Fisher-Price smart cycle Assembly instructions

Assembly Tip
Please follow these instructions carefully to properly assemble the pedals to the Smart Cycle™.
• Locate the left pedal marked with an Lon the outside end.
• Fit the threaded end of the left pedal into the hole in the left
pedal axle marked with an L.
• Hand-tighten the pedal by turning it COUNTER-CLOCKWISE.
• Fit the end of the assembly tool to the groove in the end
of the pedal.
• Turn the assembly tool COUNTER-CLOCKWISE to fully
tighten the pedal.
• Fit the end of the assembly tool to the groove in the end
of the pedal.
• Turn the assembly tool CLOCKWISE to fully tighten
the pedal.
Left Pedal Right Pedal Assembly Tool
Your Smart Cycle includes a left and right pedal along with an assembly tool.
You must use the assembly tool to attach the pedals.
• Fit the threaded end of the right pedal (marked with an R)
into the hole in the right pedal axle (also marked with an R).
• Hand-tighten the pedal by turning it CLOCKWISE.
L R
C
o
u
n
t
e
r
-
C
l
o
c
k
w
i
s
e
C
l
o
c
k
w
i
s
e
L R
C
o
u
n
t
e
r
-
C
l
o
c
k
w
i
s
e
C
l
o
c
k
w
i
s
e
12
34
TM

Fisher-Price, Inc., a subsidiary of Mattel, Inc., East Aurora, NY 14052 U.S.A.
©2007 Mattel, Inc. All Rights Reserved. ® and ™ designate U.S. trademarks of Mattel, Inc.
PRINTED IN CHINA K5054pr-0921
• Insert two #8 x 1" screws into the handlebar and tighten.
Hint: If the screws cannot be tightened, you have not
assembled the handlebar properly. Remove the handlebar
and refer back to Assembly steps 2 and 3.
• Next, push the handlebar forward and down to "snap" it
in place. Make sure you hear a "snap". This may take a
lot of force.
34
Assembly Tip
Please follow these instructions carefully to properly assemble the handlebar to the Smart Cycle™.
• Plug the handlebar connector into the socket in
the console.
Hint: The connector will only fit one way into the socket.
If it does not seem to fit, turn it around and try again!
• Place the handlebar, at an angle, onto the top of the post.
• Push to insert the tab on the back of the handlebar into
the slot in the console.
Handlebar
Connector
Socket
Tab
Post
12
TOP VIEW
