GEPS24-100U-GLX
Tetra®LED Systems Power Supply 24
Volt
Installation Guide
Power Supply Features
Save These Instructions
Use only in the manner intended by the manufacturer.
If you have any questions, contact the manufacturer.
CAUTION/ATTENTION
RISK OF INJURY
• While performing installations described, gloves, safety glasses
or goggles should be worn.
RISQUE DE BLESSURE
• Lors de l’exécution des installations décrites, des gants, des lunettes de
sécurité ou des lunettes de protection doivent être portées.
BEFORE YOU BEGIN
Read these instructions completely and carefully.
This device complies with part 15 of the FCC Rules. Operation is subject
to the following two conditions: (1) This device may not cause harmful
interference, and (2) this device must accept any interference received,
including interference that may cause undesired operation.
Note: This equipment has been tested and found to comply with the limits
for a Class A digital device, pursuant to part 15 of the FCC Rules. These
limits are designed to provide reasonable protection against harmful
interference when the equipment is operated in a commercial environment.
This equipment generates, uses, and can radiate radio frequency energy
and, if not installed and used in accordance with the instruction manual,
may cause harmful interference to radio communications. Operation of
this equipment in a residential area is likely to cause harmful interference in
which case the user will be required to correct the interference at his own
expense.
This Class [A] RFLD complies with the Canadian standard ICES-005. Ce DEFR
de la classe [A] est conforme à la NMB-005 du Canada.
Prepare Electrical Wiring
Electrical Requirements
• Limited to use in dry and damp locations.
• The suitability of rain enclosure shall be determined if
intended for wet location.
• The grounding and bonding of the LED Driver shall be
done in accordance with National Electric Code (NEC)
Article 600.
• Follow all National Electric Codes (NEC) and local codes.
WARNING/AVERTISSEMENT
RISK OF ELECTRIC SHOCK
• Disconnect power at fuse box or circuit breaker before servicing
or installing product.
• Properly ground Tetra®power supply.
• AC input connections shall be suitably enclosed. The power
supply shall be enclosed or made inaccessible to users during
normal use.
RISK OF FIRE
• Minimum power supply spacing to other power supply or other
heat producing component shall be at least 4” (101.6 mm) from
side to side and 1” (25.4mm) from end to end.
• Use only approved wire for input/output connection. Minimum
size 18 AWG (0.82 mm2).
• Follow all local codes.
RISQUES DE DÉCHARGES ÉLECTRIQUES
• Coupez l’alimentation électrique à la boîte de fusibles ou au disjoncteur avant
l’entretien ou l’installation du produit.
• Assurez-vous de correctement mettre à terre l’alimentation électrique Tetra®.
RISQUES D’INCENDIE
• N’utilisez que des ls approuvés pour les entrées/sorties de connexion.
Taille minimum 18 AWG (0.82 mm2).
• Respectez tous les codes locaux.
• Supports Tetra PowerStrip SS, Tetra PowerStrip DS, Tetra miniStrip DS,
Tetra Edgestrip, Tetra Contour, Tetra Contour LS, Tetra miniMAX,
Tetra MS, Tetra MAX, Tetra PowerMAX, Tetra PowerMAX HO and Tetra Stick
LED lighting systems
• UL: Class 2 wiring per NEC Article 725, dry and damp location rated
• IEC: SELV, CE: IP54 rated, must be protected from direct exposure to the weather

2
Power Supply Installation
2Connect the AC line to the black
(line) and white (neutral) input
wires of the power supply using
suitable wire connectors.
Connect the supply wire that is
attached to the Tetra LED System to
the red (+) and black (-) output wires
of the power supply as outlined in
the “Electrical Connections” section
of your LED system’s Installation
Instructions.
3
Input
wires
White (neutral)
Black (line)
AC line
To Tetra LED System
Output
wires
Red (+)
Black (-)
NOTE: For CSA approval, a disconnect/toggle switch of appropriate rating needs to be placed within 29.5 ft. (9 m) of primary side
of the power supply. The minimum rating of the switch must be either 120 or 220 Volts AC. The switch must also support twice the
amount of input current.
NOTE: When installing power supply, connect to the appropriate sized building breaker or disconnect device for line and neutral
connections, in accordance with local, state or country regulations.
NOTE: The grounding and bonding of the power supply and overall sign shall be done in accordance with National Electric Code
(NEC) Article 600.
Retrot Instructions
1. (Existing Signs Only) Prior to installation, survey the site for information regarding power and accessibility inside and outside the
building. Ensure that the branch circuit supplying the existing transformer or ballast will be within the voltage ratings of the new LED
power supply, and have a current rating not exceeding 20A, or that permitted by applicable local, state, or country electrical codes
(whichever is less).
2. (Existing Signs Only) Remove the existing lighting equipment to be replaced, such as neon tubing or uorescent tubes; and
associated transformers and ballasts. Care should be taken not to break the existing neon or uorescent tubes. NOTE: Follow all
federal and local regulations when disposing of neon tubing, uorescent tubes, transformers and ballasts.
3. (Existing Signs Only) If removal of the existing lighting equipment eliminates the disconnect switch, as required by applicable local,
state, or country electrical codes; a new disconnect switch must be installed.
4. (Existing Signs Only) Make sure the removal of lighting equipment does not compromise the integrity of the sign body (i.e. water
intrusion). Fill in all holes 0.5 in. (13 mm) or smaller with the appropriate amount of rated caulk or sealant. For holes greater than
0.5 in. (13 mm), use an aluminum or zinc coated steel patch with rivets and sealant.
5. Using the layout guidelines within the LED module installation instructions, determine required number of LED modules required to
illuminate the sign.
6. Using the applicable LED module maximum Loading chart, determine the number of Tetra Class 2 Power Supplies required to power
the number of LED modules required to illuminate the sign, so as not to overload any single power supply output.
7. Follow the LED module instructions to properly mount the LED modules.
8. Connect the DC output of the power supply to the LED modules using the Power Supply Installation instructions above.
9. Connect the power unit to the supply in accordance with the applicable local, state, and country electrical codes, and the Power
Supply Installation instructions above.
10. If required, the disconnect switch shall be installed by qualied personnel, in accordance with applicable local, state, and country
electrical codes.
1Mount the power supply. Mounting
the power supply base directly to
a thermally conductive installation
surface can improve thermal
performance.
NOTE: All electrical connections
should be suitably protected from
mechanical damage and the
environment. Seal all connections
exposed to water with electrical
grade self-hardening silicone.
WARNING
RISK OF ELECTRIC SHOCK
AC input connections shall be
suitably enclosed.

3
Power Supply Specications
*Maximum case temperature is 85°C
Performance Data Min Typical Max
Input Voltage (VAC) 108 120-277 305
Input Frequency (Hz) - 50/60 -
Input Current (A) 0.35 - 1.1
Output Voltage (VDC) 24 24.5 25.2
Output Current (ADC) - - 4.0
Output Power (W) - - 96
Environmental Operating Temperature Range -40°C +25°C +60°C*
Environmental Humidity (non-condensing) 0% - 95%
Environmental Storage Temperature Range -40°C - +85°C
Dimensions 9.5 in. x 1.7 in. x 1.1 in. (241 mm x 43.2 mm x 28 mm)
Chart continued on next page
Remote Mounting Distance
Supports
Tetra Products SKUs Rated Power
Maximum Load
per Power Supply
18 AWG/
0.82 mm2
16 AWG/
1.31 mm2
14 AWG/
2.08 mm2
12 AWG/
3.31 mm2
Tetra miniMAX GEMM2471-W1, GEMM2450-W1,
GEMM2441-W1, GEMM2432-W1
0.348W/
module
220 modules/
110 ft. (35.05 m)
20 ft.
(6.1 m)
25 ft.
(7.6 m)
35 ft.
(10.6 m)
40 ft.
(12.1 m)
Tetra MS GEMS2471-W1, GEMS2450-W1,
GEMS2441-W1, GEMS2432-W1
0.228W/
module
340 modules/
85 ft. (25.91 m)
20 ft.
(6.1 m)
25 ft.
(7.6 m)
35 ft.
(10.6 m)
40 ft.
(12.1 m)
Tetra MAX GEMX2471-W1, GEMX2450-W1,
GEMX2441-W1, GEMX2432-W1
0.62W/
module
130 modules/
87 ft. (26.42 m)
20 ft.
(6.1 m)
25 ft.
(7.6 m)
35 ft.
(10.6 m)
40 ft.
(12.1 m)
Tetra PowerMAX GEPM2471-W1, GEPM2450-W1,
GEPM2441-W1, GEPM2432-W1
0.84W/
module
96 modules/
64 ft. (19.5 m)
20 ft.
(6.1 m)
25 ft.
(7.6 m)
35 ft.
(10.6 m)
40 ft.
(12.1 m)
Tetra PowerMAX HO GEPMH2471-W1CS1,
GEPMH2450-W1CS1,
GEPMH2441-W1CS1,
GEPMH2432-W1CS1
1.2W/
module
64 modules/
64 ft. (19.5 m)
20 ft.
(6.1 m)
25 ft.
(7.6 m)
35 ft.
(10.6 m)
40 ft.
(12.1 m)
Tetra
PowerStrip SS
GESS2471-2, GESS2450-2,
GESS2441-2, GESS2432-2
2.52W/
module 36 modules 20 ft. (6.1 m)
25 ft.
(7.6 m)
35 ft.
(10.6 m)
40 ft.
(12.1 m)
GESS24H71-1, GESS24H50-1,
GESS24H41-1, GESS24H32-1
2.95W/
module 30 modules 20 ft. (6.1 m)
25 ft.
(7.6 m)
35 ft.
(10.6 m)
40 ft.
(12.1 m)
Tetra
PowerStrip DS
GEDS71-2, GEDS50-2,
GEDS41-2, GEDS32-2
5.04W/
module 18 modules 20 ft. (6.1 m)
25 ft.
(7.6 m)
35 ft.
(10.6 m)
40 ft.
(12.1 m)
GEDSH71-2, GEDSH50-2,
GEDSH41-2, GEDSH32-2
5.9W/
module 16 modules 20 ft. (6.1 m)
25 ft.
(7.6 m)
35 ft.
(10.6 m)
40 ft.
(12.1 m)
Tetra
EdgeStrip
GEBI71-2, GEBI50-2,
GEBI41-2, GEBI32-2
2.52W/
module
36 modules/
36 ft. (10.97 m)
20 ft.
(6.1 m)
25 ft.
(7.6 m)
35 ft.
(10.6 m)
40 ft.
(12.1 m)
GEBIH71-2, GEBIH50-2,
GEBIH41-2, GEBIH32-2
5.40W/
module
17 modules/
18 ft. (5.49 m)
20 ft.
(6.1 m)
25 ft.
(7.6 m)
35 ft.
(10.6 m)
40 ft.
(12.1 m)
Tetra miniStrip DS GEBD71-2, GEWWBDP6-50K,
GEWWBDP6-41K, GEWWBDP6
1.68W/
module
50 modules/
50 ft. (15.23 m)
20 ft.
(6.1 m)
25 ft.
(7.6 m)
35 ft.
(10.6 m)
40 ft.
(12.1 m)
GEBDH71-2, GEBDH50-1,
GEBDH41-1, GEBDH32-1
1.94W/
module
42 modules/
42 ft. (12.79 m)
20 ft.
(6.1 m)
25 ft.
(7.6 m)
35 ft.
(10.6 m)
40 ft.
(12.1 m)

4
Chart continued
Remote Mounting Distance
Supports
Tetra Products SKUs Rated Power
Maximum Load
per Power Supply
18 AWG/
0.82 mm2
16 AWG/
1.31 mm2
14 AWG/
2.08 mm2
12 AWG/
3.31 mm2
Tetra Contour LS GEXNLRD-1 1.30W/
ft. (strip) 69 ft. (21m) 20 ft.(6.1 m) 30 ft.(9.1 m) 50 ft.(15.2 m) 86 ft.(26.1 m)
GEXNLBL-1, GEXNLGL-1 1.73W/
ft. (strip) 52 ft. (15.85 m) 20 ft.(6.1 m) 30 ft.(9.1 m) 50 ft.(15.2 m) 86 ft.(26.1 m)
GEXNL65-1, GEXNL32-1 3.17W/
ft. (strip) 29 ft. (8.8 m) 20 ft.(6.1 m) 30 ft.(9.1 m) 50 ft.(15.2 m) 86 ft.(26.1 m)
Tetra Contour GEXNBL-1, GEXNGL-1,
GEXNRD-1
1.52W/
ft. (strip) 59 ft. (17.9 m) 20 ft.(6.1 m) 30 ft.(9.1 m) 50 ft.(15.2 m) 86 ft.(26.1 m)
GEXNYG-1, GEXNRC-1 2.27W/
ft. (strip) 40 ft. (12.19 m) 20 ft.(6.1 m) 30 ft.(9.1 m) 50 ft.(15.2 m) 86 ft.(26.1 m)
GEXN65-1, GEXN32-1 3.17W/
ft. (strip) 29 ft. (8.8 m) 20 ft.(6.1 m) 30 ft.(9.1 m) 50 ft.(15.2 m) 86 ft.(26.1 m)
Line Fit Light GEF12DHOLED-1
GEF12SGNHOLED-1
GEF12CWHOLED-1
5.8W/bar 16 ft. 20 ft.(6.1 m) 25 ft.(7.6 m) 35 ft.(10.6 m) 40 ft.(12.1 m)
GEF18DHOLED-1
GEF18SGNHOLED-1
GEF18CWHOLED-1
7.2W/bar 16 ft. 20 ft.(6.1 m) 25 ft.(7.6 m) 35 ft.(10.6 m) 40 ft.(12.1 m)
GEF24DHOLED-1
GEF24SGNHOLED-1
GEF24CWHOLED-1
11.5W/bar 16 ft. 20 ft.(6.1 m) 25 ft.(7.6 m) 35 ft.(10.6 m) 40 ft.(12.1 m)
GEF30DHOLED-1
GEF30SGNHOLED-1
GEF30CWHOLED-1
14.4W/bar 16 ft. 20 ft.(6.1 m) 25 ft.(7.6 m) 35 ft.(10.6 m) 40 ft.(12.1 m)
GEF36DHOLED-1
GEF36SGNHOLED-1
GEF36CWHOLED-1
17.3W/bar 16 ft. 20 ft.(6.1 m) 25 ft.(7.6 m) 35 ft.(10.6 m) 40 ft.(12.1 m)
GEF42DHOLED-1
GEF42SGNHOLED-1
GEF42CWHOLED-1
20.2W/bar 16 ft. 20 ft.(6.1 m) 25 ft.(7.6 m) 35 ft.(10.6 m) 40 ft.(12.1 m)
GEF48DHOLED-1
GEF48SGNHOLED-1
GEF48CWHOLED-1
23.0W/bar 16 ft. 20 ft.(6.1 m) 25 ft.(7.6 m) 35 ft.(10.6 m) 40 ft.(12.1 m)
GEF60DHOLED-1
GEF60SGNHOLED-1
GEF60CWHOLED-1
28.8W/bar 16 ft. 20 ft.(6.1 m) 25 ft.(7.6 m) 35 ft.(10.6 m) 40 ft.(12.1 m)
GEF64DHOLED-1
GEF64SGNHOLED-1
GEF64CWHOLED-1
30.2W/bar 16 ft. 20 ft.(6.1 m) 25 ft.(7.6 m) 35 ft.(10.6 m) 40 ft.(12.1 m)
GEF72DHOLED-1
GEF72SGNHOLED-1
GEF72CWHOLED-1
34.6W/bar 16 ft. 20 ft.(6.1 m) 25 ft.(7.6 m) 35 ft.(10.6 m) 40 ft.(12.1 m)
GEF84DHOLED-1
GEF84SGNHOLED-1
GEF84CWHOLED-1
40.3W/bar 16 ft. 20 ft.(6.1 m) 25 ft.(7.6 m) 35 ft.(10.6 m) 40 ft.(12.1 m)
GEF96DHOLED-1
GEF96SGNHOLED-1
GEF96CWHOLED-1
46.1W/bar 16 ft. 20 ft.(6.1 m) 25 ft.(7.6 m) 35 ft.(10.6 m) 40 ft.(12.1 m)
Chart continued on next page

5
Remote Mounting Distance
Supports
Tetra Products SKUs Rated Power
Maximum Load
per Power Supply
18 AWG/
0.82 mm2
16 AWG/
1.31 mm2
14 AWG/
2.08 mm2
12 AWG/
3.31 mm2
Tetra Stick GETSPMSS01871A1 / GETSPMSS01871B1 1.7 W/Stick 47 Sticks 20 ft.(6.1 m) 25 ft.(7.6 m) 35 ft.(10.6 m) 40 ft.(12.1 m)
GETSPMSS02471A1 / GETSPMSS02471B1
GETSPMSS03071A1 / GETSPMSS03071B1” 2.5 W/Stick 32 Sticks 20 ft.(6.1 m) 25 ft.(7.6 m) 35 ft.(10.6 m) 40 ft.(12.1 m)
GETSPMSS03671A1 / GETSPMSS03671B1 3.4 W/Stick 24 Sticks 20 ft.(6.1 m) 25 ft.(7.6 m) 35 ft.(10.6 m) 40 ft.(12.1 m)
GETSPMSS04271A1 / GETSPMSS04271B1 4.2 W/Stick 19 Sticks 20 ft.(6.1 m) 25 ft.(7.6 m) 35 ft.(10.6 m) 40 ft.(12.1 m)
GETSPMSS04871A1 / GETSPMSS04871B1 5.0 W/Stick 16 Sticks 20 ft.(6.1 m) 25 ft.(7.6 m) 35 ft.(10.6 m) 40 ft.(12.1 m)
GETSPMSS06071A1 / GETSPMSS06071B1 5.9 W/Stick 14 Sticks 20 ft.(6.1 m) 25 ft.(7.6 m) 35 ft.(10.6 m) 40 ft.(12.1 m)
GETSPMSS06471A1 / GETSPMSS06471B1 6.7 W/Stick 12 Sticks 20 ft.(6.1 m) 25 ft.(7.6 m) 35 ft.(10.6 m) 40 ft.(12.1 m)
GETSPMSS07271A1 / GETSPMSS07271B1 7.6 W/Stick 11 Sticks 20 ft.(6.1 m) 25 ft.(7.6 m) 35 ft.(10.6 m) 40 ft.(12.1 m)
GETSPMSS08471A1 / GETSPMSS08471B1 8.4 W/Stick 10 Sticks 20 ft.(6.1 m) 25 ft.(7.6 m) 35 ft.(10.6 m) 40 ft.(12.1 m)
GETSPMSS09671A1 / GETSPMSS09671B1 10.1 W/Stick 8 Sticks 20 ft.(6.1 m) 25 ft.(7.6 m) 35 ft.(10.6 m) 40 ft.(12.1 m)
GETSPMSS10871A1 / GETSPMSS10871B1 10.9 W/Stick 7 Sticks 20 ft.(6.1 m) 25 ft.(7.6 m) 35 ft.(10.6 m) 40 ft.(12.1 m)
GETSPMSS11771A1 / GETSPMSS11771B1 11.8 W/Stick 7 Sticks 20 ft.(6.1 m) 25 ft.(7.6 m) 35 ft.(10.6 m) 40 ft.(12.1 m)
GETSPMSS12071A1 / GETSPMSS12071B1 12.6 W/Stick 6 Sticks 20 ft.(6.1 m) 25 ft.(7.6 m) 35 ft.(10.6 m) 40 ft.(12.1 m)
GETSPMDS01871A1 / GETSPMDS01871B1 3.4 W/Stick 24 Sticks 20 ft.(6.1 m) 25 ft.(7.6 m) 35 ft.(10.6 m) 40 ft.(12.1 m)
GETSPMDS02471A1 / GETSPMDS02471B1
GETSPMDS03071A1 / GETSPMDS03071B1 5.0W/Stick 16 Sticks 20 ft.(6.1 m) 25 ft.(7.6 m) 35 ft.(10.6 m) 40 ft.(12.1 m)
GETSPMDS03671A1 / GETSPMDS03671B1 6.8 W/Stick 12 Sticks 20 ft.(6.1 m) 25 ft.(7.6 m) 35 ft.(10.6 m) 40 ft.(12.1 m)
GETSPMDS04271A1 / GETSPMDS04271B1 8.4 W/Stick 10 Sticks 20 ft.(6.1 m) 25 ft.(7.6 m) 35 ft.(10.6 m) 40 ft.(12.1 m)
GETSPMDS04871A1 / GETSPMDS04871B1 10.0 W/Stick 8 Sticks 20 ft.(6.1 m) 25 ft.(7.6 m) 35 ft.(10.6 m) 40 ft.(12.1 m)
GETSPMDS06071A1 / GETSPMDS06071B1 11.8 W/Stick 7 Sticks 20 ft.(6.1 m) 25 ft.(7.6 m) 35 ft.(10.6 m) 40 ft.(12.1 m)
GETSPMDS06471A1 / GETSPMDS06471B1 13.4 W/Stick 6 Sticks 20 ft.(6.1 m) 25 ft.(7.6 m) 35 ft.(10.6 m) 40 ft.(12.1 m)
GETSPMDS07271A1 / GETSPMDS07271B1 15.2 W/Stick 5 Sticks 20 ft.(6.1 m) 25 ft.(7.6 m) 35 ft.(10.6 m) 40 ft.(12.1 m)
GETSPMDS08471A1 / GETSPMDS08471B1 16.8 W/Stick 5 Sticks 20 ft.(6.1 m) 25 ft.(7.6 m) 35 ft.(10.6 m) 40 ft.(12.1 m)
GETSPMDS09671A1 / GETSPMDS09671B1 20.2W/Stick 4 Sticks 20 ft.(6.1 m) 25 ft.(7.6 m) 35 ft.(10.6 m) 40 ft.(12.1 m)
GETSPMDS10871A1 / GETSPMDS10871B1 21.8 W/Stick 3 Sticks 20 ft.(6.1 m) 25 ft.(7.6 m) 35 ft.(10.6 m) 40 ft.(12.1 m)
GETSPMDS11771A1 / GETSPMDS11771B1 23.6 W/Stick 3 Sticks 20 ft.(6.1 m) 25 ft.(7.6 m) 35 ft.(10.6 m) 40 ft.(12.1 m)
GETSPMDS12071A1 / GETSPMDS12071B1 25.2 W/Stick 3 Sticks 20 ft.(6.1 m) 25 ft.(7.6 m) 35 ft.(10.6 m) 40 ft.(12.1 m)
GETSPHSS01871A1 / GETSPHSS01871B1 2.4 W/Stick 33 Sticks 20 ft.(6.1 m) 25 ft.(7.6 m) 35 ft.(10.6 m) 40 ft.(12.1 m)
GETSPHSS02471A1 / GETSPHSS02471B1
GETSPHSS03071A1 / GETSPHSS03071B1 3.6 W/Stick 22 Sticks 20 ft.(6.1 m) 25 ft.(7.6 m) 35 ft.(10.6 m) 40 ft.(12.1 m)
GETSPHSS03671A1 / GETSPHSS03671B1 4.8 W/Stick 16 Sticks 20 ft.(6.1 m) 25 ft.(7.6 m) 35 ft.(10.6 m) 40 ft.(12.1 m)
GETSPHSS04271A1 / GETSPHSS04271B1 6.0 W/Stick 13 Sticks 20 ft.(6.1 m) 25 ft.(7.6 m) 35 ft.(10.6 m) 40 ft.(12.1 m)
GETSPHSS04871A1 / GETSPHSS04871B1 7.2 W/Stick 11 Sticks 20 ft.(6.1 m) 25 ft.(7.6 m) 35 ft.(10.6 m) 40 ft.(12.1 m)
GETSPHSS06071A1 / GETSPHSS06071B1 8.4 W/Stick 9 Sticks 20 ft.(6.1 m) 25 ft.(7.6 m) 35 ft.(10.6 m) 40 ft.(12.1 m)
GETSPHSS06471A1 / GETSPHSS06471B1 9.6 W/Stick 8 Sticks 20 ft.(6.1 m) 25 ft.(7.6 m) 35 ft.(10.6 m) 40 ft.(12.1 m)
GETSPHSS07271A1 / GETSPHSS07271B1 10.8 W/Stick 7 Sticks 20 ft.(6.1 m) 25 ft.(7.6 m) 35 ft.(10.6 m) 40 ft.(12.1 m)
GETSPHSS08471A1 / GETSPHSS08471B1 12.0 W/Stick 7 Sticks 20 ft.(6.1 m) 25 ft.(7.6 m) 35 ft.(10.6 m) 40 ft.(12.1 m)
GETSPHSS09671A1 / GETSPHSS09671B1 14.4 W/Stick 5 Sticks 20 ft.(6.1 m) 25 ft.(7.6 m) 35 ft.(10.6 m) 40 ft.(12.1 m)
GETSPHSS10871A1 / GETSPHSS10871B1 15.6 W/Stick 5 Sticks 20 ft.(6.1 m) 25 ft.(7.6 m) 35 ft.(10.6 m) 40 ft.(12.1 m)
GETSPHSS11771A1 / GETSPHSS11771B1 16.8 W/Stick 5 Sticks 20 ft.(6.1 m) 25 ft.(7.6 m) 35 ft.(10.6 m) 40 ft.(12.1 m)
GETSPHSS12071A1 / GETSPHSS12071B1 18.0 W/Stick 4 Sticks 20 ft.(6.1 m) 25 ft.(7.6 m) 35 ft.(10.6 m) 40 ft.(12.1 m)
Chart continued on next page
Chart continued

All trademarks are the property of their respective owners. Information provided is subject to
change without notice. All values are design or typical values when measured under laboratory
conditions. Current, powered by GE is a business of the General Electric Company.
© 2018 GE.
www.currentbyge.com SIGN244 (Rev 08/22/18) GE2021-0922
This product is intended to be used as a lamp control gear that is installed after the mains control switch.
Conforms to the following standards:
Troubleshooting
Symptom Solution
All LEDs are OFF •The GEPS24-100UGLX features a new built in output overload shutdown feature that automatically
resets when the AC supply is removed and reapplied. So if all letters are off, rst verify whether or
not the output can be reset by rst switching off then switching back on the AC supply. If the letters
do not re-light, then proceed to the following solutions.
•Check AC input connection and/or check circuit breaker.
•Check wire connection(s) at the Tetra® LED System and power supply for improper termination(s) or
short circuits. Properly terminate or replace the wire connection(s).
•Check that connections are the red striped wire (+) of the LED strip to the red wire (+) of the power
supply and the white wire (-) of the LED strip to the black or blue wire (-) of the power supply.
•Ensure the overall length of the Tetra® LED System does not exceed the maximum load. If so,
remove the excess load and cycle the AC supply to reset the drivers built in overload protection.
Some LEDs appear dim •Ensure the length of supply wire is equal to or below the recommended remote mounting distance.
Some of the LEDs are
not illuminated
•Check wire connection(s) at the Tetra® LED System and power supply for improper termination(s) or
short circuits. Properly terminate or replace the wire connection(s).
•Check that connections are the red striped wire (+) of the LED strip to the red wire (+) of the power
supply and the white wire (-) of the LED strip to the black or blue wire (-) of the power supply.
Chart continued
Remote Mounting Distance
Supports
Tetra Products SKUs Rated Power
Maximum Load
per Power Supply
18 AWG/
0.82 mm2
16 AWG/
1.31 mm2
14 AWG/
2.08 mm2
12 AWG/
3.31 mm2
Tetra Stick GETSPHDS01871A1 / GETSPHDS01871B1 4.8 W/Stick 16 Sticks 20 ft.(6.1 m) 25 ft.(7.6 m) 35 ft.(10.6 m) 40 ft.(12.1 m)
GETSPHDS02471A1 / GETSPHDS02471B1
GETSPHDS03071A1 / GETSPHDS03071B1 7.2 W/Stick 11 Sticks 20 ft.(6.1 m) 25 ft.(7.6 m) 35 ft.(10.6 m) 40 ft.(12.1 m)
GETSPHDS03671A1 / GETSPHDS03671B1 9.6 W/Stick 8 Sticks 20 ft.(6.1 m) 25 ft.(7.6 m) 35 ft.(10.6 m) 40 ft.(12.1 m)
GETSPHDS04271A1 / GETSPHDS04271B1 12.0 W/Stick 7 Sticks 20 ft.(6.1 m) 25 ft.(7.6 m) 35 ft.(10.6 m) 40 ft.(12.1 m)
GETSPHDS04871A1 / GETSPHDS04871B1 14.4 W/Stick 5 Sticks 20 ft.(6.1 m) 25 ft.(7.6 m) 35 ft.(10.6 m) 40 ft.(12.1 m)
GETSPHDS06071A1 / GETSPHDS06071B1 16.8 W/Stick 5 Sticks 20 ft.(6.1 m) 25 ft.(7.6 m) 35 ft.(10.6 m) 40 ft.(12.1 m)
GETSPHDS06471A1 / GETSPHDS06471B1 19.2 W/Stick 4 Sticks 20 ft.(6.1 m) 25 ft.(7.6 m) 35 ft.(10.6 m) 40 ft.(12.1 m)
GETSPHDS07271A1 / GETSPHDS07271B1 21.6 W/Stick 3 Sticks 20 ft.(6.1 m) 25 ft.(7.6 m) 35 ft.(10.6 m) 40 ft.(12.1 m)
GETSPHDS08471A1 / GETSPHDS08471B1 24.0 W/Stick 3 Sticks 20 ft.(6.1 m) 25 ft.(7.6 m) 35 ft.(10.6 m) 40 ft.(12.1 m)
GETSPHDS09671A1 / GETSPHDS09671B1 28.8 W/Stick 2 Sticks 20 ft.(6.1 m) 25 ft.(7.6 m) 35 ft.(10.6 m) 40 ft.(12.1 m)
GETSPHDS10871A1 / GETSPHDS10871B1 31.2 W/Stick 2 Sticks 20 ft.(6.1 m) 25 ft.(7.6 m) 35 ft.(10.6 m) 40 ft.(12.1 m)
GETSPHDS11771A1 / GETSPHDS11771B1 33.6 W/Stick 2 Sticks 20 ft.(6.1 m) 25 ft.(7.6 m) 35 ft.(10.6 m) 40 ft.(12.1 m)
GETSPHDS12071A1 / GETSPHDS12071B1 36.0 W/Stick 2 Sticks 20 ft.(6.1 m) 25 ft.(7.6 m) 35 ft.(10.6 m) 40 ft.(12.1 m)
