Fibocom NL652-EU-00 Series Instructions for use

Reproduction forbidden without Fibocom Wireless Inc. written authorization - All Rights Reserved.
FIBOCOM NL652-EU-00 Series Hardware User Manual Page 1 of 50
69100.1000.00.02.61.34_DEMO"
FIBOCOM NL652-EU-00 Series
Hardware User Manual
Version: V1.0.1
Date: 2019-12-06

Reproduction forbidden without Fibocom Wireless Inc. written authorization - All Rights Reserved.
FIBOCOM NL652-EU-00 Series Hardware User Manual Page 2 of 50
Applicability type
No. Product model Description
1 NL652-EU-00 MCP is 4+2，support MAIN_ANT, DIV_ANT

Reproduction forbidden without Fibocom Wireless Inc. written authorization - All Rights Reserved.
FIBOCOM NL652-EU-00 Series Hardware User Manual Page 3 of 50
Copyright
Copyright ©2020 Fibocom Wireless Inc. All rights reserved.
Without the prior written permission of the copyright holder, any company or individual is prohibited to
excerpt, copy any part of or the entire document, or transmit the document in any form.
Notice
The document is subject to update from time to time owing to the product version upgrade or other
reasons. Unless otherwise specified, the document only serves as the user guide. All the statements,
information and suggestions contained in the document do not constitute any explicit or implicit
guarantee.
Trademark
The trademark is registered and owned by Fibocom Wireless Inc.
Versions
Version Author Assessor Approver Update Date Description
V1.0.0 Tan Lefan Hu Wenkai Liu Ke 2019-09-11 Initial version
V1.0.1 Tan Lefan Hu Wenkai Liu Ke 2019-12-06
Modify RF power consumption.
Delete Network status indicate
function
Delete sim card hot plug function

Reproduction forbidden without Fibocom Wireless Inc. written authorization - All Rights Reserved.
FIBOCOM NL652-EU-00 Series Hardware User Manual Page 4 of 50
Content
Content ................................................................................................................................ 4
Figure Index ........................................................................................................................ 6
Table Index .......................................................................................................................... 7
1Introduction .................................................................................................................. 8
1.1 Document Introduction..................................................................................................8
1.2 Safety precautions........................................................................................................8
2Product Overview....................................................................................................... 10
2.1 Product Introduction ...................................................................................................10
2.2 Product Specification ..................................................................................................10
2.3 Functional Diagram .................................................................................................... 11
3Functional Interface ................................................................................................... 13
3.1 M.2 Key-B interface ....................................................................................................13
3.2 Pin function.................................................................................................................14
4Electrical characteristics ........................................................................................... 19
4.1 Power .........................................................................................................................19
4.2 Power supply..............................................................................................................19
4.3 Power consumption ....................................................................................................20
5Functional interface ................................................................................................... 23
5.1 Control interface .........................................................................................................23
5.1.1 Power on/off .................................................................................................................. 23
5.1.1.1 Power on ................................................................................................................................... 23
5.1.1.2 Power off ................................................................................................................................... 24
5.1.2 RESET .......................................................................................................................... 25
5.2(U)SIM card interface .................................................................................................26
5.2.1 (U)SIM pin definition...................................................................................................... 26
5.2.2 (U)SIM design requirements ......................................................................................... 27
5.3 USB interface .............................................................................................................28
6Low Power Consumption .......................................................................................... 29
6.1 Flight mode.................................................................................................................29
6.2 WAKEUP_OUT ..........................................................................................................29
6.3 Sleep mode ................................................................................................................29
6.3.1 USB Suspend................................................................................................................ 29

Reproduction forbidden without Fibocom Wireless Inc. written authorization - All Rights Reserved.
FIBOCOM NL652-EU-00 Series Hardware User Manual Page 5 of 50
6.4 Sleep Wakeup ............................................................................................................30
6.4.1 USB Remove Wakeup .................................................................................................. 30
6.4.2 WAKUP_OUT pin Wakeup ........................................................................................... 30
7RF interface................................................................................................................. 31
7.1 Operating band...........................................................................................................31
7.2 Output power..............................................................................................................31
7.3 Receive Sensitivity .....................................................................................................32
7.4 Antenna design ..........................................................................................................33
7.4.1 Antenna index ............................................................................................................... 33
7.4.2 Antenna reference design............................................................................................. 34
8Reliability .................................................................................................................... 36
8.1 Limiting voltage range.................................................................................................36
8.1.1 Absolute voltage range ................................................................................................. 36
8.1.2 Operating voltage range ............................................................................................... 36
8.2 Environment temperature range .................................................................................36
8.3 Environmental reliability requirements ........................................................................37
8.4 ESD characteristics ....................................................................................................37
9Structure specification............................................................................................... 39
9.1 Product appearance ...................................................................................................39
9.2 Structure dimension....................................................................................................39
9.3 Carrier and storage.....................................................................................................40
9.3.1 Storage Life ................................................................................................................... 40
9.4 Packing ......................................................................................................................40
9.4.1 Tray Package ................................................................................................................ 41
9.4.2 Tray size ........................................................................................................................ 42
10 Approval ............................................................................................................... 44
11 Appendix............................................................................................................... 45
11.1 GPRS and EGPRS Encoding Scheme .......................................................................45
11.2 Terms and acronyms ..................................................................................................47
11.3 Related Document......................................................................................................49
11.4 Reference Standards..................................................................................................49
11.5 Contact.......................................................................................................................50

Reproduction forbidden without Fibocom Wireless Inc. written authorization - All Rights Reserved.
FIBOCOM NL652-EU-00 Series Hardware User Manual Page 6 of 50
Figure Index
Figure 2-1 Functional Diagram......................................................................................................... 12
Figure 3-1 Pin Assignment (Top View Diagram) .............................................................................. 13
Figure 4-1 Recommend Power Design............................................................................................ 19
Figure 4-2 Power Limit ..................................................................................................................... 20
Figure 5-1 Power on Reference Design........................................................................................... 23
Figure 5-2 Power on Timing ............................................................................................................. 24
Figure 5-3 Power off Timing ............................................................................................................. 25
Figure 5-4 OC Driven Reset Reference Circuits.............................................................................. 25
Figure 5-5 Button Reset Reference Circuits .................................................................................... 26
Figure 5-6 Reset Timing................................................................................................................... 26
Figure 5-7 (U)SIM Card Connector without Detection Signal Reference Circuit............................. 27
Figure 7-1 Main and diversity Antenna Reference Circuit ............................................................... 35
Figure 9-1 Product Appearance ....................................................................................................... 39
Figure 9-2 Structure Dimension (Unit: mm) ..................................................................................... 40
Figure 9-3 Tray Packaging Process................................................................................................. 42
Figure 9-4 Tray Size (Unit: mm) ....................................................................................................... 43

Reproduction forbidden without Fibocom Wireless Inc. written authorization - All Rights Reserved.
FIBOCOM NL652-EU-00 Series Hardware User Manual Page 7 of 50
Table Index
Table 2-1 Product Specification.........................................................................................................11
Table 3-1 I/O Description.................................................................................................................. 14
Table 3-2 Pin function description .................................................................................................... 18
Table 4-1 Power Interface ................................................................................................................ 19
Table 4-2 Filter Capacitors Design of Power Supply ....................................................................... 20
Table 4-3 Power Consumption......................................................................................................... 22
Table 5-1 Control Signal................................................................................................................... 23
Table 5-2 Power off .......................................................................................................................... 24
Table 5-3 Module Reset ................................................................................................................... 25
Table 5-4 (U)SIM Card Pin ............................................................................................................... 27
Table 5-5 USB Pin Definition............................................................................................................ 28
Table 6-1 W_DISABLE# Pin Description ......................................................................................... 29
Table 6-2 Module Enter Flight Mode Ways ...................................................................................... 29
Table 6-3 W_DISABLE# Pin Description ......................................................................................... 29
Table 7-1 Operating Band ................................................................................................................ 31
Table 7-2 Output Power ................................................................................................................... 32
Table 7-3 Receive Sensitivity ........................................................................................................... 32
Table 7-4 Main Antenna Requirements............................................................................................ 34
Table 8-1 Absolute Voltage Range................................................................................................... 36
Table 8-2 Operating Voltage Range................................................................................................. 36
Table 8-3 Environment Temperature Range .................................................................................... 37
Table 8-4 Environmental Reliability Requirements .......................................................................... 37
Table 8-5 ESD Allowable Discharge Rang....................................................................................... 38
Table 10-1 Approval ......................................................................................................................... 44
Table 10-1 GPRS Encoding Scheme............................................................................................... 45
Table 10-2 Multilevel Multislot Allocation.......................................................................................... 46
Table 10-3 EGPRS Modulation and Encoding Method.................................................................. 46
Table 10-4 Terms and Acronyms...................................................................................................... 49

Reproduction forbidden without Fibocom Wireless Inc. written authorization - All Rights Reserved.
FIBOCOM NL652-EU-00 Series Hardware User Manual Page 8 of 50
1 Introduction
1.1 Document Introduction
This document describes the electrical characteristics, RF performance, structure size, application
environment, etc. of NL652-EU-00 module. With the assistance of the document and other instructions,
the developers can quickly understand the hardware functions of the NL652-EU-00 module and develop
products.
1.2 Safety precautions
By following the safety guidelines below, you can protect the personal safety and help protect the product
and work environment from potential damage. Product manufacturers need to communicate the
following safety instructions to end users. In case of failure to comply with these safety rules, Fibocom
will not be responsible for the consequences caused by the user’s misuse.
Road safety first! When you drive, do not use the handheld devices even if it has a
hand-free feature. Please stop and call!
Please turn off the mobile device before boarding. The wireless feature of the mobile
device is not allowed on the aircraft to prevent interference with the aircraft
communication system. Ignoring this note may result in flight safety issue or even
breaking the law.
When in a hospital or health care facility, please be aware of restrictions on the use of
mobile devices. Radio frequency interference may cause medical equipment to
malfunction, so it may be necessary to turn off the mobile device.
The mobile device does not guarantee that an effective connection can be made under
any circumstances, for example, when there is no prepayment for the mobile device or
the (U)SIM is invalid. When you encounter the above situation in an emergency,
remember to use an emergency call, while keeping your device turned on and in areas
where signal is strong.
Your mobile device receives and transmits RF signals when it is powered on. Radio
interference occurs when it is near televisions, radios, computers, or other electronic
devices.

Reproduction forbidden without Fibocom Wireless Inc. written authorization - All Rights Reserved.
FIBOCOM NL652-EU-00 Series Hardware User Manual Page 9 of 50
Keep the mobile device away from flammable gases. Turn off the mobile device when
near gas stations, oil depots, chemical plants or explosive workplaces. There is a
safety hazard in operating electronic equipment in any potentially explosive
environment.

Reproduction forbidden without Fibocom Wireless Inc. written authorization - All Rights Reserved.
FIBOCOM NL652-EU-00 Series Hardware User Manual Page 10 of 50
2 Product Overview
2.1 Product Introduction
The NL652-EU-00 series wireless module is a broadband wireless terminal product applicable to various
network formats and multi-bands include TDD-LTE/FDD-LTE/WCDMA/GSM.
2.2 Product Specification
Specification
Operating frequency
LTE FDD: Band 1,3,5,7,8,20,28
LTE TDD: Band 38,40,41
WCDMA/HSPA+: Band 1,5,8
GSM/GPRS/EDGE: 850/900/1800MHz
Data transmission
LTE FDD Rel.9
150Mbps DL/50Mbps UL (Cat 4)
; LTE Downlink MIMO
2x2, 4x2（support part of R10）
LTE TDD Rel.9
130Mbps DL/30.5Mbps UL (Cat 4); LTE Downlink MIMO
2x2, 4x2（support part of R10）
WCDMA Rel.8
WCDMA:384 kbps DL/384 kbps UL
DC-HSDPA+:42Mbps (Cat 24)/HSUPA:5.76Mbps (Cat 6)
GPRS/EDGE Rel.5
GPRS: 107kbps/85.6kbps UL (multi-slot class 33)
EDGE(E-GPRS):296kbps DL/236.8kbps UL
(multi-slot class 33)
Power 3.15V～4.3V (3.3V Typical)
Temperature
Normal: -30°C～+75°C
Extended: -40°C～+85°C
Storage: -45°C～+90°C
Power consumption
Power off leakage current: <20uA
Base current: <2mA
Sleep mode:≤3mA(USB sleep)
Idle mode: <20mA (USB sleep) ;<30mA (USB wake up)
Physical
characteristics
Package: M.2 Key-B
Size: (42.0±0.15)mm× (30.0±0.15)mm× (2.30±0.2)mm

Reproduction forbidden without Fibocom Wireless Inc. written authorization - All Rights Reserved.
FIBOCOM NL652-EU-00 Series Hardware User Manual Page 11 of 50
Weight: About 5.3g
Interface
Antenna Main x 1, DIV x 1
Functional Interface
W_DISABLE
Status Indicator
USB 2.0
WAKEUP_OUT
PCM
(U)SIM 3.0V/1.8V
I2C
Body SAR
Software
Protocol Stack Embedded TCP/IP and UDP/IP protocol stack
AT Command 3GPP TS 27.007 and 27.005, and proprietary FIBOCOM AT
Firmware update USB
SMS point-to-point MO, MT; cell broadcast; support Text and PDU modes
MMS service Need AP to realize MMS protocol
Ta ble 2-1 Product Specification
Note:
When the temperature is beyond the normal operating temperature range (-30 °C to + 75 °C),
the RF performance of the module may slightly exceed the 3GPP specification.
2.3 Functional Diagram
Functional diagram shows the main hardware features of the NL652-EU-00 series module:
W_DISABLE
Status Indicator
USB 2.0
WAKEUP_OUT
(U)SIM
PCM
I2C

Reproduction forbidden without Fibocom Wireless Inc. written authorization - All Rights Reserved.
FIBOCOM NL652-EU-00 Series Hardware User Manual Page 12 of 50
Body SAR
Antenna Interface
Baseband
PMIC
Transceiver
NAND
DDR2
SDRAM
Switch
Duplex
Transceiver
(U)SIM PCM I
2
CGPIOs
STATUS
RESET_N
PWRKEY
VCC
VBAT_RF
PA
Control
Control
IQ
ANT_MAIN
Tx
DRx
PRx
PCI Express M.2 Key-B interface
19.2M
XO
VDD_EXT USB
VBAT_BB
SAW
Switch
ANT_DIV
Figure 2-1 Functional Diagram

Reproduction forbidden without Fibocom Wireless Inc. written authorization - All Rights Reserved.
FIBOCOM NL652-EU-00 Series Hardware User Manual Page 13 of 50
3 Functional Interface
3.1 M.2 Key-B interface
The NL652-EU-00 series module use M.2 Key-B standard interface and has 75 pins in total.
Figure 3-1 Pin Assignment (Top View Diagram)
Note:
Notch is the breach of golden finger. The fucntions with * are in development.

Reproduction forbidden without Fibocom Wireless Inc. written authorization - All Rights Reserved.
FIBOCOM NL652-EU-00 Series Hardware User Manual Page 14 of 50
3.2 Pin function
Symbol
Description
IO Input/Output
DI Digital input
DO Digital output
PI Power input
PO Power output
AI Analog input
AO Analog output
OD Open drain
OC Open collector
Ta ble 3-1 I/O Description
The pin function description of NL652-EU-00 series module is shown as follow table:
Pin Pin Name I/O Level Description
1 CONFIG_3 - - Connected to GND internally. This module
is configured as WWAN-SSIC-0.
2 VCC PI
Vmax=4.3V
Vmin=3.15V
Vnorm=3.3V
Power supply
3 GND - - GND
4 VCC PI
Vmax=4.3V
Vmin=3.15V
Vnorm=3.3V
Power supply
5 GND - - GND
6 FULL_CARD_POWER_OFF# DI
V
IL
max=0.2V
VILmin=-0.3V
VIHmax=3.5V
VIHmin=1.6V
Power on/off signal. When it is at low
level, the module powers off. When it is at
high level, the module powers on.
(1.8V/3.3V)
7 USB D+ IO Conform to USB2.0
standard specification USB differential data bus +
8 W_DISABLE1# DI VILmax=0.2V flight mode control, pull up by default,

Reproduction forbidden without Fibocom Wireless Inc. written authorization - All Rights Reserved.
FIBOCOM NL652-EU-00 Series Hardware User Manual Page 15 of 50
Pin Pin Name I/O Level Description
VILmin=-0.3V
VIHmax=3.5V
VILmin=1.6V
active low.(1.8V/3.3V)
9 USB D- IO Conform to USB2.0
standard specification USB differential data bus -
10 LED1# OD
VOLmax=0.45V
VOHmin=1.35V
Network status indicator,
Reserved
11 GND - - GND
12 Notch - - Notch
13 Notch - - Notch
14 Notch - - Notch
15 Notch - - Notch
16 Notch - - Notch
17 Notch - - Notch
18 Notch - - Notch
19 Notch - - Notch
20 PCM_CLK DO
VOLmax=0.45V
VOHmin=1.35V
PCM clock,
Reserved
21 CONFIG_0 - -
Unconnected internally,This module is
configured as WWAN-SSIC-0.
22 PCM_IN DI
VILmin=-0.3V
VILmax=0.6V
VIHmin=1.2V
VIHmax=2.0V
PCM input,
Reserved
23 WAKEUP_OUT DO
VOLmax=0.45V
VOHmin=1.35V
Module wake up external device,
active low
24 PCM_OUT DO
VOLmax=0.45V
VOHmin=1.35V
PCM output,
Reserved
25 DPR DI
VILmin=-0.3V
VILmax=0.3V
VIHmin=1.6V
V
IH
max=2.0V
Body SAR detection (1.8V), internal
pull-up, active low
26 RESERVED - - -
27 GND - - GND

Reproduction forbidden without Fibocom Wireless Inc. written authorization - All Rights Reserved.
FIBOCOM NL652-EU-00 Series Hardware User Manual Page 16 of 50
Pin Pin Name I/O Level Description
28 PCM_SYNC IO
VOLmax=0.45V
VOHmin=1.35V
VILmin=-0.3V
VILmax=0.6V
VIHmin=1.2V
VIHmax=2.0V
PCM synchronization signal,
Reserved
29 NC - - -
30 USIM_RESET DO
For 1.8V (U)SIM:
VOLmax=0.45V
VOHmin=1.35V
For 3.0V (U)SIM:
VOLmax=0.45V
V
OH
min=2.55V
(U)SIM reset
31 NC - - -
32 USIM_CLK DO
For 1.8V (U)SIM:
VOLmax=0.45V
VOHmin=1.35V
For 3.0V (U)SIM:
VOLmax=0.45V
V
OH
min=2.55V
(U)SIM clock
33 GND - - GND
34 USIM_DATA IO
For 1.8V (U)SIM:
VILmax=0.6V
VIHmin=1.2V
VOLmax=0.45V
VOHmin=1.35V
For 3.0V (U)SIM:
VILmax=1.0V
VIHmin=1.95V
VOLmax=0.45V
VOHmin=2.55V
(U)SIM Data
35 NC - - -
36 USIM_VDD PO
For 1.8V (U)SIM:
Vmax=1.9V
Vmin=1.7V
For 3.0V (U)SIM:
Vmax=3.05V
Vmin=2.7V
IOmax=50mA
(U)SIM power supply，module support
1.8V and 3V (U)SIM card
37 NC - - -

Reproduction forbidden without Fibocom Wireless Inc. written authorization - All Rights Reserved.
FIBOCOM NL652-EU-00 Series Hardware User Manual Page 17 of 50
Pin Pin Name I/O Level Description
38 NC - - -
39 GND - - GND
40 I2C_SCL OD
VOLmax=0.45V
VOHmin=1.35V
VILmin=-0.3V
VILmax=0.6V
VIHmin=1.2V
VIHmax=2.0V
I2C clock, pull up internally
41 NC - - -
42 I2C_SDA OD
VOLmax=0.45V
VOHmin=1.35V
VILmin=-0.3V
VILmax=0.6V
VIHmin=1.2V
VIHmax=2.0V
I2C data, pull up internally
43 NC - - -
44 RESERVED - - -
45 GND - - GND
46 RESERVED - - -
47 NC - - -
48 RESERVED - - -
49 NC - - -
50 NC - - -
51 GND - - GND
52 NC - - -
53 NC - - -
54 NC - - -
55 NC - - -
56 NC - - -
57 GND - - GND
58 NC - - -
59 RESERVED - - -
60 NC - - -

Reproduction forbidden without Fibocom Wireless Inc. written authorization - All Rights Reserved.
FIBOCOM NL652-EU-00 Series Hardware User Manual Page 18 of 50
Pin Pin Name I/O Level Description
61 RESERVED - - -
62 RESERVED - - -
63 RESERVED - - -
64 RESERVED - - -
65 RESERVED - - -
66 USIM_DETECT DI
VILmin=-0.3V
VILmax=0.6V
VIHmin=1.2V
VIHmax=2.0V
(U)SIM card hot plug detection
RESERVED
67 RESET# DI - Module reset signal, active low
68 NC - - -
69 CONFIG_1 - - Connected to GND internally. This
module is configured as WWAN-SSIC-0.
70 VCC PI
Vmax=4.3V
Vmin=3.15V
Vnorm=3.3V
Power supply
71 GND - - GND
72 VCC PI
Vmax=4.3V
Vmin=3.15V
Vnorm=3.3V
Power supply
73 GND - - GND
74 VCC PI
Vmax=4.3V
Vmin=3.15V
Vnorm=3.3V
Power supply
75 CONFIG_2 - - Connected to GND internally. This
module is configured as WWAN-SSIC-0.
Table 3-2 Pin function description
Note:
Keep the unused pins floating.

Reproduction forbidden without Fibocom Wireless Inc. written authorization - All Rights Reserved.
FIBOCOM NL652-EU-00 Series Hardware User Manual Page 19 of 50
4 Electrical characteristics
4.1 Power
Table 4-1 show the power interface of NL652-EU-00 series module.
Pin Name
I/O
Pin Num
Description
VCC PI 2,4,70,72,74 Power supply,3.15V~4.3V, typical 3.3V
GND - 3,5,11,27,33,39,45,51,57,71,73 All GND pins must be grounded
Table 4-1 Power Interface
4.2 Power supply
The NL652-EU-00 series module needs to be powered by the VCC pin. The recommend power design is
shown in Figure 4-1:
Module
VCC
VBAT
8.2pF
33pF
100nF
1uF
220uF
220uF
++
Figure 4-1 Recommend Power Design
Table 4-1 is the filter capacitors design of power supply:
Recommended capacitor
Application
Description
220uF x 2 Regulating capacitor
Reduce power fluctuations during module
operation, low ESR Capacitor are
recommended, and the total capacitance in
parallel should not be less than 440uF. If
the current driving capacity of the power
supply (VBAT) is less than 2.0A, the
capacitance shall be no less than 1000uF.
1uF,100nF
Digital signal noise
Filter clock and digital signal interference

Reproduction forbidden without Fibocom Wireless Inc. written authorization - All Rights Reserved.
FIBOCOM NL652-EU-00 Series Hardware User Manual Page 20 of 50
Recommended capacitor
Application
Description
33pF 700, 850/900 MHz bands Filter low band RF interference
8.2pF
1700/1800/1900,2100/23
00,2500/2600MHz bands
Filter middle/high band RF interference
Table 4-2 Filter Capacitors Design of Power Supply
The power stability can ensure the normal operation of NL652-EU-00 series module. Special attention
requires when design circuit that the power supply ripple limit for the module is no more than 150mV (the
circuit ESR < 100mΩ). When the module is operating in GSM mode (Burst transmit), the maximum
operating current can reach 3A, and the power voltage needs to be at least 3.15V. Otherwise, the module
may power off or restart. The power limit is shown in Figure 4-2:
Burst Transmit Burst Transmit
VCC
3.15V min
Ripple≤150mV
Figure 4-2 Power Limit
4.3 Power consumption
The power consumption of NL652-EU-00 module in the case of VCC(3.3V) power supply is shown in the
following table.
Parameter
Mode
Condition
Average Current Typ. (mA)
Ioff
Power off
Power supply, module power off
0.015
ISleep
GSM
MFRMS 2(USB Sleep) 3
MFRMS 5(USB Sleep) 3
MFRMS 9(USB Sleep) 3
WCDMA
DRX=6(USB Sleep) 3
DRX=7(USB Sleep) 3
DRX=8(USB Sleep) 3
DRX=9(USB Sleep) 3
