Fracarro EDFA 4 WDM User manual

287554 EDFA 4 WDM, 287553 EDFA 8 WDM
Multi-port EYFA Amplier user manual
Contents pages
Product Features 3
Installation 3
Set and Operation 4 to 12
Main Parameters 4
Diagram 4
Front Panel 5 to 6
Rear Panel 6
Operation Flow Chart 6 to 12
Web Server 12 to 18
Notes 19
Solution to ordinary problems 19
Warranty Terms 20
Product Features
1. Output adjustable by buttons in the front panel or web SNMP, the range is down 4dBm
2. Maintenance function of one-time downward attenuation of 6dBm by buttons in the front
panel or web SNMP, to facilitate the optical ber hot-plug operation without turn off the device
3. Multi- ports output, can built in 1310/1490/1550WDM.
4. Standard RJ 45 port for remote control, we can provide output contract and web manager for
choice, and also plug-in SNMP hardware can be reserved for update.
5. With laser key to turn on/off the laser.
6. With RF test function.
7. Adopts JDSU or Oclaro Pump laser
8. Led displays the working condition of the machine
9. Dual power hot plug power supply for choice, 90V～250V AC or -48V DC
Installation
Before installation
1. Please be sure there is no visible damage outside the machine.
2. Please check the spare parts is complete or not, if not complete, please contact the seller.
Installation
1. Please keep at least 4.5cm (1.75inches) space for cooling if the machine is installed with
other machines.

2. Please check the power supply socket and the grounding of the power supply, the
grounding impedance should be ≤4Ω, 220V power supply should be with three cables and
the grounding cable should be in the middle, Untted grounding will damage the device or
influence the signal quality.
3. Please make sure the power supply switch is off in the rear panel
4. Please conrm the ber port is clean before connection the ber.
MAIN PARAMETERS
Item Parameters
EDFA 4 WDM EDFA 8 WDM
Total output power (dBm) 29 31
Total output power (mW) 800 1250
Each port power (dBm) 22 20
Each port power (mW) 160 100
Input(dBm) -5 ~+10 -8 ~+10
Range of output
adjustment dBm) Down 4
one-time downward
attenuation (dBm)
Wavelength (nm)
Down 6
1540~1565
Output stability (dB) <±0.3
Optical Return Loss (dB) ≥45
Fiber Connector SC/APC, SC/UPC
Noise Figure (dB) <6.0(input 0dBm)
Web port RJ45(SNMP)
Power Consumption (W) ≥80
Voltage (V) 220VAC(90~265), -48VDC
Working Temp (°C) -0 ~ 55
Size (mm) 370(L)×486(W)×88(H)
NW (Kg) 8
2

Product Features
DIAGRAM
Single input, standard Model
LED - DISPLAY
Single input
4 Ports With WDM
Dual inputs
8 Ports～With WDM
3

LED - DISPLAY
LED Display
Displays the working parameter of the machine
STATUS Indication light
Green: Normal Condition
Red: No input or abnormal condition
INPUT Indication Light
Green: Normal
OUTPUT Indication Light
Green: Normal
POWER Indication Light
Green: Power Connected
Key
ON: Turn on the laser
OFF: Turn off the laser
RS232
Network management for local computers
RJ45
SNMP, for remote computer network management
Rear Panel
Power Switch（220V（
ON: Turn on the power
OFF: Turn off the power
Power Socket
AC220V and DC-48V
4

5
OPERATION FLOW CHART
The following menu displays with “～” button, Use the “～” button to do the reverse loop, “ESC” as the return
button.
Single input operation flow chart:

6
Operating instructions
WEB SERVER
The user can use web browser to check the working condition and basic parameters of the amplier, it
supports IE, Chrome, Firefox ,opera and other main web browser. The following example are based on Opera
browser.
1.Please nd the IP add in the machine, normally it is 192.168.0.XXX, set the IP add of the PC in the same
range as following steps:

7

8
Operating instructions

9
2 .Open web browser, input the IP add～For example: 192.168.0.22
Then login version
User Name: admin
Password: 123456

10
Operating instructions
3. The working condition version:
4.4 Items guide on the left, click to enter:

11

Operating instructions
12

13

Operating instructions
14
NOTES
1. The main component of the amplier laser is sensitive to the static electricity, so please keep the
amplier away from the static electricity. Furthermore, please keep it away from caustic things. Please
keep the amplier in temperature between -25～and 65～.
2. Please make sure the power is earthed.
3. Please don’t now attempt to look into the optical connectors when power applied, eye damage may
result.
4. Please don’t block up the heating dispersion hole and keep the machine aired.
5. Please don’t unfold the machine or remove any parts of the machine.
6. Please don’t insert the patch cord when the power is on
7. Please don’t test the EDFA more than repeatedly.
SOLUTION TO SOME ORDINARY PROBLEM
1. Power supply light STATUS: green
LED light LASER: red
VFD display: NO LASER INPUT
Reason: N0 1550nm optical input
Solution: Input 1550nm optical signal
2. In LED n it displays the right optical power, but not enough by test meter
Reason: 1. the optical meter is not very correct
2. the input optical power is out of the requested value( -3~10dB)
3. too big loss in the test pigtail
4. There is dust in the connectors
Solution: Use absolute alcohol to wash the all the connects and the test point of optical meter
Note:
1. Don’t use Chinese optical meter to test EDFA.
2. Don’t test EDFA with pigtail again and again, it will hurt the ber connector and make the factual
power become smaller.

15
NOTE

Fracarro Radioindustrie SRL
Via Cazzaro n.3 - 31033 Castelfranco Veneto (TV) - ITALIA - Tel: [phone] - Fax: [phone].
Fracarro France S.A.S.
7/14 rue du Fossé Blanc Bâtiment C1 - 92622 Gennevilliers Cedex - FRANCE Tel: [phone] - Fax: [phone]
Fracarro (UK) - Ltd
Suite F9A, Whiteleaf Business Centre, Little Balmer, Buckingham, MK18 1TF UK - Tel: [phone] - Fax: [phone]
www.fracarro.com - [e-mail] - [email protected] - chat whatsapp [phone]
Garantito da/ Guaranteed by/ Garanti par/ Garantiert durch
Fracarro Radioindustrie SRL, Via Cazzaro n. 3, 31033 Castelfranco Veneto (Tv) – Italy
fracarro.com
EDFA WDM Quick Guide - 05-11-2020
For further information (i.e. complete user manual, any rmware updates, etc.) please refer to the technical section of our website
www.fracarro.it or www.fracarro.com
