Falltech Confined Space Davit System Operator's manual

Conned Space Davit System
User Instrucon Manual
This manual is intended to meet the Manufacturer’s Instrucons as required by the American Naonal Standards Instute (ANSI) Z359 and
should be used as part of an employee training program as required by the Occupaonal Safety and Health Administraon (OSHA).
12” to 29” Oset Davit Arm 24” to 44” Oset Davit Arm
3pc Portable Base for 12” to 29” Oset Davit Arm
3pc Portable Base for 24” to 44” Oset Davit Arm
21”, 33”, 45”, and 57” Lower Mast Extensions
MCS30 Rev B 0215191306 S. Alameda Street, Compton, CA 90221, USA Tel: [phone] Fax: [phone]

021519
MCS30 Rev B 2
Table of Contents
1.0 Warnings and Important Informaon ..................................................................................
2.0 Applicaon ...........................................................................................................................
3.0 System Requirements ..........................................................................................................
4.0 Installaon and Use .............................................................................................................
5.0 Maintenance, Service, and Storage......................................................................................
6.0 Inspecon ............................................................................................................................
7.0 Labels ...................................................................................................................................
8.0 Denions ...........................................................................................................................
Appendix A .........................................................................................................................
For the purposes of this manual, the Conned Space Davit System may be referred to as the Davit, the system, or the unit.
Throughout this manual, ANSI Z359.0-2012 fall protecon words, phrases and terms are used. These terms are all formally dened in Secon 8.0 of
this manual.
3
4
4
5
13
13
15
19
21

021519
MCS30 Rev B 3
1.0 Warnings and Important Informaon
This product is part of a personal fall arrest, restraint, work posioning, suspension, or rescue system. A Personal Fall Arrest System (PFAS) is
typically composed of an anchorage and a Full Body Harness (FBH), with a connecng device, i.e., a Shock Absorbing Lanyard (SAL), or a
Self-Retracng Lanyard (SRL), aached to the dorsal D-ring of the FBH.
These instrucons must be provided to the worker using this equipment. The worker must read and understand the manufacturer’s instrucons for
each component or part of the complete system. Manufacturer’s instrucons must be followed for proper use, care, and maintenance of this
product. These instrucons must be retained and be kept available for the worker’s reference at all mes. Alteraons or misuse of this product, or
failure to follow instrucons, may result in serious injury or death.
A Fall Protecon Plan must be on le and available for review by all workers. It is the responsibility of the worker and the purchaser of this
equipment to assure that users of this equipment are properly trained in its use, maintenance, and storage. Training must be repeated at regular
intervals. Training must not subject the trainee to fall hazards.
Consult a doctor if there is reason to doubt your tness to safely absorb the shock of a fall event. Age and tness seriously aect a worker’s ability
to withstand falls. Pregnant women or minors must not use this equipment.
ANSI limits the weight of fall protecon equipment users to a maximum of 310 lbs. Products in this manual may have a rated capacity exceeding
ANSI capacity limits. Heavy users experience more risk of serious injury or death due to falls because of increased fall arrest forces placed on the
user’s body. In addion, the onset of suspension trauma aer a fall event may be accelerated for heavy users.
The user of the equipment discussed in this manual must read and understand the enre manual before beginning work.
NOTE: For more informaon consult the ANSI Z359 body of standards.
• Avoid moving machinery, thermal, electrical, and/or chemical hazards as contact may cause serious injury or death.
• Avoid swing falls.
• Follow the weight restricons and recommendaons in this manual.
• Remove from service any equipment subjected to fall arrest forces.
• Remove from service any equipment that fails inspecon.
• Do not alter or intenonally misuse this equipment.
• Consult FallTech when using this equipment in combinaon with components or subsystems other than those described in this manual.
• Do not connect rebar hooks, large carabiners, or large snap hooks to the FBH dorsal D-rings as this may cause a roll-out condion and/or
unintenonal disengagement.
• Avoid sharp and/or abrasive surfaces and edges.
• Use cauon when performing arc welding. Arc ash from arc welding operaons, including accidental arcs from electrical equipment, can
damage equipment and are potenally fatal.
• Examine the work area. Be aware of the surroundings and workplace hazards that may impact safety, security, and the funconing of fall arrest
systems and components.
• Hazards may include, but are not limited to, cable or debris tripping hazards, equipment failures, personnel mistakes, or moving equipment
such as carts, barrows, fork lis, cranes, or dollies. Do not allow materials, tools, or equipment in transit to contact any part of the fall arrest
system.
• Do not work under suspended loads.
WARNING
IMPORTANT

021519
MCS30 Rev B 4
2.1 Purpose: The Conned Space Davit is designed to work as part of a system to raise or lower a person or material to work in a conned
space for entry, retrieval, fall arrest applicaons, and material handling. The Conned Space Davit is a modular design and allows
mulple conguraons with oponal Davit Arms, Lower Mast Extensions, and Bases.
2.2 Applicaon Limits: The FallTech Conned Space Davit is a dynamic anchorage system that will vary in its performance depending upon
congured oset. Care should be taken to understand the capacity of the system and anchorage strength requirements.
2.3 System Capacity: The maximum capacity of the Conned Space Davit is one worker for conned space entry and egress, with the
worker weighing no more than 310lbs (140kg) including clothing, tools, etc. For rescue applicaons, the Conned Space Davit has a
maximum capacity of two workers with each worker weighing no more than 310lbs including clothing, tools, etc.
2.4 Davit Anchorage Strength: When using the FallTech Conned Space Davit with the 3-Piece Portable Base, the mounng surface must
support 5000lbs. When using the FallTech Conned Space Davit with any other base, please refer to the user instrucon manual
for the specic base.
2.0 Applicaon
3.0 System Requirements
3.1 Compability of Connectors: Connectors are considered to be compable with connecng elements when they have been designed to
work together in such a way that their sizes and shapes do not cause their gate mechanisms to inadvertently open regardless of how
they become oriented. Contact FallTech if you have any quesons about compability. Connectors must be compable
with the anchorage or other system components. Do not use equipment that is not compable. Non-compable connectors
may unintenonally disengage. Connectors must be compable in size, shape, and strength. Self-closing, self-locking snap hooks
and carabiners are specied by OSHA and ANSI Z359.12.
3.2 Compability of Components: Equipment is designed for use with approved components and subsystems only. Substuons or
replacements made with non-ANSI Z359 compliant components or subsystems may jeopardize compability of equipment and may aect
the safety and reliability of the complete system, see Figure 1. Ensure compability between the connectors if non-FallTech components
are used for fall protecon.
3.3 Connectors: Only use self-locking snap hooks, rebar hooks, and carabiners with this equipment. Only use connectors that are suitable to
each applicaon. Ensure all connecons are compable in size, shape and strength. Do not use equipment that is not compable. Visually
ensure all connectors close and lock completely. Connectors (snap hooks, rebar hooks, and carabiners) are designed for use only
as specied in this manual.
Figure 1 - Non-Compable Connecons

021519
MCS30 Rev B 5
4.0 Installaon and Use
4.1 General Rescue Requirements: The equipment specied in this manual is designed to work as part of a system to help facilitate non-entry
rescue and entry rescue from conned spaces.
Conned spaces vary in size, shape, conguraon, and hazard. The equipment/device(s) detailed in this manual may not be suitable
for use during some permit-required conned space entries. Hazards such as entanglement, electric arc, engulfment, and general li
obstrucons may interfere with safe rescue and cause greater harm to the entrant.
All conned space entries should be planned whenever possible in such a manner that any foreseeable hazard is migated and non-entry
rescue can be facilitated.
In the case that non-entry rescue is not feasible, a rescue plan must be in place that provides rescuers with knowledge about the specic
conned space hazards they may encounter during a rescue, training on appropriate rescue methods for the conned space they will be
entering, and the correct equipment and PPE to perform the entry rescue. Please reference OSHA code CFR 1926.1211 and ANSI
Z117.1-2016 for further details on employer responsibilies in preparing for both entry and non-entry rescue.
4.2 System Conguraons for Non-Entry Rescue Methods: When entering a permit-required conned space, non-entry rescue is required
unless retrieval equipment would increase the overall risk of entry or would not contribute to the rescue of the worker. Mechanical
devices must be available to retrieve personnel from vercal type permit spaces more than 5 feet deep. When using mechanical devices
for non-entry rescue, consideraon must be given to the means of entry/egress, the migaon of fall hazards and the method of
emergency retrieval.
4.2.1 Single Line – Winch Only – Entry/Egress Using Ladder
When a single mechanical device is used for non-entry rescue into a conned space it serves only as backup to the worker’s primary
entry/egress method. In most cases the primary means of entry/egress into a vercal conned space is a ladder. When using only a
winch as the backup to the entrant’s primary means of entry and egress, the aendant should take care to keep the winch line taut to
avoid any potenal overload due to a fall event on the winch line. The winch is not a fall arrest device and must not be subjected to fall
forces. The winch is for emergency retrieval only. See Figure 2.
4.2.2 Single Line – 3-Way Only – Entry/Egress Using ladder
When a single mechanical device is used for non-entry rescue into a conned space it serves only as backup to the worker’s primary
entry/egress method. In most cases the primary means of entry/egress into a vercal conned space is a ladder. When using an SRL-R
only as a back up to the worker’s primary means of entry and egress the device cable will pay freely in and out of the housing as
the entrant moves into the vercal conned space. In the event the entrant falls the SRL-R will arrest the fall and reduce fall forces
applied to the body. The aendant may then engage the backup emergency retrieval winch to raise the entrant out of the conned
space. The emergency retrieval winch is not to be used for ordinary entry/egress in and out of the conned space. See Figure 3.
DUCSC1.1
052715
052715
DUCSC4.1
051415
DUCSC1.1
052715
052715
DUCSC4.1
051415
Figure 2 - Single Line Winch Only – Entry/Egress Using Ladder Figure 3 - Single Line 3-Way Only – Entry/Egress using ladder

021519
MCS30 Rev B 6
4.2.3 Dual Line – Winch and SRD/Alternate PFAS - Entry/Egress Using Ladder
When a conned space has an exisng ladder but the aendant is unable to maintain a taut winch line as the entrant descends and
ascends from the conned space, it is possible to use a regular SRD or Fall Arrestor Connector Subsystem (FACSS) to provide protecon
from impacng and overloading the winch during a fall event.
In this case the PFAS provides fall protecon as the worker freely moves vercally, and the winch provides backup as the emergency
retrieval device from the conned space. See Figure 4.
4.2.4 Dual Line – Winch and 3-Way – Entry/Egress Using a Winch
When no alternate method of entry/egress (such as a ladder) exists the conned space entrant will be suspended, raised and lowered
with the winch line aached to a shoulder yoke or sternal D-Ring of a Full Body Harness. An SRL-R is then aached to the dorsal
D-ring of the Full Body Harness to provide fall arrest and emergency retrieval. Suspended workers are required to have a backup system
to their primary means of entry/egress that will limit fall forces to the body and provide emergency retrieval in the event of a winch
malfuncon. See Figure 5.
DUCSC1.1
052715
052715
DUCSC4.1
051415
DUCSC1.1
052715
052715
DUCSC4.1
051415
Figure 4
Dual Line – Winch and SRD/Alternate PFAS
Entry/Egress Using Ladder
Figure 5
Dual Line – Winch and 3-Way
Entry/Egress Using a Winch

021519
MCS30 Rev B 7
4.3 Davit Arm Assembly
4.3.1 12” to 29” Oset Davit Arm
The 12” to 29” Oset Davit Arm is shipped in a folded posion, see Figure 6. Remove the push buon pin as shown in Figure 7. Rotate the
arm into posion and align the top tube hole with the hole in the bracket, see Figure 8. Insert the push buon pin as shown in
Figure 9.
Figure 6 Figure 17 Figure 8 Figure 9
The Davit Arm is a dynamic anchorage system that will vary in its performance depending depending upon the congured oset. Care
should be taken to understand the capacity of the system and anchorage strength requirements; see Figure 10 for the load rangs for the
12” to 29” Oset Davit Arm.
PP1 PP2 PP3 PP4
3600 lbs*
(16 kN)
3600 lbs*
(16 kN)
3100 lbs*
(13.8 kN)
2500 lbs**
(11.1 kN)
1800 lbs
(8 kN)
1800 lbs
(8 kN)
1800 lbs
(8 kN)
1800 lbs
(8 kN)
1800 lbs
(8 kN)
1800 lbs
(8 kN)
1800 lbs
(8 kN)
1800 lbs
(8 kN)
5000 lbs*
(22.2 kN)
5000 lbs*
(22.2 kN)
5000 lbs*
(22.2 kN)
5000 lbs*
(22.2 kN)
AP
TP
BP
RP
Anchor
Point
Mast Pin Posion
PP1 PP2 PP3 PP4
11.75”
(298.5 mm)
13.5”
(342.9 mm)
16”
(406.4 mm)
18.5”
(469.9 mm)
19.25”
(489.0 mm)
22.0”
(558.8 mm)
25.5”
(647.7)
29.25”
(743.0 mm)
MIN
MAX
Davit Arm Oset Range
Mast Pin Posion
Acceptable Load Rangs
* Davit conguraon suitable for two-man rescue with a 5 to 1 safety factor.
** Davit conguraon suitable for two-man rescue with a 4 to 1 safety factor.
Figure 10 - 12” to 29” Oset Davit Arm Load Rangs

4.3.2 24” to 44” Oset Davit Arm
The 24” to 44” Oset Davit Arm is shipped parally disassembled, see Figure 11. Remove the detent pin as shown and insert the
extension tube into the arm sleeve, see Figure 12. Insert the detent pin into the desired Pin Posion as shown in Figure 13.
Figure 11 Figure 13Figure 12
PP1 PP2 PP3 PP4
1800 lbs
(8 kN)
1800 lbs
(8 kN)
1800 lbs
(8 kN)
1800 lbs
(8 kN)
1800 lbs
(8 kN)
1800 lbs
(8 kN)
1800 lbs
(8 kN)
1800 lbs
(8 kN)
1800 lbs
(8 kN)
1800 lbs
(8 kN)
1800 lbs
(8 kN)
1800 lbs
(8 kN)
5000 lbs*
(22.2 kN)
5000 lbs*
(22.2 kN)
5000 lbs*
(22.2 kN)
5000 lbs*
(22.2 kN)
AP
TP
BP
RP
Anchor
Point
Mast Pin Posion
PP1 PP2 PP3 PP4
27”
(685.8 mm)
29.3”
(744.2 mm)
32.3”
(820.4 mm)
35”
(889 mm)
35”
(889.0 mm)
38”
(965.2 mm)
41.5”
(1054.1)
45”
(1143.0 mm)
MIN
MAX
Davit Arm Oset Range
Mast Pin Posion
Acceptable Load Rangs
** Davit conguraon suitable for two-man rescue with a 4 to 1 safety factor.
Figure 14 - 24” to 44” Oset Davit Arm Load Rangs
The Davit Arm is a dynamic anchorage system that will vary in its performance depending upon the congured oset. Care should
be taken to understand the capacity of the system and anchorage strength requirements; see Figure 14 for the load rangs for the
24” to 44” Oset Davit Arm.
021519
MCS30 Rev B 8

4.4 3pc Portable Base Assembly (Applies to both base sizes)
Please see Table 2 in Appendix A for 3pc Portable Base compability.
The davit base legs are shipped in a dierent orientaon to opmize packaging and storage when not in use, Figure 15. To assemble, the
legs must be rotated from the packed posion to the proper orientaon for use. On both legs, remove the detent pins as shown in
Figure 16. Rotate the round tube of the leg to the use posion, as shown in Figure 17. Align the holes of the round tubes and reinsert
the detent pins, as shown in Figure 18.
Figure 15 Figure 16
Figure 17 Figure 18
Before inserng the legs into the base center secon, refer to the table in Figure 19 to match the Base Posion with the Pin Posion of
the Davit Arm. To install the Davit Base Legs, ensure the red thumb screws are loosened (turn counter-clockwise). Insert the legs into the
base center secon and determine the oset your applicaon requires; align the holes and insert the detent pins, Figure 20. Tighten the
red thumb screws (clockwise) to ensure they are locked in place as shown in Figure 21.
1 12 3 4 234
PP1 PP2 PP3 PP4
Yes No No No
Yes Ye s No No
Yes Yes Yes No
Yes Ye s Ye s Yes
1
2
3
4
Base
Posion
Base Posions
Davit Arm Pin Posion
Short Long
Narrow
Wide
Figure 19 - 3pc Portable Base Oset Davit Arm Pin Posion Compability Chart
IMPORTANT
021519
MCS30 Rev B 9

021519
MCS30 Rev B 10
Figure 20 Figure 21
4.5 Conned Space Davit System Assembly
Place the Portable Base in the locaon suitable for the applicaon. Insert the Lower Mast Extension, see Figure 22, into the Portable Base
sleeve with the posion liming bolt toward the front of the base as shown in Figure 23.
Li the Davit Arm and place if onto the Lower Mast Extension, see Figure 24. Ensure the bolt on the Lower Mast Extension ts into the
Davit Arm mang notch as shown in Figure 25.
Figure 24 Figure 25
Figure 22 Figure 23
