Gecko Aeware 3 in.ye User manual

in.ye
spa pack general operation
(pages 2-7)
•
in.k450
keypad operation
(pages 9-15)
•
in.clear
water sanitation system operation
(pages 16-43)
•
in.stream
sound system operation
(pages 44-47)

32
in.xe™in.xe™
WARNINGS:
Before installing or connecting the unit, please read the following.
* FOR UNITS FOR USE IN OTHER THAN SINGLE-FAMILY DWELLINGS, A CLEARLY LABELED
EMERGENCY SWITCH SHALL BE PROVIDED AS PART OF THE INSTALLATION. THE SWITCH
SHALL BE READILY ACCESSIBLE TO THE OCCUPANTS AND SHALL BE INSTALLED AT LEAST
5 FEET (1.52 M) AWAY, ADJACENT TO, AND WITHIN SIGHT OF THE UNIT.
* ANY DAMAGED CABLE MUST BE IMMEDIATELY REPLACED.
* TURN POWER OFF BEFORE SERVICING OR MODIFYING ANY CABLE CONNECTIONS IN
THIS UNIT.
* TO PREVENT ELECTRIC SHOCK HAZARD AND/OR WATER DAMAGE TO THIS CONTROL,
ALL UNUSED RECEPTACLES MUST HAVE A DUMMY PLUG.
* THIS CONTROLLER MUST NOT BE INSTALLED IN PROXIMITY OF HIGHLY FLAMMABLE
MATERIALS.
* LOW VOLTAGE OR IMPROPER WIRING MAY CAUSE DAMAGE TO THIS CONTROL
SYSTEM. READ AND FOLLOW ALL WIRING INSTRUCTIONS WHEN CONNECTING TO
POWER SUPPLY.
* THIS PACK CONTAINS NO SERVICEABLE PARTS. CONTACT AN AUTHORIZED SERVICE
CENTER FOR SERVICE.
* ALL CONNECTIONS MUST BE MADE BY A QUALIFIED ELECTRICIAN IN ACCORDANCE
WITH THE NATIONAL ELECTRICAL CODE AND ANY STATE, PROVINCE OR LOCAL
ELECTRICAL CODE IN EFFECT AT THE TIME OF THE INSTALLATION.
warnings overview
in.ye
user instructions and functions

54
in.xe™in.xe™
electrical wiring
For 240 VAC (4 wires)
Correct wiring of the electrical
service box, GFCI, and pack
terminal block is essential.
ALL CONNECTIONS
MUST BE MADE BY A
QUALIFIED ELECTRICIAN
IN ACCORDANCE WITH
THE NATIONAL ELECTRICAL
CODE AND ANY STATE,
PROVINCE OR LOCAL
ELECTRICAL CODE IN
EFFECT AT THE TIME OF THE
INSTALLATION.
Electrical wiring North American model
Lamp test
All the segments and LEDs are
lighting up
Software revision
Revision of the software
Low level selection
Low level selected from low
level menu. Press Light key or
wait a couple of seconds to
confirm selection. Choose Low
Level 1 (default is set at Low
Level 1).
Software number
Software part number
power-up
Boot up displayed sequence (Each parameter is displayed for 2 seconds)

76
in.xe™in.xe™spa pack error codes summary
Prr
The Prr error message indicates a problem with regulation probe.
The system is constantly verifying if temperature probe reading is
within normal limits.
Error codes Hr
An internal hardware error has been detected.
HL
Water temperature at the heater has reached 119°F.
Do not enter spa water!
Error codes indicate a failure
condition or a problem which
needs to be corrected to
ensure proper functioning of
the system. Both the error code
and the water temperature are
alternatively displayed.
All errors codes will be displayed
on the keypad display.
FLO
The system did not detect any water flow while the main pump
was running.
Specications subjet to change without prior notice.
UPL
No low level configuration software has been downloaded
into the system.
OH
Water temperature in the spa has reached 108°F.
Do not enter spa water!
Error codes
AOH
Temperature inside the spa skirt is too high, causing the internal
temperature in the in.ye™ to increase above normal limits.
spa pack error codes summary

9
in.k450 overview
in.k450
user instructions and functions

1110
in.k450 in.k450
Set Point icon
The "Set Point" icon
automatically turns on
when set point setting
menu is activated.
(SP message on display).
Filter Cycle icon
The "Filter Cycle" icon lights
up when filter cycle is on.
Pumps icon
The "Pump" indicator
numbers light up and their
icons become fast animated
when pump or blower are in
high speed, slower animated
icon when pump or blower
are in low speed.
Heater icon
The "Heater" icon lights
up when the heater is on.
It flashes when:
1- there is a call for heat
and heater has not
started yet,
2- heater has just turned
off and element is
cooling down or
3 - not enough current
available to start heater
Light icon
The "Light" icon lights
up when the light is on.
The icon's number of
rays is proportional to
the light's intensity.
Smart Winter Mode icon
The "SWM" icon automa-
tically turns on when freeze
protection is active. It flashes
while system purges the spa
plumbing.
Time, temperature
& message digits
Service icon
A problem has
been detected. Do
not enter the water!
Spa service is
required.
Progress bar
A visual indication of
the time remaining
before an equipment
is turned off or
before the end of the
standby mode.
AM/PM (˚F/ ˚C)
functions and user instructionsfunctions and user instructions
Display
"Up/Down" keys"Light" key "Pump 3 /
Blower" key
"Pump 2" key"Pump 1" key"On/Off" key
function description

1312
in.k450 in.k450
Pump 2 key
Press Pump 2 key to turn Pump
2 on. Press a second time to
turn pump off.
A built-in timer automatically
turns pump off after a 20
minute period, unless pump
has been manually deactivated
first.
Light key
Press Light key to turn light on
Subsequent presses turn lights
on and off while changing
colors.
A built-in timer automatically
turns light off after a period
of 2 hours unless it has been
manually deactivated first.
Up/Down keys
Use Up or Down key to set
desired water temperature.
The temperature setting will
be displayed for 5 seconds to
confirm your new selection.
The "Set Point" icon indicates
that the display shows the
desired temperature, NOT the
current water temperature!
Pump 3 Key (Blower)
First press:
Pump 3 ON, Blower OFF
Second press:
Pump 3 ON, Blower ON
Third press:
Pump 3 OFF, Blower ON
Fourth press:
Pump 3 OFF, Blower OFF
A built-in timer automatically
turns blower off after a 20
minute period, unless blower
has been manually deactivated
first.
functions and user instructionsfunctions and user instructions
On/Off key
Depending on the spa manu-
facturer, this key may have
different functions: On/Off,
Standby mode or quick enable
of the Economy mode.
On/Off Mode
By default, the system is always
on. Press and hold On/Off key
for 5 sec. (or Press and hold
Pump 1 key for 5 sec.) to shut the
system down for 30 minutes.
The display will toggle between
the “OFF” message and water
temperature. Press On/Off key
to restart the system before the
expiration of the 30 minutes delay.
Pump 1 key
Press Pump 1 key to turn Pump
1 on at low speed. Press a
second time to turn pump to
high speed (with a dual-speed
pump). A third time turns
pump off.
A built-in timer automatically
turns pumps and blower off
after a period of 20 minutes,
unless pump has been
manually deactivated first.

1514
in.k450 in.k450
Filter cycle frequency
Press Prog. key a fourth time.
The display will show FFxx, with
"xx" representing the number of
filter cycles per day (up to 4).
Use Up or Down key to
change setting.
Setting temperature unit
Water temperature can be
displayed in either Fahrenheit
(˚F) or Celsius (˚C). Press Prog.
key a fifth time. The display will
show either ˚F or ˚C.
Use Up or Down key to
change setting.
Press Prog. key once more to go
back to normal mode.
Note: "F" will be displayed in
in.ye Spa Packs.
Smart Winter Mode
Our Smart Winter Mode
protects your system from
the cold by turning pumps on
several times a day to prevent
water from freezing in pipes.
When temperatures around
pack drop to near freezing, the
system will enter Smart Winter
Mode. The pack will cycle
through all pumps on high for
1 minute to prevent water from
freezing in the lines.
Water temperature regulation
In a regulation cycle, the system
first generates water flow
through the heater housing
and the plumbing, in order
to ensure accurate water
temperature readings as well as
avoiding heater activation in dry
conditions.
After verifying pump activation
and taking a water temperature
reading if required, the system
automatically turns the heater
on to reach and maintain water
temperature at Set Point.
Cooldown
After heating the spa water to
the desired Set Point, the
heater is turned off, but its
associated pump (Pump 1
Low-speed or CP) remains on
for a predetermined period of
time to ensure adequate
cooling of the heating element,
this prolongs its useful life.
The heater icon flashes during
this time.
functions and user instructionsfunctions and user instructions
Setting the time
Enter Programming mode by
holding Prog. key pressed down
for 3 sec. The display will show
the current time setting.
Setting the hour: Use Up or
Down arrows to change hour
setting (AM/PM).
Setting the minutes: Press Prog.
key a second time.
Use Up or Down key to change
hour setting.
Setting filter cycle start time
To program the filter cycle, you
must enter these parameters:
the start time and frequency.
During a filter cycle, pumps run
for one minute to purge the
plumbing, then Pump 1 runs
for the programmed number
of hours.
Press Prog. key a third time.
The display will show FSxx, with
"xx" representing the starting
hour.
Use Up or Down key to
change setting.
Program key
Use Light key to display time
or enter Programming menu
by pressing and holding key. In
Programming mode,
the following parameters can
be set: time, filter cycle start
time, filter cycle frequency, and
temperature unit.

1716
in.clear
in.clear
bromine based water sanitation system
user instructions and functions
instruction video: www.gecko.com/inclear

1918
in.clear in.clear
•The cell is installed after the heater in the circulation pump line.
• The appliance must be installed in a location that is inaccessible
to a person in the bath or spa and must be located or fixed so
that it cannot fall into the bath or spa.
• The appliance is not intended for submersion but may be
installed within the spa zone.
• A means for disconnection must be incorporated in the fixed
wiring in accordance with the wiring rules.
• To reduce the risk of injury, do not allow children to operate
this device.
• It is the responsibility of the user to test the spa water regularly
to ensure that adequate amounts of bromine are generated to
achieve proper sanitizer levels.
• Heavy spa usage may require higher bromine output to maintain
proper free available bromine residuals.
• Maintaining overly high Sodium Bromide and bromine levels
above recommended range can contribute to corrosion of spa
equipment and may damage components of the spa.
• Do NOT use any ozone or UV sanitizer.
Warnings!
Important safety instructions
• Check the expiry date of the test kit as test results may be
inaccurate if used after that date.
• Follow all aspects of the local and National Electrical Code(s)
when installing the in.clear™ Automatic Bromine Generator.
• People with a medical condition should consult a physician
before entering spa water.
• Women who are pregnant should NOT enter the spa.
• Maximum spa water usage temperature is 40°C. Bathing in spa
water at 40°C should not exceed 15 minutes.
• For proper sanitation, Spas must be completely drained
periodically. The number of days between COMPLETE SPA
DRAINAGE is equal to the volume of the Spas water in liters,
divided by 10 times the maximum number of daily spa users.
Refill spa with water and repeat DIRECTION FOR USE of the
device.
- For a 1500 liters (400 US gallons) spa used by 2 adults twice a
week: 1500 / (10 x (4/7)) = 262 days or 8 months
• In.clear™ is meant for a covered spa NOT swimming pools.
• Users should always shower before entering a spa.
warnings
Warnings!
Important safety instructions
• For Canada, in.clear™ must only be used with Sodium Bromide
(such as BromiCharge™) scheduled or registered under the Pest
Control Product Act. For USA, the Sodium Bromide (such as
BromiCharge™) must be registered under EPA.
• Read and follow this manual carefully and make sure to save it
for later.
• This manual contains important information on in.clear's
installation, use and safety recommendations. It is your
responsibility to install and use your in.clear™ unit safely.
• In.clear™ must be connected to a circuit protected by a ground
fault interrupter device (GFCI) in North America or residual
current device (RCD) having a rated residual operating current
not exceeding 30 mA in Europe.
• Make sure all electrical power is off before installing the in.clear™
unit. If the supply cord is damaged, it must be replaced by the
manufacturer, its service agent or similarly qualified persons in
order to avoid a hazard.
• Use only an electrical cord in good conditions to power
in.clear™.
• Always clean or replace your filter cartridges at regular intervals,
otherwise part of the bromine generated by in.clear™ will only
serve to oxidize the dirt accumulated in the filter.
• Do NOT add any other sanitation chemicals in the spa other than
registered Sodium Bromide (such as BromiCharge™)
• Operating the in.clear™ at reduced Sodium Bromide (such as
BromiCharge™) levels will shorten the life of the cell.
• Do not open the in.clear™ unit; there are no serviceable parts
inside.
• Disposal of the product: the in.clear™ unit must be disposed
of separately in accordance with the local waste disposal
legislation in force.
• This appliance is not intended for use by persons (including
children) with reduced physical, sensory or mental capabilities,
or lack of experience and knowledge, unless they have been
given supervision or instruction concerning use of the appliance
by a person responsible for their safety.
• To reduce the risk of injury, do not allow children to operate this
device.
• In.clear™ may not be suitable for in ground spas, it may affect
some materials used in their construction.
warnings

2120
in.clear in.clearbromine benefits
Bromine in a spa!
Bacteria requires a certain period of time before forming into micro
colonies and becoming attached to a surface. Rapid elimination
of bacteria is a key element in the proper maintenance of the spa
water. In.clear™ achieves this while oxidizing odors and reducing
eye irritation. In.clear™ enhances the clarity and quality of spa
water. For bathers this translates into a more enjoyable warm water
therapy experience.
How in.clear™ works!
When Sodium Bromide (such as BromiCharge™) is added to the
water, it separates into sodium ions and bromide ions. As the water
passes through the in.clear™ bromine generator, a low-voltage
source supplies a current that electrolytically reduces the bromine
ions into bromine which reacts with the water molecules to form
free bromine. Bromine is known to be a highly effective bactericide
and algaecide. This process releases bromide ions back into the
water for continuous recycling until the the spa is emptied. It is
important to note that the amount of bromine needed will vary
in direct proportion to the number of bathers in the spa (bather
load).
Effects of bromine
• Bromine destroys waterborne bacteria.
• Bromine destroys algae in water (e.g. Black, Green, Mustard).
• Bromine swiftly eliminates the presence of organic matter left
behind by spa users (oil, sweat, dead skin cells).
• Because bromine doesn’t contain calcium, it can be used to
sanitize hard water without increasing the calcium hardness.
The in.clear™ system operates in two modes:
Maintenance Mode and Boost Mode
Maintenance Mode:
The primary function of the Maintenance Mode is to keep the
bromine bank levels at a stable and acceptable range when
the spa is not being used. Maintenance Mode is the “everyday”
mode and is automatically ON when the system is activated.
To maintain the residual bromine level within a normal range,
the user has to set the Maintenance Level of the in.clear™
system by adjusting the value of the Maintenance Mode.
The higher the value, the more bromine generated. The
recommended bromine level is between 3 and 5 PPM.
The goal is to maintain bromine at a constant level, and within
the recommended range, when the spa is not being used or
left unused for an extended period of time. Once the proper
maintenance level is determined, keep the same setting unless
the spa usage changes.
Finding the right bromine generation level is a crucial step for
the in.clear™ system to be stable and effective. Refer to section
“6 -Determining the proper bromine generation Maintenance
Level for my spa” for more information.
Boost Mode:
The Boost Mode should be activated every time you use your
spa. Boost Mode increases the bromine generation rate to
attack pollutants in the water and helps rebuild the necessary
residual bromine in the water after each use of the spa.
Pollutants are introduced to the water by the bathers causing
the bromine levels to decrease. Activating the Boost Mode
when you enter the spa will prevent inadequate bromine levels
and will regenerate your bromine to the proper residual level.
Finding the right Boost level is another crucial step for the
in.clear™ system to be stable and effective. Refer to section “7 -
Determining the boost mode level for my spa”.
If water quality is not good after use, only the Boost level
should be adjusted, not the Maintenance level.

2322
getting started
Start up procedure:
(see video: www.geckoal.com/inclear)
1 - Draining and cleaning the spa
It's important to completely drain and clean the spa to remove
any solid residues accumulated on the surface and inside or
around the jets area. After draining the spa, use spa cleaning
products only. Household cleaners contain additives such as
phosphates which may affect the bromine production. When
the spa is clean, rinse it off thoroughly with a garden hose.
It's extremely important to clean your filter cartridge with a
filter soaking solution or replace your filter cartridges.
2 - Refilling the spa
After the in.clear™ unit has been installed, check the TDS
(Total Dissolved Solids) of the water you'll use to refill the spa.
The TDS range should be within 50 and 400 PPM. This can be
done by your local spa dealer. When you're certain the water is
within the proper TDS range, refill your spa.
If your TDS is higher than 500 PPM, ask your spa dealer for
additionnal information to help reduce initial TDS.
DO NOT use water from a "Salt Water Softener" system.
Make sure there is adequate flow and that no airlocks are
trapped in the unit's plumbing. If airlocks are formed, start the
pump and slowly loosen one of the union nuts to release the
air trapped in the plumbing. Tighten the nut again after you are
done.
It is important that the spa is well cleaned and rinsed prior to the
startup of the new system. Some biofilms may have formed in the
spa that could prevent the system from functionning properly. We
strongly recommend the use of a flushing product such as Spa
System Flush, Swirl Away or National Chemistry Spa Purge to clean
the plumbing even if the spa is brand new.
in.clear ™getting started
3 - Adjusting water chemistry in the spa
Proper chemical maintenance of a spa is essential for the health of bathers.
Maintaining the quality of the spa water within these specified values will
enhance your enjoyment of the spa and prolong the life of the in.clear™ system.
For best results, adjust to the following water chemistry parameters. Check these
parameters periodicaly.
Total hardness (TH): between 150 and 200 PPM
Alkalinity: between 100 and 120 PPM
pH: between 7.2 and 7.8
Water chemistry should be balanced before adding
Sodium Bromide into the water. It's essential that the water
chemistry parameters are within the proposed range to
obtain optimal system performance.
High Calcium Hardness may lead in faster calcification on
the electrolytic plates.
4 - Adding Sodium Bromide (such as BromiCharge™)
Water temperature between 32 and 38° C (90 and 100° F) helps dissolve
Sodium Bromide and facilitates maintenance level adjustment
Start the pump to allow water to circulate and slowly add Sodium Bromide (such
as BromiCharge™) uniformly in the spa by simply pouring it from the container.
4 - Adding Sodium Bromide (such as BromiCharge™):
(continued)
Add Sodium Bromide with at least a 98% of the active
ingredient concentration, such as BromiCharge™ at a rate of
0,143Kg /100 liters of water.
Example, if your spa holds 1200 liters of water,
add 1,72 Kg of Sodium Bromide (12 X 0,143 Kg).
Add Sodium Bromide with at least a 98% of the active
ingredient concentration, such as BromiCharge™ at a rate of
1.2lb/100 US gallons of water.
Example, if your spa holds 300 US gallons of water,
add 3.6 lbs of Sodium Bromide (3 X 1.2Lb).
Note: Your spa manufacturer can tell you how much water
your spa holds (in liters or gallons).
5 - Activating the system:
Power up your spa and activate the system by pressing the
Boost key .

2524
in.clear in.clear
Other tips:
For Canada, in.clear™ must only be used with Sodium Bromide (such as
BromiCharge™) scheduled or registered under the Pest Control Product
Act. For USA, the Sodium Bromide (such as BromiCharge™) must be
registered under EPA.
Your warranty will be void if another product is used as a substitute.
Do not breathe it or get into your eyes! First Aid
instructions should appear the container of the registered
Sodium Bromide container.
Do not use any other sanitation chemicals (including
shock) in the spa.
When adding fresh water to the spa, start a Boost to help build
a residual bromine bank.
6 - Determining the proper Maintenance Level for my spa
(refer to page 12 for details)
Determining the proper maintenance level for your spa is an
extremely important step. Using your spa while you're establishing
the residual will slow the process. Be patient. Make sure you follow
steps 1 through 6 previously described before performing the
following steps.
Your maintenance value was set at the factory. It should read 25 to
start.
Since the in.clear™ bromine generation is not an instantaneous
process, at least 24 hours should be allowed for the bromine bank
to reach stabilization. After that period, check bromine level to
make sure it is back between 3-5 PPM.
If the bromine level is within that range, you are ready to use
your spa. If the bromine level is above 5 PPM, decrease the
maintenance level. If the bromine level is below 3 PPM, increase
the maintenance level. Always allow at least 24 hours for the
bromine bank to stabilize. Repeat these steps until you are able to stabilize
your bromine level between 3 and 5 PPM.
Do NOT increase/decrease maintenance level in steps greater than 2.
Setting the maintenance level to a value that's too high can cause
damage to your equipment.
Check bromine level and always test water before entering
the spa.
If the bromine level is higher than 5 PPM, lower the main-tenance
level and turn off the system until the bromine level is back below 5
PPM. Then, restart the system and continue monitoring the bromine
level.
To lower the bromine level, expose your spa water to the sun and
activate all pumps for a few cycles.
Testing bromine levels with FAS-DPD drop count method
is more accurate than using test strips. Bromine FAS-DPD
is available at www.geckodepot.com under number 0699-300008.
7 - Determining the Boost Mode level for my spa
Every time you use your spa, activate the Boost Mode using the
Boost Key on the keypad. As a rule of thumb, the
Boost level may correspond to the number of bathers using the
spa. For example, activate the Boost level to 2 indicators if two (2)
bathers are entering the spa.
At the end of the Boost period, verify that the bromine level has
returned to the 3-5 PPM range. If the bromine level is too low or
too high after the Boost period, the Boost level should be adjusted
the next time the spa is used. For example, if bromine level is
higher than 5 PPM after Boost, lower the Boost level by one at next
use under the same conditions. Repeat these steps until you are
able to determine the ideal Boost level for your usage.
Note: Boost levels depend on the number of bathers using the
spa. We recommend you validate the Boost level after each use
to determine the ideal Boost level for every condition (number of
bathers).
getting started getting started

2726
in.clear in.clearin.clear ™ keypad operations
Keypad functions
On/Off & Boost
key
Maintenance
Diagnostic
key
Down keyUp key
Bromine
generator
ON indicatorlo hi
BromiCharge™ gauge
keypad operations
Boost key
The first press of the Boost
key turns the in.clear™
ON and puts the in.clear™
into maintenance mode. ON
appears on the keypad display.
Press and hold the Boost
key for 2 seconds to turn
in.clear™ OFF. OFF will appear
on the keypad display.
With the system in
Maintenance Mode, press the
Boost key to activate the
Boost Mode.
Note: The Boost mode should
be activated every time you use
your spa.
The keypad display will show a
numeric value that corresponds
to the selected level. There are
8 possible levels available with
the Boost Mode.
As a rule of thumb, the Boost
level corresponds to the
number of bathers using the
spa.
Set the Boost level by using the
up and down arrow to
select the number of bathers
that use the spa (i.e., husband
and wife = 2, and so on).
Confirm the selection by
pressing the Boost key again
or wait 5 seconds for the system
to save the desired level and
activate the Boost Mode cycle.
Note: In.clear™ keeps your
boost level in memory.
Press the Boost key during
a Boost cycle will cancel the
remainder of that Boost cycle
and return the in.clear™ system
to maintenance mode.
The Bromine Generation
Indicator (LED), located above
the Boost key, lights up when
the cell is producing bromine
and is OFF when no bromine is
being produced.
Note: The Bromine Generation
Indicator will blink if the
in.clear™ system cannot
generate bromine due to low or
no water flow.

2928
in.clear in.clear
keypad operations
+ / - Keys
Maintenance level adjustment
changes the rate at which
bromine will be released into
the spa water. The bromine
generation rate ranges from 1 to
50, where 1 corresponds to the
system’s minimum generating
rate and 50 corresponds to
the maximum generation rate
allowed by the system.
Changing the water
temperature setpoint of your
spa, or using the economy
mode, could require a change
in the maintenance level of
your in.clear™. Lower water
temperatures may require a
lower maintenance level than
higher temperature setpoints.
Please check your bromine
level when changing your
temperature setpoint or using
the economy mode of your spa.
Maintenance Adjustment
Press and hold the Prog key
for 2 seconds to enter
Maintenance level adjustment
mode
Use the +/- keys to adjust
maintenance level
Press the Prog key again to
enter Diagnostic Mode. This
mode may be used to monitor the
BromiCharge™ level of your spa
and may be a useful tool to use
when adding BromiCharge™ to
the water. See details next page.
Never adjust the main-
tenance level of your in.clear™
without allowing at least 24
hours following the end of the
Boost period. Boost cycles
allow the residual bromine
level to stabilize. Bromine levels
outside the 3-5 PPM range may
result from pollutants following
usage.
keypad operations
Diagnostic Mode
The primary function of
this mode is to indicate the
approximate BromiCharge™
level of your spa. This is a
useful tool when adding
BromiCharge™ to the water.
Press and hold the Prog Key
for 2 seconds, then press a 2nd
time to enter Diagnostic Mode.
An animation will be displayed
and within 10 seconds a nume-
rical value will be displayed.
The BromiCharge™ Gauge will
indicate the level of sodium
bromide in the spa water.
Diagnostic Mode can be
used to periodically adjust
BromiCharge™ level or to
check BromiCharge™ keypad
warnings and errors.
Press the Prog key to exit
Diagnostic Mode or the system
will automatically exit after
15 minutes.
Diagnostic mode and
BromiCharge™ Level Monitoring
are tools to help spa owners
maintain proper BromiCharge™
levels but do not replace the
need to perform water TDS
checks periodically at a local spa
dealer.

3130
in.clear in.clear
BromiCharge™ level monitoring
Water must be circulating through
the in.clear™ cell in order for the
Diagnostic Mode to work. If no water
is circulating through the in.clear™
unit, a FLO message will appear on the
keypad display. Make sure the pump is
circulating water through the in.clear™.
Be aware that the gauge will move
according to BromiCharge™ level.
Make sure your water temperature is at
least 32° C (90° F).
troubleshooting
Low BromiCharge™ Error
Low BromiCharge™ Error
(Err) occurs when the
BromiCharge™ level is too
low. The lo LED indicator will
blink when the error is present.
The in.clear™ system will not
generate bromine until the
Low BromiCharge™ Error (Err) is
cleared.
To clear the Low BromiCharge™
error (Err), add BromiCharge™
to the spa water. Let water
circulate for 5 minutes. Activate
diagnostic mode and add more
BromiCharge™ until gauge is
back in the green zone. Exit
diagnostic mode.
Low BromiCharge™
Warning
Low BromiCharge™ Warning
(Lo) indicates the need to add
BromiCharge™ to the spa water.
In Diagnostic Mode, add
BromiCharge™ to the water
until the gauge reaches the
green zone to clear a Low
BromiCharge™ Warning (Lo).
If after adding
BromiCharge™ the Low
BromiCharge™ Warning (Lo)
or Low BromiCharge™ Error
(Err) still occurs it could be the
result of:
• calcification of the electrolytic
plates;
• airlocks trapped in the
in.clear™ unit or insufficient
flow;
• internal pressure switch
problem.
High BromiCharge™
Warning
High BromiCharge™ Warning
(Hi) occurs when too much
BromiCharge™ is present in
the water or there is a high
TDS level (hardness, alkalinity,
organic compounds, ...).
To clear a High BromiCharge™
Warning, readjust the
BromiCharge™ content of your
water in Diagnostic Mode, into
green zone by draining some
water from your spa and adding
fresh water.
BromiCharge™ gauge (LEDs)
In Diagnostic mode, the BromiCharge™ gauge (LEDs) indicates the
approximate BromiCharge™ level of your spa water.
When adding BromiCharge™, the gauge indicator will gradually
shift to the right. When adding clean water to the spa the indicator
will shift to the left. In order to acheive the proper level, start pumps
and add 454 Grams (1 Pound) at a time and always allow 5 minutes
for the gauge to react before adding more BromiCharge™.
The green zone in the center area of the gauge and a 12.0 value
should be targeted for optimal performance.
BromiCharge™ gauge

3332
in.clear in.clear
troubleshooting
Blinking “AC ”
A blinking “AC” message
displayed on the keypad
indicates that there is a problem
with the power input. The most
common reason is that the
in.clear™ unit is supplied with
120 VAC instead of 240 VAC.
Please make sure power cord is
connected properly to a
240 VAC source.
Bromine Generation
indicator blinking
A blinking Bromine Generation
LED means that the system is
unable to generate bromine
because no water flow is
detected by the in.clear™
system. This situation is normal
if no pump is running and no
water is flowing through the
in.clear™. However, if water
is circulating through the
in.clear™ unit, and the Bromine
Generation LED is still blinking,
make sure that the in.clear™ is
installed on the pressure side
of the pump and that water is
flowing through the in.clear™
unit.
Bromine Generation
indicator is off
The Bromine Generation
LED indicator is OFF when
there is no need for bromine
generation. This situation is
normal, especially with low
maintenance level of bromine
generation set on the keypad.
Low or no bromine reading
Make sure the maintenance level is properly set according to
the procedure described in section 6 - “Determining the proper
Maintenance Level for my spa ”.
Make sure there is no error or warning message on the display, the
cell is activated and that water is circulating properly to the cell.
Make sure water chemistry is in balance. refer to section
“3 - Adjusting water chemistry in the spa” for more details.
Test your spa water for phosphate to make sure there is no conta-
mination. Phosphates should never exceed 100 ppb. Phosphates
can be introduced to your spa water by household cleaners, soaps
and lotions.
Change your filter or clean it with a filter cleaner and rinse
thouroughly with cold water.
Make sure the in.clear™ cell is not damaged and that no calcium or
lime deposits appear on the cell plates. Clean your cell regularly
(at least once a year).
troubleshooting
Long recovery time after usage
Activate Boost Mode every time you use your spa to the
appropriate level. Refer to section 7 - “Determining the Boost Mode
level for my spa”.
Heavy bather loads will require longer boost periods. If bromine
level is below 3 PPM following a boost period, re-activate Boost
Mode to bring the bromine bank within 3-5 PPM.
Bromine bank should always be regenerated following a boost
period. If high Boost level does not regenerate bromine bank
properly, increase the daily filtration time.
If bromine production is still inadequate after following all of the
instructions above, biofilm deposits could be causing the lack
of bromine generation. Flushing products such as Sea Klear Spa
System Flush, Swirl Away or National Chemistry Spa Purge have
shown to be affective for biofilm removal.
In.clear is turned off
The OFF message indicates that
the in.clear™ in turned Off.
Press Boost key to reactivate
the in.clear™.

3534
in.clear in.clear
frequently asked questions
Q3 - What should I use to clean my spa?
A3 - Always use a non-sudsing cleaner found at your spa store.
Q4 - When my in.clear™ bromine generator is off does the
Sodium Bromide continue sanitizing my spa?
A4 - No, the in.clear™ system does not sanitize if inactive. If there is
a residual bank of bromine, bromine continues to sanitize the
spa water. In.clear™ may be OFF at certain times and the spa
will still be fine and clean.
The Sodium Bromide is converted to bromine as it passes
through the electrodes of the in.clear™ system and the pump
associated with the in.clear™ is running.
Q1 - My spa water is cloudy /oily
A1 - If your spa becomes cloudy or oily due to bather load perform
an additional Boost and wait for 24 hours to see if conditions
return to nornal. If the problem persists consult a spa/pool
dealer to have your water balanced properly.
Q2 - Does the Sodium Bromide evaporate?
A2 - No. Sodium Bromide is only lost through splash out, leaks or
when draining your spa.
T.D.S
Total Dissolved Solids (TDS) is
an expression for the combined
content of all inorganic and
organic substances contained
in a liquid which are present
in a molecular, ionized or
micro-granular (colloidal sol)
suspended form.
pH
pH (potential hydrogen) is
a measure of the acidity or
basicity of a solution.
P. P. M
"Parts-per million" notation
is used to denote relative
proportions or a comparative
ratio in a given measured
quantity.
The expression "1 PPM" means
a given property exists at a
relative proportion of one part
per million parts examined, as
would occur if a water-borne
pollutant was present at a
concentration of one-millionth
of a gram per gram of sample
solution.
Total Alkalinity
Alkalinity or TA is a measure of
the ability of a solution (such as
water) to neutralize acids to the
equivalence point of carbonate
or bicarbonate.
glossary
Organic Matter
Substances left behind by spa
users such as oil, sweat and
dead skin cells that serve as
"food" for bacteria.
Calcium Hardness (CH)
Calcium Hardness describes
the concentration of calcium in
your spa water.
Total Hardness (TH)
Total Hardness describes the
concentration of calcium and
magnesium in your spa water.
Bather Load
This term is used to describe
the number of bathers using a
spa, combined with the length
and frequency of its usage.
The higher the bath usage, the
greater quantity of chemicals
needs to be added to maintain
the same spa water quality.

3736
in.clear in.clear
cell cleaning cell cleaning
Cell cleaning:
In.clear™ includes a self-cleaning feature to prevent scale deposits
on the graphite electrodes of the in.clear™ system. However,
deposits may still form due to hard water. If that happens the cell
should be cleaned in an acidic solution.
To clean the in.clear™ cell, follow these steps:
All power must be disconnected before any service
procedure is performed. Disconnect the
communication cable and power cable of the
in.clear™ unit.
Refer to acid manufacturer's instructions.
Wear eye protection and rubber gloves during these
operations. Splashing or spilling acid can cause severe
personal injuries and/or property damage.
Always work in a well-ventilated area.
Always add acid to the water, never add water to the acid.
Do not pour acid outside of the unit where
the connectors are located.
Never use Acetic acid to clean the cell, as this will cause
permanent damage to cell components and void the
warranty.
• To remove scales from the cell, we recommend to use
Phosphoric acid (non-diluted) as the preferred cleaning product.
• Close the spa Flow Shut Off Valves. Unscrew both unions
from the unit and remove the cell from the spa equipment
compartment.
Phosphoric acid
or muriatic acid
• Install the rubber washer and the plastic nut on the threaded end
of the cell. Tighten plastic nut firmly.
• Place the cell vertically with the cap end down into a plastic 19
liters (5 U.S. gallon) bucket and carefully pour the acid solution
into the cell until the 4 plates are covered (careful not to
overflow). The acid solution will begin to produce bubbles to
clean the electrodes.
A foaming action will follow, which is caused by the scale
deposits being dissolved from the plates. If rigorous foaming
action does not begin, the cell does not need to be cleaned.
Rinse and reinstall the cell.
• Allow the electrodes to remain in the solution until the foaming
has stopped. However, DO NOT leave in acid for more than
fifteen minutes. Excessive acid cleaning will damage the
electrolytic cell.
• Pour the acid solution back into the bucket and rinse the cell
thoroughly with clean tap water. If deposits are still visible, repeat
operation for fifteen minutes maximum (some acid may need to
be added to the solution).
• Remove the plastic nut and washer from the cell and keep them
for future cell cleaning.
• Rinse the in.clear™ with fresh water.
• Re-install the in.clear™ unit into spa system plumbing, tighten all
connections by hand. Open the spa flow Shut Off Valves.
• Reconnect the keypad and power cable.
• Turn power on and start up the pump. Check the keypad to
see that the bromine generation LED is on and resume normal
operation.

3938
in.clear in.clear
When you add BromiCharge™ to your spa, the TDS (Total
Dissolved Solids) of the water will increase about 1150 PPM (Parts
Per Million) per 100-U.S. gallons for every pound of BromiCharge™
added. Normal operating range of BromiCharge™ should be
between 1400 to 1500 PPM for best results.
By adding 1.2 pounds of BromiCharge™ per 100 U.S. gallons of
water you should increase the total TDS in your spa by 1440 PPM.
EXAMPLE: If you have a 300 U.S. gallon spa, add 3.5 lbs of
BromiCharge™.
BASE TDS ..........................................400 PPM
3.5 lbs. BromiCharge™ ..................1440 PPM
TOTAL PPM after BromiCharge™ . 1840 PPM
Adding BromiCharge™
You will want to maintain a TOTAL TDS of 1600 to 1900 PPM in
your spa for best performance based on the above example. This
will give you a 1400 to 1500 PPM of BromiCharge™ in your spa at
all times.
IDEAL WATER CHEMISTRY FOR SPA WATER
BromiCharge™ ..Add 1.2 pounds per 100 U.S. gallons of water (1440
PPM)
Calcium Hardness - CaCo: ................... 125 to 200 adjust if necessary
Alkalinity..................................................... 80 to 90 adjust if necessary
pH ................................................................7.0 to 7.8 adjust if necessary
Adjust the above factors to meet optimum range values.
user guide for BromiCharge™ user guide for BromiCharge™
Operation Instructions
IMPORTANT: Read instructions before using.
SPA BROMINE GENERATOR
INSTALL AND OPERATION
MANUAL
The purpose of the in.clear™ water sanitation system for spas and
hot tubs (with BROMITRON™ BROMINE GENERATOR technology)
is to reliably and automatically maintain a halogen presence in
a given recreational body of water, whether the hot tub owner
remembers to treat the water, or not.
Proper bromine levels and chemistry should be checked regularly
by hot tub owners with the use of a standardized test kit.
The in.clear™ water sanitation system for spas and hot tubs (with
BROMITRON™ BROMINE GENERATOR) should be installed before
your hot tub is filled with water. If this is an after market installation,
drain the water and install it in the return line after the heater
circulation pump.
BromiCharge™ for use with the
with BROMITRON™
Bromine Generator Technology
