Fluke FEV300-CON-TY1 Original instructions

FEV300-CON-TY1
Type 1 Plug for Test Adapter EV Charging
FEV300-CON-TY2
Type 2 Plug for Test Adapter EV Charging
Safety Information
Introduction
The FEV300-CON-TY1 and FEV300-CON-TY2 are high-quality
accessories manufactured by FLUKE, which will enable you to perform
repeatable measurements with the Fluke FEV300.
These accessories can be used in combination with other test
equipment from Fluke such as the FEV300 that test function and
safety of charging equipment for electric vehicles.
Safety Information
A Warning identies conditions and procedures that are dangerous
to the user. A Caution identies conditions and procedures that can
cause damage to the Product or the equipment under test.
WX Warning
To prevent the possibility of electric shock or personal injury:
• Read all safety information before you use the Product.
• Do not alter the Product and use only as specied, or the
protection supplied by the Product can be compromised.
• Carefully read all instructions.
• Do not use the Product if it operates incorrectly.
• Do not touch voltages >30 V ac rms, 42 V ac peak, or 60 V dc.
• Limit operation to the specied measurement category,
voltage, or amperage ratings.
PN 5361891, May 2022
© 2022 Fluke Corporation. All rights reserved.
Specications are subject to change without notice.
All product names are trademarks of their respective companies.

• Do not exceed the Measurement Category (CAT) rating
of the lowest-rated individual component of a Product,
probe, or accessory.
• Comply with local and national safety codes. Use
personal protective equipment (approved rubber
gloves, face protection, and ame-resistant clothes) to
prevent shock and arc blast injury where hazardous live
conductors are exposed.
• Remove the input signal before you clean the Product.
• Do not use cable assembly there is damage. Examine the
cable assembly for damaged insulation, exposed metal.
Check cable assembly continuity.
• Measure a known voltage rst to make sure that the
Product operates correctly.
• Do not use the Product around explosive gas, vapor, or in
damp or wet environments.
• Do not use the Product if it is altered or damaged.
• Do not use cable assembly if there is damage. Examine
the cable assembly for damaged insulation and measure
a known voltage.
• Only connect the Product to the instrument and the
charging stations as indicated in the Specication section.
• Use the Product within the operating range only. The
operating range is specied in the Specication section.
Symbols
Symbol Description
WWARNING. RISK OF DANGER.
XWARNING. HAZARDOUS VOLTAGE.
Risk of electric shock.
Consult user documentation.

Measurement Category II is applicable to test and
measuring circuits connected directly to utilization points
(socket outlets and similar points) of the low-voltage
MAINS installation.

This product complies with the WEEE Directive and its
marking requirements. The a󰀩xed label indicates that
you must not discard this electrical/electronic product
in domestic household waste. Do not dispose of this
product as unsorted municipal waste. For information
about take-back and recycling programs available in
your country, see the Fluke website.

Product Disposal
Dispose of the Product in a professional and environmentally
appropriate manner:
• Delete personal data on the Product before disposal.
• Put the Product in the electrical waste.
Contact Fluke
Fluke Corporation operates worldwide. For local contact
information, go to our website: www.uke.com
To register your product, view, print, or download the latest manual
or manual supplement, go to our website.
Fluke Corporation Fluke Europe B.V
P.O. Box 9090 PO Box 1186
Everett, WA 98206 5602 BD EINDHOVEN
U.S.A. The Netherlands
Transport and Storage
Please keep the original packaging for future transport (for
example, if calibration is necessary). Any transport damage due to
faulty packaging will be excluded from warranty claims.
The accessory must be stored in dry, closed areas. In case of an
accessory being transported in extreme temperatures, a minimum
recovery time of 2 hours is required prior to any operation.
Available Versions
• FEV300-CON-TY1 to be used with EV charging station type 1
with xed cable and vehicle connector
• FEV300-CON-TY2 to be used with EV charging station type 2
with socket outlet or xed cable and vehicle connector

Operation Elements and Connectors
1Test cable connector to
test adapter
2EV connector for charging
stations type 1 with xed
cable and vehicle connector
3EV connector for charging
stations type 2 with panel
mount socket outlet or xed
cable and vehicle connector
FEV300-CON-TY2
Type 2 plug
FEV300-CON-TY1
Type 1 plug
2 3
1
How To Test
For operation please refer to instruction manual of the relevant test
equipment to be used.
Maintenance
When using the test adapter in compliance with the user manual,
no special maintenance is required. However, should functional
errors occur during normal operation, the after-sales service will
repair your instrument. Please contact the local service o󰀩ce.
Cleaning
WX Warning
• Remove all input signals and measurement circuits
before you clean the Product.
• Never use acid-based detergents or solvent liquids for
cleaning.
• After cleaning, do not use the Product until the Product is
dried completely.
To clean the Product, use a wet cloth and a mild household
detergent.

Specications
General Features
Safety .................................... IEC 61010-1, IEC 61010-2-030,
pollution degree 2
Ratings .................................. CAT II 300 V, max 10 A
FEV300-CON-TY1: up to 250 V
(single phase system), 50/60 Hz
FEV300-CON-TY2: up to 480 V
(three phase system), 50/60 Hz
Connectors............................ FEV300-CON-TY1 Type 1 plug:
AC charging mode 3, suitable to
IEC 62196-2 type 1 or SAE J1772
with vehicle connector (type 1,
5P single-phase)
FEV300-CON-TY2 Type 2 plug:
AC charging mode 3, suitable to
IEC 62196-2 type 2 panel mount
socket outlet or xed cable and
vehicle connector (type 2,
7P three-phase)
Operating temperature.......... -20 °C to 40 °C (-4 °F to 104 °F)
Storage temperature ............. -20 °C to 50 °C (-4 °F to 122 °F)
Operating humidity range...... 10 % to 85 % relative humidity
non-condensing
Storage relative humidity ...... 0 % to 85 % non-condensing
Operating altitude.................. 2000 m (6561 ft) max.
Length ................................... Approx. 590 mm (23.2 in)
including connectors
Weight ................................... Approx. 550 g (1.2 lb)
