Preface
■Purpose of This Document and Intended Reader
We sincerely thank you for your continued use of Fujitsu microelectronics products.
MB90335 series is a 16-bit microcontroller designed for applications such as personal computer
peripheral device requiring USB communication. The USB function is not only function operation of
12 M bps but also simple HOST operation.
MB90335 series has functions which are suitable for controlling personal computer peripheral devices
such as display and audio and mobile devices supporting the USB communication.
This manual describes the functions and operations of the MB90335 Series for engineers who develop
products using the MB90335 Series. Please read through this manual.
For more information on various instructions, refer to "Instruction Manual".
Note: F2MC is the abbreviation of FUJITSU Flexible Microcontroller.
■Trademarks
The company names and brand names herein are the trademarks or registered trademarks of their
respective owners.
■Organization of This Document
This manual contains the following 23 chapters and appendix.
Chapter 1 OVERVIEW
This chapter describes basics to give the understanding of the MB90335 Series as a whole such as the
features, block diagrams, and overviews of the functions.
Chapter 2 CPU
This chapter explains the setting and operation of the CPU.
Chapter 3 INTERRUPTS
This chapter describes the overview of interruptions, interrupt vector and interrupt cause, register
configuration/function, and interrupt processing operations.
Chapter 4 RESET
This chapter describes the overview of reset, reset cause and oscillation stabilization wait time, and
reset operation.
Chapter 5 CLOCK
This chapter describes the overview of the clock, register configuration/function, clock mode, and
oscillation stability wait time.
Chapter 6 LOW-POWER CONSUMPTION MODE
This chapter describes the overview of the low-power consumption mode, register configuration/
function, and operation of the low-power consumption mode.
Chapter 7 MODE SETTING
This chapter describes the overview of mode settings, mode pin, mode data, and operation in each
mode of mode setting.

ii
Chapter 8 I/O PORT
This chapter describes the overview of the I/O port and the register configuration/function used in the
I/O port.
Chapter 9 TIME-BASE TIMER
This chapter describes the overview of the time-base time, register configuration/function, interrupt,
and operation of the time-base timer.
Chapter 10 WATCHDOG TIMER
This chapter describes the overview of the watchdog timer, register configuration/function, and
operation of the watchdog timer.
Chapter 11 USB FUNCTION
This chapter describes the functions and overview of the USB Function.
Chapter 12 USB HOST
This chapter describes the functions and operation of USB HOST.
Chapter 13 PWC TIMER
This chapter describes an overview of PWC timer, the configuration and function of register, and the
PWC timer operation and precaution.
Chapter 14 16-BIT RELOAD TIMER
This chapter describes an overview of 16-bit reload timer, the configuration and functions of register
and the 16-bit reload timer operation.
Chapter 15 8/16-BIT PPG TIMER
This chapter describes an overview of 8/16-bit PPG timer, the configuration and functions of register,
and the 8/16-bit PPG timer operation.
Chapter 16 DTP/EXTERNAL INTERRUPT
This chapter describes an overview of DTP/external interrupt, the configuration and functions of
register, and the DTP/external interrupt operation.
Chapter 17 EXTENDED I/O SERIAL INTERFACE
This chapter describes an overview of the extended I/O serial interface, the configuration and function
of registers, and operations of extended I/O serial interface.
Chapter 18 UART
This chapter describes the overview of the UART, the configuration/functions of the register, the
operation of the UART, the usage note of the UART, and the example of UART program.
Chapter 19 I2C INTERFACE
This chapter gives an overview of I2C interface, the configuration and functions of registers, and
operations of I2C interface.
Chapter 20 ROM MIRROR FUNCTION SELECTION MODULE
This chapter describes the functions of the ROM mirror function selection module and the
configuration/function of the register.
Chapter 21 ADDRESS MATCH DETECTION FUNCTION
This chapter explains the address match detection function and its operation.

iii
Chapter 22 DUAL OPERATION FLASH MEMORY
This chapter describes the function and operation of the dual operation flash memory.
Chapter 23 EXAMPLE of CONNECTING SERIAL WRITING
This chapter describes examples of serial write connection when using AF220/AF210/AF120/AF110
flash microcontroller programmer made by Yokogawa Digital Computer Corporation.
APPENDIX
Appendix includes detailed information on I/O map, interrupt vector, and instruction list, which are
not mentioned in this manual and information that is needed for programming.

iv
