Floe 510-27100-00 Quick start guide

SHEET 1 OF 16
FLOE QUICK ATTACH ROLL IN
X-SHALLOW WHEEL KIT
ASSEMBLY INSTRUCTIONS AND OWNERS MANUAL
4’, 5’, 6’ & 8’ WIDE DOCK SECTIONS
KIT P/N 510-27100-00, 510-27110-00
TOOLS REQUIRED
-9/16” SOCKET/WRENCH
-3/4” SOCKET/WRENCH
-CORDLESS DRILL WITH SOCKET
ADAPTER & 1-1/8” SOCKET OR
FLOE SPEED WRENCH
-TORQUE WRENCH
-TAPE MEASURE
-LEVEL
-BLOCKING MATERIAL
INSTRUCTION P/N: 610-27100-00
RELEASED 10/3/22
© Manufactured by:
Floe International Inc.
48473 State Hwy. 65
McGregor, MN 55760
www.floeintl.com
*DOCK NOT INCLUDED
NOTE:
FOR USE IN APPROXIMATELY 0”-13”
OF WATER.
WE RECOMMEND THAT THE LOWER
DOCK FRAME IS A MINIMUM OF 8”
ABOVE THE WATER WHEN
PROPERLY ADJUSTED. HOWEVER, IF
YOU HAVE HIGH WAVE
CONDITIONS THAT COMMONLY
EXCEED 15”, WE RECOMMEND
THAT YOU RAISE YOUR DOCK
ACCORDINGLY.
NEVER ADJUST YOUR DOCK LEGS WITH
AN IMPACT WRENCH. NEVER ADJUST
YOUR DOCK LEGS WITH MORE THAN 15
FT-LBS OF FORCE. APPLYING TOO MUCH
FORCE TO YOUR DOCK LEGS WILL
DAMAGE THE MECHANISM.

SHEET 2 OF 16
LEG ADJUSTMENT
NOTE:
FOR USE IN APPROXIMATELY 0”-13” OF WATER.
WE RECOMMEND THAT THE LOWER DOCK
FRAME IS A MINIMUM OF 8” ABOVE THE WATER
WHEN PROPERLY ADJUSTED. HOWEVER, IF YOU
HAVE HIGH WAVE CONDITIONS THAT
COMMONLY EXCEED 15”, WE RECOMMEND
THAT YOU RAISE YOUR DOCK ACCORDINGLY.
X-SHALLOW WHEEL KIT
FULLY EXTENDED
X-SHALLOW WHEEL KIT
FULLY COLLAPSED
NEVER ADJUST YOUR DOCK LEGS WITH
AN IMPACT WRENCH. NEVER ADJUST
YOUR DOCK LEGS WITH MORE THAN 15
FT-LBS OF FORCE. APPLYING TOO MUCH
FORCE TO YOUR DOCK LEGS WILL
DAMAGE THE MECHANISM.

SHEET 3 OF 16
BILL OF MATERIALS/EXPLODED VIEW
510-27100-00
WHEEL KIT, QA X-SHALLOW (PAIR) BZ
NUMBER
PART NUMBER
QTY.
DESCRIPTION
1 001-02322-00 1
FASTENERS, QA ROLL-IN SHALLOW W/K PAIR
(&X-SHALLOW)
2
002-00291-00
2
QUICK CONNECT, QA ROLL-IN – 2”
3
007-00040-00
2
SPACER, POLYETHYLENE – 1.5”
4
110-01209-00
2
ASS’Y, W/K LEG (X-SHALLOW) BRONZE
001-02322-00
FASTENERS, QA ROLL-IN SHALLOW W/K PAIR (& X-SHALLOW)
NUMBER
PART NUMBER
QTY.
DESCRIPTION
1A
001-26728-00
2
CLIP, STAINLESS STEEL SPINDLE
1B
001-70105-00
2
HHCS, 3/8-16 X 1” SS
1C
001-70205-00
2
HHCS, 1/2-13 X 1” SS 18-8
1D
001-76350-00
2
NUT, 1/2-13 ALUM.
1E
010-00020-00
2
WASHER, 2.5” O.D. X 1.75” I.D.

SHEET 4 OF 16
BILL OF MATERIALS/EXPLODED VIEW
510-27110-00
WHEEL KIT, QA X-SHALLOW (SINGLE) BZ
NUMBER
PART NUMBER
QTY.
DESCRIPTION
1 001-02321-00 1
FASTENERS, QA ROLL-IN SHALLOW W/K SINGLE
(& X-SHALLOW)
2
002-00291-00
1
QUICK CONNECT, QA ROLL-IN – 2”
3
007-00040-00
1
SPACER, POLYETHYLENE – 1.5”
4
110-01209-00
2
ASS’Y, W/K LEG (X-SHALLOW) BRONZE
001-02321-00
FASTENERS, QA ROLL-IN SHALLOW W/K SINGLE (& X-SHALLOW)
NUMBER
PART NUMBER
QTY.
DESCRIPTION
1A
001-26728-00
1
CLIP, STAINLESS STEEL SPINDLE
1B
001-70105-00
1
HHCS, 3/8-16 X 1” SS
1C
001-70205-00
1
HHCS, 1/2-13 X 1” SS 18-8
1D
001-76350-00
1
NUT, 1/2-13 ALUM.
1E
010-00020-00
1
WASHER, 2.5” O.D. X 1.75” I.D.

SHEET 5 OF 16
SUNDECK INSTALLATION
8’ WIDE SHOWN

SHEET 6 OF 16
STEP 1
TURN DOCK UPSIDE DOWN AND BLOCK CORNERS (OR USE A SOFT SURFACE) TO PROTECT THE
DECK SURFACE (FIGURE 1.1). INSTALL (1) 1/2" X 1” BOLT AND (1) 1/2" NUT INTO EACH POCKET
WELDED ON THE DOCK (FIGURE 1.2).
FIGURE 1.1
FIGURE 1.2
2X
NOTE:
DIAGRAMS SHOW 4’
WIDE DOCK
SECTIONS. IF YOU
ARE ATTACHING
WHEEL KITS TO AN
8’ WIDE SUNDECK,
REFER TO THE
EXPLODED VIEW ON
SHEET 5.

SHEET 7 OF 16
INSERT WHEEL KIT LEGS INTO THE POCKETS THAT ARE WELDED ON THE DOCK (FIGURE 1.3). UNDER
NORMAL CONDITIONS, THE WHEEL KITS ARE MOUNTED AS SHOWN IN FIGURE 1.4A. IF NECESSARY,
WHEEL KITS MAY BE TURNED 180° FOR BOAT LIFT CLEARANCE. HOWEVER, SOME STABILITY MAY BE
LOST (FIGURE 1.4B). REFER TO DOCK OWNER’S MANUAL FOR SPECIAL CONDITIONS ON SETTING
UP YOUR DOCK. TORQUE 1/2” BOLT TO 20 FT-LB (FIGURE 1.5).
FIGURE 1.3
FIGURE 1.4A
FIGURE 1.4B
FIGURE 1.5
2X
2X

SHEET 8 OF 16
STEP 2
FIRST, SLIDE THE SPACERS ONTO THE WHEEL KIT SPINDLE. THEN, SLIDE THE WHEEL(S) (SOLD
SEPARATELY) ONTO THE SPINDLE. LASTLY, PLACE A 2-1/2” WASHER ONTO THE SPINDLE (FIGURE 2.1).
INSERT SPINDLE CLIP LEG INTO ONE OF THE HOLES IN THE SPINDLE, THEN PULL CLIP DOWN TO
SNAP OTHER CLIP LEG INTO THE SECOND HOLE (FIGURE 2.2).
FIGURE 2.1
FIGURE 2.2
2X
2X

SHEET 9 OF 16
STEP 3
TURN DOCK RIGHT SIDE UP (FIGURE 3.1). ATTACH QUICK CONNECTS TO THE WHEEL KIT END OF
THE DOCK SECTION IF ANOTHER SECTION IS TO BE CONNECT TO IT. TO ATTACH DOCK
SECTIONS IN A STRAIGHT LINE, QUICK CONNECTS SHOULD BE ASSEMBLED AS SHOWN. SPACE THE
QUICK CONNECTS AS FAR OUT AS POSSIBLE (FIGURE 3.2).
FIGURE 3.1
FIGURE 3.2

SHEET 10 OF 16
WHEN ANOTHER DOCK SECTION CONNECTS TO A SIDE OF THE DOCK, QUICK CONNECTS
SHOULD BE PLACED AS SHOWN (FIGURE 3.3). ATTACH USING A 3/8” X 1” BOLT PER CONNECT
(FIGURE 3.4).
FIGURE 3.3
FIGURE 3.4

SHEET 11 OF 16
TORQUE BOLTS TO 6 FT-LBS (FIGURE 3.5). QUICK CONNECTS SHOULD BE SPREAD APART AS FAR AS
POSSIBLE TO KEEP THE JOINING SECTION FROM SHIFTING SIDEWAYS. PLACE CONNECTING DOCK
SECTIONS IN THE QUICK CONNECT INSTALLATION/REMOVAL POSITION WHEN INSTALLING OR
REMOVING MULTIPLE SECTIONS. PUSH THE DOCKS INTO POSITION IN THE WATER. ONCE THE
DOCKS ARE IN POSITION, PUT THEM IN THE QUICK CONNECTS SET POSITION (FIGURE 3.6).
FIGURE 3.5
FIGURE 3.6

SHEET 12 OF 16
WITH THE CAPS REMOVED FROM THE DOCK, USE A FLOE SPEED WRENCH OR 1-1/8” SOCKET AND
CORDLESS DRILL, ADJUST THE HEIGHT OF THE DOCK SO THE BOTTOM FRAME OF THE DOCK IS
APPROXIMATELY 8” ABOVE THE WATER. *SEE NOTE ON SHEET 1. TURN THE DOCK ADJUSTING NUT
ON THE TOP OF THE DOCK CLOCKWISE TO LOWER THE DOCK AND COUNTERCLOCKWISE TO
RAISE THE DOCK. USE A LEVEL TO MAKE SURE ALL DOCK SURFACES ARE LEVEL (FIGURE 3.7). ONCE
THE DOCK IS SET IN PLACE AND LEVELED, INSERT THE PLASTIC CAPS IN THE ADJUSTMENT NUT HOLE
(FIGURE 3.8).
FIGURE 3.7
FIGURE 3.8
2X
NEVER ADJUST YOUR DOCK LEGS WITH AN
IMPACT WRENCH. IF YOU CAN NOT TURN
THE ADJUSTING NUT, DO NOT FORCE IT –
YOU HAVE REACHED THE END OF THE
ADJUSTMENT RANGE. DO NOT EXCEED 15
FT-LBS. APPLYING TOO MUCH FORCE TO
YOUR DOCK LEGS WILL DAMAGE THE
MECHANISM.
CORDLESS DRILL MAY COME TO A
SUDDEN STOP WHEN THE LEG IS
FULLY EXTENDED OR RETRACTED.
BE SURE TO HAVE YOUR
CORDLESS DRILL IN CLUTCH
MODE WHEN ADJUSTING THE
LEGS. USE OF A CORDED DRILL
MAY CAUSE ELECTROCUTION.
FAILURE TO USE DRILL IN CLUTCH
MODE MAY CAUSE INJURY TO
YOUR HAND OR ARM.

SHEET 13 OF 16
NOTES

FLOE INTERNATIONAL, INC.
DOCK SYSTEM 15 YEAR LIMITED WARRANTY
FLOE INTERNATIONAL, INC. warrants, to the original purchaser, the FLOE dock system to be free from original defects in materials and workmanship under conditions
andloadsforwhichdesigned,andfromthedateofconsumerpurchase,(orifademo,fromthedateofrstservice),asfollows:
New Warranty Guidelines - Effective September 1, 2004
Two-Year Parts and Labor Warranty
FLOE INTERNATIONAL, INC. will repair or replace, at their option, any portion of the dock system which fails as a result of a defect in material or workmanship during
thersttwoyearsafterthedateofpurchase.ItemspurchasedbyFLOEINTERNATIONAL,INC.arewarrantedbytheoriginalmanufacturerandwarrantyisextended
only to the original retail purchaser. FLOE INTERNATIONAL, INC. reserves the right to inspect and perform repairs at its main facility (F.O.B.) McGregor, Minnesota.
Thisfulltwo-yearwarrantyincludespartsandlaboronthedocksystemandaccessoriesincludingthefollowing:
Aluminumframestructure,wheelkits,legbracing,supportpoles,quick-connects,benches,ladders,andbumpers.
Labor charges and mileage covered within 15 miles from FLOE or the authorized FLOE dealership performing the repairs. Additional mileage/travel charges will
applyiftravelover15milesisrequired.Thischargeisdeterminedbytherepairingdealerandmustbepaidbythecustomertothedealerperformingtherepairs.
Warranty does not cover damage, including broken welds, caused by improper handling, installation or removal, or any damage of any sort caused by the use of
powerequipment,suchasvehiclesusedtoremovedocks.
Extended Parts Warranty
Inadditiontothistwo-yearpartsandlaborwarranty,additionalwarrantycoverageappliestospecicpartsofthedockandaccessories.All warranty coverage beyond
two years is for parts only. Labor costs for any warranty claim are not covered past two years.
Aluminum Dock Frame & Aluminum Dock Deck — 15-Year Limited Warranty
Defects in material and workmanship of structural components of the dock frame and deck are covered for 10 years from the date of purchase (excluding paint
nish).FLOEwillprovidereplacementparts,onanonpro-ratedbasis,fortenyearsfromthedateofpurchasefortheseitemsiftheyarefoundtobedefectivein
workmanship.Afterthis10-yearpartswarranty,anadditionalve-yearpro-ratedwarrantycoversthesecomponentsasshownbelow.Aluminumdeckingwarranty
does not include paint wear, scratches or denting.
Year After Purchase Consumer Portion of Current Retail Price
11 40%
12 50%
13 60%
14 70%
15 90%
Carpet and Cedar Dock Decking
With the following exceptions, carpet, cedar and color fade dock decking is covered by the full two-year parts and labor warranty (above). On cedar decks, cracks and
splintering are normal characteristics of wood and are not covered by this warranty. There is no further warranty over the two years on cedar deck docks.
In addition to the two-year warranty, carpet docks are warranted to be free from defects in material and workmanship on a pro-rated basis, for up to 10 years as
shown below. Warranty does not cover fading, mildew, or wear.
Consumer Portion Consumer Portion
Year After Purchase of Current Retail Price Year After Purchase of Current Retail Price
3-5 0% 8 60%
6 40% 9 70%
7 50% 10 90%
page 1 of 2

Dock Accessories and Wheel Kit — 10-Year Limited Warranty
Defects in material and workmanship of certain accessories of FLOE dock systems are covered under a 10-year pro-rated warranty. Items covered in this 10-year
pro-rated warranty include wheel kit legs, wheel kit braces, plastic wheels, benches (except cedar boards), bumpers, ladders, shore-end ramps (except cedar boards),
support poles, and hammocks.
Thepro-ratedscheduleoftheseitemsisasfollows:
Year After Purchase Consumer Portion Year After Purchase Consumer Portion
of Current Retail Price of Current Retail Price
3 20% 7 60%
4 30% 8 70%
5 40% 9 80%
6 50% 10 90%
Dock Floats – 12-Year Limited Warranty
DockoatsusedonFLOEoatingdocksystemsarewarrantedtotheoriginalowneragainstcracking,peeling,sloughing,anddeteriorationfromultravioletrays,
while retaining its resiliency against ice and bumps by watercraft under normal usage.
Thiswarrantydoesnotcoveranyoatdrumthathasbeensubjecttonegligence,misuse,alterations,accidents,stormabuseorimproperinstallationandsupport.
Floatsarecoveredinthetwo-yearpartsandlaborwarranty.Inaddition,FLOEwillprovidereplacementoatsonanonpro-ratedbasisforthersteightyearsand
then pro-rated as below. Replacement labor not included.
Year After Purchase Consumer Portion of Current Retail Price
9 60%
10 70%
11 80%
12 90%
This warranty covers only the cost for replacement of materials due to defects in materials or workmanship, and represents the only warranty authorized by us. In
order to receive performance under this warranty, all warranty repairs must be authorized in advance by FLOE INTERNATIONAL, INC.
Additional Warranty Information Including Exclusions and Owner’s Rights
FLOE INTERNATIONAL, INC. will not be responsible for any costs incurred for unauthorized repairs or improper assembly. Unauthorized repairs may void the warranty
on items repaired! Warranty repairs are subject to a $20.00 customer (consumer) deductible co=payment. This warranty does not cover damage resulting from
overloading of the boat lift, misuse, wind, storm or ice damage, (or any act of God), being struck by any type of watercraft, or negligence. This warranty covers
personal use and does not apply to commercial or rental use. The manufacturer is not responsible for damage where repairs have been made or attempted by
others. Items purchased by FLOE INTERNATIONAL, INC. are warranted by the original manufacturer and warranty is extended only to the original retail purchaser.
FLOE INTERNATIONAL, INC. reserves the right to inspect and perform repairs at its main facility (F.O.B.) McGregor, Minnesota. The customer is responsible for freight
charges incurred in transporting the warranty product to and from FLOE or an authorized FLOE dealership, with the exception of claims covered by the two-year parts
and labor warranty that provides service up to 15 miles from the dealer. FLOE INTERNATIONAL reserves the right to inspect and perform rework at its main facility
(F.O.B.)McGregor,Minnesota.Specicationsmaychangewithoutnoticeorobligation.
Completing & Submitting Your Warranty Claim
To receive performance under this warranty, contact your authorized FLOE dealer. Be prepared to provide the following information so that the dealer can complete a
warrantyclaimform:receiptanddateofpurchase;yourname,addressandtelephonenumbers;theserialorvehicleidenticationnumbers;andadetaileddescrip-
tion of the problem.
THERE ARE NO OTHER EXPRESSED OR IMPLIED WARRANTIES
Our obligations under this warranty are limited to repair or replacement at our discretion, and FLOE SHALL NOT BE LIABLE FOR INCIDENTAL OR CONSEQUENTIAL
DAMAGES OF ANY KIND.
ThisWarrantygivesyouspeciclegalrightsandyoumayhaveotherrightswhichmayvaryfromstatetostate.
page 2 of 2

WARRANTY REGISTRATION
NOTE:FLOEproductsmustberegisteredwithin15daysofpurchasetovalidatewarranty.Pleasephotocopyandllout
theformbelowandplaceinanenvelopewithproperpostageorquicklyregisteronline.Pleasecompleteallinformation
requested.FLOEINTERNATIONAL,INC.isnotresponsibleforlost,stolenormisplacedwarrantyregistrations.Ifyouare
mailinginyourregistrationpleaseaddressitto:FLOEInternationalInc.,WarrantyRegistrationDept.
48473 State Hwy 65, McGregor, MN 55760-9514
NAME:_________________________________________________________________PHONE:______/_______________
ADDRESS:____________________________________________CITY:__________________STATE:__________ZIP:________
DATEPURCHASED:________/________/________ DEALERPURCHASEDFROM:_______________________________________
E-mail:_____________________________________________
Yes please Noyoucannotcontactmeviae-mailwithgreatoffersandspecialpromotionsfromFLOEInternationalandit’squalityauthorizeddealers.
PRODUCT PURCHASED Please check all that apply
FLOE TRAILER.............................Size:_________ Model:__________VIN#:__________________________________
POLARIS TRAILER .......................Size:_________ Model:__________VIN#:__________________________________
TRAILER ENCLOSURE...................Size:_________ Model:__________________________
BOAT LIFT SYSTEM...................... Model:__________________________
ROLL-IN DOCK ............................DECKINGIS:Cedar - Carpeted - Aluminum - Aluma-Grain
FLOATING DOCK .........................DECKINGIS:Cedar - Aluminum - Aluma-Grain
NOTE: Please list Size for each Dock Component.
Size:______x______ Size:______x______ Size:______x______ Size:______x______ Size:______x______
Size:______x______ Size:______x______ Size:______x______ Size:______x______ Size:______x______
Accessory:____________________ Accessory:____________________ Accessory:____________________
Accessory:____________________ Accessory:____________________ Accessory:____________________
TELL US ABOUT YOURSELF
HowdidyouhearaboutFLOE:_______________________________________________________________________________
FamilyIncome: 25,000 - 50,000 50,000 - 75,000 75,000 - 100,000 100,000 - 125,000 125,000 - 150,000 over 150,000
YourOccupation: Professional/Technical Upper Management/Executive Middle Management Sales/Marketing
Clerical/Service Worker Tradesman/Machine Operator/ Laborer
SpousesOccupation: Professional/Technical Upper Management/Executive Middle Management Sales/Marketing
Clerical/Service Worker Tradesman/Machine Operator/ Laborer
AgeRange: 18 - 29 30 - 45 46 - 55 over 55
Education: High School 2 year college 4 year college Graduate school
WhatmostinuencedyoutobuyaFLOEproduct:(selectone)
Advertisement Quality Warranty Price Style/Appearance Features/Benets
Instantly register your FLOE products online!
www.floeintl.com/registration
