Gardena 2650 User manual

DMontageanleitung
Wandschlauchträger
GB Assembly Instructions
Wall-Mounted Hose Reel
FMode d’emploi
Dévidoir mural
NL Montage-instructie
Wandslanghouder
SMonteringsanvisning
Väggslangvinda
IIstruzioni per il montaggio
Avvolgitubo a muro
EInstrucciones para el montaje
Soporte portamangueras de pared
PInstrução de montagem
Porta Mangueiras de Parede
Art. 2650

D
Der Zusammenbau erfolgt entsprechend der Bildfolge.
Hinweise:
xGriff in Trommelhälfte mit der größeren Achsen-Öffnung
(Bild 3) einführen.
xAnschlussachse bis zum Einrasten einschieben und Klemme
mit 2Schrauben festschrauben (Bild 4).
xHandkurbel aufstecken (rastet hörbar ein) (Bild 5).
Abdeckung einschnappen (Bild 6).
xVor Einbruch der Frostperiode ist der Wandschlauchträger
frostsicher zu lagern.
xSie erhalten zusätzliche Schlauchführungsrollen
(Art.-Nr. 2651) bei Ihrem GARDENA Händler.
Gefahr! Bei der Montage könnten Kleinteile verschluckt werden
und es besteht Erstickungsgefahr durch den Polybeutel.
Kleinkinder bei der Montage fernhalten.
GB
Assembly according to the pictures.
Note:
xPlease insert the axle of the side panel with carrying handle
into the reel panel (Pic. 3).
xPush in connection axle until it snaps in and secure clamp
with 2screws (Pic. 4).
xInsert rewind handle, you will hear a “click” if it is fitted
properly (Pic. 5).
xSnap cover into place (Pic. 6).
xYou can order extra Hose Guides (Art. No. 2651) from your
GARDENA dealer.
Danger! Small parts could be swallowed during assembly
and there is a risk of suffocation from the polybag. Keep infants
away during assembly.
F
Pour le montage de ce dévidoir mural, reportez vous aux
schémas explicatifs ci-joints.
Conseils :
xPlacez la poignée de transport sur le tambour côté mur
(celui où l’ouverture est la plus grande) (figure 3).
xIntroduisez le tambour sur l’axe jusqu’à encliquetage et
vissez à fond les deux demi-coquilles (figure 4).
xEnfoncez la manivelle à fond, jusqu’au déclic (figure 5).
xMettez en place le capot de protection (figure 6).
xAvant l’hiver, rangez votre dévidoir mural dans un endroit sec,
à l’abri du gel.
xVous pouvez vous procurer d’autres guides-tuyau chez les
revendeurs GARDENA (réf. 2651).
Danger ! Lors du montage, des pièces de petites dimensions
peuvent être ingurgitées et le sachet en polyéthylène peut
entraîner un risque d’étouffement. Veuillez maintenir les enfants
à distance lors du montage.
NL
Monteren volgens afbeeldingen.
Aanwijzing:
xDraaggreep in de zijde van de trommel met de grootste
as-opening bevestigen (Afbeelding 3).
xAansluitas inschuiven tot deze vastklikt en klem met
2schroeven vastschroeven (Afbeelding 4).
xHandzwengel erop steken (klikt hoorbaar vast) (Afbeelding 5).
xDeksel vastklikken (Afbeelding 6).
xVorstvrij bewaren.
xU kunt extra Slanggeleiders verkrijgen bij uw GARDENA
handelaar (Art. Nr. 2651).
Gevaar! Tijdens de montage zouden kleine onderdelen ingeslikt
kunnen worden en er bestaat gevaar voor verstikking door de
zak van polyethyleen. Houd kleine kinderen tijdens de montage
op een afstand.
S
Montera som bilderna visar.
Obs:
xFör in bärhandtagets centrumaxel i vindans mitt (Fig. 3).
xTryck in kopplingsaxeln så att den klickar fast och säkra med
klämman och de 2 skruvarna (Fig. 4).
xTryck fast veyhandtaget (Snäpplås) (Fig. 5).
xTryck fast täckplattan (Snäpplås) (Fig. 6).
xFörvara väggslangvindan frostfritt.
xDu kan köper extra Slang-guide i Din GARDENA butik
(Art. nr. 2651).
Fara! Vid monteringen kan smådelar sväljas och det finns
kvävningsrisk genom plastpåsen. Håll småbarn borta vid
monteringen.
I
Per il montaggio attenersi alle illustrazioni corrispondenti.
Nota bene:
xInserire la maniglia di trasporto nella metà tamburo in cui
l’apertura asse è maggiore (fig. 3).
xInnestare fino in fondo il raccordo di accoppiamento
(si deve sentire lo scatto) e bloccarlo con 2 viti (fig. 4).
xApplicare la manovella (si deve sentire lo scatto) (fig. 5).
xFissare il disco di copertura (fig. 6).
xPrima del gelo ricoverare l’avvolgitubo a muro in luogo
protetto.
xRulli di guida supplementari (art. 2651) sono acquistabili
presso i rivenditori GARDENA.
Pericolo! I piccoli pezzi, in fase di montaggio, potrebbero
essere ingoiati; rischio di soffocamento causato dal sacchetto
in polietilene. Tenere lontano i bambini più piccoli in fase di
montaggio.
E
El montaje se efectua según el orden de las ilustraciones.
Notas:
xIntroducir el eje del soporte en el núcleo del tambor (fig. 3).
xColocar el eje de conexión hasta que encaje y sujetar con
abrazadera mediar 2 tronillos (fig. 4).
xPoner la manivela (hasta oir un click) (fig. 5).
xColocar la tapa (fig. 6).
xEn tiempo de heladas, es aconsejable guardar el
portamangueras
en un lugar protegido.
xPuede encontrar las guías de manguera en los distribuidores
de GARDENA (art. no. 2651).
¡Peligro! Durante el montaje es posible tragarse piezas
pequeñas y existe riesgo de asfixia por la bolsa de polietileno.
Mantenga a los niños pequeños alejados del lugar de montaje.
P
Os diferentes passos estão ilustrados nas figuras.
Precauções:
xIntroduza o cabo do lado do tambor onde o eixo de abertura
é maior (fig. 3).
xPuxe a conecção do eixo até partir e fixaro gancho com
2parafusos (fig. 4).
xFixar a manivela (encaixe perceptível) (fig. 5).
xA tampa deverá encaixar (fig. 6).
xAntes da época de gelo se instalar, armazene o Porta
Mangueiras em local protegido do frio.
xOs guias de mangueira poderão ser adquiridos em um dos
representantes GARDENA (Art. no. 2651).
Perigo! Manter as crianças pequenas afastadas. Durante
a montagem são utilizadas peças pequenas que podem ser
engolidas e os sacos de plástico representam um perigo
de asfixia.
2

3
1
7
8
9
2
3
5
4
6
