
9
11
Red-All
Red 0->100%
0
255
11
14
10
12
Green-All
Green 0->100%
0
255
12
15
11
13
Blue-All
Blue 0->100%
0
255
13
16
12
14
White-All
White 0->100%
0
255
14
17
13
15
Zoom
small angle -> Big angle
0
255
15
18
14
16
Foreground
No Function
0
15
Foreground Color
16
255
16
19
15
17
Background
No Function
0
15
Background color
16
255
17
20
16
18
Pattern
On Pattern
0
15

8
Pattern control
16
31
Pattern Effect 1~14
32
255
18
21
17
19
Pattern Speed
Pattern control
Picture Effect 1-250
3
252
Pattern Effect
Slow-> Fast
0
255
Pattern
Byte 1
Direct access to Pattern of LED 1&LED 2
0
255
Bit 0
Bit0=Led1 Red Switch
0
1
Bit 1
Bit1=Led1 Green Switch
0
2
Bit 2
Bit2=Led1 Blue Switch
0
4
Bit 3
Bit3=Led1 White Switch
0
8
Bit 4
Bit4=Led2 Red Switch
0
16
Bit 5
Bit5=Led2 Green Switch
0
32
Bit 6
Bit6=Led2 Blue Switch
0
64
Bit 7
Bit7=Led2 White Switch
0
128
Pattern
Byte 2
Direct access to Pattern of LED 3&LED 4
0
255
Pattern
Byte 3
Direct access to Pattern of LED 5&LED 6
0
255
Pattern
Byte 4
Direct access to Pattern of LED 7
0
255
22
Red Pixel 1
Led Off
0
127
Led On
128
255
23
Green Pixel 1
Led Off
0
127
Led On
128
255
24
Blue Pixel 1
Led Off
0
127
Led On
128
255
25
White Pixel 1
Led Off
0
127
Led On
128
255
:
:
46
Red Pixel 7
Led Off
0
127
Led On
128
255
47
Green Pixel 7
Led Off
0
127
Led On
128
255
48
Blue Pixel 7
Led Off
0
127
Led On
128
255
49
White Pixel 7
Led Off
0
127
Led On
128
255
19
50
18
20
Control
Normal
0
7
Reset All
8
15
Pan&Tilt Reset
16
23
TBD
24
47
Other Reset
48
55

9
Display Off
56
63
Display On
64
71
TBD
72
79
TBD
80
87
Hibernation
88
95
TBD
96
255
- The device is controlled by universal DMX 512 protocol, DMX address is the start channel used to receive
instructions from the external controller. For independent control, each fixture must be assigned its unique address
control channels. For example, this device has four channel modes: 19/50/18/20, if we set the mode at standard 20
channels mode, and there are several models need to be independently controlled, we just simply address first
fixture at 1, and second fixture at 21, third one at 41, etc.
-
- If the devices have the same address, they will behave synchronically.
-
- Display is flashing when no DMX signal is received.
More functions
- RDM. RDM stands for “Remote Device Management”, with this function, users can realize remote control of the
device, such as remotely changing DMX address, reverse pan/tilt setting, check a lot of useful information such as
temperature, power consumption, fan speed. Etc. Every single device has a unique RDM code programmed at
manufacture to distinguish from each other. It is not recommended for users to change this code.
-
- Software upgrade function via DMX cable. If there is any new firmware for this device, it can be upgraded simply via
a software upgrade box, no need to change any mechanical parts. The upgrade box is not included in the package,
if need any further assistance please just contact your authorized dealer.
-
- Hibernation. The device will enter sleeping mode if activated after a period of disconnecting DMX signal to save the
power consumption, and will return immediately as soon as the DMX signal is sent again.
-
- Display back-up communication IC. There is a back-up communication IC installed in the display PCB, so users
could replace at once if the original one is broken.
-
- Display flip. By press up and down button for more than 3 seconds, the display will flip automatically, this function is
useful to read menu conveniently when device is hanged.

10
Technical Specifications
- Input Voltages: 100V~240V A, 50/60Hz
- Power Consumption: 125W
- Light source: 7 pcs Osram 15W RGBW LED
- Power Connection: Neutrik® Powercon input and output connection
- LED life: 60,000 hours
- Lux: 3,500 lumen, 9,700 lux RGBW full on @3M at 6°
- Beam angle: 6°to 60°
- PWM: 1,200Hz
- Colors: full color
- Pixel control
- Dimmer: 0-100% dimmer
- Strobe: 0.5 - 26 Hz
- Zoom: 6°to 60°
- Head movement: Pan: 630°(1.45 sec)or 540°(1.2 sec), Tile 265°(0.72 sec).16-bit resolution, auto repositioning
- Control: DMX512, 3-pin XLR interfaces, 19/50/18/20 channel mode
- Other function: wireless DMX is available
- 2.4 inch colour LCD display with back-up power.
- Thermostat Controlled, variable speed fan
- RDM and software upgrade via DMX.
- Net weight: 6Kg
- Overall Size: 249x179x369mm
- Rigging: 1pc omega brackets with 1/4 –turn quick locks
- Road case available
