Fly Products XENIT II User manual

VER. 2.0
* colors are indicative
© Copyright by FLY Products s.r.l.
Via Perù n. 30
63013 GROTTAMMARE (AP) - ITALY
tel./fax [phone]
www.flyproducts.com - [email protected]

XENIT II USER MANUAL VER. 2.0
Page 2
WHITE PAGE

XENIT II USER MANUAL VER. 2.0
© Copyright FLY Products s.r.l. Page 3
Index
Section
Description
1
XENIT II FEATURES
2
SPECIFICATIONS AND DIMENSIONS
3
TRIKE PARTS
4
ASSEMBLING THE FRAME
5
MOUNTING THE PROPELLER
6
SETTING UP MONO OR TANDEM FLIGHT
7
EMERGENCY PARACHUTE
8
A-ASSIST SYSTEM
9
STARTING AND STOPPING THE ENGINE
10
WARRANTY

XENIT II USER MANUAL VER. 2.0
Page 4
The XENIT II Trike is for all those pilots who want to fly alone or with a
passenger in a light but solid vehicle which is also cost-efficient, low-
maintenance and easy to transport.
The cage is made in powder-coated aluminum and the carriage bar, the
harnesses attach to, in stainless steel 304.
This guarantees safety, flexibility and support for the pilot and the passenger.
The choice of aluminum and steel is aimed at reducing weight whilst
maintaining solidity in the most important points.
Another important factor is the use of steel cables which keep the entire Trike
structure in shape and assure optimum performance.
The engine Thor family with the biggest displacement, liquid cooled that grants
an extraordinary steady power output and better performance at every rpm.
The die cast light-alloy aluminum cylinder grants a better thermal stability. The
liner with Nickel-Siliceous coating improves the piston sliding, its resistance to
wear and abrasion. The piston, gravity cast at high silicon content light alloy,
reduces thermal expansion and the coupling slack. The piston top design is
specific to optimize the compression ratio. The advanced technology and the
great performance of the new THOR 303 gives a better feeling when driving
making the flight even more performing, dynamic, reactive, beside granting
more stability.
It's equipped of big wheels and front fork with shock absorber.
XENIT II FEATURES
1

XENIT II USER MANUAL VER. 2.0
© Copyright FLY Products s.r.l. Page 5
MODEL
COSMOS 300
THOR 303
Cycle
2 strokes
2 strokes
Swept
volume
293.9 cc
281 cc
Power
36 HP at 7.500 RPM
38 HP at 8000 R.P.M.
Air intake
Airbox silencer - Diaphragm carburetor,
integrate choke system -
Reed valve intake
Reed valve in the crankcase
Cooling
system
Liquid cooling
Liquid cooling
Starter
Manual: 3S (Soft Starter System) - Dual:
Electric Starter + 3S (Soft Starter System)
Flash Starter
(Electric starter -optional)
Balancing
System
Counter-rotating shaft
Counter-rotating shaft
Reduction
1/3,04
Helicoidal teeth in oil bath with
2,8 or 3,2 reduction ratio
Ignition
Single Spark or Twin Spark version
Electronic CDI with adj. advance
Exhaust
pipe
Ceramic powder coating - Double joint
system, double rib reinforcement system
- Silencer pipe in anodized aluminum -
EGT sensor threaded hole
Expansion
with aluminum silencer
Fuel
Unleaded gasoline with 2,0% synthetic
oil (Motul710) - Unleaded gasoline with
1,5% synthetic oil (Motul800)
E5 petrol or LL AV GAS-al with
2,5% synthetic oil 100%
Fuel
consumption
3,2 liters/h at 40 kg of static thrust, prop.
160 cm at 4.500 RPM (2 blades) - 8,5
liters/h at 75 kg of static thrust, prop.
160 cm at 6.000 RPM (2 blades)
3 liters/h
at 30 Kg a of static trust
Weight
Single Spark, Manual: 25,0 kg
(full weight, radiator included,
liquid excluded)
Starting from Kg 20,5 (manual
starter model +radiator)
Propeller
rotation
Clockwise
Clockwise
Max pilot
weight kg
95 + 95
95 + 95
SPECIFICATIONS AND DIMENSIONS
2

XENIT II USER MANUAL VER. 2.0
Page 6
OVERALL DIMENSIONS
cm. 201 / ft. 6,6
cm. 189 / ft. 6,2
cm. 187
ft. 6,1

XENIT II USER MANUAL VER. 2.0
© Copyright FLY Products s.r.l. Page 7
1. Base frame
2. Crew seats cradle
3. Rim with protection net
4. Rim support frame
5. Propeller
6. Fuel tank
TRIKE PARTS
3

XENIT II USER MANUAL VER. 2.0
Page 8
Frame assembly and disassembly is very fast and easy.
The best way is to proceed in the following order:
Position part n. 1
Remove the belt.
Lift the back end of the carriage.
Place the back end of the carriage
on a box or any kind of support of
about 25cm (9,8 in.) high.
FRAME ASSEMBLY
4

XENIT II USER MANUAL VER. 2.0
© Copyright FLY Products s.r.l. Page 9
Position the cradle (part n. 2)
properly and insert the cradle
bolts.

XENIT II USER MANUAL VER. 2.0
Page 10
MOUNTING THE PROPELLER
5
MONO OR TANDEM FLIGHT SETUP
6
EMERGENCY PARACHUTE
7
“A” ASSIST SYSTEM
8
ENGINE START AND STOP
9
WARRANTY
10

XENIT II USER MANUAL VER. 2.0
© Copyright FLY Products s.r.l. Page
11
Warranty
Fly Products (Seller, Our, Us) warrants the original Purchaser that this product shall be
free from defects in materials and workmanship under normal use for a period of 12
months from the date of purchase. If for any reason this product is powered by fuel that
does not meet the criteria stated in the engine manual, or is used with other equipment,
parts or replaceable items (such as consumables) which are neither made nor approved
by Fly products, Fly Products shall not be responsible for any loss of quality, degradation
of performance or actual damage that results from the use of such fuel, equipment, parts
or replaceable items.
Seller obligation and liability under this warranty is expressly limited to repairing or
replacing, at Seller's option, any product not meeting the specifications. The dealer, from
whom you purchased the product, or Fly Products, will repair the product free-of-charge.
In no event shall Fly Products be liable to the Purchaser or any other person for any loss
or damage whether direct ot indirect orconsequential or incidental, including without
limitation, any damages or claims by third parties caused by defective products or
otherwise arising from the incorrect or otherwise improper use of this product.This
warranty applies only to defects in parts and workmanship relating to normal use.
It does not cover:
• damage arising from improper maintenance or negligence
• damage caused by incorrect pilot operation
• damage caused by wind or adverse weather conditions
• fair wear and tear
Fly Products shall, at its option, repair or replace any defective products. Improper use,
that is, use for purposes otherthan those mentioned in this manual will void the
warranty. 
Limited warrantyFly Products shall not be liable to the Purchaser or any other person for
damage arising from improper storage, handling or use of this product.Repairs to this
Product must be carried out by qualified technicians appointed by Fly Products. This
Product must be assembled in accordance with the instructions in this manual.
To obtain warranty service, please contact your dealer or Fly Products directly. Shipping
charges are the responsibility of the purchaser.
Internet info and upgrade
For information, more details and news see our internet site: www.flyproducts.com
