Forest garden UPK01 User manual

Forest Garden plc.
Unit 288 Hartlebury Trading Estate
Hartlebury
Worcestershire
Dy10 4JB
General Enquiries: 0844 248 9853
E-mail: [email protected]
www.forestgarden.co.uk
ULTIMA PERGOLA
UPK01
2700
2140 2140
2700
DRILL
POZI DRIVE SCREWDRIVER
SPIRIT LEVEL
TAPE MEASURE
HAMMER
REQUIRED TOOLS : (NOT SUPPLIED)
60mm
U-Bracket
TRELLIS
BRACE
25mm
Thank you for choosing this Pergola manufactured by the UK's largest manufacturer of timber garden products. In order to gain the
most benefit from it, please note the following:
- Exercise particular care and follow instructions.
- This Pergola is pressure treated to ensure the longevity of all timber components and protect against rot. This may leave a colour
difference on some parts that will even out as the moisture content stabilises. For extra protection from the elements we
recommend that you treat your structure using a wood preservative treatment. Apply in accordance with the manufacturers
instructions.
- In line with your statutory rights, please check all parts prior to assembly, as assembly of damaged parts may be deemed to be
acceptance and this may affect the remedies you are entitled to. If the product is not constructed in accordance with the
instructions, or is altered in anyway (eg painted), the manufacturer cannot be held liable for any resulting damage.
- This product will shrink and swell as a result of varying moisture content.
- Please keep all plastic bags and small parts away from children in order to reduce the risk of suffocation.
- Important Note : Do not lean or stand on rafters during assembly they are not load bearing.
- If there are any technical queries with the product, please contact our customer help line on 0333 7777 089 between the hours of
8.30 am and 5.00 pm Monday to Friday.
8
24
48
Important : Assembly
of this Pergola requires
two people.
MUST PRE DRILL
BRACE UCBCBI
POST USU94BI
RAFTER URCB9BI
12
8
4
ISSUE 0214
JE
UPK01FP (Fixing pack)
RETAIN FOR FUTURE REFERENCE: READ CAREFULLY.
UPK01FP

324mm
1950
25mm
U-Bracket 12 24
1
2
3
4
5
25mm
25mm
Fix the URCB9BI (rafters) in place
using 25mm screws to fix the rafter to
the brackets
URCB9BI
Secure the URCB9BI (rafters), with
U-brackets attached, to two of the
USU94BI (posts) using 2x60mm
Screws for each. Make sure the
post is lined up with U-bracket as
shown
Repeat the procedure for the
other rafter
USU94BI
URCB9BI
25mm 24
60mm
8
60mm
16
Space out the u-brackets evenly
along the URCB9BI (rafters) at
362mm. Secure in place using
2x25mm screws
Secure the UCBCBI (braces) in place
to the USU94BI (post) and the
URCB9BI (rafter) through the pre-
drilled holes using 2x60mm screws
for each brace
URCB9BI
UCBCBI
USU94BI
URCB9BI
