Fisher-Price FORD MUSTANG P5920 Use and care manual

Please read this manual and save
Please read this manual and save
it with your original sales receipt.
it with your original sales receipt.
Tools needed for assembly: Phillips
Tools needed for assembly: Phillips
Screwdriver (not included) and
Screwdriver (not included) and
Assembly Tool (included).
Assembly Tool (included).
Use only with a Power Wheels
Use only with a Power Wheels
®
®
12 Volt Rechargeable Battery and
12 Volt Rechargeable Battery and
Power Wheels
Power Wheels
®
®
12 Volt Charger with
12 Volt Charger with
Type 12V connector (both included).
Type 12V connector (both included).
Requires three "AA" (LR6)
Requires three "AA" (LR6)
alkaline
alkaline
batteries for simulated radio
batteries for simulated radio
operation (not included).
operation (not included).
Owner's Manual
Owner's Manual
with Assembly Instructions
with Assembly Instructions
Model: P5920
Model: P5920
Product features may vary
Product features may vary
from the photograph above.
from the photograph above.

2P5920pr-0920
• Your new vehicle requires adult assembly. Please set aside at least
60 minutes for assembly.
• You must charge your battery for 18 - 30 hours before you use
your vehicle for the first time. We recommend that you start
charging your battery before beginning assembly. Please see
Battery Charging beginning on page 7 for detailed instructions.
• Read this manual carefully for important safety information and
operating instructions before using your vehicle. Keep this manual
for future reference as it contains important information.
• This vehicle is designed for use on: concrete, grass, asphalt and
other hard surfaces; on generally level terrain; and by children
3 years of age and older.
• This vehicle has been pre-set so it will only operate in low
speed. See the instructions on page 21 to remove the high
speed lock-out screw.
• Use this vehicle ONLY outdoors. Most interior flooring can be
damaged by riding this vehicle indoors. Fisher-Price®will not be
responsible for damage to the floor if the vehicle is used indoors.
• To prevent damaging the motors and gears, teach your child to
stop the vehicle before switching direction. Do not tow anything
behind the vehicle or overload it. Do not exceed the maximum
weight capacity of 130 lbs (59 kg).
• This product contains a magnet. Do not use around items that
are sensitive to or are affected by magnetic fields.
• This vehicle has adjustable play seat belts. Please note that the
adjustable seat belts are designed to be a play feature and do
not function as protective safety restraints.
• If you have any questions about your Power Wheels®vehicle,
please call our toll-free service lines at 1-800-348-0751 from
9 AM to 7 PM (EST) Monday through Friday and 11 AM to 5 PM
(EST) Saturday. Trained customer service representatives are
available to take your call in English or French. Habla Español?
Si usted tiene alguna pregunta ó necesita asistencia llame gratis
1-800-348-0755 para los Estados Unidos. Tenemos representantes
que hablan español para atender su llamada.
• For your convenience, Power Wheels®maintains an independently
owned and operated Authorized Service Center Network with more
than 300 authorized service centers nationwide. Our authorized
service centers will repair or replace parts under warranty at no
extra charge, and can perform non-warranty repairs for a minimal
charge. To find the authorized service center nearest you,
please visit us on-line at www.powerwheels.com
or call 1-800-348-0751.
• To register your vehicle, please visit us on-line at
www.powerwheels.com.
IMPORTANT INFORMATION
TABLE OF CONTENTS
Important Information . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .2
Parts . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .4
Parts Picture . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .6
Battery Charging . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .7
Assembly . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .8
Decoration . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .16
Battery Installation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .18
Battery Care and Disposal. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .19
Safe Driving Rules . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .20
Vehicle Operation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .21
Cool Sound Effects . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .22
Vehicle Care . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .22
Problems and Solutions Guide . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .23
FCC Statement . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .26
ICES and NMB Statements . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .26
Limited Warranty . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .27

3
P5920pr-0920
IMPORTANT INFORMATION
• Prevent Injuries and Deaths
• Direct Adult Supervision Required
• Never Ride at Night.
• Keep Children Within Safe Riding Areas.
These areas must be:
- away from swimming pools and other bodies of water to prevent drownings
- generally level to prevent tipovers
- away from steps, steep inclines, cars, roads and alleys.
• Riding Rules
Make sure children know and follow these rules for safe driving and riding.
- Always sit on the seat.
- Always wear shoes.
- Only 2 (two) riders at a time.
ELECTRICAL HAZARD
WARNING
To prevent electric shock, do not immerse in water; wipe clean with a damp cloth.
DANGER
• Battery can fall out and injure a child if vehicle tips over. Always use battery retainer.
• PREVENT FIRE
- Never modify the electrical system. Alterations could cause a re resulting in serious injury
and could also ruin the electrical system.
- Use of the wrong type battery or charger could cause a re or explosion resulting in
serious injury.
- Use of Power Wheels®components in products other than Power Wheels®vehicles could
cause overheating, re or explosion.
• The battery must be handled by adults only. The battery is heavy and contains sulfuric acid
(electrolyte). Dropping the battery could result in serious injury.
• Never allow children to charge the battery. Battery charging must be done by adults only.
A child could be injured by the electricity involved in charging the battery.
• Read the safety instructions on the battery.
• Examine the battery, charger and their connectors for excessive wear or damage each time
you charge the battery. If damage or excessive wear is detected, do not use the charger or
the battery until you have replaced the worn or damaged part.
• HOT motors. Handle carefully.
WARNING
RIDING HAZARD

4P5920pr-0920
PARTS
• If you experience a problem with this product, or are missing a part, please call us at 1-800-348-0751, rather than return this
product to the store.
• Please identify all parts before assembly and save all packaging material until assembly is complete to ensure that no parts are discarded.
• Metal parts have been coated with a lubricant to protect them during shipment. Wipe all metal parts with a paper towel to remove
any excess lubricant.
Front Bumper
2 Wheel Covers
Vehicle
Bumper Support
Front Wheels
(Left and Right)
Dash Assembly
Seat
Hood
Spoiler
Rear Deck
Grill

5
P5920pr-0920
PARTS
12 Volt Battery
12 Volt Charger
#8 x ¾" Screw - 29
⅜" -16 Lock Nut - 2
Fasteners Shown Actual Size
For your convenience, we included extra fasteners!
Note: Tighten and loosen all screws with a Phillips screwdriver.
Do not over-tighten the screws.
Steering Column
2 Short Seat BeltsLong Seat Belt
Assembly Tool
Steering Wheel Steering Wheel Cap
2 Mirrors
2 Mirror Covers
Part not shown: Label Sheet
4 Hubcaps 2 Bushings
Steering Column Cap
7⁄16" Washer - 2
5⁄32" x 1½" Pin - 1
¼" x 1¼" Screw - 2
#8 x ¾" Black Screw - 7

6P5920pr-0920
PARTS PICTURE
15
1 Vehicle
2 Front Bumper
3 Dash Assembly
4 Hood
5 Rear Deck
6 Seat
7 Bumper Support
8 Front Wheels - 2
9 Wheel Covers - 2
10 Steering Wheel
11 Steering Wheel Cap
12 Hubcaps - 4
13 Bushings - 2
14 Mirrors - 2
15 Mirror Covers - 2
16 Steering Column Cap
17 Steering Column
18 7/16" Washers - 2
19 Long Seat Belt
20 Short Seat Belts - 2
21 5/32" x 11/2" Pin
22 12 Volt Battery
23 12 Volt Charger
24 3/8"-16 Lock Nuts - 2
Assembly Tool
#8 x ¾" Screws - 29
#8 x ¾" Black Screws - 7
¼" x 1¼" Screws - 2
Label Sheet
Parts Not Shown
2
3
4
5
6
7
89
10
11
12
13
14
1
16
17
18
19
20
20
21
25
22
23
24
Note: Some parts shown are assembled
to both sides of the vehicle.
26
25 Spoiler
26 Grill

7
P5920pr-0920
BATTERY CHARGING
Use the charger in dry locations only.
Important Notes
• Your new battery must be charged for at least 18 hours before
you use it in your vehicle for the first time.
• We recommend that you start charging your battery before
beginning assembly of your new vehicle.
• The battery must be upright while charging.
• The charger is not a toy.
• Do not short circuit the battery.
• You do not need to remove the battery from your vehicle to
recharge it.
• Before charging the battery, examine the battery case for cracks
and other damage which may cause sulfuric acid (electrolyte) to
leak during the charging process. If damage is detected, do not
charge the battery or use it in your vehicle. Battery acid is very
corrosive and can cause severe damage to surfaces it contacts.
• Do not charge the battery on a surface (such as a kitchen
counter top) which could be damaged by the acid contained
inside the battery. Take precautions to protect the surface on
which you charge your battery.
• Use only a Power Wheels®12 volt charger with "12 V" connector
(input 120 VAC, 60 Hz, with an output of 12 VDC) to charge
your Power Wheels®12 volt battery.
Adults Note: Regularly examine the charger for damage to the
cord, plug, housing or other parts that may result in the risk of
fire, electric shock or injury. In the event of any damage, do not
use the charger until the damage has been properly repaired.
Please call 1-800-348-0751.
• If your battery is old and will not accept a charge, do not leave
it in the vehicle. Always remove a dead battery from the vehicle.
About Thermal Fuses
Your Power Wheels®12 volt battery is equipped with a built-in
thermal fuse. The thermal fuse is a self-resetting safety device
which automatically “trips” and shuts down operation of the
vehicle if the vehicle is overloaded or the driving conditions too
severe. Once a fuse has “tripped”, remove your foot from the
pedal and wait approximately 25 seconds before operating the
vehicle again. To avoid repeated automatic shut-downs, do not
overload the vehicle by exceeding the 130 lbs (59 kg) maximum
weight capacity or by towing anything behind the vehicle. Avoid
severe driving conditions, such as driving up slopes or running
into fixed objects, which can cause the wheels to stop spinning
while power is still being supplied to the motors and make sure
your child stops the vehicle before switching direction.
If a thermal fuse in a battery continually trips under normal
driving conditions, please contact your local Power Wheels®
Authorized Service Center. For the location of the Authorized
Service Center nearest to you, visit us on-line at
www.powerwheels.com, or call 1-800-348-0751.
CAUTION
ELECTRICAL HAZARD
• Battery can fall out and injure a child if vehicle
tips over. Always use battery retainer.
• PREVENT FIRE
- Never modify the electrical system.
Alterations could cause a re resulting
in serious injury and could also ruin the
electrical system.
- Use of the wrong type battery or charger
could cause a re or explosion resulting
in serious injury.
- Use of Power Wheels®components in
products other than Power Wheels®
vehicles could cause overheating,
re or explosion.
• The battery must be handled by adults
only. The battery is heavy and contains
sulfuric acid (electrolyte). Dropping the
battery could result in serious injury.
• Never allow children to charge the battery.
Battery charging must be done by adults only.
A child could be injured by the electricity
involved in charging the battery.
• Read the safety instructions on the battery.
• Examine the battery, charger and their
connectors for excessive wear or damage
each time you charge the battery. If damage
or excessive wear is detected, do not use
the charger or the battery until you have
replaced the worn or damaged part.
WARNING

8P5920pr-0920
BOTTOM VIEW
1
BATTERY CHARGING
Charger
Connector
A
B
• Plug the charger connector into the battery A.
• Plug the charger into a standard wall outlet. The power
indicator lights B.
Notes:
- If power flow to the wall outlet is controlled by a switch,
make sure the switch is “ON”.
- Use the charger only in a wall outlet. Do not plug the charger
into a ceiling outlet.
- The power indicator on the charger does not indicate the charge
status of your battery. The power indicator allows you to see
that there is power from the wall outlet.
• Before first-time use, charge the battery for at least 18 hours.
Never charge the battery longer than 30 hours.
• Recharge the battery for at least 14 hours after each use of
your vehicle. Do not charge the battery longer than 30 hours.
• Once the battery is charged, disconnect the battery connector
from the charger connector. Unplug the charger from the wall
outlet. The battery is now ready to be installed in your vehicle.
Please see the Battery Installation section on page 18 for
detailed instructions on installing your battery. If your battery
is already installed in your vehicle, simply re-connect the motor
harness connector to the battery.
WARNING
Children can be harmed by small parts,
sharp edges and sharp points in the vehicle's
unassembled state, or by electrical items.
Care should be taken in unpacking and
assembly of the vehicle. Children should
not handle parts, including the battery,
or help in assembly of the vehicle.
• Place the vehicle upside down.
• Slide the bumper support, ribbed side up, into the slot in the
front end of the vehicle.
• Insert two ¼" x 1¼" screws into the bumper support and tighten.
Bumper Support
ASSEMBLY
Power
Indicator
CAUTION
• In the unassembled state, this package
contains small parts. Adult assembly
is required.

9
P5920pr-0920
2
ASSEMBLY
Front Axle
4
• Slide a 7⁄16" washer the right (passenger's) side of the front axle.
• Fit a bushing, flat side first, onto the front axle.
• Insert six #8 x ¾" screws into the front bumper and tighten.
3
Note: There is a right and left front wheel. They are marked with
an R and L.
• Locate the right front wheel marked with an R. Place the front
wheel R, onto the front axle on the right (passenger's) side of
the vehicle.
• Fit a wheel cover on to the right front wheel.
Wheel Cover
5
• Fit the front bumper onto the vehicle.
Front Bumper
Washer
Bushing
Front Wheel
(Marked R)

10 P5920pr-0920
9
Assembly
Tool
E
• Insert six #8 x ¾" screws into the front bumper and tighten.
• Fit the grill onto the front number.
• Insert two black #8 x ¾" screws into the grill and tighten.
8
• Fit a ⅜"-16 lock nut, rounded side out, onto the front axle.
IMPORTANT! Tighten the lock nut firmly with the closed end of
the assembly tool.
• Test to be sure the front wheel moves freely on the front axle.
Turn the front wheel.
• If the front wheel does not move freely, loosen the lock nut
¼turn and test again. Repeat this procedure as necessary.
• Repeat steps 4-6 to assemble the other washer, bushing,
front wheel and wheel cover with the remaining ⅜"-16 lock
nut on the other side of the vehicle.
6
• Align the slot in a hubcap with the rib in the wheel cover.
“Snap” a hubcap into the center of each wheel cover.
• Turn the vehicle upright.
7
Hubcaps
Hubcaps
ASSEMBLY
FRONT VIEW
Lock Nut
Grill
9
G
ril
l

11
P5920pr-0920
ASSEMBLY
12
• Insert four #8 x ¾" screws into the dash assembly and tighten.
• Fit the dash assembly onto the posts near the front end of
the vehicle.
11 13
• Insert two black #8 x ¾" screws into the dash assembly
as shown and tighten.
Posts
PostsPosts
BACK VIEW
• Fit a mirror and mirror cover to an end of the dash assembly.
Hint: Each mirror and mirror cover only fit on one side of the
vehicle. If they do not seem to fit, try assembling on the
other side.
• Insert two #8 x ¾" screws into the mirror cover and tighten.
• Repeat this procedure to attached the other mirror and mirror
cover to the opposite end of the dash assembly.
Mirror
10
Mirror Cover
Dash Assembly

12 P5920pr-0920
14
• Locate the simulated
radio on the dash.
• Loosen two screws
under the dash to remove the simulated radio. Set the
screws aside.
• Remove the simulated radio from the dash.
• Loosen the screw in the battery compartment door.
Remove the battery compartment door.
• Insert three “AA” (LR6) alkaline batteries.
Hint: We recommend using alkaline batteries for longer
battery life.
• Replace the battery compartment door and tighten the screw.
• Replace the simulated radio in the opening in the dash.
• Insert the two screws back under the dash and tighten to
secure the simulated radio.
• If this simulated radio begins to operate erratically, you
may need to reset the electronics. Remove the batteries and
replace them back in the simulated radio.
• When sounds from the simulated radio become faint or stop,
it’s time for an adult to change the batteries!
15
Battery Safety Information
In exceptional circumstances, batteries may leak fluids that can
cause a chemical burn injury or ruin your product. To avoid
battery leakage:
• Do not mix old and new batteries or batteries of different
types: alkaline, standard (carbon-zinc) or rechargeable
(nickel-cadmium).
• Insert batteries as indicated inside the battery compartment.
• Remove batteries during long periods of non-use. Always
remove exhausted batteries from the product. Dispose of
batteries safely. Do not dispose of product in a fire.
The batteries may explode or leak.
• Never short-circuit the battery terminals.
• Use only batteries of the same or equivalent type,
as recommended.
• Do not charge non-rechargeable batteries.
• Remove rechargeable batteries from the product
before charging.
• If removable, rechargeable batteries are used, they are only to
be charged under adult supervision.
1.5V x 3
"AA" (LR6)
• Protect the environment by not disposing of this
product with household waste (2002/96/EC). Check
your local authority for recycling advice and facilities
(Europe only).
Battery Compartment Door
Battery Compartment DoorBattery Compartment Door
ASSEMBLY
DASH VIEW
• Before applying the labels, wipe the surface of the vehicle with
a clean, dry cloth to remove any dust or oils.
• Place the labels exactly as shown in the illustrations. For best
results, avoid repositioning a label once it has been applied to
the vehicle.
17
15
24
25
28 29
11 17 17 17

13
P5920pr-0920
19
ASSEMBLY
• Fit the tabs on the rear deck into the slots in the back end of
the vehicle.
18
• Fit the long tabs on the hood into the slots in the front end of
the vehicle.
• Pull the hood forward and lower.
Note: The hood is held down by magnets. Simply lift to open the
hood. Do not use around items that are sensitive to or affected
by magnetic fields.
16
Hood
Rear Deck
Short Seat Belts
Long Seat Belt
• Insert the fastener end of a short seat belt strap through the
slot near the outer edge of the seat. Make sure the side of the
seat belt with the fastener faces the outer edge of the seat.
• Pull the short seat belt strap completely through the slot until
the last T-loop at the opposite end of the belt catches against
the slot. You will pull one T-loop through the slot.
• Repeat this procedure to assemble the other short seat belt strap.
• Insert each fastener end of the long seat belt strap through
each slot in the center of the seat. Make sure the fasteners
face the outer edge of the seat.
• Pull each side of the long seat belt strap evenly through the
slots. Make sure to pull each T-loop through a slot.
FRONT VIEW
BACK VIEW
Seat
• Fit the spoiler onto the rear deck.
• Insert four #8 x ¾" screws into the holes and tighten.
17
Rear Deck
Spoiler

14 P5920pr-0920
• Insert three black #8 x ¾" screws into the back of the seat
and tighten.
Note: You will need to remove these three screws if you change
the seat position later.
21
• Turn the vehicle over.
• Insert two #8 x ¾" screws through the vehicle and into the
rear deck. Tighten the screws.
22
• Insert the straight end of the steering column down through
the hole in the vehicle floor and out through the hole in
the dash.
23
• Insert the curved end of the steering column though the hole
in the steering linkage.
24
Steering
Column
ASSEMBLY
Steering Linkage
Steering Linkage
BACK VIEW
BOTTOM VIEW
Steering Column
Steering ColumnSteering Column
20
Note: The seat is adjustable and has three positions. You can
move the seat back as your child grows.
• Insert both tabs on the front edge of the seat into one of the
sets of slots inside the vehicle.
• Choose the slots closest to the dash for shorter drivers and
the slots furthest from the dash for taller drivers.
Slots
TOP VIEW

15
P5920pr-0920
ASSEMBLY
• Fit the Steering
Column cap onto
the end of the
steering column.
• Insert a #8 x ¾"
screw through the
large opening in the Steering Column cap and into the hole in
the steering column. Tighten the screw.
• Turn the vehicle upright.
25
• Position the steering wheel so that the large opening is UP.
• Fit the steering wheel onto the steering column.
26
• While pressing down on the steering wheel, grasp the steering
column under the dash and pull it up as far as it will go.
• Insert the 5⁄32" x 1½" pin through the hole in the steering column.
• Grasp the steering column again and pull down to fit the pin
into the center of the steering wheel.
27
• Fit the steering wheel cap onto the center of the steering wheel.
• Insert two #8 x ¾" screws and tighten.
28
Steering Wheel Cap
Large Opening
Steering Column Steering Wheel
Lift Steering
Lift Steering
Column
Column
Press Wheel
Steering Column Cap
Steering Column Cap
DASH VIEW

16 P5920pr-0920
26 27
FRONT VIEW
DECORATION
• Before applying the labels, wipe the surface of the vehicle with a clean, dry cloth to remove any dust or oils.
• Place the labels exactly as shown in the illustrations. For best results, avoid repositioning a label once it has been applied to the vehicle.
• After applying a label, rub the label firmly with a clean, dry cloth to make sure the label is adhered to your vehicle.
Start at the center of a label, and smooth towards the outer edges to remove air bubbles.
BACK VIEW
7
1
114
1
12
21
5
18
16
18
6
13
8

17
P5920pr-0920
DECORATION
LEFT VIEW
RIGHT VIEW
94
19
10
3
DOOR VIEW
22 23
2 2
20

18 P5920pr-0920
IMPORTANT! Use only a Power Wheels®12 volt lead-acid
rechargeable battery. Use of any other battery will damage
your vehicle. Make sure that you charge the battery for at
least 18 hours using the enclosed Power Wheels®12 volt
charger before operating your vehicle for the first time.
Charge the battery for at least 14 hours after each use of the
vehicle. Never charge the battery longer than 30 hours. Failure
to follow these instructions may damage your battery and will
void your warranty.
BATTERY INSTALLATION
• Place the battery in the battery compartment. Slide the battery
retainer over the top of the battery.
• Close the hood.
• Open the hood.
• Plug the motor harness connector into the battery.
1
2
Motor Harness Connector
12 Volt Battery
Battery Retainer

19
P5920pr-0920
• Your Power Wheels®battery is a non-spillable, sealed lead-acid
battery. It must be recycled or disposed of in an environmentally
sound manner.
• Do not dispose of a lead-acid battery in a fire. The battery may
explode or leak.
• Protect the environment by not disposing of this product with
household waste (2002/96/EC). Check your local authority for
recycling advice and facilities (Europe only).
• Do not dispose of a lead-acid battery in your regular, household
trash. The incineration, landfilling or mixing of sealed lead-acid
batteries with household trash is prohibited by law in most areas.
• Return an exhausted battery to a federal or state approved
lead-acid battery recycler, such as a Power Wheels®authorized
service center or a local seller of automotive batteries. For the
authorized service center location nearest to you, please visit
us on-line at www.powerwheels.com or call 1-800-348-0751.
Contact your local waste management officials for other
information regarding the environmentally sound collection,
recycling and disposal of lead-acid batteries. If you live in the
State of Florida or the State of Minnesota, it is prohibited by law
for anyone to throw away lead-acid batteries in the municipal
waste stream.
Care
If a battery leak develops, avoid contact with the leaking acid and
place the damaged battery in a plastic bag. See information below
for proper disposal.
If acid comes in contact with skin or eyes, flush with cool
water for at least 15 minutes and call a physician.
If acid is internally ingested, give water, milk of magnesia or
egg whites immediately. Never give emetics or induce vomiting.
Call a physician.
• Charge a new battery for at least 18 hours before first use.
Never charge the battery longer than 30 hours. Overcharging
or undercharging the battery may shorten battery life and
decrease vehicle running time.
• After the first charge, recharge the battery for at least 14 hours
after each use. Never charge the battery longer than 30 hours.
Charge the battery after each use, regardless of how long the
vehicle was used.
• The battery must be upright while charging.
• Do not allow the battery to run down completely before charging.
• Charge the battery before storing the vehicle.
• Charge the battery at least once per month, even if the vehicle
has not been used.
• Leaving the battery in a discharged condition will ruin it.
• Always remove an exhausted battery from the vehicle.
Battery leakage and corrosion can damage the vehicle.
• Do not store the battery on a surface (such as a kitchen
counter top) which could be damaged by the acid contained
inside the battery. Take precautions to protect the surface on
which you store the battery.
• Do not store the battery in temperatures above 75° F or
below -10° F.
• Use only a Power Wheels®12 volt battery. Remember to
charge the new battery for at least 18 hours before first use.
• Prevent the battery from moving freely inside the battery
compartment. Always use the battery retainer to secure
the battery in the battery compartment.
• Examine the battery, charger and their connectors for
excessive wear or damage each time you charge the battery.
If damage is detected, do not use the charger or the battery
until you have replaced the worn or damaged part.
Disposal
BATTERY CARE AND DISPOSAL

20 P5920pr-0920
SAFE DRIVING RULES
Teach Safety Rules to Children
While children can quickly develop the skill necessary to drive
this vehicle, it is important to remember that their judgment skills
are still very immature. Unsupervised driving by children can
lead to serious injury. Before children use this vehicle, an adult
should carefully evaluate the driving area as well as the children’s
skill level and ability to drive this vehicle safely. Children are not
always able to recognize or anticipate hazards, even when they
have been taught about them. There is no acceptable substitute
for direct adult supervision.
Teach appropriate safety rules to your child before allowing
operation of this vehicle. These rules should also be reviewed
with neighborhood children or other playmates who want to
drive this vehicle.
Riding Rules
Make sure children know and follow these rules for safe driving:
1. Always sit on the seat.
2. Always wear shoes.
3. Only 2 (two) riders at a time. A child who is not sitting on the
seat or who is standing on the vehicle could fall off, cause
a tip-over or block the driver’s view. A child could be
seriously injured.
4. Do not allow any child to drive the vehicle in the street or near
moving (motorized) vehicles.
5. Do not allow any child to drive near bodies of water (such as
pools or creeks), obstructions (such as furniture, low tree limbs
or play equipment), or drop-offs (such as stairs or decks).
6. Do not allow any child to drive the vehicle in the dark. A child
could encounter unexpected obstacles and have an accident.
Operate the vehicle only in the daytime or a well-lit area.
7. Do not allow your child to drive on sloped or inclined surfaces.
Restrict your child’s driving to generally level ground ONLY!
8. Do not allow your child to drive down or across a steep slope.
- The vehicle may gain unsafe speed, even if the pedal is released
to stop.
- The vehicle may tilt and tip over.
- The wheels could lose traction, causing the vehicle to slip.
9. Do not allow your child to drive up steep inclines. The motor may
stop and the vehicle could roll backwards at an unsafe speed.
10.Never put anything near any moving parts. Rotating parts such
as motors, gear boxes and wheels can snag fingers, hair, etc.,
causing serious injury. Do not allow operation of the vehicle
when it is on its side or in an upside-down position.
11.Do not operate the vehicle near flammable vapors (gasoline,
paint thinner, acetone, liquid wax, etc.). The vehicle’s electrical
switches, like most electrical switches, emit an internal spark
when first turned on or turned off. The presence of flammable
liquids or vapors could cause an explosion or a fire. Keep all
flammable products in tightly sealed containers and away
from the vehicle.
12.Do not allow a child to operate the vehicle without direct
adult supervision. To prevent unsupervised use of the vehicle,
disconnect the motor harness from the battery when the
vehicle is not in use.
RIDING HAZARD
• Prevent Injuries and Deaths
• Direct Adult Supervision Required
• Never Ride at Night.
• Keep Children Within Safe Riding Areas.
These areas must be:
- away from swimming pools and other
bodies of water to prevent drownings
- generally level to prevent tipovers
- away from steps, steep inclines, cars,
roads and alleys.
• Riding Rules
Make sure children know and follow
these rules for safe driving and riding.
- Always sit on the seat.
- Always wear shoes.
- Only 2 (two) riders at a time.
WARNING
