Forest garden Ultima Arch User manual

ULTIMA ARCH ASSEMBLY
ISSUE 0210
Fixing Pack Contents (UPARTFP) :
Required Tools : (Not Supplied )
Important :
Assembly
of this arch
requires
two people.
Helpful Tip : use the illustration of the screw/nail shown in each step to help you
identify which fixing is required during the assembly of your arch.
SHOULD YOU REQUIRE ANY ADDITIONAL GUIDANCE WITH THE ASSEMBLY OF YOUR ARBOUR PLEASE
CONTACT OUR TECHNICAL HELP LINE ON 0844 248 9853.
Thank you for choosing this arch manufactured by the UK's largest manufacturer of timber garden products. In order to gain the most benefit from it, please note
the following:
- If there are any technical queries with the product, please contact our customer help line on 0844 248 9853 between the hours of 8.30 am and 5.00 pm Mondayto
Friday.
-This product is pressure treated to ensure the longevity of all timber components and protect against rot. This may leave a colour difference on some parts that will
even out as a the moisture content stabilises.
- Please ensure that you thoroughly check all component parts for quantity and quality before you commence building the product. If there are any missing parts,
please contact the help line as shown immediately. The manufacturer cannot be held liable for damaged items once any part of the product has been fitted or altered
in any way (e.g. Painted)
- Timber is a natural material. It will shrink and swell as a result of varying moisture content.
- Please keep all plastic bags and small parts away from children in order to reduce the risk of suffocation.
Please note : arbour uprights will need to be concreted 465mm into ground.
Alternatively, if using post supports, you will be required to trim 465mm off the
bottom of each post.
70mm Screw x 10
50mm Screw x 24
SPIRIT LEVEL
TAPE MEASURE
HAMMER
POZI DRIVE SCREWDRIVER
DRILL
42
2
4
2
UPARTSU
POST 2400mm
ELD62
PLANED LATTICE 6x2ft
UPARTNRLN
LARGE NOTCHED
RAFTER
UCBC
ANGLED
BRACE
URCB6
LONG RAFTER
UPARTNRSN
SMALL
NOTCHED
3
1820
1465 790
2447,5
1355
“IMPORTANT, RETAIN FOR FUTURE REFERENCE: READ CAREFULLY”
Forest Garden Ltd, Units 291 & 296 Hartlebury Trading Estate, Hartlebury, Worcestershire, Dy10 4JB

12
34
505
8
X2
50mm
8
4
70mm
Position the rafter assembly into the slots. Make sure the
post assemblies are 1325mm apart. Secure using 2x50mm
screws through post into rafter as shown.
MUST PRE DRILL MUST PRE DRILL
MUST PRE DRILL
50mm
50mm
50mm
50mm
MUST PRE DRILL
50mm
50mm
8
NOTE IT IS SOMETIMES EASIER TO ATTACH RAFTER
ASSEMBLY WHILE PRODUCT IS LAY ON THE GROUND
6
70mm
50mm
50mm
Secure the lattice (ELD62) between two
posts (UPARTSU) using 2x50mm
screws through the lattice framing into
the post. Make sure the lattice is
positioned as shown with drainage
holes to the bottom of the assembly.
Repeat on both sides and construct 2.
Position the angled braces (UCBC) So that
they are flat onto the uprights and the long
rafters. Secure using 1x50mm through each
end.
70mm
70mm
70mm
70mm
70mm
70mm
Attach the rafters with
small notches
(UPARTNRSN) to the
large rafters (URCB6)
using 70mm screws
one in the centre and 2
300mm either side.
70mm
70mm
70mm
70mm
Position the large notched rafters
(UPARTNRLN) in the centre of the posts onto
the large rafter and secure using 70mm
screws.
ISSUE 0210
Forest Garden Ltd, Units 291 & 296 Hartlebury Trading Estate, Hartlebury, Worcestershire, Dy10 4JB
50mm
