Front Runner TRAC003 User manual

ENG
120 min
TRAC003_REV_A00_MV © COPYRIGHT 2016 FRONT RUNNER VEHICLE OUTFITTERS
1
IMPORTANT WARNING!
Don’t be a hero and muscle through this without first reading these fitting instructions! Improper installation of this gear may void certain aspects of
your warranty.
Before you begin, take a moment and open all your Front Runner rack kit boxes and gather the assembly instructions for the various components.
A complete kit will contain:
1. A Front Runner Mounting System specific to your vehicle
2. A Front Runner Rack Tray or Load Bar Slats
This document will guide you through the assembly of the mounting system and assist you in fitting the roof rack tray or load bars to your specific
vehicle.
Please refer to the next page for a list of all the components, quantities and tools required.
TRAC003
READ ME FIRST
START HERE!
1800mm - 70.8 inch
Universal Track
IT IS CRITICAL THAT ALL FRONT RUNNER PRODUCTS BE PROPERLY AND SECURELY ASSEMBLED AND ATTACHED TO YOUR VEHICLE. IMPROPER ATTACHMENT COULD
RESULT IN AN AUTOMOBILE ACCIDENT, AND COULD CAUSE SERIOUS BODILY INJURY OR DEATH. YOU ARE RESPONSIBLE FOR ASSEMBLING AND SECURING ALL FRONT
RUNNER PRODUCTS TO YOUR VEHICLE. CHECKING THE ATTACHMENTS PRIOR TO USE, AND PERIODICALLY INSPECTING THE PRODUCTS FOR ADJUSTMENT, WEAR AND
DAMAGE. THEREFORE YOU MUST READ AND UNDERSTAND ALL OF THE INSTRUCTIONS AND PRECAUTIONS SUPPLIED WITH YOUR FRONT RUNNER PRODUCT PRIOR TO
INSTALLATION OR USE. IF YOU DO NOT UNDERSTAND ALL OF THE INSTRUCTIONS AND CAUTIONS, OR IF YOU HAVE NO MECHANICAL EXPERIENCE AND ARE NOT THOROUGHLY
FAMILIAR WITH THE INSTALLATION PROCEDURES, YOU SHOULD HAVE THE PRODUCT INSTALLED BY A PROFESSIONAL INSTALLER OR OTHER QUALIFIED PERSONNEL.

TRAC003_REV_A00_MV © COPYRIGHT 2016 FRONT RUNNER VEHICLE OUTFITTERS 2
IN THE BOX
FIGURE 1.1
IN THE BOX IN THE BOX
2
1
3
5
4
1GET ORGANIZED
Here is what you are looking at for TRAC003
IN THE BOX
1 10 X
2 2 X
3 2 X
4 10 X
5 10 X
M6 x 30 Counter Sunk Bolt
1800mm Roof Track
1800mm Protective Trim
M6x30x1 Flat Washer M6
Nyloc Hex Nut
IN THE BOX TOOLS NEEDED
10 mm
4mm
Allen Key
Measuring
Tape
IN THE BOX
Sealant
Hacksaw
Marker 4mm
7mm
Utility
Knife

4
3
2
1
© COPYRIGHT 2016 FRONT RUNNER VEHICLE OUTFITTERS
3 TRAC003_REV_A00_MV
2.1
Remove the vehicles' interior head lining and factory fitted roof rails if fitted. Determine best possible
position for mounting the tracks. Positioning over the ditch molding is preferred and take care not to
drill into or through any reinforcements. Mesure and trim the tracks to the desired length.
FIT AND SECURE
2
10mm
2.6
Fit and secure the tracks with the
supplied fasteners. (Items 1, 4 and 5)
Reinstall vehicles interior head lining
removed in step 2.1
10mm
2.2
Once you are happy with the placement of the track, mark all the holes using a suitable marking pen.
2.3
Drill a 4mm pilot hole and then open up the pilot hole with a 7mm drill bit. Take care when drilling.
2.4
Peel off the double sided tape backing from the tracks (Item 2) and apply the protective rubber trim
(Item 3). Remove the excess with a craft knife.
2.5
Apply a bead of suitable sealant to each hole drilled in step 2.3
INSTALL OTHER VEHICLE AND RACK ACCESSORIES
5
Now's the time to visit your favorite Front Runner Dealer in person or Online.
COMPLETION
4
Congratulations. You did it. Take a step back and admire your work!
4mm
