GE Tetra GEPS12-60 User manual

• Supports Tetra miniMAX, Tetra MAX, Tetra PowerMAX
and Tetra PowerStrip LED lighting systems
• Class 2 wiring per NEC Article 725 (SELV)
• Damp location rated
• IP66 rated: separate enclosure required
(GEPS12-60 & GEPS12-60U)
Tetra® LED Systems Power Supply
12
Volt
GE
Lighting Solutions
Installation Guide
imagination at work
Power Supply Features
Power Supply Installation
1Connect the AC line to the black
(line) and white (neutral) input
wires of the power supply using
18-14 AWG (0.82-2.08 mm2) or
18-10AWG (0.82-5.26 mm2) twist-on
wire connectors.
NOTE: Power Supply Loads
Exceeding maximum load will cause the
power supply to shut down. Once the
excess load is removed, cycle the input
power to restart the power supply.
Specic load information for the supported
LED systems can be found in the “Power
Supply Specications” section on the next
page.
NOTE: For CSA approval, a disconnect/
toggle switch of appropriate rating needs
to be placed within 29 feet (8.84 meters)
of primary side of the power supply. The
minimum rating of the switch must be
either 120 or 220 Volts AC. The switch
must also support twice the amount of
input current.
Connect the supply wire that is
attached to the Tetra LED System to
the red (+) and black (-) output wires
of the power supply as outlined
in the “Electrical Connections”
section of your LED system’s
Installation Instructions.
2
RISK OF ELECTRIC SHOCK:
• Disconnect power at fuse box or circuit breaker before servicing or
installing product.
• Properly ground Tetra® power supply.
RISK OF FIRE:
• Use only Tetra® supply wire to make connection from Tetra® power
supply to Tetra® LED strip.
• Use only approved wire for input/output connection.
Minimum size 18 AWG (0.82mm2)
• Follow all local codes.
RISQUES DE DÉCHARGES ÉLECTRIQUES
• Coupez l’alimentation électrique à la boîte de fusibles ou au
disjoncteur avant l’entretien ou l’installation du produit.
• Assurez-vous de correctement mettre à terre l’alimentation
électrique Tetra®.
RISQUES D’INCENDIE
• N’utilisez que le l d’approvisionnement Tetra® pour faire la
connexion entre l’alimentation Tetra® et la bande DEL Tetra®.
• N’utilisez que des ls approuvés pour les entrées/sorties de
connexion. Taille minimum 18 AWG (0.82mm2).
• Respectez tous les codes locaux.
BEFORE YOU BEGIN
Read these instructions completely and carefully.
WARNING/AVERTISSEMENT
Input
wires
White (neutral)
Black (line)
AC line
To Tetra LED System
Output
wires
Red (+)
Black (-)

NOTE: When installing power supply, connect to the appropriate sized building breaker or disconnect device for line and neutral
connections, in accordance with local, state or country regulations.
NOTE: The grounding and bonding of the power supply and overall sign shall be done in accordance with National Electric Code (NEC)
Article 600.
SIGN098-R092911
Power Supply Specications
GE Lighting Solutions • 1-888-MY-GE-LED • www.gelightingsolutions.com
1 - 8 8 8 - 6 9 - 4 3 - 5 3 3
GE Lighting Solutions, LLC is a subsidiary of the General Electric Company. Tetra is a trademark of GE Lighting Solutions, LLC. The GE brand and logo are trademarks of the General Electric Company.
© 2011 GE Lighting Solutions, LLC. Information provided is subject to change without notice. All values are design or typical values when measured under laboratory conditions.
Performance Data GEPS12-60 GEPS12-60U
Min Typical Max Min Typical Max
Input Voltage (VAC) 90 100-240 264 108 120-277 305
Input Frequency (Hz) - 50/60 - - 50/60 -
Input Current (A) - - 0.85 - - 0.61
Output Voltage (VDC) 11.4 12.0 12.6 11.5 12.0 12.5
Output Current (ADC) 0.8 - 5.0 0.8 - 5.0
Output Power (W) - - 60 - - 60
Dimensions 9.5 in. x 1.7 in. x 1.2 in. (240 mm x 43 mm x 30 mm)
Environmental Specications Min Typical Max
Environmental Operating Temperature Range -40°C +25°C +65°C*
Environmental Humidity (non-condensing) - - 95%
Environmental Storage Temperature Range -40°C - +85°C
*Maximum case temperature is 90°C
Conforms to the following standards:
Load per Power Supply Min Max
Tetra miniMAX GEWHMMTS8, GEWWMMTS8 3 modules/1.2 ft. (0.37 m) 150 modules/60 ft. (18.29 m)
GEWHMMS6, GEWWMMS6 3 modules/1 ft. (0.30 m) 120 modules/40 ft. (12.20 m)
GEBLMMS5, GEGLMMS5, GERDMMS5 3 modules/1.2 ft. (0.37 m) 90 modules/36 ft. (10.97 m)
Tetra MAX GEWHMXTS6, GEWWMXTS6 2 modules/1 ft. (0.30 m) 120 modules/60 ft. (18.29 m)
GEWHMHTS6, GEWWMHTS6 2 modules/1 ft. (0.30 m) 80 modules/40 ft. (12.20 m)
GEWHMXWA5, GEWWMXWA5, GEBLMXWA5,
GEGLMXWA5, GERDMXWA5 3 modules/1.2 ft. (0.37 m) 135 modules/54 ft. (16.46 m)
GERCMXWA6, GEYGMXS6 3 modules/1 ft. (0.30 m) 162 modules/54 ft. (16.46 m)
GERCMXWL6 2 modules/1 ft. (0.30 m) 160 modules/80 ft. (24.38 m)
GERDMXWL6 2 modules/1 ft. (0.30 m) 140 modules/70 ft. (21.34 m)
Tetra PowerMAX GEWHPMTL5, GEWWPMTL5 2 modules/1.3 ft. (0.41 m) 38 modules/25 ft. (7.62 m)
GEWHPMS2-65K, GEWWPMS2-30K 2 modules/1 ft. (0.30 m) 50 modules/25 ft. (7.62 m)
Tetra PowerStrip GEWHSSP3-65K, GEWWSSP3-41K 1 module/1 ft. (0.30 m) 16 modules/16 ft. (4.88 m)
Maximum Remote Mounting Distance
18 AWG
(0.82 mm2)
16 AWG
(1.31 mm2)
14 AWG
(2.08 mm2)
12 AWG
(3.31 mm2)
10 AWG
(5.27 mm2)
8 AWG
(8.35 mm2)
Tetra miniMAX 30 ft./9.1 m 50 ft./15.2 m 80 ft./24.4 m 120 ft./36.6 m - -
Tetra MAX 30 ft./9.1 m 50 ft./15.2 m 80 ft./24.4 m 120 ft./36.6 m - -
Tetra PowerMAX GEWHPMTL5, GEWWPMTL5 30 ft./9.1 m 50 ft./15.2 m 80 ft./24.4 m 120 ft./36.6 m - -
GEWHPMS2-65K,
GEWWPMS2-30K 15 ft./4.5 m 20 ft./6.1 m 30 ft./9.1 m 60 ft./18.2 m - -
Tetra PowerStrip 30 ft./9.1 m 25 ft./7.6 m 35 ft./10.6 m 40 ft./12.1 m 75 ft./22.8 m 100 ft./30.5 m
