Exsys EX-1171 User manual

Anleitung
Vers. 1.0 / 15.02.18
Manual
7 Port USB 2.0 Plastic HUB
EX-1171
7 Port USB 2.0 Plastik HUB

2
EX-1171
1. Beschreibung······················································································ 3
2. ieferumfang ······················································································ 3
3. Aufbau & Anschlüsse ·········································································4-5
3.1 Aufbau······································································································ 4
3.2 Anschlüsse······························································································4-5
4. Hardware Installation············································································ 5
5. Treiber Installation ··············································································· 6
6. Reinigung ·························································································· 6
7. Technische Daten················································································ 7
8. Technische Zeichnung·········································································· 7
1. Description ························································································· 8
2. Extent of Delivery ················································································ 8
3. ayout & Connections······································································· 9-10
3.1 ayout ······································································································ 9
3.2 Connections ··························································································9-10
4. Hardware Installation···········································································10
5. Driver Installation················································································11
6. Cleaning ···························································································11
7. Technical Information ··········································································12
8. Technical Drawing ··············································································12
Inhaltsverzeichnis
Index
© Copyright 2018 by EXSYS Vertriebs GmbH. All Rights Reserved

3
EX-1171 Deutsch
Der EX-1171 ist ein USB 2.0 Plastik HUB für bis zu 7 Endgeräte. Der Hub ist mit 7 Ports
für Endgeräte und 1 Port für den Anschluss an den PC ausgestattet. Er unterstützt alle
USB Anschlüsse von 1.1 bis 3.1. Durch die Stromversorgung über die 5V Buchse, wer-
den an jedem Port die vollen 500mA zur Verfügung gestellt. Der USB 2.0 Bus unterstützt
optimal die eistung des schnellen NEC Chipsatz. Der EX-1163 gewährleistet so eine
sichere Datenübertragung und exzellente Performance von bis zu 480Mbit/s. Er unter-
stützt den Self Power und Bus Power Modus.
Merkmale:
• Kompatibel zu USB 1.1, 2.0, 3.0 & 3.1
• Bis zu 480Mbit/s
• Es werden alle Betriebssysteme unterstützt
• Zertifiziert für
Bevor Sie den EX-1171 an Ihren PC anschließen, überprüfen Sie bitte zuerst den Inhalt
der ieferung:
• EX-1171
• Netzteil (5V/2A)
• USB 2.0 Kabel
• Anleitung
1 Beschreibung
2 Lieferumfang
© Copyright 2018 by EXSYS Vertriebs GmbH. All Rights Reserved

4
Deutsch EX-1171
3 1 Aufbau
3 2 Anschlüsse
4x USB 2.0
Downstream A-Buchse
3 Aufbau & Anschlüsse
1x USB 2.0
Upstream B-Buchse 5V Buchse für im ieferumfang
enthaltenem Netzteil
5V Buchse:
ACHTUNG!!!
Nur zur Verwendung mit im Lieferumfang enthaltenem Netzteil!
© Copyright 2018 by EXSYS Vertriebs GmbH. All Rights Reserved
Status ED
für jeden Port
Betriebs ED

5
EX-1171 Deutsch
3 Aufbau & Anschlüsse
3 2 Anschlüsse
USB 2 0 A-Buchse:
USB 2 0 A-Buchse
Pin Signal Pin Signal
1VCC 3DATA+
2DATA- 4GND
USB 2 0 B-Buchse:
USB 2 0 B-Buchse
Pin Signal Pin Signal
1VCC 3DATA+
2DATA- 4GND
© Copyright 2018 by EXSYS Vertriebs GmbH. All Rights Reserved
4 Hardware Installation
Beachten Sie bitte die folgenden Installationshinweise. Da es große Unterschiede zwi-
schen PC‘s gibt, können wir Ihnen nur eine generelle Anleitung zum Einbau der EX-
1171 geben. Bei Unklarheiten halten Sie sich bitte an die Bedienungsanleitung Ihres
Computersystems.
1. Verbinden Sie das mitgelieferte USB Kabel mit der USB B-Buchse des Hub´s.
2. Verbinden Sie jetzt den Stromanschluss des im ieferumfang enthaltenem Netzteils
mit der 5V Buchse des Hub´s und stecken Sie den Netzstecker des Netzteils in eine
Steckdose.
3. Verbinden Sie nun das andere Ende (A-Stecker) des mitgelieferten USB Kabels mit
der A-Buchse an Ihrem PC.

6
Deutsch EX-1171
6 Reinigung
5 Treiber Installation
Alle Betriebssysteme
Nach Abschluss der Hardwareinstallation erkennt das Betriebssystem den EX-1163
automatisch und installiert diesen.
ÜBERPRÜFEN DES INSTA IERTEN TREIBER
Öffnen Sie den >Geräte-Manager<. Jetzt müssten Sie unter „USB-Controller“ folgen-
de Einträge sehen:
Sind diese oder ähnliche Einträge vorhanden, ist der USB Hub richtig installiert.
Zur Reinigung des Gerätes verwenden Sie bitte ausschließlich ein trockenes nicht fa-
serndes Tuch und entfernen Sie die Verschmutzung mit leichtem Druck. Im Bereich der
Anschlüsse bitte darauf Achten, dass keine Fasern des Tuchs in der Buchse hinterlas-
sen werden. Verwenden Sie bitte zu Reinigung in keinem Fall ein feuchtes oder
nasses Tuch!
© Copyright 2018 by EXSYS Vertriebs GmbH. All Rights Reserved

7
EX-1171 Deutsch
8 Technische Zeichnung
7 Technische Daten
Chip-Set: NEC uPD720113
Datentransfer-Rate: 480Mbit/s
Anschlüsse: 7x USB 2.0 A-Buchse, 1x USB 2.0 B-Buchse,
1x 5V Buchse
Hardwaresystem: USB 1.1, 2.0, 3.0 & 3.1
Betriebssystem: Alle Betriebssysteme
Betriebstemperatur: 0° bis 55° Celsius
Lagertemperatur: -20° bis 85° Celsius
Rel Luftfeuchtigkeit: 5% bis 95%
Stromversorgung: +5 Volt
Abmessung: 150 x 70 x 30 mm
Gewicht: 200g
© Copyright 2018 by EXSYS Vertriebs GmbH. All Rights Reserved
Demnächst verfügbar!

8
English EX-1171
The EX-1171 is a plug & play high-speed USB 2.0 plastic hub for 7 USB devices. The
EX-1171 provides 7 ports for USB devices and 1 uplink port for PC. It supports all USB
connections from 1.1 to 3.1. The power over the 5V connector provides a maximum of
power on each USB port of 500mA. The EX-1171 design fully utilize the NEC chipset,
which represents the latest in high speed USB interface technology. It uses data trans-
fer rates up to 480Mbit/s. It provides a secure and very high data transfer on each sin-
gle port. The EX-1171 support the Self Powered and Bus Powered mode.
Features:
• Compatible for USB 1.1, 2.0, 3.0 & 3.1
• Up to 480Mbit/s
• All Operating Systems are supported
• Certificate for
Before you connect the EX-1171 to your PC, you should first check the contents of the
delivery:
• EX-1171
• Power Supply (5V/2A)
• USB 2.0 Cable
• Manual
1 Description
2 Extent of Delivery
© Copyright 2018 by EXSYS Vertriebs GmbH. All Rights Reserved

9
EX-1171 English
3 Layout & Connections
© Copyright 2018 by EXSYS Vertriebs GmbH. All Rights Reserved
3 1 Layout
3 2 Connections
4x USB 2.0
Downstream A-Port
1x USB 2.0
Upstream B-Port 5V Connector for included external
Power Supply
5V Connector:
ATTENTION!!!
Use only with Power Supply which is included in delivery!
Status ED
for each Port
Power ED

10
English EX-1171
3 Layout & Connections
Because there are large differences between PC’s, we can give you only a general in-
stallation guide. Please refer your computer’s reference manual whenever in doubt.
1. Connect the USB cable to the USB B-Port at the Hub.
2. Connect the included power supply to the 5V connector at the Hub.
3. Now connect the other end from the USB cable (A-Plug) to the A-Port at your PC.
© Copyright 2018 by EXSYS Vertriebs GmbH. All Rights Reserved
3 2 Connections
USB 2 0 A-Port:
USB 2 0 A-Port
Pin Signal Pin Signal
1VCC 3DATA+
2DATA- 4GND
USB 2 0 B-Port:
USB 2 0 B-Port
Pin Signal Pin Signal
1VCC 3DATA+
2DATA- 4GND
4 Hardware Installation

11
EX-1171 English
6 Cleaning
5 Driver Installation
All Operating Systems
After the hardware installation the OS will recognize the device automatically and install
the drivers.
CHECK INSTA ED DRIVER
Open the >Device manager<. Now you should see at „USB-Controller“ the following
new entry's:
If you see this or a similar information the device is installed correctly.
For cleaning please use only a dry fluff less cloth and remove the dirt with gently pres-
sure. In the area of the connectors please make sure that no fibres from the cloth re-
main in the connectors. Attention! Never use a moist or wet cloth for cleaning!
© Copyright 2018 by EXSYS Vertriebs GmbH. All Rights Reserved

12
English EX-1171
7 Technical Information
Chip-Set: NEC uPD720113
Data Transfer Rate: 480Mbit/s
Connectors: 7x USB 2.0 A-Port, 1x USB 2.0 B-Port,
1x 5V Connector
Hardware System: USB 1.1, 2.0, 3.0 & 3.1
Operating System: All Operating Systems
Operating Temperature: 32°F to 131°Fahrenheit
Storage Temperature: -40°F to 185°Fahrenheit
Rel Humidity: 5% to 95%
Power: +5 Volt
Size: 150 x 70 x 30 mm
Weight: 200g
© Copyright 2018 by EXSYS Vertriebs GmbH. All Rights Reserved
8 Technical Drawing
Soon available!
