Forest garden RPK90FP User manual

2309
2342
2342
A
B
2
4
5
Slot the Rafter 1 and 7 onto the ends of
the arc rafters as shown. Make sure that
they in line with each other and the un
notched post.
Do not secure to the post at this time.
Locate the notched posts so they are 18
inches in the ground and the un notched post
20 inches into the ground.
Alternatively if you are using a fencefast you
will need to trim this off the bottom of each
post.
4
50mm
Place the remaining rafters.
3
Slot the Arced rafters into the
notched posts as shown.
Secure using 2x50mm screws for the
middle and 1x50mm screw for each of
the outer posts through the notched
post into the arced rafter.
Place Rafter 4 so that the notch
overlaps the join between the two arc
rafters and sits on the un notched post
central, between the other rafters.
1
Before starting the construction it is a
good idea to lay the rafters out on the
ground and make sure that they all line
up, and for the positioning of the posts.
6

Forest Garden plc.
Unit 288 Hartlebury Trading Estate
Hartlebury
Worcestershire
Dy10 4JB
General Enquiries: 0844 248 9853
E-mail: [email protected]
www.forestgarden.co.uk
2745
2745
2490
DRILL POZI DRIVE SCREWDRIVER
SPIRIT LEVEL
TAPE MEASURE
HAMMER
REQUIRED TOOLS : (NOT SUPPLIED)
TRELLIS
Thank you for choosing this Pergola manufactured by the UK's largest manufacturer of timber garden products. In order to gain the most benefit from it, please note the
following:
- Exercise particular care and follow instructions.
- This Pergola is pressure treated. For extra protection from the elements we recommend that you treat your structure using a wood preservative treatment. Apply in
accordance with the manufacturers instructions.
- .In line with your statutory rights, please check all parts prior to assembly, as assembly of damaged parts may be deemed to be acceptance and this may affect the
remedies you are entitled to. If the product is not constructed in accordance with the instructions, or is altered in anyway (eg painted), the manufacturer cannot be held
liable for any resulting damage
- Timber is a natural material. It will shrink and swell as a result of varying moisture content.
- Please keep all plastic bags and small parts away from children in order to reduce the risk of suffocation.
- Important Note : Do not lean or stand on rafters during assembly they are not load bearing.
- If there are any technical queries with the product, please contact our customer help line on 0333 7777 089 between the hours of 8.30 am and 5.00 pm Monday to
Friday.
Important : Assembly
of this Pergola requires
two people.
MUST PRE DRILL
RAFTER 1 RPK90R1
1
3
120mm not to scale
70mm 13
When all the rafters are in the correct positions fix them
to the arced rafter by screwing through the rafter using
a 70mm screw for each.
Secure the rafters to each other using 2x120mm
screws, screwing from each side as shown.
Using the remaining 120mm screw, secure the central
rafter to the un notched post.
JE
1
1
1
1
Notched Upright RPK90NP
POST RPK90P
ARC RAFTER RPK90ARC
RAFTER 7 RPK90R7
RAFTER 4 RPK90R4
RAFTER 5 RPK90R5
RAFTER 6 RPK90R6
RAFTER 3 RPK90R3
RAFTER 2 RPK90R2
RAFTER 7 RPK90R7
1
1
3
2
1
50mm
120mm not to scale
3
4
70mm 13
RADIAL PERGOLA
90 DEGREES
ISSUE 0214
RPK90FP
Fixing Pack(RPK90FP)
7
