Fibocom FG360-NA Installation instructions

FG360-NA Hardware Guide
Version: Draft V1.0.2
Date: 2021-05-06

Reproduction forbidden without Fibocom Wireless Inc. written authorization - All rights reserved.
FG360-NA Hardware Guide 2/28
Applicability Type
NO.
Product Model
Description

Reproduction forbidden without Fibocom Wireless Inc. written authorization - All rights reserved.
FG360-NA Hardware Guide 3/28
Copyright
Copyright © 2021 Fibocom Wireless Inc. All rights reserved.
Without the prior written permission of the copyright holder, any company or individual is prohibited to
excerpt, copy any part of or the entire document, or distribute the document in any form.
Notice
The document is subject to update from time to time owing to the product version upgrade or other reasons.
Unless otherwise specified, the document only serves as the user guide. All the statements, information
and suggestions contained in the document do not constitute any explicit or implicit guarantee.
Trademark
The trademark is registered and owned by Fibocom Wireless Inc.

Reproduction forbidden without Fibocom Wireless Inc. written authorization - All rights reserved.
FG360-NA Hardware Guide 4/28
Change History
Version
Author
Update Date
Remark
V1.0.2
Xu
Shaofeng
2021-05-06
Section 2.1.1: update band information
V1.0.1
Xu Xialin
2021-04-22
Section 2.1.1: add weight information
Section 2.3: Add section 2.3 antenna configuration
Section 3.1: Update pin name of Pin
193,175,157,148,139,130
Section 4.1: Update module appearance
Section 3.1: Add PCIe D as reserved and update pin
name of Pin 3,265,38,39,41,44
V1.0.0
Peng Yujun
Xu Xialin
2021-03-09
Initial version

Reproduction forbidden without Fibocom Wireless Inc. written authorization - All rights reserved.
FG360-NA Hardware Guide 5/28
Contents
1Foreword........................................................................................................................6
1.1 Introduction...................................................................................................................6
2Overview ........................................................................................................................6
2.1 Introduction...................................................................................................................6
2.1.1 Key Features................................................................................................................... 6
2.2 Application Framework .................................................................................................9
2.3 Antenna Configuration................................................................................................10
3Pin Definition ...............................................................................................................16
3.1 Pin Map ......................................................................................................................16
3.1.1 Table of Pin No. and Pin Name..................................................................................... 17
3.1.2 Pin Definition ................................................................................................................. 19
4Structural Specification ..............................................................................................27
4.1 Product Appearance ...................................................................................................27
4.2 Dimension of Structure ...............................................................................................27
4.3 Storage.......................................................................................................................28
4.4 Packing.......................................................................................................................28

Reproduction forbidden without Fibocom Wireless Inc. written authorization - All rights reserved.
FG360-NA Hardware Guide 6/28
1 Foreword
1.1 Introduction
The document describes the electrical characteristics, RF performance, dimensions and application
environment, etc. of FG360-NA (hereinafter referred to as FG360). With the assistance of the document
and other instructions, the developers can quickly understand the hardware functions of FG360 modules
and develop products.
2 Overview
2.1 Introduction
The FG360 series module is a 5G module which supports NSA and SA network architectures. The FG360
integrates core devices such as Baseband, Memory, PMU, Transceiver, and PA. It supports 5G NR Sub6,
FDD-LTE, TDD-LTE, and WCDMA long-distance communication modes. Supports uplink 2×2 MIMO and
downlink 4×4 MIMO multi-antenna configuration in SA mode. It also supports GNSS wireless positioning
technology. The FG360 is designed in an LGA package and is suitable for a variety of eMBB scenarios,
such as CPE, VR/AR, gateway, TV box, and intelligent monitoring.
2.1.1Key Features
Table 2-1 Key features
Performance
Description
Operating Band
LTE FDD: B2, B4, B7,B5, B12, B13,B14,B17,B25,B26,B30,B66, B71
LTE TDD: B41 ,B48
NR: n2,n25, n41, n66, n71
WCDMA/HSPA+: B2,B4,B5
GNSS
Support GPS, GLONASS, Galileo, BDS, QZSS
NR
3GPP Release 15
LTE
3GPP Release 15
UMTS
3GPP Release 8
Feature
NR:
DL 4×4 MIMO: n2,n25, n41, n66
UL 2×2MIMO: n41

Reproduction forbidden without Fibocom Wireless Inc. written authorization - All rights reserved.
FG360-NA Hardware Guide 7/28
LTE:
DL 4×4MIMO: B2, B4, B7, B25,B30,B66
NSA and SA supported
SRS: n41, Support: 1T2R, 1T4R, 2T4R
HPUE: B41, n41
Data Transmission
SA 5G/NR Sub-6 Peak
DL 4.67Gbps/UL 1.25Gbps
NSA Peak
DL 3.74Gbps/UL 700Mbps
LTE
DL 1.6Gbps (CAT19)/UL 211Mbps (CAT18)
UMTS/HSPA+
DL UMTS: 384kbps/UL 384 kbps
DL DC-HSPA+: 42 Mbps (CAT24)/UL 11.5Mbps
(CAT7)
Power Supply
DC: 3.3~4.4V, typical voltage: 3.8V
Antenna Type:
External
Antenna Gain:
<3.76dBi
Temperature
Normal operating temperature: -30~75℃1
Extended operating temperature: -40~85℃2
Storage temperature: -40~85℃
Physical
characteristics
Dimension: 41 mm×44mm×2.75 mm
Package: 430 pin LGA
Weight: about 12.0 g
CPU
ARM Cortex-A55, quad core, up to 2.0 GHz
Memory
2GB LPDDR4x+32GB eMMC Flash
Interface
USB Interface
USB2.0 high speed (HS) interface, data transmission rate up to 480Mbps
USB3.0 Super-speed (SS) interface, data transmission rate up to 5Gbps
PCIe Interface
PCIe Gen3 2Lane×1, PCIe Gen3 1Lane×2 (PCIe only support RC mode)
SIM Interface
Dual SIM: 1.8V/3V
SIM1: USIM
SIM2: ESIM/USIM
I2C
One set of I2C interface, data transmission rate up to 400Kbit/s
ADCs
A/D conversion channel, Voltage Range: 0~1.45V
Software
Firmware update
USB/PCIe/FOTA
Operating System
Linux/Android/Windows

Reproduction forbidden without Fibocom Wireless Inc. written authorization - All rights reserved.
FG360-NA Hardware Guide 8/28
Note：
1. When temperature keeps in the range of -30~75°C, the module can work normally. Module
performance meets the 3GPP specifications.
2. When temperature keeps in the range of -40~85°C, module performance may be slightly out of
3GPP specifications.

Reproduction forbidden without Fibocom Wireless Inc. written authorization - All rights reserved.
FG360-NA Hardware Guide 9/28
2.2 Application Framework
The application framework below shows the main hardware functions of the FG360 module:
Baseband
RF transceiver
PMU
Memory
Peripheral interface
Main PMU
ET TRX Blocks
Transceiver
DRF
RFFE
RFFE
RX
TX
Baseband
eMCP
eMMC
LPDDR4X
BBCLK
26MHz
RFCLK
26MHz
Sleep CLK
32KHz
SPMI
ANT0 ANT1 ANT2 ANT3 ANT4 ANT5 GNSS
PWRKEY
RESET_N
VBAT
JTAG
USIM1 SDIO PCIe3.0
Coex
UART I2S
SGMII
GPIO/EINT USB2.0/3.0 UART
eSIM
I2C
SPI ADCs MIPI DSI
26MHz
Crystal
Sub PMU
Figure 2-1 Hardware block diagram

Reproduction forbidden without Fibocom Wireless Inc. written authorization - All rights reserved.
FG360-NA Hardware Guide 10/28
2.3 Antenna Configuration
FG360 module supports seven antennas and the configuration is as below table:
PAD
Function
Description
Band
Configuration(TX)
Band
Configuration(RX)
Frequency
Range(MHz)
130
LMHB TRX
B2/4/5/7/12/13/14/17/
25/30/41/66/71
n2/25/41/66/71
B2/4/5/7/12/13/14/17/25/30/
41/66/71
n2/25/41/66/71
617~2690
175
41TRx+MHB/UCB/
LAA Rx
B41
n41
B2/4/7/25/30/41/48/66
n2/25/41/66
1710~5925
157
MHB/UCB/LAA Rx
Only SRS
B2/4/7/25/30/41/48/66
n2/25/41/66
1930~5925
139
LMHB Rx
Only SRS
B2/4/5/7/12/13/14/17/25/30/
41/66/71
n2/25/41/66/71
617~2690
148
Reserved
193
Reserved
199
GNSS
GNSS receive
2.4 Waring
2.4.1 Important Notice to OEM integrators
1. This module is limited to OEM installation ONLY.
2. This module is limited to installation in fixed applications, according to Part 2.1091(b).
3. The separate approval is required for all other operating configurations, including portable
configurations with respect to Part 2.1093 and different antenna configurations
4. For FCC Part 15.31 (h) and (k): The host manufacturer is responsible for additional testing to verify
compliance as a composite system. When testing the host device for compliance with Part
15 Subpart B, the host manufacturer is required to show compliance with Part 15 Subpart B while the
transmitter module(s) are installed and operating. The modules should be transmitting and the evaluation
should confirm that the module's intentional emissions are compliant (i.e. fundamental and out of band
emissions). The host manufacturer must verify that there are no additional unintentional emissions other
than what is permitted in Part 15 Subpart B or emissions are complaint with the transmitter(s) rule(s).
The Grantee will provide guidance to the host manufacturer for Part 15 B requirements if needed.

Reproduction forbidden without Fibocom Wireless Inc. written authorization - All rights reserved.
FG360-NA Hardware Guide 11/28
Important Note
notice that any deviation(s) from the defined parameters of the antenna trace, as described by the
instructions, require that the host product manufacturer must notify to Fibocom Wireless Inc. that they
wish to change
the antenna trace design. In this case, a Class II permissive change application is required to be filed
by the USI, or the host manufacturer can take responsibility through the change in FCC ID (new
application) procedure followed by a Class II permissive change application.
End Product Labeling
When the module is installed in the host device, the FCC/IC ID label must be visible through a window
on the final device or it must be visible when an access panel, door or cover is easily re-moved. If not, a
second label must be placed on the outside of the final device that contains the following text: “Contains
FCC ID: ZMOFG360NA”
“Contains IC: 21374-FG360NA “
The FCC ID/IC ID can be used only when all FCC/IC compliance requirements are met.
Antenna Installation
(1) The antenna must be installed such that 20 cm is maintained between the antenna and users,
(2) The transmitter module may not be co-located with any other transmitter or antenna.
(3) Only antennas of the same type and with equal or less gains as shown below may be used with this
module. Other types of antennas and/or higher gain antennas may require additional authorization for
operation.
(4)The max allowed antenna gain is 3.76dBi for external monopole antenna.
In the event that these conditions cannot be met (for example certain laptop configurations or co-location
with another transmitter), then the FCC/IC authorization is no longer considered valid and the FCC ID/IC
ID cannot be used on the final product. In these circumstances, the OEM integrator will be responsible
for re-evaluating the end product (including the transmitter) and obtaining a separate FCC/IC
authorization.
Manual Information to the End User
The OEM integrator has to be aware not to provide information to the end user regarding how to install or
remove this RF module in the user’s manual of the end product which integrates this module. The end
user manual shall include all required regulatory information/warning as show in this manual.

Reproduction forbidden without Fibocom Wireless Inc. written authorization - All rights reserved.
FG360-NA Hardware Guide 12/28
2.4.2 FCC Statement
Federal Communication Commission Interference Statement
This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions:
(1) This device may not cause harmful interference, and (2) this device must accept any interference
received, including interference that may cause undesired operation.
This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant
to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful
interference in a residential installation. This equipment generates, uses and can radiate radio frequency
energy and, if not installed and used in accordance with the instructions, may cause harmful interference
to radio communications. However, there is no guarantee that interference will not occur in a particular
installation. If this equipment does cause harmful interference to radio or television reception, which
can be determined by turning the equipment off and on, the user is encouraged to try to correct the
interference by one of the following measures:
- Reorient or relocate the receiving antenna.
- Increase the separation between the equipment and receiver.
- Connect the equipment into an outlet on a circuit different from that to which the receiver is connected.
- Consult the dealer or an experienced radio/TV technician for help.
Any changes or modifications not expressly approved by the party responsible for compliance could void
the user's authority to operate this equipment. This transmitter must not be co-located or operating in
conjunction with any other antenna or transmitter.
This device is intended only for OEM integrators under the following
conditions: (For module device use)
1) The antenna must be installed such that 20 cm is maintained between the antenna and users, and
2) The transmitter module may not be co-located with any other transmitter or antenna.
As long as 2 conditions above are met, further transmitter test will not be required. However, the
OEM integrator is still responsible for testing their end-product for any additional compliance
requirements required with this module installed.
Radiation Exposure Statement
This equipment complies with FCC radiation exposure limits set forth for an uncontrolled environment.
This equipment should be installed and operated with minimum distance 20 cm between the radiator &
your body.

Reproduction forbidden without Fibocom Wireless Inc. written authorization - All rights reserved.
FG360-NA Hardware Guide 13/28
2.4.3 IC Statement
Industry Canada Statement
This device complies with Industry Canada’s licence-exempt RSSs. Operation is subject to the
following two conditions:
(1) This device may not cause interference; and
(2) This device must accept any interference, including interference that may cause undesired
operation of the device.
Le présent appareil est conforme aux CNR d'Industrie Canada applicables aux appareils radio exempts
de licence. L'exploitation est autorisée aux deux conditions suivantes:
(1) l'appareil ne doit pas produire de brouillage, et
(2) l'utilisateur de l'appareil doit accepter tout brouillage radioélectrique subi, même si le brouillage est
susceptible d'en compromettre le fonctionnement."
Radiation Exposure Statement
This equipment complies with IC radiation exposure limits set forth for an uncontrolled environment. This
equipment should be installed and operated with minimum distance 20 cm between the radiator & your
body.
Déclaration d'exposition aux radiations:
Cet équipement est conforme aux limites d'exposition aux rayonnements ISED établies pour un
environnement non contrôlé. Cet équipement doit être installé et utilisé avec un minimum de 20 cm de
distance entre la source de rayonnement et votre corps.
This device is intended only for OEM integrators under the following
conditions: (For module device use)
1) The antenna must be installed such that 20 cm is maintained between the antenna and users, and
2) The transmitter module may not be co-located with any other transmitter or antenna.
As long as 2 conditions above are met, further transmitter test will not be required. However, the
OEM integrator is still responsible for testing their end-product for any additional compliance
requirements required with this module installed.
Cet appareil est conçu uniquement pour les intégrateurs OEM dans les
conditions suivantes: (Pour utilisation de dispositif module)

Reproduction forbidden without Fibocom Wireless Inc. written authorization - All rights reserved.
FG360-NA Hardware Guide 14/28
1) L'antenne doit être installée de telle sorte qu'une distance de 20 cm est respectée entre l'antenne et
les utilisateurs, et
2) Le module émetteur peut ne pas être coïmplanté avec un autre émetteur ou antenne.
Tant que les 2 conditions ci-dessus sont remplies, des essais supplémentaires sur l'émetteur ne
seront pas nécessaires. Toutefois, l'intégrateur OEM est toujours responsable des essais sur son
produit final pour toutes exigences de conformité supplémentaires requis pour ce module installé.
IMPORTANT NOTE:
In the event that these conditions can not be met (for example certain laptop configurations or colocation
with another transmitter), then the Canada authorization is no longer considered valid and the IC ID can
not be used on the final product. In these circumstances, the OEM integrator will be responsible for re-
evaluating the end product (including the transmitter) and obtaining a separate Canada authorization.
NOTE IMPORTANTE:
Dans le cas où ces conditions ne peuvent être satisfaites (par exemple pour certaines configurations
d'ordinateur portable ou de certaines co-localisation avec un autre émetteur), l'autorisation du
Canada n'est plus considéré comme valide et l'ID IC ne peut pas être utilisé sur le produit final. Dans
ces circonstances, l'intégrateur OEM sera chargé de réévaluer le produit final (y compris l'émetteur)
et l'obtention d'une autorisation distincte au Canada.
End Product Labeling
This transmitter module is authorized only for use in device where the antenna may be installed such
that 20 cm may be maintained between the antenna and users. The final end product must be
labeled in a visible area with the following: “Contains IC: 21374-FG360NA”.
Plaque signalétique du produit final
Ce module émetteur est autorisé uniquement pour une utilisation dans un dispositif où l'antenne
peut être installée de telle sorte qu'une distance de 20cm peut être maintenue entre l'antenne et les
utilisateurs. Le produit final doit être étiqueté dans un endroit visible avec l'inscription suivante:
"Contient des IC: 21374-FG360NA ".
Manual Information To the End User
The OEM integrator has to be aware not to provide information to the end user regarding how to

Reproduction forbidden without Fibocom Wireless Inc. written authorization - All rights reserved.
FG360-NA Hardware Guide 15/28
install or remove this RF module in the user’s manual of the end product which integrates this
module.
The end user manual shall include all required regulatory information/warning as show in this
manual.
Manuel d'information à l'utilisateur final
L'intégrateur OEM doit être conscient de ne pas fournir des informations à l'utilisateur final quant à
la façon d'installer ou de supprimer ce module RF dans le manuel de l'utilisateur du produit final qui
intègre ce module.
Le manuel de l'utilisateur final doit inclure toutes les informations réglementaires requises et
avertissements comme indiqué dans ce manuel.

Reproduction forbidden without Fibocom Wireless Inc. written authorization - All rights reserved.
FG360-NA Hardware Guide 16/28
3 Pin Definition
The FG360 module applies LGA interface with 430 pins.
3.1 Pin Map
392
391
263
260
257
254
251
248
245
242
239
236
233
230
227
224
221
218
215
212
209
206
203
200
197
Power Pins GND Pins GPIO Pins RESERVED/NC Pins
390
389
PCIe Pins LCD Pins (U)SIM Pins USB Pins
I2C Pins
BT&WIFI Pins
ADC Pins UART Pins SPI Pins ANT Pins SDIO Pins
299 300 301 302 303 304 305 306 307
308 309 310 311 312 313 314 315 316
317 318 319 320 321 322 323 324 325
326 327 331 332
328 329 330 333 334
335 336 340 341
337 338 339 342 343
344 345 349 350
346 347 348 351 352
353 354 355 356 357 358 359 360 361
362 363 364 365 366 367 368 369 370
371 372 373 374 375 376 377 378 379
380 381 382 383 384 385 386 387 388
65
68
71
74
77
80
83
86
89
92
95
98
101
104
107
110
113
116
119
122
125
128
131
64
67
70
73
76
79
82
85
88
91
94
97
100
103
106
109
112
115
118
121
124
127
130
132
264
262
259
256
253
250
247
244
241
238
235
232
229
226
223
220
217
214
211
208
205
202
199
196
193 190 187
184 181 178
175 172
166 163 160
157 154 151
148 145 142
169
139 136 133
195
194 191 188
185 182 179
176 173
167 164 161
158 155 152
149 146 143
170
140 137 134
192 189 186
183 180 177
174 171 168
165 162 159
156 153 150
147 144 141
138 135
298 297 296
295 294 293
292 291 290
289 288 287
286 285 284
283 282
281 280 279
278 277 276
275 274 273
272 271 270
269 268 267
266 265
60 57 54
51 48 45
39 36
30 27 24
21 15
12
9 6 3
62 59 56
53 50 47
44 41
35 32 29
26 23
17 14 11
38
8 5 2
61 58 55
52 49 46
43 40
34 31 28
25 22
16 13 10
37
7 4 1
63
237
234
231
228
225
222
219
216
213
210
207
204
201
258
255
252
249
246
243
240
198
261
90
93
96
99
102
105
108
111
114
117
120
123
126
69
72
75
78
81
84
87
129
66
19
20
SGMII Pins
18
33 42
GRFC&RFFE I2S Pins
CTL Pins CLOCK Pins
430
429
428
427
426
425
424
423
422
421
420
419
418
417
416
415
414
413
412
393
394
395
396
397
398
399
400
401
402
403
404
405
406
407
408
409
410
411
Figure 3-1 Pin map
Note：
The pin "RESERVED" means that the position pin is reserved and does not need to be connected.

Reproduction forbidden without Fibocom Wireless Inc. written authorization - All rights reserved.
FG360-NA Hardware Guide 17/28
3.1.1 Table of Pin No. and Pin Name
Table 3-1 Table of pin no. and pin name
No.
PIN Name
No.
PIN Name
No.
PIN Name
No.
PIN Name
No.
PIN Name
1
PWRKEY
2
PON_1
3
CLK_OUT
4
SYS_RESIN_N
5
SPI0_MISO
6
SPI0_CSB
7
SIM1_VDD
8
SPI0_MOSI
9
SPI0_CLK
10
SIM1_DATA
11
SIM2_RST
12
SIM2_DATA
13
SIM1_CLK
14
SIM1_DET
15
SIM2_CLK
16
SIM1_RST
17
SGMII_1_TXN
18
SIM2_VDD
19
GND
20
SGMII_1_TXP
21
SGMII_0_TXP
22
SGMII_1_RXN
23
RESERVED
24
SGMII_0_TXN
25
SGMII_1_RXP
26
PCIE_B_LN0_TXN
27
EINT17
28
GBE0_RST
29
PCIE_B_LN0_TXP
30
PCIE_B_LN0_RXP
31
GND
32
RESERVED
33
PCIE_B_LN0_RXN
34
PCIE_A_CLKN
35~36
GND
37
PCIE_A_CLKP
38
PCIE_D_LN0_TXP
39
PCIE_D_LN0_TXN
40
PCIE_A_LN0_TXN
41
PCIE_D_LN0_RXP
42
GND
43
PCIE_A_LN0_TXP
44
PCIE_D_LN0_RXN
45
SDC_CLK
46
PCIE_A_LN0_RXN
47
SDC_CMD
48
RESERVED
49
PCIE_A_LN0_RXP
50
GND
51
SDC_DATA2
52
GND
53
SDC_DATA1
54
SDC_DATA3
55
SSUSB_TXN
56
SDC_DATA0
57
VBUS_DET
58
SSUSB_TXP
59
USB_DM
60
USB_ID
61
SSUSB_RXN
62
USB_DP
63
SSUSB_RXP
64
AP_URTS1
65
GBE1_INT
66
MDC
67
PCIE_B_PEWAKEN
68
G3BE1_RST
69
MDIO
70
PCIE_B_CLKREQN
71
LSCE0B
72
LSDA
73
AP_URXD1
74
LSDI
75
LSA0
76
PCIE_B_PERSTN
77
AP_UTXD1
78
LRSTB
79
AP_UCTS1
80
LSCK
81~83
GND
84~89
VBAT_RF
90~92
GND
93
PCM0_SYNC
94
I2S0_MCK
95
PCM0_DI
96
PCM0_CLK
97
PCM0_DO
98
CDC_RESET_N
99
PTA_TX
100
CDC_INT1_N
101
I2S0_BCK
102
PTA_RX
103
I2S0_DO
104
I2S0_DI
105
I2S0_LRCK
106
NET_STATUS
107
AUDIO_PWR_EN
108
STATUS
109
W_DISABLE
110
NET_MODE
111
SLEEP_IND
112
I2C_SCL0
113
WAKEUP_IN
114
ISINK1
115
I2C_SDA0
116
ANTCTL3
117
IRIG_B
118~119
GND
120
GPS_PPS
121
NC
122
GND
123
EINT20
124~125
GND
126
DBG_UART_RX
127~128
GND
129
DBG_UART_TX
130
ANT8_M
131~134
GND
135
BT_UTXD
136~137
GND
138
BT_URXD
139
ANT7_D
140
GND
141
DSI_TE
142~143
GND
144
EINT16
145~147
GND
148
ANT6
149
GND
150
BT_PRI_RXD
151~152
GND
153
BT_ACT_TXD
154~155
GND
156
DISP_PWM
157
ANT5_M2
158
GND
159
USB_DRVBUS
160~161
GND
162
GPIO78/
PCIE_D_CLKREQN
163~164
GND

Reproduction forbidden without Fibocom Wireless Inc. written authorization - All rights reserved.
FG360-NA Hardware Guide 18/28
No.
PIN Name
No.
PIN Name
No.
PIN Name
No.
PIN Name
No.
PIN Name
165
NC
166
NC
167
GND
168
NC
169~170
GND
171
NC
172~173
GND
174
NC
175
ANT3_M1
176
GND
177
NC
178~179
GND
180
LCD_PWR_EN2
181~182
GND
183
TDI
184
NC
185
GND
186
TCK
187~188
GND
189
TDO
190~192
GND
193
ANT1
194~197
GND
198
MIPI1_D_SDATA
199
ANT10_GNSS
200
GND
201
MIPI1_D_SCLK
202~203
GND
204
ANTCTL2
205
NC
206
GND
207
ANTCTL1
208
GND
209
GPIO76/
PCIE_D_PERSTN
210
ANTCTL0
211
SDIO_VDD
212
EINT15
213~215
GND
216
MIPI2_D_SDATA
217
RESERVED
218
GND
219
MIPI2_D_SCLK
220~222
GND
223
RESERVED
224
GND
225
VDD_EXT_1V8
226~228
GND
229
RESERVED
230
GND
231
NC
232~234
GND
235
RESERVED
236
GND
237
RESERVED
238~239
GND
240~241
RESERVED
242
GND
243
RESERVED
244~245
GND
246~247
RESERVED
248
GND
249
ADC0
250~251
GND
252
ADC1
253
RESERVED
254
GND
255
NC
256~258
GND
259
RESERVED
260
GND
261
VBAT_BB
262
GND
263~264
VBAT_BB
265
PCIE_D_CLKN
266
GND
267
SIM2_DET
268
SGMII_0_RXP
269
SGMII_0_RXN
270
SGMII_PWR_EN1
271
PCIE_B_CLKP
272
PCIE_B_CLKN
273
USB_BOOT
274
PCIE_A_PEWAKEN
275
PCIE_A_PERSTN
276
PCIE_A_CLKREQN
277
GND
278
GBE0_INT
279
EINT18
280
SDC_DET
281
SD_PWR_EN
282
BT_URTS
283
BT_UCTS
284
GND
285
GPIO77/
PCIE_D_PEWAKEN
286
WIFI_GPIO1
287
WLAN_ACT
288
LCM_RST
289
GND
290
NC
291
WIFI_GPIO2
292
NC
293
RESERVED
294
NC
295
TRST_N
296
TMS
297
SYSRSTB
298
LCD_PWR_EN1
299~392
GND
393
PCIE_C_LN0_RXN
394
PCIE_C_LN0_RXP
395
PCIE_C_LN0_TXP
396
PCIE_C_LN0_TXN
397~398
GND
399
PCIE_C_CLKP
400
PCIE_C_CLKN
401
PCIE_C_PERSTN
402
PCIE_C_CLKREQN
403
PCIE_C_PEWAKEN
404
DSI0_D0P
405
DSI0_D0N
406
DSI0_CKN
407
DSI0_CKP
408
DSI0_D1N
409
DSI0_D1P
410~425
NC
426
RESERVED
427
RESERVED
428
RESERVED
429
RESERVED
430
RESERVED

Reproduction forbidden without Fibocom Wireless Inc. written authorization - All rights reserved.
FG360-NA Hardware Guide 19/28
3.1.2 Pin Definition
Table 3-2 IO Parameter definition
Type
Description
PI
Power Input
PO
Power Output
DI
Digital Input
DO
Digital Output
DIO
Digital Input/Output
AI
Analog Input
AO
Analog Output
AIO
Analog Input/Output
OD
Open Drain
PU
Internal pull up
PD
Internal pull down
Hi-Z
High impedance
Table 3-3 LGA pin description
Pin Name
Pin No.
Type
Power Domain
Reset Value
Pin Description
Power
VBAT_BB
261 263, 264
PI
-
-
Baseband power input
VBAT_RF
84, 85, 86, 87,
88, 89
PI
-
-
RF power input
VDD_EXT_1V8
225
PO
-
-
1.8V power output
USB
SSUSB_TXN
55
AO
-
-
USB super speed transmit
data minus
SSUSB_TXP
58
AO
-
-
USB super speed transmit
data plus
SSUSB_RXN
61
AI
-
-
USB super speed receive data
minus
SSUSB_RXP
63
AI
-
-
USB super speed receive data
plus
USB_DM
59
AIO
-
-
USB high speed data minus
USB_DP
62
AIO
-
-
USB high speed data plus
VBUS_DET
57
DI
-
-
USB VBUS detection
USB_DRVBUS
159
DO
VDD_EXT_1V8
PD
USB OTG power enable
USB_ID
60
DI
VDD_EXT_1V8
PD
USB ID
USIM

Reproduction forbidden without Fibocom Wireless Inc. written authorization - All rights reserved.
FG360-NA Hardware Guide 20/28
Pin Name
Pin No.
Type
Power Domain
Reset Value
Pin Description
SIM1_VDD
7
PO
-
-
SIM1 power supply,3V/1.8V
SIM1_DATA
10
DIO
SIM1_VDD
PD
SIM1 data input/output
SIM1_CLK
13
DO
SIM1_VDD
PD
SIM1 clock signal
SIM1_RST
16
DO
SIM1_VDD
PD
SIM1 reset signal
SIM1_DET
14
DI
VDD_EXT_1V8
PD
SIM1 detect signal
SIM2_VDD
18
PO
-
-
SIM2 power supply,3V/1.8V,
Reserved
SIM2_DATA
12
DIO
SIM2_VDD
PD
SIM2 data input/output,
Reserved
SIM2_CLK
15
DO
SIM2_VDD
PD
SIM2 clock signal, Reserved
SIM2_RST
11
DO
SIM2_VDD
PD
SIM2 reset signal, Reserved
SIM2_DET
267
DI
VDD_EXT_1V8
PD
SIM2 detect, Reserved
GPIO
W_DISABLE
109
DI
VDD_EXT_1V8
PD
Module airplane mode control
signal
WAKEUP_IN
113
DI
VDD_EXT_1V8
PD
Module wake up input from
host
NET_STATUS
106
DO
VDD_EXT_1V8
PD
Module network status
indication
NET_MODE
110
DO
VDD_EXT_1V8
PD
Module network mode
indication
SLEEP_IND
111
DO
VDD_EXT_1V8
PD
Module output to wake up
host
STATUS
108
DO
VDD_EXT_1V8
PD
Module current working status
indication
IRIG_B
117
DO
VDD_EXT_1V8
PD
B code output
GPS_PPS
120
DO
VDD_EXT_1V8
PD
PPS signal output
ISINK1
114
AI
VBAT_BB
HI-Z
LED negative drive signal
ANT
ANT1
193
AIO
-
-
UCB TRx
NC
184
AIO
-
-
NC
ANT3_M1
175
AIO
-
-
41 TRx + MHB/UCB/LAA Rx
NC
166
AIO
-
-
NC
ANT5_M2
157
AIO
-
-
MHB/UCB/LAA Rx
ANT6
148
AIO
-
-
UCB TRx
ANT7_D
139
AIO
-
-
LMHB Rx
ANT8_M
130
AIO
-
-
LMH TRX
NC
121
AIO
-
-
NC
ANT10_GNSS
199
AI
-
-
GNSS antenna
NC
205
AIO
-
-
NC
ANT Tuner Control
MIPI1_D_SDATA
198
DIO
VDD_EXT_1V8
PD
External Tuner MIPI Control
Data Pin
MIPI1_D_SCLK
201
DO
VDD_EXT_1V8
PD
External Tuner MIPI Control
Clock Pin
MIPI2_D_SDATA
216
DIO
VDD_EXT_1V8
PD
External Tuner MIPI Control
Data Pin
