FLIR CX series User manual

User’s manual
FLIR Cx series

User’s manual
FLIR Cx series
#T559918; r. AA/20829/20829; en-US iii

Table of contents
1 Disclaimers ........................................................................................1
1.1 Legal disclaimer .........................................................................1
1.2 Usage statistics .......................................................................... 1
1.3 Changes to registry .....................................................................1
1.4 U.S. Government Regulations........................................................1
1.5 Copyright ..................................................................................1
1.6 Quality assurance .......................................................................1
1.7 Patents.....................................................................................1
1.8 EULATerms ..............................................................................1
1.9 EULATerms ..............................................................................2
2 Safety information ...............................................................................3
3 Notice to user .....................................................................................6
3.1 User-to-user forums ....................................................................6
3.2 Calibration.................................................................................6
3.3 Accuracy ..................................................................................6
3.4 Disposal of electronic waste ..........................................................6
3.5 Training ....................................................................................6
3.6 Documentation updates ...............................................................6
3.7 Important note about this manual....................................................6
4 Customer help ....................................................................................7
4.1 General ....................................................................................7
4.2 Submitting a question ..................................................................7
4.3 Downloads................................................................................7
5 Quick Start Guide ................................................................................9
5.1 Procedure.................................................................................9
6 Description.......................................................................................10
6.1 View from the front .................................................................... 10
6.2 View from the rear..................................................................... 10
6.3 Connector............................................................................... 11
6.4 Screen elements ...................................................................... 11
6.5 Auto-orientation........................................................................ 11
6.6 Navigating the menu system ....................................................... 12
7 Operation .........................................................................................13
7.1 Charging the battery.................................................................. 13
7.2 Turning on and turning off the camera............................................ 13
7.3 Saving an image....................................................................... 13
7.3.1 General........................................................................ 13
7.3.2 Image capacity .............................................................. 13
7.3.3 Naming convention......................................................... 13
7.3.4 Procedure .................................................................... 13
7.4 Recalling an image.................................................................... 13
7.4.1 General........................................................................ 13
7.4.2 Procedure .................................................................... 13
7.5 Deleting an image..................................................................... 14
7.5.1 General........................................................................ 14
7.5.2 Procedure .................................................................... 14
7.6 Deleting all images.................................................................... 14
7.6.1 General........................................................................ 14
7.6.2 Procedure .................................................................... 14
7.7 Measuring a temperature using a spotmeter ................................... 15
#T559918; r. AA/20829/20829; en-US v

Table of contents
7.7.1 General........................................................................ 15
7.8 Hiding measurement tools .......................................................... 15
7.8.1 Procedure .................................................................... 15
7.9 Changing the color palette .......................................................... 15
7.9.1 General........................................................................ 15
7.9.2 Procedure .................................................................... 15
7.10 Changing the image mode .......................................................... 15
7.10.1 General........................................................................ 15
7.10.2 Procedure .................................................................... 16
7.11 Changing the temperature scale mode .......................................... 17
7.11.1 General........................................................................ 17
7.11.2 When to use Lock mode .................................................. 17
7.11.3 Procedure .................................................................... 17
7.12 Setting the emissivity ................................................................. 17
7.12.1 General........................................................................ 17
7.12.2 Procedure .................................................................... 18
7.13 Changing the reflected apparent temperature ................................. 18
7.13.1 General........................................................................ 18
7.13.2 Procedure .................................................................... 18
7.14 Performing a non-uniformity correction .......................................... 18
7.14.1 What is a non-uniformity correction?................................... 18
7.14.2 When to perform a non-uniformity correction ........................ 18
7.14.3 Procedure .................................................................... 19
7.15 Using the camera lamp .............................................................. 19
7.15.1 General........................................................................ 19
7.15.2 Procedure .................................................................... 19
7.16 Changing the settings ................................................................ 19
7.16.1 General........................................................................ 19
7.16.2 Procedure .................................................................... 20
7.17 Updating the camera ................................................................. 20
7.17.1 General........................................................................ 20
7.17.2 Procedure .................................................................... 20
8 Technical data...................................................................................21
8.1 Online field-of-view calculator ...................................................... 21
8.2 Note about technical data ........................................................... 21
8.3 FLIR C2.................................................................................. 22
9 Mechanical drawings ......................................................................... 25
10 Cleaning the camera .......................................................................... 26
10.1 Camera housing, cables, and other items....................................... 26
10.1.1 Liquids......................................................................... 26
10.1.2 Equipment.................................................................... 26
10.1.3 Procedure .................................................................... 26
10.2 Infrared lens ............................................................................ 26
10.2.1 Liquids......................................................................... 26
10.2.2 Equipment.................................................................... 26
10.2.3 Procedure .................................................................... 26
11 Application examples......................................................................... 27
11.1 Moisture & water damage ........................................................... 27
11.1.1 General........................................................................ 27
11.1.2 Figure.......................................................................... 27
#T559918; r. AA/20829/20829; en-US vi

Table of contents
11.2 Faulty contact in socket .............................................................. 27
11.2.1 General........................................................................ 27
11.2.2 Figure.......................................................................... 28
11.3 Oxidized socket........................................................................ 28
11.3.1 General........................................................................ 28
11.3.2 Figure.......................................................................... 28
11.4 Insulation deficiencies................................................................ 29
11.4.1 General........................................................................ 29
11.4.2 Figure.......................................................................... 29
11.5 Draft ...................................................................................... 30
11.5.1 General........................................................................ 30
11.5.2 Figure.......................................................................... 30
12 About FLIR Systems .......................................................................... 32
12.1 More than just an infrared camera ................................................ 33
12.2 Sharing our knowledge .............................................................. 33
12.3 Supporting our customers........................................................... 34
12.4 A few images from our facilities.................................................... 34
13 Glossary ..........................................................................................35
14 Thermographic measurement techniques ............................................ 38
14.1 Introduction ............................................................................ 38
14.2 Emissivity................................................................................ 38
14.2.1 Finding the emissivity of a sample...................................... 38
14.3 Reflected apparent temperature................................................... 41
14.4 Distance ................................................................................. 42
14.5 Relative humidity ...................................................................... 42
14.6 Other parameters...................................................................... 42
15 History of infrared technology............................................................. 43
16 Theory of thermography..................................................................... 46
16.1 Introduction ............................................................................. 46
16.2 The electromagnetic spectrum..................................................... 46
16.3 Blackbody radiation................................................................... 46
16.3.1 Planck’s law .................................................................. 47
16.3.2 Wien’s displacement law.................................................. 48
16.3.3 Stefan-Boltzmann's law ................................................... 50
16.3.4 Non-blackbody emitters................................................... 50
16.4 Infrared semi-transparent materials............................................... 52
17 The measurement formula.................................................................. 54
18 Emissivity tables ............................................................................... 58
18.1 References.............................................................................. 58
18.2 Tables .................................................................................... 58
#T559918; r. AA/20829/20829; en-US vii

Disclaimers
1
1.1 Legal disclaimer
All products manufactured by FLIR Systems are warranted against defective
materials and workmanship for a period of one (1) year from the delivery date
of the original purchase, provided such products have been under normal stor-
age, use and service, and in accordance with FLIR Systems instruction.
Uncooled handheld infrared cameras manufactured by FLIR Systems are war-
ranted against defective materials and workmanship for a period of two (2)
years from the delivery date of the original purchase, provided such products
have been under normal storage, use and service, and in accordance with
FLIR Systems instruction, and provided that the camera has been registered
within 60 days of original purchase.
Detectors for uncooled handheld infrared cameras manufactured by FLIR Sys-
tems are warranted against defective materials and workmanship for a period
of ten (10) years from the delivery date of the original purchase, provided such
products have been under normal storage, use and service, and in accordance
with FLIR Systems instruction, and provided that the camera has been regis-
tered within 60 days of original purchase.
Products which are not manufactured by FLIR Systems but included in sys-
tems delivered by FLIR Systems to the original purchaser, carry the warranty, if
any, of the particular supplier only. FLIR Systems has no responsibility whatso-
ever for such products.
The warranty extends only to the original purchaser and is not transferable. It
is not applicable to any product which has been subjected to misuse, neglect,
accident or abnormal conditions of operation. Expendable parts are excluded
from the warranty.
In the case of a defect in a product covered by this warranty the product must
not be further used in order to prevent additional damage. The purchaser shall
promptly report any defect to FLIR Systems or this warranty will not apply.
FLIR Systems will, at its option, repair or replace any such defective product
free of charge if, upon inspection, it proves to be defective in material or work-
manship and provided that it is returned to FLIR Systems within the said one-
year period.
FLIR Systems has no other obligation or liability for defects than those set forth
above.
No other warranty is expressed or implied. FLIR Systems specifically disclaims
the implied warranties of merchantability and fitness for a particular purpose.
FLIR Systems shall not be liable for any direct, indirect, special, incidental or
consequential loss or damage, whether based on contract, tort or any other le-
gal theory.
This warranty shall be governed by Swedish law.
Any dispute, controversy or claim arising out of or in connection with this war-
ranty, shall be finally settled by arbitration in accordance with the Rules of the
Arbitration Institute of the Stockholm Chamber of Commerce. The place of ar-
bitration shall be Stockholm. The language to be used in the arbitral proceed-
ings shall be English.
1.2 Usage statistics
FLIR Systems reserves the right to gather anonymous usage statistics to help
maintain and improve the quality of our software and services.
1.3 Changes to registry
The registry entry HKEY_LOCAL_MACHINE\SYSTEM\CurrentControlSet
\Control\Lsa\LmCompatibilityLevel will be automatically changed to level 2 if
the FLIR Camera Monitor service detects a FLIR camera connected to the
computer with a USB cable. The modification will only be executed if the cam-
era device implements a remote network service that supports network logons.
1.4 U.S. Government Regulations
This product may be subject to U.S. Export Regulations. Please send any in-
quiries to [email protected].
1.5 Copyright
© 2014, FLIR Systems, Inc. All rights reserved worldwide. No parts of the soft-
ware including source code may be reproduced, transmitted, transcribed or
translated into any language or computer language in any form or by any
means, electronic, magnetic, optical, manual or otherwise, without the prior
written permission of FLIR Systems.
The documentation must not, in whole or part, be copied, photocopied, repro-
duced, translated or transmitted to any electronic medium or machine read-
able form without prior consent, in writing, from FLIR Systems.
Names and marks appearing on the products herein are either registered
trademarks or trademarks of FLIR Systems and/or its subsidiaries. All other
trademarks, trade names or company names referenced herein are used for
identification only and are the property of their respective owners.
1.6 Quality assurance
The Quality Management System under which these products are developed
and manufactured has been certified in accordance with the ISO 9001
standard.
FLIR Systems is committed to a policy of continuous development; therefore
we reserve the right to make changes and improvements on any of the prod-
ucts without prior notice.
1.7 Patents
One or several of the following patents and/or design patents may apply to the
products and/or features. Additional pending patents and/or pending design
patents may also apply.
000279476-0001; 000439161; 000499579-0001; 000653423; 000726344;
000859020; 001106306-0001; 001707738; 001707746; 001707787;
001776519; 001954074; 002021543; 002058180; 002249953; 002531178;
0600574-8; 1144833; 1182246; 1182620; 1285345; 1299699; 1325808;
1336775; 1391114; 1402918; 1404291; 1411581; 1415075; 1421497;
1458284; 1678485; 1732314; 2106017; 2107799; 2381417; 3006596;
3006597; 466540; 483782; 484155; 4889913; 5177595; 60122153.2;
602004011681.5-08; 6707044; 68657; 7034300; 7110035; 7154093;
7157705; 7237946; 7312822; 7332716; 7336823; 7544944; 7667198;
7809258 B2; 7826736; 8,153,971; 8018649 B2; 8212210 B2; 8289372;
8354639 B2; 8384783; 8520970; 8565547; 8595689; 8599262; 8654239;
8680468; 8803093; D540838; D549758; D579475; D584755; D599,392;
D615,113; D664,580; D664,581; D665,004; D665,440; D677298; D710,424
S; DI6702302-9; DI6903617-9; DI7002221-6; DI7002891-5; DI7002892-3;
DI7005799-0; DM/057692; DM/061609; EP 2115696 B1; EP2315433; SE
0700240-5; US 8340414 B2; ZL 201330267619.5; ZL01823221.3;
ZL01823226.4; ZL02331553.9; ZL02331554.7; ZL200480034894.0;
ZL200530120994.2; ZL200610088759.5; ZL200630130114.4;
ZL200730151141.4; ZL200730339504.7; ZL200820105768.8;
ZL200830128581.2; ZL200880105236.4; ZL200880105769.2;
ZL200930190061.9; ZL201030176127.1; ZL201030176130.3;
ZL201030176157.2; ZL201030595931.3; ZL201130442354.9;
ZL201230471744.3; ZL201230620731.8.
1.8 EULA Terms
• You have acquired a device (“INFRARED CAMERA”) that includes soft-
ware licensed by FLIR Systems AB from Microsoft Licensing, GP or its af-
filiates (“MS”). Those installed software products of MS origin, as well as
associated media, printed materials, and “online” or electronic documen-
tation (“SOFTWARE”) are protected by international intellectual property
laws and treaties. The SOFTWARE is licensed, not sold. All rights
reserved.
• IF YOU DO NOT AGREE TO THIS END USER LICENSE AGREEMENT
(“EULA”), DO NOT USE THE DEVICE OR COPY THE SOFTWARE. IN-
STEAD, PROMPTLY CONTACT FLIR Systems AB FOR INSTRUCTIONS
ON RETURN OF THE UNUSED DEVICE(S) FOR A REFUND. ANY USE
OF THE SOFTWARE, INCLUDING BUT NOT LIMITED TO USE ON
THE DEVICE, WILL CONSTITUTE YOUR AGREEMENT TO THIS EU-
LA (OR RATIFICATION OF ANY PREVIOUS CONSENT).
•GRANT OF SOFTWARE LICENSE. This EULA grants you the following
license:
• You may use the SOFTWARE only on the DEVICE.
•NOT FAULT TOLERANT. THE SOFTWARE IS NOT FAULT TOLER-
ANT. FLIR Systems AB HAS INDEPENDENTLY DETERMINED
HOW TO USE THE SOFTWARE IN THE DEVICE, AND MS HAS
RELIED UPON FLIR Systems AB TO CONDUCT SUFFICIENT
TESTING TO DETERMINE THAT THE SOFTWARE IS SUITABLE
FOR SUCH USE.
•NO WARRANTIES FOR THE SOFTWARE. THE SOFTWARE is
provided “AS IS” and with all faults. THE ENTIRE RISK AS TO SAT-
ISFACTORY QUALITY, PERFORMANCE, ACCURACY, AND EF-
FORT (INCLUDING LACK OF NEGLIGENCE) IS WITH YOU.
ALSO, THERE IS NO WARRANTY AGAINST INTERFERENCE
WITH YOUR ENJOYMENT OF THE SOFTWARE OR AGAINST IN-
FRINGEMENT. IF YOU HAVE RECEIVED ANY WARRANTIES RE-
GARDING THE DEVICE OR THE SOFTWARE, THOSE
WARRANTIES DO NOT ORIGINATE FROM, AND ARE NOT
BINDING ON, MS.
• No Liability for Certain Damages. EXCEPT AS PROHIBITED BY
LAW, MS SHALL HAVE NO LIABILITY FOR ANY INDIRECT, SPE-
CIAL, CONSEQUENTIAL OR INCIDENTAL DAMAGES ARISING
FROM OR IN CONNECTION WITH THE USE OR PERFORM-
ANCE OF THE SOFTWARE. THIS LIMITATION SHALL APPLY
EVEN IF ANY REMEDY FAILS OF ITS ESSENTIAL PURPOSE. IN
NO EVENT SHALL MS BE LIABLE FOR ANY AMOUNT IN EX-
CESS OF U.S. TWO HUNDRED FIFTY DOLLARS (U.S.$250.00).
•Limitations on Reverse Engineering, Decompilation, and Dis-
assembly. You may not reverse engineer, decompile, or disassem-
ble the SOFTWARE, except and only to the extent that such activity
is expressly permitted by applicable law notwithstanding this
limitation.
•SOFTWARE TRANSFER ALLOWED BUT WITH RESTRICTIONS.
You may permanently transfer rights under this EULA only as part of
a permanent sale or transfer of the Device, and only if the recipient
agrees to this EULA. If the SOFTWARE is an upgrade, any transfer
must also include all prior versions of the SOFTWARE.
•EXPORT RESTRICTIONS. You acknowledge that SOFTWARE is
subject to U.S. export jurisdiction. You agree to comply with all appli-
cable international and national laws that apply to the SOFTWARE,
including the U.S. Export Administration Regulations, as well as
end-user, end-use and destination restrictions issued by U.S. and
other governments. For additional information see http://www.micro-
soft.com/exporting/.
#T559918; r. AA/20829/20829; en-US 1

Disclaimers1
1.9 EULA Terms
Qt4 Core and Qt4 GUI, Copyright ©2013 Nokia Corporation and FLIR Sys-
tems AB. This Qt library is a free software; you can redistribute it and/or modify
it under the terms of the GNU Lesser General Public License as published by
the Free Software Foundation; either version 2.1 of the License, or (at your op-
tion) any later version. This library is distributed in the hope that it will be
useful, but WITHOUT ANY WARRANTY; without even the implied warranty of
MERCHANTABILITY or FITNESS FOR A PARTICULAR PURPOSE. See the
GNU Lesser General Public License, http://www.gnu.org/licenses/lgpl-2.1.html.
The source code for the libraries Qt4 Core and Qt4 GUI may be requested
from FLIR Systems AB.
#T559918; r. AA/20829/20829; en-US 2

Safety information
2
WARNING
Applicability: Cameras with one or more batteries.
Do not disassemble or do a modification to the battery. The battery contains safety and protection devices
which, if damage occurs, can cause the battery to become hot, or cause an explosion or an ignition.
WARNING
Applicability: Cameras with one or more batteries.
If there is a leak from the battery and you get the fluid in your eyes, do not rub your eyes. Flush well with
water and immediately get medical care. The battery fluid can cause injury to your eyes if you do not do
this.
WARNING
Applicability: Cameras with one or more batteries.
Do not continue to charge the battery if it does not become charged in the specified charging time. If you
continue to charge the battery, it can become hot and cause an explosion or ignition. Injury to persons
can occur.
WARNING
Applicability: Cameras with one or more batteries.
Only use the correct equipment to remove the electrical power from the battery. If you do not use the cor-
rect equipment, you can decrease the performance or the life cycle of the battery. If you do not use the
correct equipment, an incorrect flow of current to the battery can occur. This can cause the battery to be-
come hot, or cause an explosion. Injury to persons can occur.
WARNING
Make sure that you read all applicable MSDS (Material Safety Data Sheets) and warning labels on con-
tainers before you use a liquid. The liquids can be dangerous. Injury to persons can occur.
CAUTION
Do not point the infrared camera (with or without the lens cover) at strong energy sources, for example,
devices that cause laser radiation, or the sun. This can have an unwanted effect on the accuracy of the
camera. It can also cause damage to the detector in the camera.
CAUTION
Do not use the camera in temperatures more than +50°C (+122°F), unless other information is specified
in the user documentation or technical data. High temperatures can cause damage to the camera.
CAUTION
Applicability: Cameras with one or more batteries.
Do not attach the batteries directly to a car’s cigarette lighter socket, unless FLIR Systems supplies a spe-
cific adapter to connect the batteries to a cigarette lighter socket. Damage to the batteries can occur.
CAUTION
Applicability: Cameras with one or more batteries.
Do not connect the positive terminal and the negative terminal of the battery to each other with a metal
object (such as wire). Damage to the batteries can occur.
#T559918; r. AA/20829/20829; en-US 3

Safety information
2
CAUTION
Applicability: Cameras with one or more batteries.
Do not get water or salt water on the battery, or permit the battery to become wet. Damage to the batteries
can occur.
CAUTION
Applicability: Cameras with one or more batteries.
Do not make holes in the battery with objects. Damage to the battery can occur.
CAUTION
Applicability: Cameras with one or more batteries.
Do not hit the battery with a hammer. Damage to the battery can occur.
CAUTION
Applicability: Cameras with one or more batteries.
Do not put your foot on the battery, hit it or cause shocks to it. Damage to the battery can occur.
CAUTION
Applicability: Cameras with one or more batteries.
Do not put the batteries in or near a fire, or into direct sunlight. When the battery becomes hot, the built-in
safety equipment becomes energized and can stop the battery charging procedure. If the battery be-
comes hot, damage can occur to the safety equipment and this can cause more heat, damage or ignition
of the battery.
CAUTION
Applicability: Cameras with one or more batteries.
Do not put the battery on a fire or increase the temperature of the battery with heat. Damage to the battery
and injury to persons can occur.
CAUTION
Applicability: Cameras with one or more batteries.
Do not put the battery on or near fires, stoves, or other high-temperature locations. Damage to the battery
and injury to persons can occur.
CAUTION
Applicability: Cameras with one or more batteries.
Do not solder directly onto the battery. Damage to the battery can occur.
CAUTION
Applicability: Cameras with one or more batteries.
Do not use the battery if, when you use, charge, or put the battery in storage, there is an unusual smell
from the battery, the battery feels hot, changes color, changes shape, or is in an unusual condition. Speak
with your sales office if one or more of these problems occurs. Damage to the battery and injury to per-
sons can occur.
#T559918; r. AA/20829/20829; en-US 4

Safety information
2
CAUTION
Applicability: Cameras with one or more batteries.
Only use a specified battery charger when you charge the battery. Damage to the battery can occur if you
do not do this.
CAUTION
Applicability: Cameras with one or more batteries.
The temperature range through which you can charge the battery is ±0°C to +45°C (+32°F to +113°F),
unless other information is specified in the user documentation or technical data. If you charge the battery
at temperatures out of this range, it can cause the battery to become hot or to break. It can also decrease
the performance or the life cycle of the battery.
CAUTION
Applicability: Cameras with one or more batteries.
The temperature range through which you can remove the electrical power from the battery is -15°C to
+50°C (+5°F to +122°F), unless other information is specified in the user documentation or technical data.
If you operate the battery out of this temperature range, it can decrease the performance or the life cycle
of the battery.
CAUTION
Applicability: Cameras with one or more batteries.
When the battery is worn, apply insulation to the terminals with adhesive tape or equivalent materials be-
fore you discard it. Damage to the battery and injury to persons can occur if you do not do this.
CAUTION
Applicability: Cameras with one or more batteries.
Remove any water or moisture on the battery before you install it. Damage to the battery can occur if you
do not do this.
CAUTION
Do not apply solvents or equivalent liquids to the camera, the cables, or other items. Damage to the bat-
tery and injury to persons can occur.
CAUTION
Be careful when you clean the infrared lens. The lens has an anti-reflective coating which is easily dam-
aged. Damage to the infrared lens can occur.
CAUTION
Do not use too much force to clean the infrared lens. This can cause damage to the anti-reflective
coating.
Note
The encapsulation rating is only applicable when all the openings on the camera are sealed with their
correct covers, hatches, or caps. This includes the compartments for data storage, batteries, and
connectors.
#T559918; r. AA/20829/20829; en-US 5

Notice to user
3
3.1 User-to-user forums
Exchange ideas, problems, and infrared solutions with fellow thermographers around the
world in our user-to-user forums. To go to the forums, visit:
http://www.infraredtraining.com/community/boards/
3.2 Calibration
We recommend that you send in the camera for calibration once a year. Contact your local
sales office for instructions on where to send the camera.
3.3 Accuracy
For very accurate results, we recommend that you wait 5 minutes after you have started
the camera before measuring a temperature.
3.4 Disposal of electronic waste
As with most electronic products, this equipment must be disposed of in an environmen-
tally friendly way, and in accordance with existing regulations for electronic waste.
Please contact your FLIR Systems representative for more details.
3.5 Training
To read about infrared training, visit:
• http://www.infraredtraining.com
• http://www.irtraining.com
• http://www.irtraining.eu
3.6 Documentation updates
Our manuals are updated several times per year, and we also issue product-critical notifi-
cations of changes on a regular basis.
To access the latest manuals and notifications, go to the Download tab at:
http://support.flir.com
It only takes a few minutes to register online. In the download area you will also find the lat-
est releases of manuals for our other products, as well as manuals for our historical and
obsolete products.
3.7 Important note about this manual
FLIR Systems issues generic manuals that cover several cameras within a model line.
This means that this manual may contain descriptions and explanations that do not apply
to your particular camera model.
#T559918; r. AA/20829/20829; en-US 6

Customer help
4
4.1 General
For customer help, visit:
http://support.flir.com
4.2 Submitting a question
To submit a question to the customer help team, you must be a registered user. It only
takes a few minutes to register online. If you only want to search the knowledgebase for
existing questions and answers, you do not need to be a registered user.
When you want to submit a question, make sure that you have the following information to
hand:
• The camera model
• The camera serial number
• The communication protocol, or method, between the camera and your device (for ex-
ample, HDMI, Ethernet, USB, or FireWire)
• Device type (PC/Mac/iPhone/iPad/Android device, etc.)
• Version of any programs from FLIR Systems
• Full name, publication number, and revision number of the manual
4.3 Downloads
On the customer help site you can also download the following:
• Firmware updates for your infrared camera.
• Program updates for your PC/Mac software.
• Freeware and evaluation versions of PC/Mac software.
• User documentation for current, obsolete, and historical products.
• Mechanical drawings (in *.dxf and *.pdf format).
• Cad data models (in *.stp format).
• Application stories.
#T559918; r. AA/20829/20829; en-US 7

Customer help
4
• Technical datasheets.
• Product catalogs.
#T559918; r. AA/20829/20829; en-US 8

Quick Start Guide
5
5.1 Procedure
Follow this procedure:
1. Charge the battery for approximately 1.5 hours, using the FLIR power supply.
2. Push the On/off button to turn on the camera.
3. Aim the camera toward your target of interest.
4. Push the Save button to save an image.
(Optional steps)
5. Install FLIR Tools on your computer.
6. Start FLIR Tools.
7. Connect the camera to your computer, using the USB cable.
8. Import the images into FLIR Tools.
9. Create a PDF report in FLIR Tools.
#T559918; r. AA/20829/20829; en-US 9

Description
6
6.1 View from the front
1. Camera lamp.
2. Digital camera lens.
3. Infrared lens.
4. Attachment point.
6.2 View from the rear
1. On/off button.
2. Save button.
3. Camera screen.
#T559918; r. AA/20829/20829; en-US 10

Description6
6.3 Connector
The purpose of this USB Micro-B connector is the following:
• Charging the battery using the FLIR power supply.
• Moving images from the camera to a computer for further analysis in FLIR Tools.
Note
Install FLIR Tools on your computer before you move the images.
6.4 Screen elements
1. Main menu toolbar.
2. Submenu toolbar.
3. Result table.
4. Status icons.
5. Temperature scale.
6. Spotmeter.
6.5 Auto-orientation
The camera has an auto-orientation feature, which means that the camera automatically
adjusts the measurement information on the display to the vertical or horizontal position of
the camera.
#T559918; r. AA/20829/20829; en-US 11

Description6
Note
The auto-orientation feature is enabled by a setting. Select Settings >Device settings >Auto orientation
>On.
6.6 Navigating the menu system
The camera has a touch screen. You can use your index finger or a stylus pen specially
designed for capacitive touch usage to navigate the menu system.
Tap the camera screen to bring up the menu system.
#T559918; r. AA/20829/20829; en-US 12
