Franke DVS AC17-080 Manual

Thermal Disinfection Valve
Installation & Operating Instructions
Dart Valley Systems | Kemmings Close | Long Road | Paignton | Devon | TQ4 7TW | UK
t [phone] | f [phone] | www.dartvalley.co.uk | [e-mail]
Step 2 : PartsStep 1 : Safety First
These instructions relate to the use of the Thermal
Disinfection Valve only, any external or ‘add-on’ parts will be
supplied with separate instructions.
You must read these instructions thoroughly before attempting
to install this product.
Please note; Once returned to normal operation, be sure
to run water for 10 seconds to purge out hot water in cold
pipework.
IMPORTANT : Please read these instructions
carefully and follow each stage in order!
A typical system will comprise of the parts* below:
Instruction Manual x1
PP00-749 080219
Step 3 : Optional parts
Optional system parts will comprise of the parts* below:
1x Label 1x Allen key 1x AC17-080
UC00-070 - Reducing Kit
AC17-080

Page 4
MT04-001 AquariTherm Tap (Manual) www.dartvalley.co.uk
Revision No. MAQTIN16071301
PP00-749 080219
Step 4 : Typical Installation
Warranty
The DVS Thermal Disinfection Valve is guaranteed for 5 years from purchase against defective material and assembly.
Support
For technical support please visit our technical pages on our website at www.dartvalley.co.uk or contact us by e-mail at;
[e-mail] Alternatively, you can telephone us direct on 01803 529021 and our customer service team will be
pleased to help you.
Head Office
Dart Valley Systems Ltd
Kemmings Close
Long Road
Paignton
Devon
UK
TQ4 7TW
Contact Details
t : [phone]
f : [phone]
e : [e-mail]
w : www.dartvalley.co.uk
Warranty & Support
HOT
COLD
The Thermal Disinfection Valve is typically directly plumbed
into the water supply, when a thermal purge is required the
valve can be switched between “NORMAL” and “PURGE”
operation via quarter turn.
The Thermal Disinfection Valve will not function correctly
unless Hot water is fed into the Red inlet and Cold water is fed
into the Blue inlet.
IMPORTANT:
Ensure pipe length for hot feed is as short as practicable.
This product is not to be used as a thermostatic mixing valve.
This Thermal Disinfection Valve should be installed prior to
and used in conjunction with an approved thermostatic mixing
valve.
Page 2
NORMAL OPERATION THERMAL PURGE OPERATION
AC17-080 Thermal Disinfection Valve (TDV)
As short as practicable
