Front Runner QE Series User manual

ENG
220 min
Mitsubishi Pajero Sport (QE Series)
Foot Rail
FAMP002_REV_A00 © COPYRIGHT 2016 FRONT RUNNER VEHICLE OUTFITTERS
1
IMPORTANT WARNING!
Don’t be a hero and muscle through this without first reading these fitting instructions! Improper installation of this gear may void certain aspects of
your warranty.
Before you begin, take a moment and open all your Front Runner rack kit boxes and gather the assembly instructions for the various components.
A complete kit will contain:
1. A Front Runner Mounting System specific to your vehicle
2. A Front Runner Rack Tray or Load Bar Slats
This document will guide you through the assembly of the mounting system and assist you in fitting the roof rack tray or load bars to your specific
vehicle.
Please refer to the next page for a list of all the components, quantities and tools required.
FAMP002
READ ME FIRST
START HERE!
IT IS CRITICAL THAT ALL FRONT RUNNER PRODUCTS BE PROPERLY AND SECURELY ASSEMBLED AND ATTACHED TO YOUR VEHICLE. IMPROPER ATTACHMENT COULD
RESULT IN AN AUTOMOBILE ACCIDENT, AND COULD CAUSE SERIOUS BODILY INJURY OR DEATH. YOU ARE RESPONSIBLE FOR ASSEMBLING AND SECURING ALL FRONT
RUNNER PRODUCTS TO YOUR VEHICLE. CHECKING THE ATTACHMENTS PRIOR TO USE, AND PERIODICALLY INSPECTING THE PRODUCTS FOR ADJUSTMENT, WEAR AND
DAMAGE. THEREFORE YOU MUST READ AND UNDERSTAND ALL OF THE INSTRUCTIONS AND PRECAUTIONS SUPPLIED WITH YOUR FRONT RUNNER PRODUCT PRIOR TO
INSTALLATION OR USE. IF YOU DO NOT UNDERSTAND ALL OF THE INSTRUCTIONS AND CAUTIONS, OR IF YOU HAVE NO MECHANICAL EXPERIENCE AND ARE NOT THOROUGHLY
FAMILIAR WITH THE INSTALLATION PROCEDURES, YOU SHOULD HAVE THE PRODUCT INSTALLED BY A PROFESSIONAL INSTALLER OR OTHER QUALIFIED PERSONNEL.

FAMP002_REV_A00 © COPYRIGHT 2016 FRONT RUNNER VEHICLE OUTFITTERS 2
IN THE BOX
FIGURE 1.1
1 2 X Front Foot Rail; 1xLH, 1xRH
2 2 X Rear Foot Rail; 1xLH, 1xRH
3 2 X Foot Spacer 1
4 2 X Foot Spacer 2
5 2 X Foot Spacer 3
6 2 X Foot Spacer 4
7 2 X Joiner Plate
8 20 X Nut Cap M6
9 12 X M6 x 20 Hex Bolt
10 12 X M6 Spring Washer
11 20 X M6 x 12 x 1 SS Flat Washer
12 10 X M8 x 20 Hex Bolt
13 10 X M8 x 16 x 1.6 SS Flat Washer
IN THE BOX
TOOLS NEEDED
12mm
13mm
4mm
10mm Allen Key
Measuring
Tape
IN THE BOX IN THE BOX
14 10 X M8 Nyloc Nut
15 10 X M8 Nut Cap
16 8 X M6 x 16 Button Head Bolt
17 8 X M6 Nyloc Nut
IN THE BOX IN THE BOX CONTINUED
1RH
2RH
16
84
6
13
14
15
10
8
10
8
3
9
11
12
14
13
5
12
15
7
11
9
17
11
1GET ORGANIZED
Here is what you are looking at for FAMP002

© COPYRIGHT 2016 FRONT RUNNER VEHICLE OUTFITTERS
3 FAMP002_REV_A00
FIT AND SECURE
2
13mm
2.1
2.2
2.3
Before you start with the fitment of the
foot rails, you need to remove the
factory roof rails. Do this by unclipping
and removing the front and rear
end-caps of the roof rail. In the middle of
the roof rail you will see a small cover
plate, this will also need to be removed.
Now loosen the two bolts in front, one
bolt in the middle and 3 bolts at the rear
of the roof rail.
After you have removed all the bolts,
remove both the roof rails from the
vehicle.
11
7
17
8
16
Place a bead of sealant in and over each
hole in the roof, then place the spacers
(items 3, 4, 5 & 6) over front, middle and
two rear holes as shown.
Place the foot rail that you assembled in
step 2.2 on the spacers and loosely
secure it with items 9, 10 & 11 as shown.
Assemble the front and rear foot rail
(items 1 and 2) with the joiner plate
(item 7) and fasteners (items 16, 11, 17
& 8) as shown.
10mm
4mm
12mm
10mm
3
4
5
6
11
9
10
FRONT OF VEHICLE
Factory Roof Rails

© COPYRIGHT 2016 FRONT RUNNER VEHICLE OUTFITTERS
4 FAMP002_REV_A00
4
FIT AND SECURE
3
2.2
2.4
2.1
3.2
3.3
4MM
3.1
Refer to RRSTUNI when assembling your Slimline II Tray.
Make sure that the wind deflector is
installed before you proceed to the next
step.
3.4
Centre the rack and fully tighten all the fasteners. Use M6 & M8 nut caps (Items 8 & 15) to
finish off the nuts.
Slide item 12 into the t-slots shown in
step 3.3. Loosely fit the roof rack to the
foot rails by using items 13 & 14.
12
13
14
13mm
13mm

© COPYRIGHT 2016 FRONT RUNNER VEHICLE OUTFITTERS
5 FAMP002_REV_A00
4
COMPLETION
4
INSTALL OTHER VEHICLE AND RACK ACCESSORIES
5
Now's the time to visit your favorite Front Runner Dealer in person or online.
9
4.1
Congratulations. You did it. Take a step back and admire your work!
