After regulation repeat the operations indicated in paragraph “2. Pressure
regulator” at page 9 and 12.
If the range has been disconnected and then connected again to the gas sup-
ply line repeat the operations indicated in paragraph “5. Leak Testing” at page
12.
IMPORTANT:
After conversion to LP/PROPANE gas has been carried out affix inside the
drawer, near the data plate, the conversion label supplied and also affix a con-
version label at page 3 of this instruction manual.
ADJUSTMENT OF THE OVEN BURNER MINIMUM
This needs to be done only for the oven burner (the broil is a fixed capacity)
by acting on the thermostat in the following way:
– Turn on the burner by setting the thermostat knob on position 8.
– Remove the knob and unscrew the by-pass screw "G" (fig. 2.14) about three
times by passing a small flat screwdriver (Ø 3 mm blade, 100 mm length)
through the panel opening.
– Re-mount the knob and let the oven heat up for about 10 minutes, then bring
the knob to position 1 (minimum) to operate the thermostat by-pass.
– After having removed the knob again and being very careful not to turn the
tap rod, slowly screw the by-pass screws “G” (fig. 2.14) until you obtain a
flame of 3-4 mm in height.
N.B. For LP/PROPANE gas the by-pass screw must be fixed thoroughly.
G
Fig. 2.14
