Festo SPC200 Series User manual

Manual
Function block
SPC200−PC for
Simatic S7
SPC200 Smart Positioning Controller
Manual
540 189
en 0609a
[710 241]

Contents and general instructions
I
Festo P.BE−SPC200−S7−PC−EN en 0609a
Original de. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Edition en 0609a. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Designation P.BE−SPC200−S7−PC−EN. . . . . . . . . . . . . . . . . . .
© (Festo AG&Co. KG, D73726 Esslingen, Federal Republic
of Germany, 2006)
Internet: http://www.festo.com
e−mail: [e-mail]
The reproduction, distribution and utilization of this docu
ment as well as the communicaton of its contents to others
without express authorization is prohibited. Offenders will
be held liable for the payment of damages. All rights reser
ved in the event of the grant of a patent, utility module or
design.

Contents and general instructions
II Festo P.BE−SPC200−S7−PC−EN en 0609a
PROFIBUS®is a registered trademark of PROFIBUS International.
SIMATIC®is a registered trademark of Siemens AG

Contents and general instructions
III
Festo P.BE−SPC200−S7−PC−EN en 0609a
Contents
Designated use V. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Basic principles of programmed software VI. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Target group VI. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Important user instructions VII. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
References to necessary SPC200 manuals IX. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
1. Installation of the function block 1−1. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
1.1 Incorporating the function block in your project 1−3. . . . . . . . . . . . . . . . . . . . . .
2. Function block description 2−1. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
2.1 Symbolic representation of the function block 2−3. . . . . . . . . . . . . . . . . . . . . . . .
2.2 Working method 2−3. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
2.3 Input parameters 2−4. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
2.4 Output parameters 2−6. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
2.5 Reaction to start 2−7. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
2.6 Reaction to reset 2−9. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
2.7 Fault word 2−11. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
2.8 Parameters of the SPC200 2−15. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Contents and general instructions
V
Festo P.BE−SPC200−S7−PC−EN en 0609a
Designated use
Function block SPC200−PC" serves for reading and writing
parameters of the SPC200 from a Simatic S7 controller with
PROFIBUS. For this purpose it uses the SPC200 parameter
channel (PC = parameter channel). The SPC200 must be
connected to the S7 by means of field bus module type
SPC200−COM−PDP.
Basic components and modules for the SPC200 are described
in the user manual type P.BE−SPC200−... . The safety
instructions specified in the manuals must always be
observed and the relevant components and modules must
only be used as intended. Please observe also the safety
instructions listed in the operating instructions for the
pneumatic components used. The SPC200 and the modules
and cables to be connected are only to be used as follows:
inaccordance with designated use
 only in industrial applications
 without any modifications by the user. Only the conver
sions or modifications described in the documentation
supplied with the product are permitted.
infaultless technical condition.
When used together with commercially available compo
nents, such as sensors and actuators, the specified limits for
pressures, temperatures, electrical data, torques etc. must be
observed. National and local safety regulations must also be
observed.
Note also the Siemens specifications regarding the use of
their PLC Simatic S7.

Contents and general instructions
VI Festo P.BE−SPC200−S7−PC−EN en 0609a
Basic principles of programmed software
Please note that it is not possible with the present state of
technology to create programmed software which functions
without problems and is compatible with all applications and
combinations intended by the user.
As a rule the software must therefore be used in the desig
nated manner as specified in the program description and in
the user instructions.
At the moment when the software is transferred or made
available, it is in a state in which it will function under normal
operating and application conditions.
Festo does not guarantee that the software will suffice for all
applications and purposes intended by the user, or that it will
function without problems when used with other programs,
or that it is compatible with these programs. The responsibil
ity for the correct selection and the consequences of using
the software within the scope of use defined by the user, as
well as for the intended and achieved results therefore lies
with the user. The same applies to the written material sup
plied with the software.
The use of the programmed software does not exempt you as
customer from your duties and responsibility for observing
and adhering to technical machine and safety regulations as
well as for a comprehensive functional check.
Target group
This manual is intended exclusively for technicians trained in
control and automation technology, who have experience in
installing, commissioning, programming and diagnosing
PROFIBUS−DP slaves.

Contents and general instructions
VII
Festo P.BE−SPC200−S7−PC−EN en 0609a
Important user instructions
Danger categories
This manual contains instructions on the possible dangers
which may occur if the product is not used correctly. These
instructions are marked (Warning, Caution, etc.), printed on a
shaded background and marked additionally with a picto
gram. A distinction is made between the following danger
warnings:
Warning
This means that failure to observe this instruction may
result in serious personal injury or damage to property.
Caution
This means that failure to observe this instruction may
result in personal injury or damage to property.
Please note
This means that failure to observe this instruction may
result in damage to property.
The following pictogram marks passages in the text which
describe activities with electrostatically sensitive compo
nents.
Electrostatically sensitive components may be damaged if
they are not handled correctly.

Contents and general instructions
VIII Festo P.BE−SPC200−S7−PC−EN en 0609a
Marking special information
The following pictograms mark passages in the text contain
ing special information.
Pictograms
Information:
Recommendations, tips and references to other sources of
information.
Accessories:
Information on necessary or sensible accessories for the
Festo product.
Environment:
Information on environment−friendly use of Festo products.
Text markings
·The bullet indicates activities which may be carried out in
any order.
1. Figures denote activities which must be carried out in the
numerical order specified.
 Hyphens indicate general activities.

Contents and general instructions
IX
Festo P.BE−SPC200−S7−PC−EN en 0609a
References to necessary SPC200 manuals
The following manuals are necessary for understanding the
user manual SPC200_PC (English versions):
 System Manual for the SPC200
Designation P.BE−SPC200−EN
Edition en 0503c or later
Order number 170 246
 Manual for the PROFIBUS−DP field bus module
Designation P.BE−SPC200−COM−PDP−EN
Edition en 0503b or later
Order number 188 893
The SPC200−PC user manual contains all necessary informa
tion on commissioning the SPC200_PC function block.
Siemens
When reference is made in this manual to documents from
Siemens, this means basically Step 7 version 5.1 (service
pack 1). Other versions of Step 7 may differ from that de
scribed in this manual.
Necessary firmware versions
Function block SPC200 requires the following firmware ver
sions:
 SPC200 firmware as from version 4.6
PROFIBUSmodule SPC200−COM−PDP as from version 2.0
 GSD file as from revised version 05.03.2003
 WinPISA as from version 4.31
Earlier versions of the SPC200 or PROFIBUS module do not
support communication with the function block.

Contents and general instructions
XFesto P.BE−SPC200−S7−PC−EN en 0609a

Installation of the function block
1−1Festo P.BE−SPC200−S7−PC−EN en 0609a
Chapter 1

1. Installation of the function block
1−2 Festo P.BE−SPC200−S7−PC−EN en 0609a
Contents
1. Installation of the function block 1−1. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
1.1 Incorporating the function block in your project 1−3. . . . . . . . . . . . . . . . . . . . . .

1. Installation of the function block
1−3
Festo P.BE−SPC200−S7−PC−EN en 0609a
1.1 Incorporating the function block in your project
Step 1
·Install a SPC200 in the Hardware Manager and incorpor
ate the parameter channel in the I/O configuration.
Step 2
·Dearchivate the project which contains the function block.
In order to do this, you must select the menu item [File]
[Dearchivate] in the Simatic Manager and specify the
zip−file:
 FB1_PKW.ZIP
Please note
Always use the Dearchivate" function of the Simatic
Manager in order to expand the zip−file.
Step 3
·Open the FB1_PKW project. Select the FB1 SPC200−PC"
in the folder Blocks" and copy it with [Edit] [Copy].
Step 4
·Change your project and paste the function block. If there
is already an FB1 in your project, you must assign a
different function block number to the function block
SPC200−PC.

1. Installation of the function block
1−4 Festo P.BE−SPC200−S7−PC−EN en 0609a
Step 5
·If this is not yet the case, add also the system function
blocks SFC14 and SFC15 to your project. These are
required by function block SPC200−PC.
Step 6
·Add the access to the FB1 to your sequence program. In
order to do this, you must specify an instance data block.
As this is not yet available, the STEP 7 software askes
whether this should be created. You must confirm this
question.
Caution
You require for one SPC200 only one instance data block.
With this instance data block all axes of the SPC200 can be
addressed.
For each additional SPC200 in the network you will require
another instance data block.
Rule:
Each PKW I/O module in the Hardware Manager requires one
intance data block.

Function block description
2−1Festo P.BE−SPC200−S7−PC−EN en 0609a
Chapter 2

2. Function block description
2−2 Festo P.BE−SPC200−S7−PC−EN en 0609a
Contents
2. Function block description 2−1. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
2.1 Symbolic representation of the function block 2−3. . . . . . . . . . . . . . . . . . . . . . . .
2.2 Working method 2−3. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
2.3 Input parameters 2−4. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
2.4 Output parameters 2−6. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
2.5 Reaction to start 2−7. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
2.6 Reaction to reset 2−9. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
2.7 Fault word 2−11. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
2.8 Parameters of the SPC200 2−15. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

2. Function block description
2−3
Festo P.BE−SPC200−S7−PC−EN en 0609a
2.1 Symbolic representation of the function block
Fig.2/1: Symbolic representation
The function block is created in LAD/FBD, but contains STL
elements. If you open the function block, please use the
representation FBD or LAD.
2.2 Working method
The function block has been designed asynchronously, i.e.
the processing of a read or write request covers several
accesses. By means of the input parameters, the function
block encodes the request in accordance with the PKW
protocol and transfers it to the SPC200 using the SFC15
DPWR_DAT" or SFC14 DPRD_DAT".
The reply received is transferred to the function block out
puts. When the transfer is finished, DONE=TRUE will be set.

2. Function block description
2−4 Festo P.BE−SPC200−S7−PC−EN en 0609a
2.3 Input parameters
Parameter Declaration Data
type
Memory
range
Description
Start INPUT BOOL I, Q, M, L, D,
Constant
Start transferring parameter value.
A rising edge 0 −−> 1 causes the input para
meters to be accepted and thereby triggers
the transfer of the parameter.
Prerequisites:
Done = TRUE and Error = FALSE.
Reset INPUT BOOL I, Q, M, L, D,
Constant
Resetting a fault
If there is a fault, a rising edge will cause all
internal data, as well as the output word and
the fault to be reset. If there is no fault, the
signal edge will be ignored.
LADDR_E INPUT WORD I, Q, M, L, D,
Constant
Planned starting address from the process
image input area of the PKW module of the
SPC200
 The address must be entered in hexadeci
mal form: Starting address 256:
LADDR_E:=W#16#100.
 LADDR_E and LADDR_A can but need not
have the same address.
LADDR_A INPUT WORD I, Q, M, L, D,
Constant
Planned starting address from the process
image output area of the PKW module of the
SPC200 (see LADDR_E).
RD_WR INPUT BOOL I, Q, M, L, D,
Constant
Defines whether the parameter is to be read
or written.
0 = The parameter is read out of the
SPC200.
1 = The parameter is written into the
SPC200.
PNU INPUT INT I, Q, M, L, D,
Constant
Selected parameter number.
Available parameters see manual for the field
bus module SPC200−COM−PDP.
