Furuno FELCOM 70 User manual

INMARSAT FLEET F77
SHIP EARTH STATION
FELCOM 70

Thepaperusedinthismanual
iselementalchlorinefree.
Your Local Agent/DealerYour Local Agent/Dealer
9-52
A
shihara-cho,9-52
A
shihara-cho,
Nishinomi
y
a 662-8580, JAPANNishinomi
y
a 662-8580, JAPAN
Tele
p
hone :Tele
p
hone : 0798-65-21110798-65-2111
FaxFax 0798-65-42000798-65-4200
::
FIRST EDITION :FIRST EDITION : FEB.FEB. 20042004
Printed in JapanPrinted in Japan
A
ll ri
g
hts reserved.
A
ll ri
g
hts reserved. C1C1 :: JUL.JUL. 26, 200526, 2005
Pub. No.Pub. No. OME-56340OME-56340
*
0
0014766302*
*
0
0014766302*
*
0
0014766302*
*
0
0014766302*
(( TATATATA )) FELCOM70FELCOM70 * 0 0 0 1 4 7 6 6 3 0 2 ** 0 0 0 1 4 7 6 6 3 0 2 *
*
O
ME
5
6340C10*
*
O
ME
5
6340C10*
*
O
ME
5
6340C10*
*
O
ME
5
6340C10*
* O M E 5 6 3 4 0 C 1 0 ** O M E 5 6 3 4 0 C 1 0 *

i
SAFETY INSTRUCTIONS
WARNING
Leave the equipment powered while
underway.
Distress cannot be communicated unless
the equipment is powered.
Do not disassemble or modify the
equipment.
Fire, electrical shock or serious injury can
result.
Turn off the power immediately if water
leaks into the equipment or the equip-
ment is emitting smoke or fire.
Continued use of the equipment can cause
fire or electrical shock.
Do not operate the equipment with wet
hands.
Electrical shock can result.
Do not approach the radome
closer than 4 meters when
it is transmitting.
The radome emits radio waves
which can be harmful to the
human body, particularly
the eyes.
ELECTRICAL SHOCK HAZARD
Do not open the equipment.
Only qualified personnel
should work inside the
equipment.
Any repair work must be done by a
licensed radio technician.
Improper repair work can cause electrical
shock or fire.
Use the proper fuse.
Fuse rating is shown on the equipment.
Use of a wrong fuse can result in damage
to the equipment.
WARNING
A warning label is attached to the
terminal, communication and antenna
units. Do not remove any label. If a label
is missing or damaged, contact a
FURUNO agent or dealer.
WARNING
To avoid electrical shock, do not
remove cover. No user-serviceable
parts inside.
Terminal, Communication
Unit
Name: Warning Label (1)
Type: 86-003-1011
Code No.: 100-236-231
Antenna Unit
Name: Radiation Warning Label
Type: 16-016-1802-0
Code No.: 100-312-020

ii
TABLE OF CONTENTS
FOREWORD ......................................................................................................... v
SPECIFICATIONS................................................................................................ vi
SYSTEM CONFIGURATION.............................................................................. viii
1. INTRODUCTION ...........................................................................................1-1
1.1 General .....................................................................................................................1-1
1.2 Communication services ........................................................................................... 1-2
2. OPERATION FROM HANDSET....................................................................2-1
2.1 Display Panel and Key Panel of ISDN Handset......................................................... 2-1
2.2 Switching ON ............................................................................................................ 2-2
2.3 SIM card....................................................................................................................2-3
2.4 ISDN Handset ........................................................................................................... 2-3
2.5 FELCOM 70 starts up................................................................................................ 2-4
2.6 Making a call ............................................................................................................. 2-4
2.7 Redialing...................................................................................................................2-5
2.8 Dialing from phone book............................................................................................ 2-6
2.9 Incoming calls ........................................................................................................... 2-6
2.10 Call hold and transfer ................................................................................................ 2-7
2.11 Internal communication ............................................................................................. 2-7
2.12 Various call procedures ............................................................................................. 2-8
2.13 To call FELCOM 70 ................................................................................................... 2-9
2.14 Phone book entry ...................................................................................................... 2-9
2.15 Phone book editing...................................................................................................2-11
2.16 Analogue telephone ................................................................................................ 2-12
3. HANDSET FUNCTIONS................................................................................3-1
3.1 Overview................................................................................................................... 3-1
3.2 Satellite search.......................................................................................................... 3-3
3.3 Phone setup.............................................................................................................. 3-5
3.3.1 Active MSN (Multiple Subscriber Number) ...................................................... 3-5
3.3.2 Keyclick .......................................................................................................... 3-5
3.3.3 Ringer............................................................................................................. 3-6
3.3.4 Answer beep................................................................................................... 3-6
3.3.5 Backlight On/Off.............................................................................................. 3-7
3.3.6 Protocol .......................................................................................................... 3-7
3.3.7 Software version............................................................................................. 3-8
3.4 Selecting default Net service provider ....................................................................... 3-8
3.5 Priority calls............................................................................................................... 3-9
3.6 Distress Alarm......................................................................................................... 3-10
3.7 Setting serial ports....................................................................................................3-11
3.8 Information available ............................................................................................... 3-12

TABLE OF CONTENTS
iii
4. OPERATION FROM PC ................................................................................4-1
4.1 Installing the PC program...........................................................................................4-1
4.2 Starting up .................................................................................................................4-3
4.3 Phone book ...............................................................................................................4-5
4.4 Traffic Log..................................................................................................................4-7
4.5 Traffic log settings...................................................................................................... 4-9
4.6 Traffic log printout viewer - normal calls (Cct) .......................................................... 4-11
4.7 Traffic log printout viewer - Mobile Packet Data Service calls (MPDS) ..................... 4-12
5. CONFIGURATION FROM PC .......................................................................5-1
5.1 Menu functions ..........................................................................................................5-1
5.2 Function reference list................................................................................................5-2
5.3 Access level............................................................................................................... 5-3
5.3.1 Activating/Changing user PIN code................................................................. 5-3
5.3.2 Functions requiring owner level....................................................................... 5-4
5.4 Selecting default Net service provider........................................................................5-6
5.5 Phone setup ..............................................................................................................5-8
5.6 Advanced functions ................................................................................................. 5-11
5.7 Access control .........................................................................................................5-12
5.7.1 Restricted dialing...........................................................................................5-12
5.7.2 Restricted dialing setup (owner level only)..................................................... 5-13
5.7.3 Access code (owner level only) .....................................................................5-14
5.7.4 Restricted SIM usage .................................................................................... 5-15
5.8 Software update preparation....................................................................................5-16
5.9 Configuration menu ................................................................................................. 5-17
5.9.1 ISDN protocol configuration...........................................................................5-17
5.9.2 Net service providers (owner level only)........................................................ 5-18
5.9.3 Set diagnostics.............................................................................................. 5-19
5.9.4 Dual-port USB...............................................................................................5-20
5.9.5 Spot beam report method..............................................................................5-23
5.10 Information available................................................................................................5-24
5.11 Customization menu (owner level only).................................................................... 5-25
5.12 Routing of incoming calls.........................................................................................5-26
5.13 MSN configuration ...................................................................................................5-28
5.13.1 ISDN Handset w/Distress Alarm....................................................................5-29
5.13.2 Testing the Distress Alarm.............................................................................5-31
5.13.3 ISDN port......................................................................................................5-32
5.13.4 RS-232 port ..................................................................................................5-33
5.13.5 USB port .......................................................................................................5-34
5.13.6 Analogue port................................................................................................5-35
5.14 Saving and reloading configurations ........................................................................5-36
5.15 Print handling setup................................................................................................. 5-38
5.16 Ethernet interface ....................................................................................................5-39
6. DATA COMMUNICATION..............................................................................6-1
6.1 Mobile Packet Data Service (RS-232)........................................................................6-1
6.1.1 Introduction .....................................................................................................6-1
6.1.2 Connecting up................................................................................................. 6-2
6.1.3 MPDS-setup....................................................................................................6-3
6.1.4 Checking default settings ................................................................................6-9

TABLE OF CONTENTS
i
v
6.1.5 Connecting to server..................................................................................... 6-12
6.1.6 Traffic log...................................................................................................... 6-16
6.1.7 AT-commands............................................................................................... 6-17
6.1.8 Troubleshooting............................................................................................ 6-19
6.2 Mobile Packet Data Service (USB).......................................................................... 6-22
6.2.1 Introduction................................................................................................... 6-22
6.2.2 Connecting up............................................................................................... 6-23
6.2.3 PC setup....................................................................................................... 6-24
6.2.4 MPDS-setup ................................................................................................. 6-26
6.2.5 Checking default settings.............................................................................. 6-30
6.2.6 Connecting to server..................................................................................... 6-33
6.2.7 Traffic log...................................................................................................... 6-37
6.2.8 AT-commands............................................................................................... 6-38
6.2.9 Troubleshooting............................................................................................ 6-40
6.3 Mobile Data Service (RS-232)................................................................................. 6-44
6.3.1 PPP modem via RS-232............................................................................... 6-44
6.3.2 Connecting up............................................................................................... 6-45
6.3.3 PC setup....................................................................................................... 6-46
6.3.4 Checking default settings.............................................................................. 6-52
6.3.5 Connecting to server..................................................................................... 6-55
6.3.6 Troubleshooting............................................................................................ 6-57
6.3.7 AT commands............................................................................................... 6-58
6.3.8 DTE interface................................................................................................ 6-68
6.4 Mobile Data Service (USB)...................................................................................... 6-70
6.4.1 PPP modem via USB.................................................................................... 6-70
6.4.2 PC setup....................................................................................................... 6-72
6.4.3 Checking default settings.............................................................................. 6-78
6.4.4 Connecting to server..................................................................................... 6-81
6.4.5 Troubleshooting............................................................................................ 6-83
6.5 Mobile Data Service (ISDN) .................................................................................... 6-85
6.5.1 PPP modern via ISDN................................................................................... 6-85
6.5.2 Connection up............................................................................................... 6-86
6.5.3 PC setup....................................................................................................... 6-87
6-5.4 Troubleshooting............................................................................................ 6-94
7. TROUBLESHOOTING ..................................................................................7-1
7.1 Troubleshooting......................................................................................................... 7-1
7.2 Alarms and messages............................................................................................... 7-4
7.2.1 Introduction....................................................................................................... 7-4
7.2.2 Alarms.............................................................................................................. 7-6
7.2.3 Clear causes.................................................................................................... 7-8
7.2.4 Troubleshooting: Real time status indications................................................. 7-13
7.2.5 Troubleshooting: Other logs .......................................................................... 7-15
7.3 Throughput.............................................................................................................. 7-16
8. LIST OF TERMS............................................................................................8-1
9. SYSTEM DESCRIPTION...............................................................................9-1
APPENDIX: TERMINAL IDENTITIES.............................................................AP-1
APPENDIX: MAINTENANCE PARTS ............................................................AP-2

v
FOREWORD
A Word to the Owner of the FURUNO FELCOM 70
Congratulations on your choice of the FURUNO FELCOM 70 Inmarsat Fleet F77 Mobile
Earth Station. We are confident you will see why the FURUNO name has become
synonymous with quality and reliability.
For over 50 years FURUNO Electric Company has enjoyed an enviable reputation for
quality marine electronics equipment. This dedication to excellence is furthered by our
extensive global network of agents and dealers.
This equipment is designed and constructed to meet the rigorous demands of the marine
environment. However, no machine can perform its intended function unless operated and
maintained properly. Please carefully read and follow the recommended procedures for
operation and maintenance.
We would appreciate hearing from you, the end-user, about whether we are achieving our
purposes. Thank you for considering and purchasing FURUNO equipment.
Features
The FELCOM 70 mainly consists of an antenna unit, communication unit, distress alert unit,
and a handset. The FELCOM 70 provides telephone, facsimile, and data services.
The main features of the FELCOM 70 are
• Conforms to the following standards: INMARSAT MINI-M SDM, CN-MM056, 059,
IEC 60945 (Ed. 4), IEC 60529 (Ed. 2), IEC 61162-1 (Ed. 2)
• Voice communication: 4.8 kbps
• Facsimile: G4-64 kbps, G3-Max. 33.6 kbps, G3-9.6 kbps(low cost)
• Connection to ISDN (Up to 8 sets of analog telephone or G3 FAX via Terminal Adapter or
Video Phone, etc.)
• Always-on Internet connections via MPDS
• Compact antenna unit (comparing Inmarsat B antenna unit): φ970 x 1130 mm, 50 kg;
Dome with hatch is also available (φ1260 x 1153 mm, 65 kg)
Program number
System version of the communication unit: REL 3.0
Software for PC, vtLight: 6.2

FURUNO
FELCOM 70
SPECIFICATIONS OF THE INMARSAT FLEET F77 SHIP EARTH STATION
FELCOM 70
1. ANTENNA UNIT
Gain Greater than 20.3dBi
Axial Ratio Less than 2.0dB
Antenna Beamwidth 16 deg. approx. (at -3dB)
Stabilization Triple-axis control type
Positioning AZ: 0° to 360°
EL: 5° to 90°
Positioning Accuracy AZ: Better than ±3°
EL: Better than ±3°
Tracking Circular tracking system
2. COMMUNICATION UNIT
Standard Functions Duplex voice 4.8 kbps
56/64 kbps ISDN (voice, G3 and G4 Telefax or Data)
MPDS packet data service
Distress alert
Transmit Frequency 1626.5MHz to 1660.5MHz
Receiver Frequency 1525.0MHz to 1559.0MHz
Channel Interval 1.25 kHz (Min) at test mode
5 kHz (Voice)
40 kHz (ISDN/MPDS)
G/T Better than - 4dB/K
EIRP BPSK/O-QPSK 20 dBW
16QAM 32 dBW
Modulation
-Voice (4.8 kbps AMBE) O-QPSK/5.6 kbps
-MES Signaling BPSK/3 kbps
-ISDN Operation 16QAM/33.6k Symbols/s
-MPDS 16QAM/33.6 k Symbols/s
-Access Method SCPC/FDMA Audio, HSD
TDMA/FDMA MPDS
3. INTERFACE
PC: RS-232/RS-422
Navigator: IEC 61162-1 ed.2 (2000/7)/NMEA0183
USB: B connector
ISDN: Max 7 ports (RJ-45 connector and 4-terminals)
Analogne telephone/Telefax: Max 6 ports (RJ-45 connector and 2-terminals)

FURUNO FELCOM 70
4. POWER SUPPLY
Power supply & rated 100-240 VAC: 1.47 A – 0.89 A
Current
5. ENVIRONMENTAL CONDITION
Category of unit Antenna unit: To be installed in a Exposed area
Others: To be installed in a protected area
Ambient Temperature Complies with Inmarsat SDM and IEC60945 (Ed.4)
Antenna unit: -25°C to +50°C
Communication unit: 0°C to +45°C
Handset: 0°C to +45°C
Relative Humidity 95% at 40°C (Inmarsat SDM 95 & IEC60945)
Waterproofing Complies with IEC 60529;
Antenna Unit: IPX6
Communication Unit: IPX0
Handset: IPX0
Vibration Complies with Inmarsat SDM and IEC60945
Motion Roll: ± 30°/8s, Pitch: ± 10°/6s, Yaw: ± 8°/50s, Surge: ± 0.2G,
Sway: ± 0.2G, Heave: ± 0.5G, Rotation: 6°/s, Speed: 30 kt
6. COATING COLOR
Antenna Unit Munsell N9.5
Communication Unit Munsell N1.0
ISDN Handset Munsell N1.0
Distress Alert Unit Munsell N1.0

viii
SYSTEM CONFIGURATION
ISDN telephone
ISDN 1
USB
ISDN 3
ISDN 2
Tel 4 (2W)
Tel 3 (2W) RS232
Tel 1 (2W)
Tel 2 (2W)
ISDN4
NMEA-0183(4W)
SIM CARD
Broad Band output (BRO)
GPS
16S0116-0
M12
M12
ANTENNA UNIT
SF-170
TA
G3 FAX
20- 60m : N-P8DFB 60-100m : N-P12DSFA
8D-FB- CV "30M" 20S0021-0 8D-FB- CV "50M" 20S0022-0 12D-SFA-CV "100M" 16S0211-0
20- 60m : N-P8DFB 60-100m : N-P12DSFA
Ship's Analogue
PABX
AC IN
100-240V AC
φ1, 50-60Hz
GND
optional supply external equipment
(user supply)
FC755D1 (Japanese)
SF-370
standard supply
PC or Data Equipment
Communication unit
SF-270
*Total Number of ISDN : Max 8 (include TA)
Connection Box QUFC911918
ISDN Wall Socket
ANALOGUE WALL SOCKET (OP16-11)
SF-870
G4 FAX
SF-370
SF-870
QDGY911912
Analogue- to ISDN TA
FC755D1 (Japanese)
FAX-8070P/3850
Analogue Telephone
102176
SF-870
ISDN Handset ISDN Handset
ISDN Handset
Distress Alert Unit Distress Alert
Unit
Incoming Indicator
Adapter
220VAC
Incoming Indicator
MJ-2S
DBAR104001/888
ISDN Wall Socket 102176
TTYCY-1 or CO-SPEVV-SB-C 0.2x1P (10/20/30/40m)
TTYCY-1 or CO-SPEVV-SB-C 0.2x1P (10/20/30/40m)
CO-SPEVV-SB-C 0.2x1P (10/20/30/40m)
103776
(15m Max)
TTYCY-1 or CO-SPEVV-SB-C 0.2x1P (10/20/30/40m)
TTYCY-1 or CO-SPEVV-SB-C 0.2x1P (10/20/30/40m)
ISDN Cable
RS232C Cable
RS232C Cable
(M)
RS232-USB converter Gyro/GPS
(not requipment)
RS232
Environmemtal Category Antenna unit To be installed in an exposed area Commnication unit Distress alert unit To be installed in a protected area ISDN handset, etc
**: USB port can not be used.
**

1-1
1. INTRODUCTION
1.1 General
The FELCOM 70 consists of the Above Deck Equipment (ADE) and Below Deck
Equipment (BDE).
Above Deck Equipment - ADE
The FELCOM 70 Above Deck Equipment consists of:
• Servo stabilized antenna dish with RF-Transceiver
• Mast mounted radome, or
• Deck mounted radome
Below Deck Equipment - BDE
The FELCOM 70 Communication Unit (CU) - which constitutes the major
electronic part - is designed for wall or desktop installation.
The CU mains input is 100 - 240 VAC. The power requirement is approx. 40 W
in receive/idle mode, and approx. 150 W in transmit mode.
The CU supplies 48 VDC power to the ADE through the coaxial cable.
ISDN Handset
The ISDN Handset keypad and built-in display allow dialing and control of the
CU and antenna.
Distress Alert Unit
The Distress Alert Unit provides remote activation of an alert transmission and
indication of incoming distress calls.
Communication Unit
CU
Handset
7
4
1
3
6
9
2
5
8
0
DIAL 00+INTL
TEL.NO.+#
Distress Alert Unit
DEL
DISTRESS
FELCOM 70 satellite terminal
CD
The CD ROM supplied with FELCOM 70 contains program for PC (vtLite Mobile
and driver software.

1. INTRODUCTION
1-2
1.2 Communication services
FELCOM 70 provides the following services:
• ISDN: - 64 kbps Mobile Data Service (UDI)
- 56 kbps Mobile Data Service
- 4.8 kbps speech
- 64 kbps speech
- 3.1 kHz audio (64 kbps) (e.g. G4 FAX)
• RS-232: - 64 kbps Mobile Data Service (UDI)
- Mobile Packet Data Service (MPDS)
• RS-422: - 64 kbps Mobile Data Service (UDI)
• USB: - 64 kbps Mobile Data Service (UDI)
- Mobile Packet Data Service (MPDS)
Note: USB Interface is currently not supported.
• ANALOGUE: - 4.8 k speech/64 k speech
- 3.1 kHz (e.g. telefax Gr.3)
Internal communication
Equipment connected to the various interfaces may communicate with each
other via an internal MSN (Multiple Subscriber Number) assigned to each unit.
Control interface
The RS-232/RS-422 or USB port allows connection of a PC for configuration of
the FELCOM 70 Communication Unit (CU).
A PC program (vtLite Mobile) that provides the software to operate and configure
the CU is supplied on the enclosed CD (requires at least Windows
95).
Additional
ISDN Handsets
7
4
1
3
6
9
DEL
2
5
8
0
DIAL00+INTL
TEL.NO.+#
Analogue telephones
(wall or desk) Telefax
(Group 3 or 4)
Additional
Distress Alert Unit
PC
(user supply)
Distress
Additional equipment

2-1
2. OPERATION FROM HANDSET
2.1 Display Panel and Key Panel of ISDN Handset
KDD IOR
Ready for call
ALPHA
Handsfree microphone
Display indicators:
appears at hook OFF
flashes when receiving a call
Net provider & Ocean Region
appears when loudspeaker
is ON
appears when selecting
letters on the keypad, e.g. for
Phone Book entries
signal strength indicator
alarm indicator
Function keys:
allows adjusting the earpiece
volume during conversation
opens/closes Phone Book
reverts to previous position
used to transfer a call
selects function menu
handsfree microphone/
loudspeaker ON/OFF (hook
ON/OFF when in cradle)
hook ON/OFF
. . . . . number keys.
The keys include letters for
Phone Book entries.
enters selected choise
deletes last character or
complete entery
scrolls up/down through
function menu/choices
Handsfree loudspeaker
ISDN
ALPHA
Display and keys Holder/cradle wallmounted
click!
Hook ON magnet

2. OPERATION FROM HANDSET
2-2
2.2 Switching ON
The ON/OFF switch located on the upper end of the Communication Unit
switches all basic units of the FELCOM 70 terminal on/off:
• the ISDN Handset
• the Communication Unit (CU), and
• the Antenna Unit.
See figure below for location of the power ON/OFF switch and indicator.
Power
ON/OFF
switch
SIM card
Cover Power
indicator
Location of SIM card and ON/OFF switch
*
*: Insert SIM card, contact upside down.
Note: Wait about 10 seconds to turn on the power after turning it off.

2. OPERATION FROM HANDSET
2-3
OK
>Active MSN
Kayclick
Ringer
Answer beep
Backlight
Language
MSN
Protocol
Set to Fleet
MENU
2.3 SIM card
The SIM card carries subscription information from your Net service provider on
an integrated circuit. The FELCOM 70 used with the SIM card assumes the
identity of the SIM card.
The SIM card has its own set of Inmarsat Mobile Numbers (IMN) on which the
user can be contacted irrespective of the FELCOM 70 used. All outgoing calls
will be billed to the owner of the SIM card.
The SIM card is protected by a SIM PIN (Personal Identification Number).
Contact your Net service provider if you do not have the PIN code.
If the PIN code entered does not match the PIN code on the SIM card, operation
with that particular SIM card will lock-up after three failed attempts. You must
then use the SIM un-block code (PUK code) provided by your Net service
provider to un-lock the card. Contact your Net service provider if you do not
have the PUK code.
Note: When the PUK is used, the SIM PIN is set to 1 2 3 4.
To change or disable the PIN code, see "5.3 Access level" later in this manual.
The SIM card can store various information, e.g.:
• PIN code (Personal Identification Number)
• Phone book
• Allowed and preferred Net service providers
Note: FELCOM 70 can be used with or without SIM card. The Net service
provider, however, sometimes requires the use of SIM card.
The SIM card driver is located on the upper end of the Communication Unit, see
page 2-3. The cover must be removed to access the card slot. The cover is
attached by two serrated screws. No tools are required to loosen the screws.
Note: Turn on the power, wait for the indication “Ready for call”, and then insert
the SIM card. If the ship’s mains is turned off instantaneously, eject the
SIM card and turn the power off and on again.
2.4 ISDN Handset
When connected, the handset is automatically set to Fleet mode, providing an
idle display as shown on next page.
To switch back to ISDN Handset mode, press and hold down
DEL
when turning
ON power.
Switching back to Fleet mode is then achieved as follows:
1. Open the MENU and scroll down
to Set to Fleet
2. Press
OK
.
The handset will now
stay in Fleet mode.

2. OPERATION FROM HANDSET
2-4
Calling ...
008167244700
Timer, minutes:seconds
Connected 09:46
008167244700-
2.5 FELCOM 70 starts up
FELCOM 70 automatically initializes the system and searches for the satellite.
Furuno Fleet
Euro-ISDN
Enumerating
KDD IOR
Initializing
KDD IOR
Searching
KDD IOR
Ready for call
See “3.2 Satellite search” in this manual to restart a search manually.
If required, see "3.4 Selecting default Net service provider".
Idle
When idle, the ISDN Handset displays as follows.
KDD IOR
Ready for call
Ocean Region
Service provider
Signal strength
indicator
Alarm indicator
The alarm indicator flashes when an alarm condition occurs. The indicator stops
once the alarm has been read in the Display Handset by pressing
MENU
>
Information > Alarms & messages”.
The indicator continues to be displayed if the alarm condition persists.
Note: If the searching begins suddenly due to satellite blocking, restart a search
manually, specifying your ocean region. See page 3-3 for details.
2.6 Making a call
1. Dial 00, country code and subscriber number, e.g.:
For normal call
For handsfree call
6
mno
2
abc
00
7
pqrs
7
pqrs
4
abc
4
abc
08
abc
1
pqrs
0
Dial (4.8K)
008167244700
Japan
• When entered, the display
reads:
• When the remote end answers,
the display reads:
The timer starts.
2. End the call by pressing
hook ON/OFF
, or
replacing the handset in the cradle.
Disconnected

2. OPERATION FROM HANDSET
2-5
Use
DEL
key to modify entries: Pressing
DEL
key once, erases one digit.
Holding the key more than 0.5 second erases the whole number.
Use the handsfree key to toggle the loudspeaker ON/OFF.
Alternative dialing:
Press or to get the dialing tone, then dial the number.
6
mno
2
abc
0
0
7
pqrs
7
pqrs
4
abc
4
abc
0
8
abc
1
pqrs
0
#
A a
2.7 Redialing
The Redial Memory stores the last 30 called and received numbers (since
incoming IMN numbers are not conveyed from “ashore”, the received numbers
are listed by local MSN numbers.)
The data are erased when disconnecting the handset or FELCOM 70 is switched
off.
To redial calls made:
1Press the arrow up key to recall the latest
number dialed.
2Use the arrow keys to scroll through
the list.
3Pressing hook ON/OFF sends the chosen
number.
To view calls received:
4 Press the arrow down key to recall the
last number received. Scroll
through list.
To delete a listed number:
5Press
DEL
to clear the chosen number
from list.
Press OK to delete:
Revert to idle:
INFEB10 16:11
20 02
OUT:Aug 01 01:45
008179560215 02
››
OUT:Aug 01 02:11
008179803113 01
››
KDD IOR
Ready for call
IN:JAN20 13:09
20 01
"Redial list entry"
appears if no number
is stored
Clear?
00467244700
OK
DEL

2. OPERATION FROM HANDSET
2-6
2.8 Dialing from phone book
1Press the phone book key and scroll through
the phone book.
2 Press the hook ON/OFF key to call the
selected number.
2.9 Incoming calls
The handset rings when receiving a call. The ringing symbol
flashes until the call is answered.
• Answer the call by pressing hook ON/OFF key or
handsfree key
With the ISDN Handset in the cradle, the loudspeaker and
microphone are ON for handsfree operation.
If lifting the handset, the loudspeaker turns off.
Use the handsfree key to toggle the loudspeaker on/off.
• End the call by pressing hook ON/OFF key , or replacing the handset in
the cradle.
• Reject the call by pressing DEL key
Internal communication
When receiving a call, the caller`s MSN number will appear in the display (if
programmed).
4.8 Speech
00:00
Timer,
minutes:seconds
ALPHA
››BT
Furuno
Calling ...
ALPHA
BT

2. OPERATION FROM HANDSET
2-7
2.10 Call hold and transfer
Pressing
R
during a conversation will put the current call on hold. Another call
may now be made.
Switching between the two calls:
• The 2nd call is established by keying:
R
[MSN]
• The original call is put on hold, and 2nd connected.
• Toggling between the two calls is achieved by
pressing
R
repeatedly.
Call transfer (connection via satellite):
toggles between subscribers
R
Hang up
R
MSN/Handset ld
20
Exception!
Transfer from analogue to ISDN is not possoble.
2.11 Internal communication
FELCOM 70 allows calls to be made internally between the connected ISDN and
analogue telephones.
Internal calls:
ISDN-to-ISDN
telephone: MSN
(example)
20
Note: If the telephone lack the *-key, 103 may be dialed instead,
f.ex.:
10320
When receiving a call, the caller’s MSN number will appear in the display (if
programmed). When FELCOM 70 is busy with a satellite link call, it is possible to
make internal calls.
R
1 on hold
**20#
2 on hold

2. OPERATION FROM HANDSET
2-8
2.12 Various call procedures
Short number dialing from Phone Book (prefix 23)
2315
fetches and sends the telephone number stored in the Phone
Book under short number 15.
Short number dialing (prefix 23) through selected Net service provider
3
2315
fetches and sends the telephone number stored under
short number 15 via the selected Net service provider (KDDI=no.3).
Service calls
Special information services are accessible with 2-digit service address code.
Note: Not all Net service providers offer every service.
Examples:
Obtaining assistance from the International Operator:
11
Calling the technical staff of the Land Earth Station (LES):
33
Telefax
On a telefax with keypad, enter as the last digit before starting
transmission.
Note: Some types of equipment do not have # implemented in software even if
the #-key is on the keypad. Then in front of the telephone number use.
903 if dialing the number digit by digit, or
902 if for the number to be sent as a block. E.g.:
90
2
00
47
67
24
47
00
