1
Introduction
The Fluke 729 and 729 FC Automatic Pressure
Calibrators (the Product) are portable field pressure
calibration tools for lab or field use. This battery-operated
product performs automatic pressure calibration of
transmitters, pressure switches, and gauges. The
automatic functions are done by the Product or by
downloaded tasks from calibration-management software
(CMS). The Product also supplies basic HART®
communicator functions when used with HART-capable
transmitters. “FC” designates Fluke Connect®throughout
this manual.
Product key features and benefits include:
•Automatic pressure calibration of transmitters,
pressure switches and pressure gauges.
•Source and measure pressure to test and calibrate
pressure sensors, transmitters, and other pressure
instruments.
•Source and simulate milliamp signals while
measuring pressure for testing current to pressure
converters (I/P).
•HART (Highway Addressable Remote Transducer)
communication to configure and perform trim on
HART smart-pressure transmitters.
•Provides Loop Power and simultaneously measures
mA output from a connected device.
•Measures pressure with any of 50 Fluke-750P Series
pressure modules.
www.GlobalTestSupply.com
Find Quality Products Online at: [e-mail]

Automatic Pressure Calibrator
Standard Equipment
3
Standard Equipment
Figure 1 and Table 1 show standard equipment.
1
2
3
456
7
8
9
10
11 12 13
14
16
17
15
idj016.emf
Figure 1. Standard Equipment
www.GlobalTestSupply.com
Find Quality Products Online at: [e-mail]

729/729FC
Users Manual
4
Table 1. Standard Equipment
No. Equipment No. Equipment
729 or 729 FC Automatic Pressure Calibrator Fitting, 1/8 in NPT-Female X M20-Female
AC/DC converter Fitting, 1/4 in BSP-Female X 1/8 in NPT-Female
Mains line cable Hanger Kit
Rechargeable Li-ion Battery Hose to drain condensed water generated from
the Product. 1/8 in diameter, 1 ft length
Stackable test lead set Hose for leakage test. 1/8 in diameter, 2 in
length
AC280 Sure Grip hook set (red and black)
Not
Shown
Adjustable quick-release strap for hanging the
Product
Alligator clips (red and black)
One set of TP220 test probes (red and black) Soft carrying case
USB communication cable: 3 ft (1 m) Type A
plug for host (PC) to Mini-B plug for device Printed multilingual Safety Information
Nylon hose 1/8 in diameter, 3.5 ft length Traceable calibration report with data
Fitting, 1/8 in NPT-Female x 1/4 in NPT-
Female PTFE Tape
Tube fitting, male connector (qty 2), 1/8 in
NPT male connector, 1/8 in hose International AC Adapter Kit
www.GlobalTestSupply.com
Find Quality Products Online at: [e-mail]

Automatic Pressure Calibrator
Buttons
5
Buttons
See Figure 2 and Table 2 for the Product buttons and the softkeys.
4
13 98
12 11
10
7
6
5
3
2
1
18
16
15
14
17
idj001.emf
Figure 2. Buttons
www.GlobalTestSupply.com
Find Quality Products Online at: [e-mail]

729/729FC
Users Manual
6
Table 2. Buttons
Number Description Number Description
Power button. Push to turn on or turn off
the Product. Display brightness button. Push to change the display brightness from dim to bright and back again.

BACK button. Push to move to the
previous user interface (UI) screen. When
navigating through the screens, BACK can
move out of most screens and with
repeated pushes, can take you all the way
to the startup screen.
Numeric keypad. Used when a numeric entry is
necessary.

F1-F4 softkeys. Performs the specified
function of the label above each softkey on
the display. These labels change
throughout the UI.

ENTER button. Push to make a selection on the UI.
Only ENTER confirms numbers and characters.
Confirm all editable items with ENTER.

Arrow buttons. Push to move the display
cursor left, right, up, or down. Cursor
highlights in yellow over the selection.

CLEAR (ZERO) button. Push to clear highlighted
entry. When PI/PV/IP/SWT starts, push to zero the
pressure reading.

SELECT button. Push to make a selection
on the UI. This button cannot confirm
number or character choices (push
ENTER).
mA button. Push to select the mA measure function.
www.GlobalTestSupply.com
Find Quality Products Online at: [e-mail]

Automatic Pressure Calibrator
Buttons
7
Table 2. Buttons (cont.)
Number Description Number Description
VDC button. Push to select the measure dc
voltage function. 
SOURCE PRESSURE button. Use this function
to output (source) a target pressure from the
Product. Use the arrows to select the Setpoint
field and enter the values with the number
buttons.

SETUP button. Push to enter the Setup menu
to change operating parameters. See Setup
Menu.
MEASURE PRESSURE button. Use this function
for pressure measurement mode.
TASKS button. Push to enter the Tasks menu.
See TASKS Menu. HART button. Push to enter HART communication mode.

VENT button. Push to release pressure at the
internal pressure port. VENTING shows on the
display as the Product vents. VENTED shows
after venting is complete.

HOLD button. Push to freeze the reading on the
display. Push it a second time to release the hold
on the display. Push and hold to capture the
screen and save into memory.
www.GlobalTestSupply.com
Find Quality Products Online at: [e-mail]

729/729FC
Users Manual
8
The Display
Figure 3 and Table 3 explain the display.
13
12
10
9
12 3 4 5 6
7
8
11
idj014.emf
Figure 3. The Display
www.GlobalTestSupply.com
Find Quality Products Online at: [e-mail]

Automatic Pressure Calibrator
The Display
9
Table 3. The Display
Number Description Number Description
Step size indicator Pressure units indicator
Setpoint indicator 
External display shows selected device that is
connected. The device can be a pressure module,
temperature probe, process variable (PV) of
connected HART device, or Fluke Connect
secondary device reading.
Fluke Connect on indicator (729 FC only) Softkey indicator
HART on indicator Current, voltage, or pressure switch display
24 volt loop power active indicator Main display with measured or sourced value
Battery charge level Time and date display
Pressure port status
www.GlobalTestSupply.com
Find Quality Products Online at: [e-mail]

729/729FC
Users Manual
10
The display can also show different configurations:
Typically, the display does not show the third functions, see
Figure 4. See Triple-Function Display.
•The upper display for the internal pressure has these
different functions:
oVENT
oSOURCE
oMEASURE
•The lower display shows these different functions:
oMeasure Current
oSource Current
oSimulate Current
oMeasure VDC
oSwitch
Figure 4. Typical Dual-Function Display
www.GlobalTestSupply.com
Find Quality Products Online at: [e-mail]

Automatic Pressure Calibrator
The Display
11
The screen has two sections:
The upper display shows the internal pressure controller
status and includes:
•Mode: Measure, Source, and Vent
•Pressure Value: Current measured pressure and unit
•Status: Shows nothing in measure mode, NOT READY,
STABLE in source mode, and VENTING, VENTED in
vent mode.
•Setpoint: Current setpoint for source function.
•Step Size: The step size when B (Step Up) and
C(Step Down) are pushed when sourcing
pressure.
The lower display shows the electrical status and includes:
•Mode: Measure Current, Source Current, Simulate
Current, Measure V dc, and Switch.
•Reading: Current reading from measure functions or
setpoint for source functions.
•Switch State: Shows the pressure reading when the
switch contacts open and close.
•Percent: Shows the percentage value of 4 mA to 20 mA
or 1 V to 5 V in measure functions.
•Status: Shows Open circuit detected in mA source
mode.
www.GlobalTestSupply.com
Find Quality Products Online at: [e-mail]

729/729FC
Users Manual
12
Triple-Function Display
When the third function (RTD, External Pressure
Module, HART Transmitter, or FC secondary device) is
connected, the Product changes to triple-function display
automatically. In the subsequent triple-function display,
the original bottom half of the display is divided into two
parts:
•The left display continues to show the electrical
measurement display.
•The right display shows the model name, reading,
and units from the selected third function. See
Figure 5. The figure shows a transmitter device
(3051C).
When more than one third function is available, use the
arrow keys to highlight the device (in yellow) in the right
display. Then use the softkeys to select the device to
show.
Figure 5. Triple-Function Display
www.GlobalTestSupply.com
Find Quality Products Online at: [e-mail]

Automatic Pressure Calibrator
The Display
13
RTD Connection
The display can show RTD temperature measurements in
the selected unit (C/F) as the third-function. When the
temperature unit field highlights, push the softkey to toggle
the temperature setting. The ohms reading shows.
Note
The Product supports PT100-385 RTD only.
Pressure Module Connection
The Product automatically detects external pressure module
installation or removal. Move the cursor to the unit type and
push Eto configure the pressure-unit type (it can be
different from the pressure unit of internal pressure). Change
the unit type of the internal pressure to automatically change
the unit type of the pressure module.
Figure 6 shows a pressure module as the third function.
•When you plug in an external pressure module, the
pressure-unit type defaults to the internal pressure unit
type.
•When you remove or install an external pressure
module, the zero offset resets.
Figure 6. Triple-Function Display with External Pressure
Module Connected
www.GlobalTestSupply.com
Find Quality Products Online at: [e-mail]

729/729FC
Users Manual
14
Fluke Connect Device Connection
The display shows connected FC device measurements as
the third-function.
See Setup Menu for information to manage secondary FC
devices.
www.GlobalTestSupply.com
Find Quality Products Online at: [e-mail]

Automatic Pressure Calibrator
Ports
15
Ports
Figure 7 and Table 4 show the Product ports.
89
7
6
5
1
2
34
Left Right
Bottom
idj013.emf
Figure 7. Product Ports
www.GlobalTestSupply.com
Find Quality Products Online at: [e-mail]
