USER MANUAL
Accushine
60 W DAYLIGHT COB LED MONOLIGHT
ACC-60-L

Accushine 60 W Daylight COB LED Monolight - USER MANUAL
2
THANK YOU FOR CHOOSING GENARAY
The Genaray Accushine is a compact yet extremely
powerful daylight-balanced COB LED that boasts 12,900
lux of flicker-free and color-accurate light that’s perfect
for video shoots. The 5600 K light simulates or matches
bright sunlight conditions, and dimming from 10% to
100% in 1% increments lets you fine-tune your output to
the ideal level. This light is fan cooled and is designed
with heat sinks that prevent overheating, so you can
have continuous light throughout lengthy shoots.
The Accushine has 99 selectable receiver channels, and
it can be controlled wirelessly from up to 98 feet away
with Genaray’s MB-WRT remote (sold separately). The
remote will also let you integrate the Accushine into a
sophisticated multiple-light setup with other Genaray
lights. Attach the included reflector, or another modifier
like a snoot or Fresnel lens, to the integrated Bowens
S-mount to style and shape your light.
Accushine
INTRODUCTION

Accushine 60 W Daylight COB LED Monolight - USER MANUAL 3
· Please read and follow these
instructions, and keep this manual
in a safe place.
· Keep this unit away from water and
any flammable gases or liquids.
· Make sure the unit is powered off
when plugging it into a power source.
· Do not attempt to disassemble or
repair the equipment—doing so will
void the warranty, and Genaray will
not be responsible for any damage.
· Handle the unit with care.
· Do not stare directly at the lights
when they are powered on.
· Clean the unit with only a soft,
dry cloth.
· Images are for illustrative
purposes only.
PRECAUTIONS
Precautions

Accushine 60 W Daylight COB LED Monolight - USER MANUAL
4
PRODUCT
OVERVIEW Power
switch
Umbrella
locking knob
Angle adjustment
knob
LED
screen
Dimmer/Channel
select knob
Umbrella
mounting hole
Control panel
5/8 in. receiver
locking knob

Accushine 60 W Daylight COB LED Monolight - USER MANUAL 5
Product overview
COB LED
array
5/8 in. receiver
Bowens S-type
mount
AC power input
Mounting
handle
Bowens mount
release button
7 in. reflector

Accushine 60 W Daylight COB LED Monolight - USER MANUAL
6
ATTACHING THE
REFLECTOR
MOUNTING THE
ACCUSHINE
CONTENTS
INCLUDE
· Light fixture
· 7 in. reflector
· AC power cord
· User manual
Mount the Accushine on any light
stand with a 5/8-inch stud, and turn
the locking knob until secure.
Once the light is securely mounted,
remove the protective cover by pressing
the release button, turning the cover
counterclockwise, and pulling it off the light.
The Accushine features an integrated Bowens
S-mount to attach the reflector and other
Bowens-compatible accessories such as grids
and snoots.
1. Align the reflector’s mounting pegs
with the slots on the Bowens mount,
and insert them into the mount.
2. Turn the reflector clockwise until it clicks
into place.
To remove the reflector, press the release
button and turn the reflector counterclockwise
until it slides out of the mount.
1
contents

Accushine 60 W Daylight COB LED Monolight - USER MANUAL 7
The Accushine can be powered
directly from an AC outlet.
Connect the AC power cable to the
Accushine, and plug it into an outlet.
To turn on the fixture, move the
power switch to the ON position.
Make sure the umbrella hole in the
reflector is aligned with the umbrella
mounting hole in the handle.
Loosen the umbrella locking knob, and slide
the umbrella’s shaft through the reflector
and the handle’s mounting hole. Tighten the
locking knob to fix the umbrella in place.
POWERING THE
ACCUSHINE
Power the Accushine on. The LCD screen
will show the last setting that was used.
After powering on the Accushine, set
the brightness by rotating the dimmer
knob on the back of the fixture.
Brightness is adjustable from 100%
to 10% in 1% increments.
ADJUSTING THE
BRIGHTNESS
ADDING AN
UMBRELLA
instructions

Accushine 60 W Daylight COB LED Monolight - USER MANUAL
8
2
3. Take the spare fuse out of the
enclosed side of the case and
place it in the fuse clip.
4. Press the fuse case back into the fuse
compartment until it clicks into place.
The Accushine comes with a 5 A,
250 V fuse installed. To replace
the fuse, follow these steps:
1. Insert a small slotted screwdriver
into the slot and open the
fuse compartment.
2. Remove the fuse case from the
compartment. Then remove the spent
fuse from the open-ended side of the
case.
REPLACING THE
FUSE
1 3 4
instructions

Accushine 60 W Daylight COB LED Monolight - USER MANUAL 9
The MB-WRT Wireless Transmitter (sold
separately) adjusts brightness from
100% to 10%. The MB-WRT can operate
the Accushine, as well as several other
Genaray LED lights like the Full Moon
and Mini Moon, from up to 98 feet away.
You can adjust brightness and color
temperature on multiple lights that are
all set at different values. This makes
the MB-WRT a convenient tool for use
in a sophisticated lighting setup.
To set the receiving channel on the
Accushine, follow these steps:
1. Press the dimmer knob to display the
channel selection. The CH will blink.
2. Use the dimmer/channel knob to set
the receiving channel from 1 to 99.
3. Press the knob again. The CH
icon will stop blinking and the
displayed channel will be set.
Refer to the MB-WRT user manual to
set the channel on the transmitter.
Important
Make sure the channel on the
Accushine matches the MB-WRT.
Refer to the MB-WRT user manual to
operate the Accushine remotely.
USING THE MBWRT
WIRELESS TRANSMITTER
instructions

Accushine 60 W Daylight COB LED Monolight - USER MANUAL
10
PRODUCT
SPECIFICATIONS
LED Chip Type: COB
Beam Angle: 120° without reflector
55° with reflector
Color Temperature: 5600 K
Color Accuracy Standard: CRI: 95.9
TLCI: 98
Cooling System: Fan cooled
Dimming: Yes, 10% to 100% (1% increments)
Display: LCD
Housing Material: ABS plastic
Light Intensity @3 ft.: 12,900 lx
Number of LEDs: N/A
Expected Lamp Life: 50,000 hr.
Dimensions (H × D × W): 8.6 × 8.6 × 5 in.
(21.8 × 21.8 ×
12.7 cm)
Weight: 2.5 lb. (1.1 kg)
Light Fixture
Power Input Connector: 3 prong
Connectors
Fixture Mount: 5/8 in. receiver
Reflector Mount: Bowens S-mount
Mounting
Remote Control Type: Proprietary wireless
Wireless Range: 98.4 ft. (30 m)
Wireless Channels/Groups: 99
Remote Operation
AC Input Power: 100 to 240 V, 50/60 Hz
Power Source: AC adapter
Fuse: 5 A, 250 V (5 × 22 mm)
Max Power Consumption: 60 W
Power
sPecifications

ONE-YEAR LIMITED WARRANTY
This Genaray product is warranted to the original purchaser to be free from defects in materials and
workmanship under normal consumer use for a period of one (1) year from the original purchase date
or thirty (30) days after replacement, whichever occurs later. Genaray’s responsibility with respect
to this limited warranty shall be limited solely to repair or replacement, at Genaray’s discretion, of
any product that fails during normal use of this product in its intended manner and in its intended
environment. Inoperability of the product or part(s) shall be determined by Genaray. If the product
has been discontinued, Genaray reserves the right to replace it with a model of equivalent quality and
function.
This warranty does not cover damage or defect caused by misuse, neglect, accident, alteration, abuse,
improper installation or maintenance. EXCEPT AS PROVIDED HEREIN, GENARAY MAKES NEITHER
ANY EXPRESS WARRANTIES NOR ANY IMPLIED WARRANTIES, INCLUDING BUT NOT LIMITED TO
ANY IMPLIED WARRANTY OF MERCHANTABILITY OR FITNESS FOR A PARTICULAR PURPOSE. This
warranty provides you with specific legal rights, and you may also have additional rights that vary from
state to state.
To obtain warranty coverage, contact the Genaray Customer Service Department to obtain a return
merchandise authorization (“RMA”) number, and return the defective product to Genaray along with the
RMA number and proof of purchase. Shipment of the defective product is at the purchaser’s own risk
and expense.
For more information, or to arrange service, visit www.genaray.com or contact us at [e-mail].
