Front Runner RRAC178 User manual

RRAC178_REV_A00 © 2020 FRONT RUNNER VEHICLE OUTFITTERS
front runner
RRAC178
ENG
1
Thank you for purchasing a Front Runner Rack Mount Shower Cubicle.
Before you start, take a moment to familiarize yourself with the Fitting Instructions and the components received.
Refer to Page 2 for a list of all the components, quantities and tools required.
READ ME !
IMPORTANT WARNING!
IT IS CRITICAL THAT ALL FRONT RUNNER PRODUCTS BE PROPERLY AND SECURELY ASSEMBLED AND ATTACHED TO YOUR VEHICLE. IMPROPER ATTACHMENT COULD
RESULT IN AN AUTOMOBILE ACCIDENT, AND COULD CAUSE SERIOUS BODILY INJURY OR DEATH. YOU ARE RESPONSIBLE FOR ASSEMBLING AND SECURING ALL FRONT
RUNNER PRODUCTS TO YOUR VEHICLE, CHECKING THE ATTACHMENTS PRIOR TO USE, AND PERIODICALLY INSPECTING THE PRODUCTS FOR ADJUSTMENT, WEAR AND
DAMAGE. THEREFORE, YOU MUST READ AND UNDERSTAND ALL OF THE INSTRUCTIONS AND PRECAUTIONS SUPPLIED WITH YOUR FRONT RUNNER PRODUCT PRIOR TO
INSTALLATION OR USE. IF YOU DO NOT UNDERSTAND ALL OF THE INSTRUCTIONS AND CAUTIONS, OR IF YOU HAVE NO MECHANICAL EXPERIENCE AND ARE NOT THOROUGHLY
FAMILIAR WITH THE INSTALLATION PROCEDURES, YOU SHOULD HAVE THE PRODUCT INSTALLED BY A PROFESSIONAL INSTALLER OR OTHER QUALIFIED PERSONNEL.
NOTE: Front Runner will not be responsible for any damage caused by the failure to install the product according to these instructions.
Please call us if you have any questions about the installation of this product.
Rack Mount Shower Cubicle

RRAC178_REV_A00 © 2020 FRONT RUNNER VEHICLE OUTFITTERS 2
TOOLS NEEDED
FIGURE 1.1
GET ORGANIZED
1
IN THE BOX
6
8
4
10
5
2
1
7
9
3
11
1
1
1 1 X Shower Cubicle Kit
4 X Peg
4 X Guy Rope and Tensioner
2 3 X Poles
3 2 X Top Bracket
4 2 X Bottom Bracket
5 2 X Elbow
6 2 X M8 x 16 Button Head Bolt
7 2 X M8 x 25 Button Head Bolt
8 2 X M8 Schnorr Washer
9 2 X M8 x 16 x 1.6SS Flat Washer
10 2 X M8 Thin Nut
11 2 X M8 Nyloc Nut
5mm

RRAC178_REV_A00 © 2020 FRONT RUNNER VEHICLE OUTFITTERS
3
FIT AND SECURE2
2.1
2.2
2.3
Determine where you want to mount your
Shower Cubicle on the side of your Front
Runner Rack.
The Shower Cubicle frame spans over six
slats.
Slide two M8 Nyloc Nuts (Item 11), nyloc
facing down in the side profile using the
opening on the inside of the corner as show.
Align the nuts with slat 1 and slat 6. See 2.2.
Slide two M8 Thin Nuts (Item 10) into the
chosen slats using the machined slots as
shown.
Secure the Top and Bottom Brackets (Items
3 & 4) to the rack using M8 x 16 Button Head
Bolts, M8 x 25 Button Head Bolts, M8 x 16
x 1.6SS Flat Washers, M8 Schnorr Washers
(Items 6, 7, 8 & 9) and the nuts inserted in
2.1 as shown
Insert two Poles (Item 2) through both the
holes in the Top Bracket (Item 3) as shown.
4mm
1
2
3
4
5
6

RRAC178_REV _A00 © 2020 FRONT RUNNER VEHICLE OUTFITTERS 4
FIT AND SECURE2
2.4
2.5
2.6
Slide the Curtain onto one of the Poles
inserted in 2.3.
Insert the Elbows (Item 5) into each end of
the third Pole (Item 2).
Slide the other ends of the Elbows into the
two Poles inserted in 2.3 as shown.
Close the Cubicle by slide it along the rail to
the other side.
5
3

RRAC178_REV _A00 © 2020 FRONT RUNNER VEHICLE OUTFITTERS 5
INSTALL OTHER VEHICLE AND RACK ACCESSORIES
4
Now's the time to visit your favorite Front Runner Dealer in person or online.
Be sure to tag us. We love to see our gear in action! #FrontRunnerOutfitters #BornToRoam
Share your adventures on:
FINISH
3
Congratulations! You did it. Take a step back and admire your work!
FIT AND SECURE2
2.7
Set the four bottom corners using the Guy
Ropes and Pegs
Loop the one end of the Guy Rope through
the eyelet and back through the Tensioner.
Tie the end of the Guy Rope to the Peg.
Eyelet
Guy Rope
Peg
Tensioner
