DO NOT DISCARD: IMPORTANT LITERATURE. KEEP THESE INSTRUCTIONS FOR FUTURE REFERENCE. OBSERVE ALL SAFETY
WARNINGS AND CAUTIONARY STATEMENTS TO REDUCE THE RISK OF SERIOUS OR FATAL INJURY.
Consumer Information
2
WARNING
TO AVOID SERIOUS INJURY:
• DO NOT install this product on a hard
surface. A fall onto hard surface could
result in a head or other serious injuries.
Never place on concrete, asphalt, wood,
packed earth or other hard surfaces.
Carpet over hard floors may not prevent
injury.
• Instruct children to remove their bike or
other sports helmet before playing on the
playground equipment.
• CHOKING HAZARD – Small parts. This
product contains small parts and sharp
points which are necessary for assembly.
Prior to or during assembly of this product,
keep all components out of children’s
reach. Small parts pose a choking hazard
to children under 3 years of age.
• Warning. Only for domestic use. Suitable for indoor and outdoor
use. This product is designed for normal residential use only, and
is not intended for use in schools, parks, day care centers,
nurseries, or other public places.
• Warning. This product is intended for use by children ages 2 - 5
years.
• Warning. Maximum weight limit: 50 lbs (23 kg) on each seat.
Limit 2 child at any one time.
• Adult assembly required. Phillips / cross-headed screwdriver (not included) required during assembly.
• Instruct children on proper use of this product, only after properly installed and assembled, and not in any manner other than intended.
• Recommend to place the activity toy on a level surface at least 2 m (6.5 feet) from any structure or obstruction such as a fence, garage,
house, overhanging branches, laundry lines or electrical wires.
• On-site adult supervision is required for children of all ages at all times when on or around this product. Never leave children unattended.
• When the seesaw is exposed to direct sunlight, check the temperature on the product surface. If the seesaw is too hot, pour cold water on
the seesaw until it cools and wipe dry before giving it to children.
• Do not use without water in the Base 1 & 2.
• It is recommended to place the seesaw out of direct sunlight to reduce the likelihood of serious burns and injure child’s eyes. A seesaw that
faces north will receive the least direct sunlight.
• Teach and instruct children to sit in the centre with their full weight on the seats. Do not allow children to stand on the seesaw.
• Instruct children to hold on to the handle bar with both hands, and warn children not to get off seesaw when it is in motion.
CAUTION
• Observing the following statements and
warnings to reduce the likelihood of
serious or fatal injury.
• DO NOT allow children to play on this
product until it is completely installed.
• DO NOT allow children to stand, walk
close to, behind, in front of, or between
moving product. Instruct children to keep a
safe distance away.
• DO NOT let children use this product in
any manner other than intended.
• Dress children appropriately while on and
around this product. Use well-fitting shoes
that do not have slippery soles. DO NOT
allow children to wear ponchos, scarves,
hoods, jewelry, loose shoes, loose-fitting
clothing, neckties, clothing with loose
strings and/or clothing that might be
potentially hazardous while using this
product.
• Instruct children to remove their bike or
other sports helmet before using this
product.
• Make sure all parts are securely snapped
together before use.
The owner of this product should disassemble and dispose of the playground equipment in such a way that no unreasonable hazards will exist
at the time the playground equipment is discarded.
For Disposal

Information on Playground surfacing materials:
Maximum fall height for this product is 1 ft 3 inch / 400 mm.
Select Protective Surfacing – One of the most important things you can do to reduce the likelihood of serious head injuries is to install shock-absorbing protective surfacing under
and around your play equipment. The protective surfacing should be applied to a depth that is suitable for the equipment height in accordance with ASTM Specification F 1292. There
are different types of surfacing to choose from; whichever product you select, follow these guidelines:
Loose-Fill Materials:
Maintain a minimum depth of 9 inches of loose fill materials such as wood mulch/chips, engineered wood fiber (EWF), or shredded/recycled rubber mulch for equipment up to 8 feet
high; and 9 inches of sand or pea gravel for equipment up to 5 feet high. NOTE: An initial fill level of 12 inches will compress to about a 9 inch depth of surfacing over time. The
surfacing will also compact, displace, and settle, and should be periodically refilled to maintain at least a 9 inch depth.
Use a minimum of 6 inches of protective surfacing for play equipment less than 4 feet in height. If maintained properly, this should be adequate. (At depths less than 6 inches, the
protective material is too easily displaced or compacted.)
NOTE: Do not install home playground equipment over concrete, asphalt, or any other hard surface. A fall onto a hard surface can result in serious injury to the equipment user. Grass
and dirt are not considered protective surfacing because wear and environmental factors can reduce their shock absorbing effectiveness. Carpeting and thin mats are generally not
adequate protective surfacing. Ground level equipment – such as a sandbox, activity wall, playhouse or other equipment that has no elevated play surface – does not need any
protective surfacing.
Use containment, such as digging out around the perimeter and/or lining the perimeter with landscape edging. Don’t forget to account for water drainage.
Check and maintain the depth of the loose-fill surfacing material. To maintain the right amount of loose-fill materials, mark the correct level on play equipment support posts. That
way you can easily see when to replenish and/or redistribute the surfacing.
Do not install loose-fill surfacing over hard surfaces such as concrete or asphalt.
Poured-In-Place Surfaces or Pre-Manufactured Rubber Tiles – You may be interested in using surfacing other than loose-fill materials – like rubber tiles or poured-in-place surfaces.
Installations of these surfaces generally require a professional and are not “do-it-yourself” projects.
Review surface specifications before purchasing this type of surfacing. Ask the installer/manufacturer for a report showing that the product has been tested to the following safety
standard: ASTM F1292 Standard Specification for Impact Attenuation of Surfacing Materials within the Use Zone of Playground Equipment. This report should show the specific
height for which the surface is intended to protect against serious head injury. This height should be equal to or greater than the fall height – vertical distance between a designated
play surface (elevated surface for standing, sitting, or climbing) and the protective surfacing below – of your play equipment.
Check the protective surfacing frequently for wear.
Placement – Proper placement and maintenance of protective surfacing is essential. Be sure to:
Extend surfacing at least 6 feet from the equipment in all directions.
Consumer Information
3
• The owner of this product shall be responsible for maintaining the legibility of the warning labels.
• Check all coverings for bolts and sharp edges and replace when required.
• Replace defective parts in accordance with the manufacturer’s instructions.
• DO NOT allow children to climb or to play when the product is wet. It may be slippery when wet.
• DO NOT leave this item exposed to strong wind and inclement weather.
• Clean the seesaw regularly with soapy water in order to avoid a build up of static electricity.
• NEVER attach any materials that are not specifically designed for use with this product, such as (but not limited to) jump ropes, clotheslines, pet leashes, cables and chains, these
pose a potential strangulation hazard.
• Discard all packaging properly after unit has been assembled.
• Disassemble and dispose of this product in a safe place and manner so as not to present any hazard to any individual at the item when the product is discarded.
• Twice a month during play season; rake and check depth of loose fill protective surfacing materials to prevent compaction and to maintain appropriate depth. Replace as necessary.
• Twice a month during play season; check the unit for tightness, and tighten as required. It is particularly important that this procedure be followed at the beginning of each season
and monthly thereafter for evidence of deterioration. Replace as needed. If not checked regularly, parts can be loose or missed and components can become detached and case
injuries.
• At the beginning of each play season; rake and check depth of loose fill protective surfacing materials to prevent compaction and to maintain appropriate depth. Replace as
necessary.
• At the beginning of each play season; check metal parts for rust. If found, sand and repaint using a non-lead based paint meeting the requirements of 16 CFR 1303.
• At the beginning of each play season; reinstall the plastic parts or any other items that were removed for the cold season.
• At the end of each play season or when temperature falls below 32°F / 0°C; remove the product and store indoors. In extreme cold weather, plastic materials lose resilience and
may become brittle and crack upon impact.
• At the end of each play season or when temperature falls below 32°F / 0°C; rake and check depth of loose fill protective surfacing materials to prevent compaction and to maintain
appropriate depth. Replace as necessary.
Care

Parts
4
Note: Illustrations not to scale.
B
C
D
E
A
I - Screw - 2 inch / 50 mm x 4
H - Screw - 1.2 inch / 31 mm x 2
F - Nut x 4 G - Cap x 4
FASTENER SHOWN ACTUAL SIZE
#DESCRIPTION QTY
A 1
B2
C1
D1
E 1
H 2
Horizontal Bar
Seat
Support Base
Base 1
Base 2
I 4
Screw
Screw
F 4Nut
G 4Cap
PARTS LIST

A
B
I
I
F
HB
5
Assembly
1
2a
• To prevent tipping and potential injury, do not attempt to use this item without filling two panels of dry sand.
Once filled, seal base with plug. The unit may fall over without weight in the base.
• UNSTABLE EQUIPMENT CAN CAUSE INJURY.
• Funnel is not included.
Sand Filling
DE
Dry Sand Wet Sand
!

6
Assembly
5 6
2b 3
4
E
E
D
D
C
Click !Click !
Click !Click !

7
Safety Space Requirement
MADE IN CHINA (SZ)
CONSUMER ASSISTANCE
[email protected]
Call toll free 1-888-468-9898 (US & Canada only)
24 hours, 7 days a week
Write to us at: Grow’n Up Consumer Relations,
Room 808B, New Mandarin Plaza, Tsim Sha Tsui,
Kowloon, Hong Kong.
www.grow-n-up.com
FISHER-PRICE and associated trademarks are owned by and used under license from Mattel.
©2017 Mattel. All Rights Reserved. Manufactured for and designed by Grow’n Up Ltd.
Room 808B, New Mandarin Plaza,
Tsim Sha Tsui, Kowloon, Hong Kong.
Place the seesaw on level ground NOT LESS THAN 2 METRES away from any other hard or fixed object. e.g. fence, shed, trees.
Recommended play area : Diameter 5.5m
2 m 2 m
